Victrola VC-250 User manual

Bedside Clock Radio
Model: VC-250

02 0603
07 0908
04 05
01
1 LED Display
2 Power ON/OFF (Standby)
• Short press to power on
• Long press to power off
• When power on the unit, short press to switch
Input mode
3 Alarm Button
Short press to turn ON/OFF all alarm clocks
4 Conversion Key
• In FM mode:
Press till display shows “VOL”, press button / to
adjust the volume.
• Press till display shows “FrE”, press button / to
adjust the FM frequency.
5 Backlight Level Adjustment
Press to select High/Medium/Low Brightness
6 Set Button
• In clock mode: Short press to set up time.
Long press to set the clock to 24 hrs / 12 hrs.
• In FM mode:
Short press to swtich to saved FM radio stations.
Long press to choose the position for saved stations.
• In alarm mode: Short press to set up the alarm
clocks.
7 Previous
In FM mode: Short Press the Conversion Key to
change to either “FrE” or “VOL”
• In “FrE”: Short press to skip to the previous
frequency.
Press and hold to find the nearest FM Station that is
in reception.
• In “VOL”: Short press to decrease the volume by one.
Press and hold to continuously lower the volume.
8 Snooze
Short press to activate snooze function, alarm will ring
again in 5 minutes.
9 Next
In FM mode: Short Press the Conversion Key to
change to either “FrE” or “VOL”
• In “FrE”: Short press to skip to the next frequency.
Press and hold to find the nearest FM Station that is
in reception.
• In “VOL”: Short press to increase the volume by one.
Press and hold to continuously increase the volume.
9 Power Indicator Light
While the unit is connected to the adaptor, the light will
stay lit red.
10 Reset Hole
11 Micro USB Power Port
12 Antenna
09 10
11 12

To Power on the unit:
1. Connect the Micro USB to the Wall Adapter (included), then connect the Micro USB to the Micro USB Power
Port located on back of the unit.
2. Connect the Wall Adapter into the nearest outlet. The Power Indicator will light red to indicate it is connected
properly.
3. Press the Standby button to power on the unit. The LED Display will show “LoAd” and then “00:00”.
4. Press and hold the Standby button to power off.
Operation
Clock Set Up
Alarm Clock
FM Radio
1. Press Standby to power on, display shows “LoAd”.
2. Long press the SET button to choose between 24-hour /12-hour system.
3. Press the SET button, the hour digits will flash, press Previous/Next buttons to adjust the hour time. To confirm the hour
value press the SET button again.
3. After hour value is confirmed, the minute digits will flash. Repeat the same steps to set the minute value.
4. Press SET again to return to Standby mode or the unit will automatically return to standby mode in 10 seconds.
SETTING ALARMS
1. Press Standby until the display shows “ALA1”
2. Press the Previous/Next buttons to select between the 4 different alarms which display as
“AL1”, “AL2”, “AL3”, and “AL4”.
3. After selecting which Alarm, press the SET button. Then press the previous/next buttons to chose the alarm mode to be
one of the following options:
• “OFF”: The alarm will be off.
• “bEEP”: The alarm sound will be a beeping tone.
• “rad”: The alarm sound will be the previous FM Station selected.
3. To set the alarm time: the hour digits will flash, press Previous/Next buttons to adjust the hour time. To confirm the hour
value press the SET button again. After hour value is confirmed, the minute digits will flash. Repeat the same steps to
set the minute value.
4. After finishing the above steps, press SET once more to confirm.
5. Press the Standby button twice to return to Standby mode.
6. In Stanby mode, press the Alarm button to turn ON/OFF all alarms.
Note: The icon alarms will dissapear when alarms are turned off.
SNOOZE OR STOP ALARMS
1. When the alarm sounds, press any button (except for Snooze) to stop the alarm.
2. When you press Snooze, the display shows snooze icon and alarm icon flashes.
After 5 mintues, the alarm will sound again.
1. Press Standby twice to enter FM mode, display will shows radio frequency and the FM icon will light (this may take a
few seconds after pressing the button).
Note: After a few seconds, the display will automatically show the time if no buttons are pressed.
2. Press the Conversion Key and the display will show “FrE” to manually tune the radio.
• Press the Previous/Next button to manually tune at a frequency of 0.1MHz to find a station.
• Long press the Previous/Next button to scan for the nearest FM stations in reception.
Note: For best reception, fully extend the antenna located on the back of the unit.
PROGRAM PRESET STATIONS
The unit allows you to save up to 20 preset FM radio stations.
1. In FM mode, first select the desired radio station, then long press the SET button to save the current radio station
selected; “ P01 ” with flash on the LED Display then press Previous/Next buttons to choose the saved position, then
long press SET button to confirm and exit. Repeat process for all 20 presets.
2. Press the SET button to select from the saved stations from P01 to P20.
ADJUSTING VOLUME
1. Press Conversion Key button to enter volume state, display will show “VOL”.
2. Press Previous/Next to Increase/Decrease the volumel level.

