Videology 24RS2.0XW-EXSDI User manual

Doc # INS-24RS2.0SW-EXSDI
Issue Date: 11/27/2017
Revision: A
Page 1 of 19
Prior to Using This Document: Videology reserves the right to modify the information in this
document as necessary and without notice. It is the user’s responsibility to be certain they possess the
most recent version of this document by going to www.videologyinc.com, searching for the model
number, and comparing revision letters on the respective document, located in the document’s footer.
For technical assistance with this product, please contact the supplier from whom the product was
purchased.
Videology®Imaging Solutions, Inc.
Videology®Imaging Solutions, Europe B.V.
37M Lark Industrial Parkway
Greenville, Rhode Island 02828 USA
Tel: [phone] Fax: [phone]
Americas, Middle East, Far East & Australia sales:
[e-mail]
Neutronenlaan 4
5405 NH Uden, The Netherlands
Tel: [phone] Fax: +31 (0) 413
251712
Europe & N. Eurasia sales:
[email protected]l
Instruction Manual
24RS2.0XW-EXSDI
IMAGING SOLUTIONS INC.
Original Equipment Manufacturer

Doc # INS-24RS2.0SW-EXSDI
Issue Date: 11/27/2017
Revision: A
Page 2 of 19
License Agreement (Software):
This Agreement states the terms and conditions upon which Videology Imaging Solutions, Inc. USA and
Videology Imaging Solutions, B.V. Europe (hereafter referred to as "Videology®") offer to license to you the
software together with all related documentation and accompanying items including, but not limited to,
the executable programs, drivers, libraries, and data files associated with such software.
The Software is licensed, not sold, to you for use only under the terms of this Agreement.
Videology grants to you, the purchaser, the right to use all or a portion of this Software provided that the
Software is used only in conjunction with Videology's family of products.
In using the Software you agree not to:
Decompile, disassemble, reverse engineer, or otherwise attempt to derive the source code for any
Product (except to the extent applicable laws specifically prohibit such restriction);
Remove or obscure any trademark or copyright notices.
Limited Warranty (Hardware and Software):
ANY USE OF THE SOFTWARE OR HARDWARE IS AT YOUR OWN RISK. THE SOFTWARE IS PROVIDED FOR
USE ONLY WITH VIDEOLOGY'S HARDWARE. THE SOFTWARE IS PROVIDED FOR USE "AS IS" WITHOUT
WARRANTY OF ANY KIND, TO THE MAXIMUM EXTENT PERMITTED BY LAW, VIDEOLOGY DISCLAIMS ALL
WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, IMPLIED
WARRANTIES OR CONDITIONS OF MERCHANTABILITY, QUALITY AND FITNESS FOR A PARTICULAR
APPLICATION OR PURPOSE. VIDEOLOGY IS NOT OBLIGATED TO PROVIDE ANY UPDATES OR UPGRADES
TO THE SOFTWARE OR ANY RELATED HARDWARE.
Limited Liability (Hardware and Software):
In no event shall Videology or its Licensor's be liable for any damages whatsoever (including, without
limitation, incidental, direct, indirect, special or consequential damages, damages for loss of business
profits, business interruption, loss of business information, or other pecuniary loss) arising out of the use
or inability to use this Software or related Hardware, including, but not limited to, any of Videology's
family of products.

