Vido WD030210254 User manual

Miter saw
WD030210254
1800W

WD030210254
Thank you for purchasing a VIDO product. We are confident that you will appreciate the quality
of the product and you will be entirely satisfied with your purchase. Please read carefully the
user safety and operating instruction on how to operate this product correctly within safety
norms and regulations.
2

WD030210254
3
20
16
6
4
2
1
3
10
7
9
5
8
11
14
12
27 28
26 25 24
18
17
15
19
21
22
23
29
34 35 36
30
32 31 33
13

WD030210254
4
1
1
2
2
4
4
5
5
7
7
8
8
10
10
11
11
3
3
6
6
9
9
12
12
321
654
987
121110

WD030210254
5
13
1
14
2
16
4
17
5
19
7
20
8
22
10
23
11
15
3
18
6
90°
24
12
151413
181716
212019
242322

WD030210254
6
25
13
26
14
28
16
29
17
31
19
32
20
34
22
35
23
90°
27
15
30
18
33
21
36
24
272625
302928
333231
363534

WD030210254
7
37
13
38
14
41
17
43
19
44
20
40
1616
39
15
42
18
45
21
393837
424140
454443

1800W MITER SAW ENG
COMPONENT LIST
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
13)
14)
15)
16)
17)
18)
19)
20)
21)
22)
23)
24)
25)
26)
27)
28)
29)
30) Trenching depth lock nut
31)
32)
33)
34)
35)
36)
NORMAL ACCESSORIES
1) Workpiece clamp: 1set
2) Hex key: 1pc
3) Side bars: 2pcs
4) Dust bag: 1pc
5) Spare carbon brush: 1set
8
Side support bars (x2)
Side support bar location holes (2 sets)
Side support bar locking screws
Clamp assembly lock (x2)
Clamp assembly
Laser cover
Slide bars
Saw arm
Slide lock
Dust extraction port
Guard retraction arm
Upper fixed blade guard
Hex key
Carrying handle
Guard release latch
Operating handle
Switch trigger
Rotating blade guard
Blade bolt cover
Laser light assembly
Bevel scale
Fence
Mitre table
Mitre lock
Table insert (kerf plate)
Mitre scale
Laser light on/off switch
Release knob
Dust bag
0° Bevel adjustment screw
Bevel lock
45° Bevel adjustment screw
Spindle lock
Trenching depth adjustment screw
Trenching stop

1800W MITER SAW ENG
We recommend that you purchase your accessories from the same store that sold you the tool.
Use good quality accessories marked with a well-known brand name. Choose the type according to the
work you intend to undertake. Refer to the accessory packaging for further details. Store personnel can
assist you and offer advice.
GENERAL POWER TOOL SAFETY WARNINGS
Warning: Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructionsfor future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use.Use
of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication.A moment of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection.Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will
reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
9

1800W MITER SAW ENG
finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times.This enables better control of
the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.The correct
power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off.Any power tool that cannot
be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in the
hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power tool
for operations different from those intended could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR POWER TOOL
1) Wear ear protectors. Exposure to noise can cause hearing loss.
2) Make sure that the guard operates properly and that it can move freely. Never lock the guard in
place when opened.
3) Keep hands away from the cutting area while the machine is running. Danger of injury when coming
in contact with the saw blade.
4) Never remove cutting remainders, wood chips, etc. from the sawing area while the machine is
running. Always guide the power tool arm back to the neutral position first and then switch the machine
off.
5) Guide the saw blade against the workpiece only when the machine is switched on. Otherwise there
is damage of kickback, when the saw blade becomes wedged in the workpiece.
10