Output Power: ................................ RMS 1.5W (THD+N=10%, f0=1KHZ)
S/N Ratio: .................................................................................... ≥ 70dBA
Distortion (%):.....................................................................................≤1%
Frequency Response: ........................................................ 500Hz-15KHz
Input Mode: ..................................................................... FM (20 presets)
Loudspeaker:.................................................................Φ32mm, 8Ω , 2W
Buit-in Memory Battery (Non-replaceable): ...........CR2032 3.0V/220mAh
Charging Source: .......................................................... DC 5V 600mA
Working Temperature: ..........................................................0ºC ~ +50 ºC
Unit Size: .......................................... 170 (6.7”) x 58 (2.3”) x 88mm (3.5”)
Net Weight:...................................................................... 0.2 kg (0.44 lbs)
Included:............................................... Power Adapter, Micro USB Cord,
Instruction Manual, Clock Radio
Specifications
Troubleshooting Guide
Disconnect the external
power supply and external
audio device. Re-plug the
external power supply after
one minute.
external AC power supply.
RADIO SLEEP TIMER
1. Long press the Brightness button to set sleep function: OFF/ S 15 / S 30 / S 45 / S 60 / S 90 / S 120,
2. The “SLEEP” icon on the LED Display will be lit, then the radio will automatically be powered off in 15/30/45/60/90/120
minutes. Choose OFF to turn off the sleep function.
CAN ICES-3 (B)/NMB-3(B)

California Prop 65 Warning
FCC Statement
This product can expose you to chemicals including lead, which is known to the State of California to cause cancer.
For more information go to www.P65Warnings.ca.gov.
WARNING

1 LED Display
2 Power ON/OFF (Standby)
• Short press to power on
• Long press to power off
• When power on the unit, short press to switch
Input mode
3 Alarm Button
Short press to turn ON/OFF all alarm clocks
4 Conversion Key
• In FM mode:
Press till display shows “VOL”, press button / to
adjust the volume.
• Press till display shows “FrE”, press button / to
adjust the FM frequency.
5 Backlight Level Adjustment
Press to select High/Medium/Low Brightness
6 Set Button
• In clock mode: Short press to set up time.
Long press to set the clock to 24 hrs / 12 hrs.
• In FM mode:
Short press to swtich to saved FM radio stations.
Long press to choose the position for saved stations.
• In alarm mode: Short press to set up the alarm
clocks.
7 Previous
In FM mode: Short Press the Conversion Key to
change to either “FrE” or “VOL”
• In “FrE”: Short press to skip to the previous
frequency.
Press and hold to find the nearest FM Station that is
in reception.
• In “VOL”: Short press to decrease the volume by one.
Press and hold to continuously lower the volume.
8 Snooze
Short press to activate snooze function, alarm will ring
again in 5 minutes.
9 Next
In FM mode: Short Press the Conversion Key to
change to either “FrE” or “VOL”
• In “FrE”: Short press to skip to the next frequency.
Press and hold to find the nearest FM Station that is
in reception.
• In “VOL”: Short press to increase the volume by one.
Press and hold to continuously increase the volume.
9 Power Indicator Light
While the unit is connected to the adaptor, the light will
stay lit red.
10 Reset Hole
11 Micro USB Power Port
12 Antenna
Warranty
Victrola is a registered trademark of Innovative Technology Electronics LLC.
Innovative Technology Electronics LLC.
Limited Warranty: 90 Days Labor, One Year Parts
Innovative Technology Electronics LLC. (IT) warrants the product to be free from “Defects” in materials under normal use
for a period of “One Year” from the date of the original purchase. The Warranty is “Not” transferable. IT agrees, within the
initial “90 Day” period, to repair or replace the product if it is determined to be defective at “No Charge”. It is further
agreed that IT will cover the cost to repair or replace damaged “Parts” only for a total period of “One Year” from the date
of the original purchase. The warranty does not cover cosmetic damage, antennas, AC cords, cabinets, headbands,
ear-pads, or damage due to line power surges, connection to improper voltage supply or settings, misuse, mishandling,
accident, acts of God or attempted repair by an unauthorized service agent.
To obtain service, the purchaser MUST present an original sales receipt / proof of purchase. Please contact us at
www.victrola.com to request an RMA (Return Material Authorization) number to return products for service or
replacement. Returns without an RMA number on the package will be refused and returned to sender. Upon receipt of the
returning item and our full inspection (IT) may issue a replacement to customer for the same item or of one that has
equivalent value and features. To return an item, supply full name, return address, phone number, item purchased, receipt
of purchase and reason for return to obtain RMA number.
All returns must be in the original packaging or reasonable substitute to prevent damage. Customer “Must” include full
name, shipping address and telephone number inside of package. No return will be shipped back to a PO Box or APO
address.
Please include your check or money order in the amount of:
• USD $5.00 for items $10.00 to $39.99. (Price Paid Per Unit)
• USD $10.00 for items $40.00 to $99.99. (Price Paid Per Unit)
• USD $16.00 for items $100.00 and up. (Price Paid Per Unit)
• Shipping fees are non-refundable.
to be payable to Innovative Technology Electronics LLC. (for handling and return shipping charges) (IT) will not be
responsible for delays or unprocessed claims resulting from a purchaser’s failure to provide any / all of the necessary
information. Send all inquiries or RMA request via our website www.victrola.com/pages/technical-support.
Innovative Technology Electronics LLC.
1 Channel Drive
Port Washington, NY 11050
Toll free: 1-877-483-2497
Website for support: www.victrola.com/pages/technical-support
