ViewSonic VNB101 User manual

- User Guide
- Guide de l’utilisateur
- Bedienungsanleitung
- Guía del usuario
-Pyководствопользователя
-Οδηγόςχρηστών
- 使用手冊(繁中)
- 使用手冊 (簡中)
VNB101
NetBook
ViewSonic®
Model No. : VS12638

ViewSonic VNB101 i
Compliance Information
CE Conformity for European Countries
The device complies with the EMC Directive 2004/108/EC and Low Voltage
Directive 2006/95/EC.
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical and
Electronic Equipment Directive 2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment as unsorted
municipal waste, but use the return and collection systems according to local
law.
If the batteries, accumulators and button cells included with this equipment, display
the chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy
metal content of more than 0.0005% Mercury or more than, 0.002% Cadmium, or
more than 0.004% Lead.
R&TTE Compliance Statement
This wireless module device complies with the Essential Requirements of the R&TTE
Directive of the European Union (1999/5/EC). This equipment meets the following
conformance standards:
ETSI EN 300 328
EN 301 489-01
EN 301 489-17
EN 62311
Notied Countries: Germany, UK, Netherlands, Belgium, Sweden, Denmark, Finland,
France, Italy, Spain, Austria, Ireland, Portugal, Greece, Luxembourg, Estonia, Latvia,
Lithuania, Czech Republic, Slovakia, Slovenia, Hungary, Poland and Malta.

ViewSonic VNB101 ii
Important Safety Instructions
1. DO NOT press or touch the LCD Screen. DO NOT place the Notebook PC with small
items, they may scratch LCD Screen or enter the Notebook PC.
2. DO NOT expose the Notebook PC to dirty or dusty environment. Keep the environment
clean and dry.
3. DO NOT place the Notebook PC on uneven or unstable work surface.
4. DO NOT place or drop objects on the top of the Notebook PC. DO NOT shove any
foreign objects into the Notebook PC. DO NOT cover the LCD Screen strongly.
5. DONOTexposetheNotebookPCtostrongmagneticorelectricalelds;DONOT
placetheoppydisknearorontheNotebookPC,thatmaylossthedataoftheoppy
disk.
6. DO NOT leave the Notebook PC facing the sun as it can damage the LCD Screen,
especially in the car.
7. SAFE TEMP: This Notebook PC should only be used in environments with ambient
temperatures between 5°C (41°F) and 35°C(95°F).
8. DO NOT expose the Notebook PC to or use near liquids, rain, or moisture.
9. Caution: risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.
10. DO NOT throw the Notebook PC in municipal waste. Check local regulations for
disposal of electronic products. Please recycle the Battery Pack, and check with your
Local Authority or retailer for recycling advice.
11. The Notebook PC and the Adapter may occur some heat during operating or charging.
DO NOT leave the Notebook PC on your lap or any part of the body in order to prevent
discomfort or injury from heat exposure.
12. INPUT RATING: Refer to the rating label on the Notebook PC and be sure that the
PowerAdaptercomplieswiththerating.Onlyuseattachmentsoraccessoriesspecied
by the manufacturer.
13. Checking the connections between the main unit and attachments before turning on
the Notebook PC.
14. DO NOT use the Notebook PC during eating food avoid dirtying the Notebook PC.
15. DO NOT insert anything into the Notebook PC that may result in short circuit or
damage the circuit.
16. Powering off the Notebook PC, if you want install or remove some external devices,
which are not support hot-plug.

ViewSonic VNB101 iii
17. Disconnect the Notebook PC from the electrical outlet and remove any installed
batteries before cleaning. And Keep it away from children.
18.DONOTdisassembletheNotebookPC,onlyacertiedservicetechnician
should perform repairs on your computer. Otherwise, problem may result and the
manufacturer should not hold responsibility for the damage.
19. Only use Battery Packs approved by the manufacturer or else damage may occur.
20.TheNotebookPChassomelittlemetalaketodisperseheat.DONOTplacethe
Notebook PC on soft objects (e.g.: bed, sofa, your lap), or else the Notebook PC may
become hot and halt the system operating.