1800W MITER SAW ENG
6) Keep handles dry, clean, and free from oil and grease. Greasy, oily handles are slippery causing
loss of control.
7) Operate the power tool only when the work area to the workpiece is clear of any adjusting tools,
wood chips, etc. Small pieces of wood or other objects that come in contact with the rotating saw blade
can strike the operator with high speed.
8) Keep the floor free of wood chips and material remainders. You could slip or trip.
9) Always firmly clamp the piece to be worked. Do not saw workpieces that are too small to clamp.
Otherwise, the clearance of your hand to the rotating saw blade is too small.
10)Use the machine only for cutting the materials listed under Intended use. Otherwise, the machine
can be subject to overload.
11)Secure the workpiece. A workpiece clamped with clamping devices or in a vice is held more secure
than by hand.
12)Connectthe power tool to a dust collection device and ensure that it is operated properly.
13)Avoid cutting nails. Inspect the workpiece and remove all nails and other foreign objects before
beginning sawing.
14)If the saw blade should become jammed, switch the machine off and hold the workpiece until the
saw blade comes to a complete stop. To prevent kickback, the workpiece may not be moved until after
the machine has come to a complete stop. Correct the cause for the jamming of the saw blade before
restarting the machine.
15)Do not use dull, cracked, bent or damaged saw blades. Unsharpened or improperly set saw blades
produce narrow kerf causing excessive friction, blade binding and kickback.
16)Always use saw blades with correct size and shape of arbor holes. Saw blades that do not match
the mounting hardware of the saw will run eccentrically, causing loss of control.
17)Do not use high speed steel (HSS) saw blades. Such saw blades can easily break.
18)During slide cutting, always ensure thatthe saw blade is pushed away from the operator
19)Never leave the machine before it has come to a complete stop. Cutting tools that are still running
can cause injuries.
20)Do not touch the saw blade after working before it has cooled. The saw blade becomes very hot
while working.
21)Store the machine in a safe manner when not being used. The storage location must be dry and
lockable. This prevents the machine from storage damage, and from being operated by untrained
persons.
22)Do not direct the laser beam at persons or animals and do not stare into the laser beam yourself,
not even from a distance. This power tool produces laser class 2 laser radiation according to EN
60825-1. This can lead to persons being blinded.
23)Do not replace the installed laser with another laser type. A laser that does not fit to this power tool
could pose dangers for other persons.
24)Wear gloves when handling saw blades.
25)Periodically check that all nuts, bolts and other fixings are properly tightened.
26)When an extension cord is required you must ensure it has the correct ampere rating for your
power tool and that it is in a safe electrical condition. Fully unwind extension cords to avoid potential
overheating.
11

1800W MITER SAW ENG
DOUBLE INSULATION
The power tool is double insulated. This means that all the external metal parts are electrically insulated
from the main power supply. This is done by placing insulation barriers between the electrical and
mechanical components making it unnecessary for the power tool to be earthed.
IMPORTANT NOTE
Be sure the supply is the same as the voltage given on the rating plate. The power tool is fitted with a
two-core cable and plug.
Remove the main plug from socket before carrying out any adjustment or servicing.
SYMBOLS
To reduce the risk of injury, user must read instruction manual
Double insulation
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Laser radiation, do not stare into beam
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice
12

1800W MITER SAW ENG
TECHNICAL DATA
Note: For power tool specifications refer to the nameplate on your power tool.
OPERATING INSTRUCTIONS
Note: Before using the power tool, readthe instruction manual carefully.
1. Intended use
The machine is intended as a stationary machine for making straight lengthways and crossways cuts in
wood. Horizontal mitre angles of –52° to +52° as well as vertical bevel angles of 0° to 45° are possible.
The machine is designed with sufficient capacity for sawing hard and softwood as well as press and
particle board. The power tool is not suitable for cutting aluminium or other non-ferrous metals or alloys.
2. Unpacking
Due to modern mass production techniques, it is unlikely that your power tool is faulty or that a part is
missing. If you find anything wrong, do not operate the tool until the parts have been replaced or the
fault has been rectified. Failure to do so could result in serious personal injury.
1) Remove all loose partsfrom the carton.
2) Remove the packing materials from around the saw.
3) Using the carrying handle carefully lift the saw from the carton and place it on a level work surface.
4) The saw has been shipped with the saw arm locked in the down position. To release the saw arm,
push down on the top of the saw arm, pull on the release knob, rotate it 45° and let go, slowly raise the
saw arm.
Model WD030210254
Voltage 110-120V AC 220-240V AC
Frequency 50-60Hz 50-60Hz
Power input 1800W 1800W
No load speed 5500/min 5500/min
Blade size Ø10” x Ø 1” Ø 254 mm x Ø 25.4 mm
Mitretable angles 0° to 52° left & right 0° to 52° left & right
Bevel cuts 0° to 45° left 0° to 45° left
Straight cut 0° x 0°: 3 1/4” x 11 5/8” 0° x 0°: 81.5 mm x 295 mm
Mitre cut 45° (L&R) x 0°: 3 1/4” x8 1/16” 45° (L&R) x 0°: 81.5 mm x 205 mm
Bevel cut 0° x 45°(L): 1 5/8” x11 5/8” 0° x 45°(L): 43 mm x 295 mm
Compound mitre cut 45°(L) x 45°(L): 1 5/8” x 8 1/16”45°(L) x 45°(L): 43 mm x 205 mm
Protection class
Machine weight 13.5Kg 13.5Kg
13
//

