Videotec MAXIMUS MVXHD User manual

EN
English - Instruction manual
ENGLISH
MAXIMUS MVXHD
High-spec ex-proof HD camera in a compact design
Manual B

Instruction manual - English - EN
3MNGCMVXHDCAM_1813_EN
Contents
ENGLISH 1
1 About this manual ....................................................................................................................5
1.1 Typographical conventions ................................................................................................................................................ 5
2 Notes on copyright and information on trademarks.............................................................5
3 Identication.............................................................................................................................5
3.1 Product marking..................................................................................................................................................................... 5
4 Installation ................................................................................................................................6
4.1 Range of use............................................................................................................................................................................. 6
4.2 Connection of the power supply line.............................................................................................................................. 6
4.3 Connection of the Ethernet cable .................................................................................................................................... 7
4.4 Signal cable connection....................................................................................................................................................... 7
4.4.1 Alarm and relay connections............................................................................................................................................................... 7
4.4.1.1 Connecting an alarm with dry contact....................................................................................................................................................................7
4.4.1.2 Relays connection ...........................................................................................................................................................................................................8
4.5 Washing system connection .............................................................................................................................................. 8
5 Switching on .............................................................................................................................8
5.1 Before powering the product in an explosive atmosphere.................................................................................... 8
5.2 First start-up ............................................................................................................................................................................. 8
6 Conguration............................................................................................................................9
6.1 Default IP address................................................................................................................................................................... 9
6.2 Web interface........................................................................................................................................................................... 9
6.2.1 First access to the web pages.............................................................................................................................................................. 9
6.3 Inserting an SD Card.............................................................................................................................................................. 9
7 Maintenance ...........................................................................................................................10
7.1 Factory Default......................................................................................................................................................................10
8 Information on disposal and recycling.................................................................................10
9 Troubleshooting .....................................................................................................................11
10 Technical data .......................................................................................................................11
10.1 Cameras.................................................................................................................................................................................11

EN - English - Instruction manual
4 MNGCMVXHDCAM_1813_EN

Instruction manual - English - EN
5MNGCMVXHDCAM_1813_EN
1 About this manual
Read all the documentation supplied carefully before
installing and using this unit. Keep the manual in a
convenient place for future reference.
This document has been compiled and published
using product descriptions and specications
available at the time of publication. The contents
of this document and the specications of the
products discussed herein are subject to change
without notice. Avigilon Corporation reserves the
right to make any such changes without notice.
Neither Avigilon Corporation nor any of its aliated
companies: (1) guarantees the completeness or
accuracy of the information contained in this
document; or (2) is responsible for your use of, or
reliance on, the information. Avigilon Corporation
shall not be responsible for any losses or damages
(including consequential damages) caused by
reliance on the information presented herein.
1.1 Typographical conventions
DANGER!
High level hazard.
Risk of electric shock. Disconnect the
power supply before proceeding with any
operation, unless indicated otherwise.
CAUTION!
Medium level hazard.
This operation is very important for the
system to function properly. Please read
the procedure described very carefully and
carry it out as instructed.
INFO
Description of system specications.
We recommend reading this part carefully
in order to understand the subsequent
stages.
2 Notes on copyright and
information on trademarks
The mentioned names of products or companies are
trademarks or registered trademarks.
AVIGILON, the AVIGILON logo, and AVIGILON
CONTROL CENTER are trademarks of Avigilon
Corporation.
Other names or logos mentioned herein may be the
trademarks of their respective owners.
The absence of the symbols ™ and ® in proximity to
each trademark in this document or at all is not a
disclaimer of ownership of the related trademark.
ONVIF® is a trademark of Onvif, Inc.
3 Identication
3.1 Product marking
See the label attached to the product.