ViewSonic VNB101 iv
Declaration of RoHS Compliance
This product has been designed and manufactured in compliance with Directive 2002/95/
EC of the European Parliament and the Council on restriction of the use of certain
hazardous substances in electrical and electronic equipment (RoHS Directive) and is
deemed to comply with the maximum concentration values issued by the European
Technical Adaptation Committee (TAC) as shown below:
Substance Proposed Maximum Concentration Actual Concentration
Lead (Pb) 0,1% < 0,1%
Mercury (Hg) 0,1% < 0,1%
Cadmium (Cd) 0,01% < 0,01%
Hexavalent Chromium (Cr6+) 0,1% < 0,1%
Polybrominated biphenyls (PBB) 0,1% < 0,1%
Polybrominated diphenyl ethers (PBDE) 0,1% < 0,1%
Certain components of products as stated above are exempted under the Annex of the
RoHS Directives as noted below:
Examples of exempted components are:
1.Mercuryincompactuorescentlampsnotexceeding5mgperlampandinotherlamps
notspecicallymentionedintheAnnexofRoHSDirective.
2.Leadinglassofcathoderaytubes,electroniccomponents,uorescenttubes,and
electronic ceramic parts (e.g. piezoelectronic devices).
3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight
or more lead).
4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium
containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead
by weight.

ViewSonic VNB101 v
Copyright Information
Copyright © ViewSonic®Corporation, 2009. All rights reserved.
Microsoft®, Windows®, Windows NT®, and the Windows®logo are registered trademarks of
Microsoft®Corporation in the United States and other countries.
ViewSonic®, the three birds logo, OnView®, ViewMatch™, and ViewMeter®are registered
trademarks of ViewSonic®Corporation.
Intel®, Pentium®, and Atom™ are registered trademarks of Intel Corporation.
Disclaimer: ViewSonic®Corporation shall not be liable for technical or editorial errors or
omissionscontainedherein;norforincidentalorconsequentialdamagesresultingfrom
furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic®Corporation reserves the
righttochangeproductspecicationswithoutnotice.Informationinthisdocumentmay
change without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any
purpose without prior written permission from ViewSonic®Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes
available, please register your product on the Internet at: www.viewsonic.com. The
ViewSonic®Wizard CD-ROM also provides an opportunity for you to print the registration
form, which you may mail or fax to ViewSonic®.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
VNB101
ViewSonic 10" NetBook
VS12638
VNB101-1_UG_ENG Rev. 1B07-22-09
Product disposal at end of product life
The lamp in this product contains mercury. Please dispose of in accordance with local,
state or federal laws.
ViewSonic®is concerned about the preservation of our environment. Please dispose of this
product properly at the end of its useful life. For the recycling information, please refer to
our website:
1. USA: www.viewsonic.com/pdf/RecyclePlus.pdf
2. Europe: www.viewsoniceurope.com
3. Taiwan: recycle.epa.gov.tw

ViewSonic VNB101 vi
Directions
Meanings of icons:
Forbidding: forbid improper operations to avoid damaging the Notebook PC.
Caution: cautions for operators to avoid potential damages. Please note and
remember.
Importance:importantinformation,commonnotes,denitions,generalknowledge
and references, etc.