1800W MITER SAW ENG
Warning:Do not lift the saw whilst holding on to the guards. Use the carrying handle.
3. Transportation
Lift the mitre saw only when the saw arm is locked in the down position, the saw is switched off and the
plug is removed from the power point.
Only lift the saw by the carrying handle or outer castings (See Fig 1). Do not lift the saw using the guard
or operating handle.
4. Bench mounting
The saw base has holes in each cornertofacilitate bench mounting (See Fig 2).
1) Mount the sawto a level, horizontal bench or work table using bolts (not supplied) and fix the saw to
the bench using 4 bolts.
2). If desired, you can mount the saw to a piece of 13mm or thicker plywood which can then be clamped
to your work support or moved to other job sites and re-clamped.
Note: Make sure that the mounting surface is not warped as an uneven surface can cause binding and
inaccurate sawing.
5. Release knob
The release knob is provided for holding the cutting head down whilst transporting or storing the mitre
saw (See Fig 3). The saw must never be used with the release knob locking the head down.
6. Slide lock
When tightened, the slide lock prevents the saw head from sliding. Tighten the slide lock during
transportation (See Fig 4).
7. Mitre table lock
The mitre table lock is used to lock the table at the desired mitre angle (See Fig 5). The mitre saw cuts
from 0° to 45° both left and right. To adjust the mitre angle loosen the mitre table lock and depress the
mitre lever to allow the table to rotate, rotate to the desired mitre angle and lock the table in place. The
mitre table features positive click stops at 0°, 15°, 22.5°, 30° and 45° for quick setting of common mitre
angles.
Warning:Be sure to tighten the mitre table lock before making a cut. Failure to do so could
result in the table moving during the cut and cause serious personal injury.
8. Bevel lock
The bevel lock is used to set the blade at the desired bevel angle (See Fig 6). The mitre saw bevel cuts
from 0° to 45°. To adjust the bevel angle loosen the bevel lock and pull out the 0° bevel adjuster. Adjust
the saw arm tothe desired bevel angle.
Warning:Be sure to tighten the bevel lock before making a cut. Failure to do so could result in
the saw arm moving during the cut and cause serious personal injury.
9. Clamp assembly
The clamp assembly can be mounted to the fence, either side of the saw blade,to suit the task at hand
14

1800W MITER SAW ENG
(See Fig 7).
Use the clamp assembly lock at the back of the fence to secure the clamp assembly in position (See
Fig 8).
10. Spindle lock button
The spindle lock button prevents the blade in the saw from rotating (See Fig 9). Depress and hold the
spindle lock button while installing, changing, or removing the blade.
11. Rotating lower blade guard
The rotating lower blade guard provides protection from both sides of the blade (See Fig 10). It retracts
over the upper blade guard as the saw is lowered into the workpiece.
12. Dust bag
The dust bag fits over the dust extraction port. For more efficient operation, empty the dust bag when it
is no more than half full. This allows better air flow through the bag (See Fig 11).
13. Attaching the side bars
The side support bars help to support the material when working with long workpieces. There are two
location holes for a support bar on either side of the table. Loosen the lock screws with the hex key.
Ensure the side bars are fully inserted before using them to support the workpiece (See Fig 12).
The side support bar locking screws must be tightened to secure the support bars in position (See Fig
13).
14. Trench depth adjustment
In its normal position, the trenching stop permits the saw blade to cut right through a workpiece. When
the saw arm is lifted, the trenching stop can be moved to the left so that the trenching depth adjustment
screw contacts the stop as the saw arm is lowered (See Fig 14).
This restricts the cut to a “trench” in the workpiece. The depth of the trench can be adjusted with the
trenching depth adjustment screw (See Fig 15) and locked in position with the trenching depth lock nut
(See Fig 16).
15. Turning on and off
1) Pull in switch trigger to start the unit (See Fig 17).
2) To turn the saw off release the on/off trigger switch.
16. Turning on the laser line generator
The laser line generator emits a single beam of pure red light to guide you as you cut. It improves
operator cutting vision, enables faster set-up, increases accuracy and improves safety. To turn on the
laser lines press the laser light on/off switch (See Fig 18). To turn off the laser press the laser light
on/off switch one more time.
17. Setting the table square withthe blade
1) Make sure that the electrical plug is removed from the power point.
2) Push the saw arm down to its lowest position and engage the release knob to hold the saw arm in
the transport position.
15