EN - English - Instruction manual
6 MNGCMVXHDCAM_1813_EN
4 Installation
CAUTION! Device installation and
maintaining must be performed by
specialist technical sta only.
The external multipolar cable shield
(armature) must be earthed.
All disconnected wires must be electrically
isolated.
The product comes with a multipolar cable
or a cable tail for coupling purposes. When
installing the device with the multipolar
cable, keep at least 250mm free space
from the bottom of the housing to allow
for the minimum curvature radius of the
multipolar cable.
4.1 Range of use
For indoors and outdoors installation.
Installation temperature: from -40°C (-40°F) up to
+60°C (140°F).
Operating temperature:
• -40 °C to 55 °C (-40 °F to 131 °F), in enclosed space
• -40 °C to 60 °C (-40 °F to 140 °F), with ambient
convection
Relative humidity: from 10% up to 95% (no
condensation).
4.2 Connection of the power
supply line
Electrical connections must be performed
with the power supply disconnected and
the circuit-breaker open.
When commencing installation make sure
that the specications for the power supply
for the installation correspond with those
required by the device.
Check that the power supply is adequately
dimensioned.
The device can be provided with dierent power
supply voltages. The power supply voltage is
indicated on the product identication label. (3.1
Product marking, page5).
The multicore cable has the power and earth cables
inside.
Perform the connections following the instructions
reported in the table .
CONNECTION OF THE POWER SUPPLY LINE
Power supply 24Vac/ 24Vdc/ 12Vdc
Colour Terminals
Black 1 (+) L (Phase)
Black 2 (-) N (Neutral)
Yellow/Green
Tab. 1

Instruction manual - English - EN
7MNGCMVXHDCAM_1813_EN
4.3 Connection of the Ethernet
cable
The Ethernet cable shield must always be
earthed via the connector. Always use a
shielded RJ45 connector.
Use of Ethernet cables with the following
characteristics is highly recommended:
• STP (shielded)
• Category 5E (or higher)
The product can be directly connected to an Ethernet
switch.
Carry out the connections as described in the table
(according to the standard specications: TIA/EIA-
568-B).
CONNECTION OF THE ETHERNET CABLE
Pin number Cable color
1 Orange-White
2 Orange
3 Green-White
4 Blue
5 Blue-White
6 Green
7 Brown-White
8 Brown
Tab. 2
The example below shows a typical installation.
Switch
Personal
Computer
Fig. 1
4.4 Signal cable connection
CAUTION! TNV-1 installation type. The
installation is type TNV-1, do not connect it
to SELV circuits.
SIGNAL CABLE CONNECTION
Colour Function
White RS-485 A (+)
Yellow RS-485 B (-)
Pink Relay 1, Terminal A
Violet (blue, cable
tail version)
Relay 1, Terminal B
Red (brown, cable
tail version)
Alarm/Digital input
Green GND/Common alarm
Grey Reset
Tab. 3
4.4.1 Alarm and relay connections
The external relay and alarm cable shield
must be earthed.
The unit is equipped with the alarms and relays
indicated in the table (Tab. 3, page7).
4.4.1.1 Connecting an alarm with dry contact
In case of free contact alarm make the connection as
shown in the gure.
AL1 COM
dry contact
Fig. 2AL1: Alarm 1. COM: Common alarms.
The dry contact alarm can be NO (normally open) or
NC (normally closed).