Doc # INS-24RS2.0SW-EXSDI
Issue Date: 11/27/2017
Revision: A
Page 3 of 19
Safety Precaution
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
To prevent electric shocks and risk of fire hazards, do NOT use other than specific power source.
The symbol is intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The symbol is intended to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying the unit.
Warning: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
Caution: Any changes or modifications in construction of this device which are not expressly approved by
the party responsible for compliance could void the user's authority to operate the equipment.
Mains power quality should be that of a typical commercial environment. If the user of the model requires
continued operation during power mains interruptions, it is recommended that the model be powered from
an uninterruptible power supply (UPS) or a battery.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Doc # INS-24RS2.0SW-EXSDI
Issue Date: 11/27/2017
Revision: A
Page 4 of 19
Table of Contents
1. Document History....................................................................................................................5
2. Heading .................................................................................................................................5
3. Dimensions.............................................................................................................................5
4. OSD Menu Table ......................................................................................................................6
5. OSD Menu ..............................................................................................................................7
5.1. LENS (Default: MANUAL) ...................................................................................................7
5.1.1. DC (auto iris).............................................................................................................7
5.1.2. MANUAL....................................................................................................................7
5.2. FOCUS ASt.......................................................................................................................7
5.3. EXPOSURE .......................................................................................................................7
5.3.1. BRIGHTNESS .............................................................................................................7
5.3.2. SHUTTER ..................................................................................................................8
5.3.3. AGC..........................................................................................................................8
5.4. BACKLIGHT ......................................................................................................................9
5.4.1. HLC (High Light Compensation) ...................................................................................9
5.4.2. BLC (Backlight Compensation) .....................................................................................9
5.4.3. WDR (Wide Dynamic Range) .....................................................................................10
5.5. DAY & NIGHT .................................................................................................................11
5.5.1. EXTERN (Not supported) ........................................................................................... 11
5.5.2. AUTO...................................................................................................................... 11
5.5.3. COLOR (Default: COLOR) ..........................................................................................12
5.5.4. B/W........................................................................................................................ 12
5.6. COLOR .......................................................................................................................... 12
5.6.1. AWB (Auto White Balance) ........................................................................................ 12
5.6.2. COLOR GAIN ........................................................................................................... 12
5.7. 3D-NR (Digital Noise Reduction) ....................................................................................... 13
5.8. IMAGE ........................................................................................................................... 13
5.8.1. SHARPNESS ............................................................................................................ 13
5.8.2. GAMMA ................................................................................................................... 13
5.8.3. MIRROR .................................................................................................................. 13
5.8.4. FLIP........................................................................................................................ 13
5.8.5. ACE (D-WDR, Works in both CVBS and HD-SDI) .......................................................... 14
5.8.6. DEFOG.................................................................................................................... 14
5.8.7. PRIVACY ................................................................................................................. 14
5.9. MOTION......................................................................................................................... 15
5.9.1. DET WINDOW ..........................................................................................................15
5.9.2. DET TONE ...............................................................................................................15
5.9.3. MDRECT FILL ........................................................................................................... 15
5.9.4. SENSITIVITY ........................................................................................................... 16
5.9.5. MOTION OSD........................................................................................................... 16
5.9.6. TEXT ALARM ............................................................................................................ 16
5.10. SYSTEM...................................................................................................................... 16
5.10.1. OUTPUT .................................................................................................................. 16
5.10.2. RESOLUTION ...........................................................................................................17
5.10.3. TV SYSTEM.............................................................................................................. 17
5.10.4. LANGUAGE .............................................................................................................. 17
5.10.5. CAM TITLE .............................................................................................................. 17
5.10.6. RESET .................................................................................................................... 17
5.11. EXIT .......................................................................................................................... 17
5.11.1. SAVE ...................................................................................................................... 17
5.11.2. CANCEL .................................................................................................................. 17
6. Specifications........................................................................................................................ 18
7. Contact Information...............................................................................................................19

Doc # INS-24RS2.0SW-EXSDI
Issue Date: 11/27/2017
Revision: A
Page 5 of 19
1. Document History
2. Heading
•Ultra low light performance with SONY’s STARVIS sensor
•Color 0.005 LUX, B/W 0.0001 LUX
•Full HD 2MP HD-SDI/ EX-SDI camera
•1920x1080 @ 30/25fps
•1080p, 720p or CVBS selectable
•True WDR @ 30/25fps
•ROI (Region of Interest) WDR mode (adds additional scene quality optimization)
•NTSC/PAL** changeable via OSD
•Functions and OSD Control
-Motion Detection, Privacy Mask, Defog, Sens-up (32x), ACE (D-WDR), Sharpness, Deblur,
Mirror/Flip, BLC/HLC, Anti-saturation, Smart IR, Title Set
•Power 12VDC polarity protected
**specify N for NTSC preset, P for PAL preset within model number when ordering
3. Dimensions
(Unit: mm)
Revision
Issue Date
Reason
CN#
Rev A
11-08-17
Initial release
17-0081
32
32
28
28
21
1.2
4.6