1800W MITER SAW ENG
3) Loosen the mitre lock (See Fig 19).
4) Rotate the table until the pointer is positioned at 0º.
5) Tighten the mitre lock.
6) Loosen the bevel lock and set the saw arm at 0º bevel (the blade at 90º to the mitre table). Tighten
the bevel lock (See Fig 20).
7) Place a set square against the table and the flat part of the blade (See Fig 21).
Note: Make sure thatthe square contacts the flat part of the saw blade, notthe teeth.
8) Rotate the blade by hand and check the blade-to-table alignment at several points.
9) The edge of the set square and the saw blade should be parallel.
10) If the saw blade angles away from the set square, adjust as follows.
11) Use a wrench or adjustable wrench to loosen the lock nut securing the 0° bevel adjustment screw
(See Fig 22). Also, loosen the bevel lock.
12) Adjust the 0° bevel adjustment screw with the hex key to bring the saw blade into alignment
the square(See Fig 23).
13) Loosen the screws holding the pointer of the bevel scale and adjust the position of the pointer so
that it accurately indicates zero on the scale (See Fig 24). Retighten the screw.
14) Retighten the bevel lock and the lock nut securing the 0° bevel adjustment screw.
Note. The above procedure can also be used to check the angle of the saw blade to the table at the 45º
bevel angle (See Fig 25 & 26).
18. Setting the fence square with thetable
1) Make sure that the electrical plug is removed from the power point.
2) Push the saw arm down to its lowest position and engage the release knob to hold the saw arm in
the transport position.
3) Loosen the mitre lock.
4) Rotate the table until the pointer is positioned at 0º.
5) Tighten the mitre lock.
6) Using the hex key , loosen the four screws securing the fence to the base (See Fig 27).
7) Place a square against the fence and alongside the blade (See Fig 28).
8) Adjust the fence until it is square with the blade.
9) Tighten the screws securing the fence.
10) Loosen the screw holding the pointer of the mitre scale and adjust it so that it accurately indicates
the zero position on the mitre scale (See Fig 29).
11) Retighten the screw securing the mitre scale pointer.
12) Replace the top section of the fence and secure the hex screw using the hex key.
19. Changing a blade
Warning: Never try to use a blade larger than the stated capacity of the saw. It might come into
contact with the blade guards. Never use a blade that is too thick to allow the outer blade washer to
engage with the flats on the spindle. It will prevent the blade screw from properly securing the blade on
the spindle. Do not use the saw to cut metal or masonry. Ensure that any spacers and spindle rings that
may be required suit the spindle and the blade fitted.
1) Make sure that the electrical plug is removed from the power point.
16
with