EN - English - Instruction manual
8 MNGCMVXHDCAM_1813_EN
4.4.1.2 Relays connection
The relays are usable with the specications
described below. Working voltage: up
to 15Vac or 30Vdc. Current: 1A max. Use
suitable cable sections with the following
characteristics: from 0.25mm² (23AWG) up
to 1.5mm² (15AWG).
Due to the absence of polarity, both terminals of the
same relay can be connected either to alternating or
direct current voltages.
4.5 Washing system connection
For further details on conguration and
use, refer to the relative manual.
5 Switching on
The automatic pre-heating procedure (De-
Ice) activates for 2 hours if on device switch
on an ambient temperature is detected
under -10 °C (+14°F). The procedure is
necessary to guarantee correct operation of
the devices even at low temperatures.
The full functionality of the product is guaranteed
from the following ambient temperature: -40°C.
Do not turn on the unit when the ambient
temperature is lower than indicated: -40°C.
The unit is switched on by connecting the power
supply.
To switch o the unit disconnect the power.
5.1 Before powering the product
in an explosive atmosphere
Make sure that all parts are fastened down
rmly and safely.
Make sure that the unit and other
components of the installation are closed
so that it is impossible to come into contact
with live parts.
Make sure that the device has been
connected to an earth link as described.
Ensure the rear cover plate is correctly
closed.
Ensure the product is correctly closed.
Ensure that the sealing of cable entry
systems (if any) has been performed
properly and the time of glue hardening
has been observed.
5.2 First start-up
Make sure that the unit and other
components of the installation are closed
so that it is impossible to come into contact
with live parts.
Make sure that all parts are fastened down
rmly and safely.

Instruction manual - English - EN
9MNGCMVXHDCAM_1813_EN
6 Conguration
6.1 Default IP address
The unit is congured to obtain an IP
address from a DHCP server.
The IP address acquired via DHCP is visible in the
DHCP server log le.
If the DHCP server is not available, the unit
automatically congures itself with a self-generated
IP address in the 169.254.x.x/16 subnet. Conguring
the IP address of the PC as belonging to the same
subnet (example: IP address: 169.254.1.1, subnet
mask: 255.255.0.0).
Use an ONVIF compliant VMS or the Avigilon™
Camera Conguration Tool to nd the IP address of
the device.
6.2 Web interface
Browsers supported (the latest version):
Microsoft Edge, Google Chrome, Mozilla
Firefox.
6.2.1 First access to the web pages
The rst operation in conguring the device consists
in connecting to the web interface.
To access the web interface of the product, simply
use a browser to connect to http://ip_address.
On rst access, the Home page will be displayed.
Additional information about setting up and using
the device is available in the following guides:
• Web Interface User Guide — Avigilon High
Denition H4 and H5 IP Cameras
• Avigilon Camera Conguration Tool User Guide
• Designing a Site with Avigilon Video Analytics
• Avigilon Control Center™ Client User Guide
These guides are available on help.avigilon.com and
on the Avigilon website: avigilon.com/support-and-
downloads.
6.3 Inserting an SD Card
For instruction about opening and closing
the camera, please refer to Manual A.
For onboard video storage capabilities, please insert
an industrial grade microSD card into the slot as show
(Fig. 3, page9).
Fig. 3

EN - English - Instruction manual
10 MNGCMVXHDCAM_1813_EN
7 Maintenance
Read the product Manual A before
performing any operation.
Please provide the device serial number when
requesting any replacement parts.
7.1 Factory Default
It is possible to reset to the factory default settings.
Follow the procedure below:
• Power the unit. Wait for 3 minutes.
• Connect the signal cable grey and green wires (
Tab. 3, page7).
• Wait for 3 minutes.
• Switch o the unit.
Disconnect the previously connected green and grey
wires.
• Power the unit.
8 Information on disposal
and recycling
The European Directive 2012/19/EU on Waste
Electrical and Electronic Equipment (WEEE) mandates
that these devices should not be disposed of in the
normal ow of municipal solid waste, but they should
be collected separately in order to optimize the
recovery stream and recycling of the materials that
they contain and to reduce the impact on human
health and the environment due to the presence of
potentially hazardous substances.
The symbol of the crossed out bin is marked
on all products to remember this.
The waste may be delivered to appropriate collection
centers, or may be delivered free of charge to the
distributor where you purchased the equipment at
the time of purchase of a new equivalent or without
obligation to a new purchase for equipment with size
smaller than 25cm (9.8in).
For more information on proper disposal of these
devices, you can contact the responsible public
service.