Doc # INS-24RS2.0SW-EXSDI
Issue Date: 11/27/2017
Revision: A
Page 6 of 19
4. OSD Menu Table
Camera setup menu can be accessed and controlled by OSD controller.
•EXIT: You can exit the menu with saving changed commands or by cancelling the changed
commands.
•RETURN: Returns to the previous menu.
MENU
SUB MENU
CONFIGURATION
LENS
DC
MODE (INDOOR, OUTDOOR, DEBLUR)
MANUAL
FOCUS Ast.
ON, OFF
EXPOSURE
BRIGHTNESS
0~20
SHUTTER
AUTO
DEBLUR, NORMAL
MANUAL
(SPEED)
NTSC
1/30, 1/60, 1/200, 1/250, 1/500, 1/1000,
1/2000, 1/4000, 1/8000, 1/1500, 1/3000
PAL
1/25, 1/50, 1/100, 1/200, 1/400, 1/800,
1/1600, 1/3200, 1/6400, 1/12800, 1/25600
FLICKERLESS
SENS-UP
OFF, x2, x4, x8, x16, x32
AGC
0~10
BACKLIGHT
OFF
HLC
LEVEL, COLOR
BLC
H/V-POS, H/V-SIZE
WDR
MODE
ROI
WINDOW ZONE/USE, H/V-POS, H/V-SIZE
NORMAL
WEIGHT
MIDDLE, HIGH, LOW
DAY & NIGHT
EXTERN
SMART IR, ANTI-SAT., D>N THRES, N>D THRES, DELAY
AUTO
SMART IR, ANTI-SAT., AGC THRES, AGC MARGIN, DELAY
COLOR
B&W
SMART IR, ANTI-SAT.
COLOR
AWB
AUTO, AUTOext, PRESET, MANUAL (C-TEMP, R/B-GAIN)
COLOR GAIN
0~20
3D-NR
OFF, LOW, MIDDLE, HIGH
SHARPNESS
MAIN OUTPUT
ANALOG OUT0, ANALOG OUT1, SDI OUTPUT
ANALOG OUT0
CVBS
ANALOG OUT1
CVBS OFF, OFF
SDI OUTPUT
HD-SDI, EX-SDI 1.0, EX-SDI 2.0, OFF
GAMMA
0.45, 0.55, 0.65, 0.75
MIRROR
OFF, ON
FLIP
OFF, ON
ACE (D-WDR)
OFF, LOW, MIDDLE, HIGH
DEFOG
OFF, ON
MODE (AUTO, MANUAL)
LEVEL (LOW, MIDDLE, HIGH)
PRIVACY
OFF, ON
ZONE NUM, ZONE DISP, H/V-POS, H/V- SIZE, Y LEVEL, CB/CR LEVEL,
TRANS
MOTION
OFF, ON
DET WINDOW
WINDOW ZONE, WINDOW USE, DET H/V-POS, DET H/V-SIZE
DET TONE
0~4
MDRECT FILL
OFF, ON
SENSITIVITY
0~10
MOTION OSD
OFF, ON
TEXT ALARM
OFF, ON
SYSTEM
OUTPUT
SDI OUTPUT
HD-SDI, EX-SDI 1.0, EX-SDI 2.0, OFF
ANALOG OUT0
CVBS
RESOLUTION
1080p 25/30, 720p 25/30, 720p 50/60(Cropped)
TV SYSTEM
US(NTSC), EU(PAL)
LANGUAGE
ENG, CHN(S), CHN, JPN, KOR, GER
CAM TITLE
OFF, RIGHT UP, LEFT DOWN
RESET
In order to store the default settings you must click SAVE after reset is chosen
EXIT
SAVE, CANCEL
If CVBS video is enabled through ANALOG OUT0 or Sub-out port,
WDR and 3D-NR functions are disabled in all video outputs.

Doc # INS-24RS2.0SW-EXSDI
Issue Date: 11/27/2017
Revision: A
Page 7 of 19
5. OSD Menu
5.1. LENS (Default: MANUAL)
Choose either DC (auto iris) or MANUAL lens depending on which you intend to use with the camera.
5.1.1. DC (auto iris)
DC is for when DC Auto iris Vari-focal lens is installed
• INDOOR: Optimized for an indoor environment.
• OUTDOOR: Optimized for an outdoor environment.
• DEBLUR: The shutter is set to fixed values to remove any appearance of blur.
5.1.2. MANUAL
MANUAL yields the best image when a fixed lens is installed.
5.2. FOCUS ASt.
Focus Assist function is useful to set the focus on video.
There are three status bars for short range, middle range and long range. Shows exactly how focus
is set. When green bar with yellow bar appears on columns, focus the lens NEAR or FAR. The
maximum yellow bar indicates the best focusing position.
5.3. EXPOSURE
5.3.1. BRIGHTNESS
Adjusts the brightness of video (0~20).