1800W MITER SAW ENG
2) Push down on the operating handle and pull the release knob to disengage the saw arm. The
release knob can be turned so that it is held in the retracted position (See Fig 30).
3) Raise the saw arm to its highest position.
4) Using a screwdriver loosen and remove the screw thatsecures the guard retraction arm to the
rotating blade guard (See Fig 31).
5) Using a screwdriver to loosen and remove the screw that secures the blade bolt cover (See Fig 32).
6) Pull the rotating blade guard down then swing it up together with the blade bolt cover. When the
rotating blade guard is positioned over the upper fixed blade guard it is possible to access the blade
bolt (See Fig 33).
7) Hold the rotating guard up and press the spindle lock button (See Fig 34). Rotate the blade until the
spindle locks.
8) Use the hex key provided to loosen and remove the blade bolt. (Loosen in a clockwise direction as
the blade screw has a left hand thread) (See Fig 35).
9) Remove the flat washer and outer blade washer and the blade.
10) Wipe a drop of oil onto the inner blade washer and the outer blade washer where they contact the
blade.
11) Fit the new blade onto the spindle taking care that the inner blade washer sits behind the blade
(See Fig 36).
Note: To ensure correct blade rotation, always install the blade with the blade teeth and the arrow
printed on the side of the blade pointing down. The direction of blade rotation is also stamped with an
arrow on the upper blade guard.
12) Replace the outer blade washer (See Fig 37).
13) Depress the spindle lock button and replace the flat washer and blade bolt.
14) Use the hex key to tighten the blade bolt securely (tighten in an anti-clockwise direction).
15) Lower the blade guard, hold the rotating lower blade guard and blade bolt cover in position and
tighten the fixing screw (See Fig 38).
16) Replace the guard retraction arm and secure onto the rotating blade guard (See Fig 39).
17) Check that the blade guard operates correctly and covers the blade as the saw arm is lowered.
18) Connect the saw to the power supply and run the blade to make certain that it is operating correctly.
20. Cross-cutting (without slide action)
When cutting a narrow piece of wood it is not necessary to use the slide mechanism. In these cases
ensure that the slide lock is screwed down to prevent the saw arm from sliding.
A crosscut is made by cutting across the grain of the workpiece. A 90º crosscut is made with the mitre
table set at 0º (See Fig 40). Mitre crosscuts are made with the table set at some angle other than zero.
1) Pull on the release knob and lift the saw arm to its full height.
2) Loosen the mitre lock.
3) Rotate the mitre table until the pointer aligns with the desired angle.
4) Retighten the mitre lock.
Warning:Be sure to tighten the mitre lock before making a cut. Failure to do so could result in
the table moving during the cut and cause serious personal injury.
5) Place the workpiece flat on the table with one edge securely against the fence. If the board is warped,
place the convex side against the fence. If the concave side is placed against the fence, the board
could break and jam the blade.
17

1800W MITER SAW ENG
6) When cutting long pieces of timber, support the opposite end of the timber with the side support bars,
a roller stand or a work surface that is level with the saw table.
7) Use the clamp assembly to secure the workpiece wherever possible.
8) It is possible to remove the clamp assembly by loosening the clamp assembly lock and moving it to
the other side of the table. Make sure the clamp assembly lock is tight before using the clamp (See Fig
41).
9) Before turning on the saw, perform a dry run of the cutting operation to check that there are no
problems.
10) Hold the operating handle firmly and squeeze the switch trigger. Allow the blade toreach maximum
speed and slowly lower the blade into and through the workpiece.
11) Release the switch trigger and allow the saw blade to stop rotating before raising the blade out of
the workpiece. Wait until the blade stops before removing the workpiece.
21. Cross-cutting (with slide action)
When cutting wide workpieces, first unscrew the slide lock.
1) Pull on the release knob, raise the saw arm to its highest position and slide it towards you (See Fig
42).
2) Hold the handle firmly and squeeze the switch trigger. Allow the blade to reach maximum speed.
3) Slowly lower the blade into the workpiece and slide it away from you at the same time until the
workpiece is cut.
4) Release the switch trigger and allow the saw blade to stop rotating before raising the blade out of the
workpiece. Wait until the blade stops before removing the workpiece.
22. Bevel cut
A bevel cut is made by cutting across the grain of the workpiece with the blade angled to the fence and
mitre table. The mitre table is set at the zero degree position and the blade set at an angle between 0º
and 45º (See Fig 43).
Use the slide action when cutting wide workpieces.
1) Pull on the release knob and lift the saw arm to its full height.
2) Loosen the mitre lock.
3) Rotate the mitre table until the pointer aligns with zero on the mitre scale.
4) Retighten the mitre lock.
Warning:Be sure to tighten the mitre lock before making a cut. Failure to do so could result in
the table moving during the cut, causing serious personal injury.
5) Loosen the bevel lock and pull out the 0º bevel adjuster. Move the saw arm to the desired bevel
angle (between 0º and 45º). Tighten the bevel lock.
6) Place the workpiece flat on the table with one edge securely against the fence. If the board is warped,
place the convex side against the fence. If the concave side is placed against the fence, the board
could break and jam the blade.
7) When cutting long pieces of timber, support the opposite end of the timber with the side bars, aroller
stand or a work surface that is level with the sawtable.
8) Use the clamp assembly to secure the workpiece wherever possible.
9) It is possible to remove the clamp assembly by loosening the clamp assembly lock and moving it to
the other side of the table. Make sure the clamp assembly lock is tight before using the clamp.
18

1800W MITER SAW ENG
10) Before turning on the saw, perform a dry run of the cutting operation to check that there are no
problems.
11) Hold the operating handle firmly and squeeze the switch trigger. Allow the blade toreach maximum
speed.
12) Press the release latch and slowly lower the blade into and through the workpiece.
13) Release the switch trigger and allow the saw blade to stop rotating before raising the blade out of
the workpiece. Wait until the blade stops before removing the workpiece.
23. Compound mitre cut
A compound mitre cut involves using a mitre angle and a bevel angle at the same time (See Fig 44). It
is used in making picture frames, to cut mouldings, making boxes with sloping sides and for roof
framing. Always make a test cut on a piece of scrap wood before cutting into the good material. Use the
slide action when cutting wide workpieces.
1) Pull on the release knob and lift the saw arm to its full height.
2) Loosen the mitre lock.
3) Rotate the mitre table until the pointer aligns with the desired angle on the mitre scale.
4) Retighten the mitre lock.
Warning:Be sure to tighten the mitre lock before making a cut. Failure to do so could result in
the table moving during the cut, causing serious personal injury.
5) Loosen the bevel lock and pull out the 0º bevel adjuster and move the saw arm to the left or right to
the desired bevel angle (between 0º and 45º). Tighten the bevel lock.
6) Place the workpiece flat on the table with one edge securely against the fence. If the board is warped,
place the convex side against the fence. If the concave side is placed against the fence, the board
could break and jam the blade.
7) When cutting long pieces of timber, support the opposite end of the timber with the side bars, aroller
stand or a work surface that is level with the sawtable.
8) Use the clamp assembly to secure the workpiece wherever possible.
9) It is possible to remove the clamp assembly by loosening the clamp assembly lock and moving it to
the other side of the table. Make sure the clamp assembly lock is tight before using the clamp.
10) Before turning on the saw, perform a dry run of the cutting operation to check that there are no
problems.
11) Hold the operating handle firmly and squeeze the switch trigger. Allow the blade toreach maximum
speed and slowly lower the blade into and through the workpiece.
12) Release the switch trigger and allow the saw blade to stop rotating before raising the blade out of
the workpiece. Wait until the blade stops before removing the workpiece.
24. Adjusting the laserline
The laser is factory set to the centre of the blade width. To adjust the position of the laser, proceed as
follows:
1) Remove the laser cover by pulling it towards you.
2) Switch on the laser light with the on/off switch.
3) Using a screwdriver (not supplied), adjust the position of the laser line by turning the laser pitch
control (See Fig 45).
4) Adjust until the laser hits the centre of the blade.
19

1800W MITER SAW ENG
5) Switch off the laser light.
25. Using the laser line generator
Warnings:
•Do not stare directly at the laser beam.
•Never aim the beam at any person or an object other than the workpiece.
•Do not deliberately aim the beam at personnel and ensure that it is not directed towards the eye of a
person for longer than 0.25s.
•Always ensure the laser beam is aimed at a sturdy workpiece without reflective surfaces. Wood or
rough coated surfaces are acceptable. Bright shiny reflective surfaces are not suitable for laser use as
the reflective surface could direct the beam back at the operator.
•Always remember to switch off the laser on/off switch after finishing a job. Only turn the laser beam on
when the workpiece is on the mitre sawtable.
1) Mark the line of the cut on the workpiece.
2) Adjust the angle of mitre and bevel of the cut as required.
3) Switch on the laser light on/off switch.
4) Clamp the workpiece in position using the laser line to align the blade with the pencil mark on the
workpiece.
5) After each use, clean the laser light assembly as described below:
•Switch off the laser light switch and then remove the plug from the power point.
•With the saw arm in the raised position, use a soft brush to dust away the sawdust build-up around the
assembly.
Note: Wear eye protection whilst brushing the dust away.
MAINTENANCE
Warning: Remove the plug from the socket before carrying out any adjustment, servicing
or maintenance.
1. Cleaning
•Keep the power tool’s air vents unclogged and clean at all times.
•Remove dust and dirt regularly. Cleaning is best done with a soft brush or a rag.
•Re-lubricate all moving parts at regular intervals.
•Never use caustic agents to clean plastic parts.
2. Regularly check that all the fixing screws are tight. They may vibrate loose over time.
3. Always store your power tool in a dry place.
4. If you see some sparks flashing in the ventilation slots, this is normal and will not damage your power
tool.
5. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
20