Doc # INS-24RS2.0SW-EXSDI
Issue Date: 11/27/2017
Revision: A
Page 8 of 19
5.3.2. SHUTTER
Selects AUTO, Manual of Flickerless.
If SHUTTER is set to MANUAL, SENS-UP mode is inactivated.
5.3.2.1. AUTO
Optimizes the video level by controlling the iris and the shutter speed automatically.
• DEBLUR: The shutter is set to fixed values to remove any appearance of blur.
• NORMAL: The shutter is optimized for indoor and outdoor lighting conditions.
5.3.2.2. MANUAL:
Shutter will be set to a fixed value:
5.3.2.3. FLICKERLESS
Flickerless means that a PAL camera can be used in a 60 Hz (or a NTSC camera in a 50 Hz)
light environment without flickering. This mode can also be used to reduce side effects when
the camera is used with fluorescent light environment. This Flickerless Mode may also help
to minimize white balance drift when used in a fluorescent environment.
5.3.2.4. SENS-UP
Automatically detects the ambient level of darkness in a dark or low contrast scene to
extend the accumulated time, keeping the image bright and sharp. It can be set to Off, x2,
x4, x8, x16 or x32.
5.3.3. AGC
The AGC (Auto Gain Control) function is used to amplify the video signal when it falls below the
set parameter. As the AGC level increases, the overall screen gets brighter but the level of noise
will also increase at the same time. AGC levels are (0~10).
NTSC
1/30, 1/60, 1/200, 1/250, 1/500, 1/1000,
1/2000, 1/4000, 1/8000, 1/1500, 1/3000
PAL
1/25, 1/50, 1/100, 1/200, 1/400, 1/800,
1/1600, 1/3200, 1/6400, 1/12800, 1/25600

Doc # INS-24RS2.0SW-EXSDI
Issue Date: 11/27/2017
Revision: A
Page 9 of 19
5.4. BACKLIGHT
When there is a strong backlight behind the object, clear images of the background as well as the object
can still be obtained by using the BACKLIGHT function.
5.4.1. HLC (High Light Compensation)
HLC (High Light Compensation): This function is used to suppress or mask a strong light source
(for example, headlights of cars during nighttime) so that other subjects can be seen in more
detail.
5.4.1.1. LEVEL (0~20)
Sets the HLC level.
It sets the HLC level to determine when the HLC mask will be implemented. The HLC area is
masked with the selected color.
5.4.1.2. COLOR
Select mask color from 9 colors.
Black, White, Yellow, Cyan, Green, Magenta, Red, Blue and Customize.
5.4.2. BLC (Backlight Compensation)
This function is used to brighten an image in the foreground with a highly light area behind it
such as sunlight, limiting the effect of silhouette.
BLC has a target window for compensation and its size and position can be set by H-POS, V-
POS, H-SIZE and V-SIZE.
5.4.2.1. H-POS, V-POS
Sets the position of BLC area to move vertically and horizontally.
5.4.2.2. H-SIZE, V-SIZE
Sets the size of BLC area to move vertically and horizontally.

Doc # INS-24RS2.0SW-EXSDI
Issue Date: 11/27/2017
Revision: A
Page 10 of 19
5.4.3. WDR (Wide Dynamic Range)
The WDR function works to correct excessive light within the frame to produce a usable image.
When the image has simultaneous bright and dark areas, it makes both areas distinct. Video
outputs image processed from two images by dual shutter (long and short shutter) in a field to
provide the best dynamic range. Bright area is compensated by the short shutter and dark area
is compensated by the long shutter.
5.4.3.1. MODE
Selects WDR mode normal or ROI setting.
• NORMAL
WDR function applies full screen.
• ROI (Region of Interest)
Window Zone: Four zones possible.
Window Use: On/OFF
H/V Positions: Sets the position of ROI area to move vertically and
horizontally.
H/V Size: Sets the size of ROI area to move vertically and horizontally.
5.4.3.2. WEIGHT
LOW, MIDDLE, HIGH
Select the WDR level of the camera.
If CVBS video is enabled through ANALOG OUT0 or Sub-out port,
WDR and 3D-NR functions are disabled in all video outputs.