ViewSonic VNB101
Content
1. Knowing Your Notebook PC............................................................................. 1
1-1 Top Side......................................................................................................... 1
1-2 Right Side....................................................................................................... 2
1-3 Left Side......................................................................................................... 2
1-4 Rear Side ....................................................................................................... 2
1-5 Bottom Side.................................................................................................... 2
2. Caring the Notebook PC.................................................................................... 3
2-1 LCD Screen.................................................................................................... 3
2-2 Hard Disk Drive (HDD)................................................................................... 3
2-3 Battery Pack................................................................................................... 4
2-4 Keyboard........................................................................................................ 4
2-5 Touch Pad...................................................................................................... 4
2-6 Other accessories .......................................................................................... 4
2-7 If the water comes into the Notebook PC ....................................................... 5
2-8 Other Notes.................................................................................................... 5
3. Traveling with the Notebook PC....................................................................... 6
3-1 Attention ......................................................................................................... 6
3-2 How to enter the suspend mode .................................................................... 6
4. Keep the data for future possible use.............................................................. 7
4-1 HDD Partition ................................................................................................. 7
4-2 Class the data in the HDD.............................................................................. 7
5. Getting Started................................................................................................... 8
5-1 Install the Rechargeable Battery .................................................................... 8
5-2 Remove the Battery Pack............................................................................... 8
5-3 Connecting the Power Adapter ...................................................................... 9
6. Using Your Notebook PC ................................................................................ 10
6-1 Turning on the Notebook PC........................................................................ 10
6-2 Adjust the Brightness of LCD Screen........................................................... 10
6-3 Keyboard Usage .......................................................................................... 10
6-4 Touch Pad（Optional, Under Windows XP）.............................................. 11
6-5 Card Reader Usage ..................................................................................... 12
6-6 The Memory Card ........................................................................................ 13
7. Internet Connection......................................................................................... 14
7-1 Connect the Lineate LAN ............................................................................. 14
7-2 Wireless LAN ............................................................................................... 15
8. Bluetooth.......................................................................................................... 16
8-1 Initial Bluetooth Configuration Wizard .......................................................... 16
8-2 Add a Bluetooth Device................................................................................ 17

ViewSonic VNB101
8-3 Establish a connection ................................................................................. 17
8-4 Bluetooth Service Selection ......................................................................... 18
8-5 Terminate a connection................................................................................ 18
9. Power Managing System................................................................................. 19
9-1 Battery System............................................................................................. 19
9-1-1 Checking Battery Power .................................................................... 19
9-1-2 Charging the Battery Pack ................................................................. 20
9-1-3 Low Power Warning........................................................................... 20
9-1-4 Battery Power .................................................................................... 20
9-1-5 Store the Battery Pack ....................................................................... 20
9-1-6 Prolonging the Battery’s Life .............................................................. 21
9-2 Power Management Modes ......................................................................... 21
9-2-1 Standby mode of the System............................................................. 21
9-2-2 Hibernate ........................................................................................... 21
9-2-3 Log Off ............................................................................................... 22
9-2-4 Restart the System ............................................................................ 22
9-3 Power Saving ............................................................................................... 22
9-3-1 Connect the Adapter without using Battery Pack............................... 22
9-3-2 Adjust the brightness of LCD Screen ................................................. 22
10. Upgrading Your Notebook PC ...................................................................... 23
10-1 Connect the External Monitor..................................................................... 23
10-2 How to connect the External Monitor .................................................. 23
10-3 Connect Keyboard and Mouse............................................................ 23
10-4 Connect Audio Device......................................................................... 23
10-5 Lock Port............................................................................................. 23
11 System Recovery Management..................................................................... 24
11-1 One Key for System Recovery ................................................................... 24
11-2 System Recovery CD................................................................................. 25
12 Quick OS.......................................................................................................... 26
12-1 Getting Started ........................................................................................... 26
12-2 System and Device Basics......................................................................... 27
12-3 Using the Tool Bar and Settings................................................................. 28
12-4 Getting on the Internet ............................................................................... 33
12-5 Quick System Recovery ............................................................................. 34
12-3 Enter the BIOS Setup Menu....................................................................... 37
13. Appendix......................................................................................................... 39
13-1 Troubleshooting ......................................................................................... 39
13-2 Specifications ............................................................................................. 41

ViewSonic VNB101 1
1.Knowing Your Notebook PC
1-1 Top Side
1. Built-in Camera
Click Fn+F1 to turn on or off the
camera function.
2. LCD Screen
3. Microphone
4. HDD Status Indicator
Light is green when the HDD is in
active mode.
5. Numeric Keypad Indicator
Click Fn+NumLk to turn on the light
and the numeric keypad is unlocked.
6. Cap Lock Indicator
Light is green when the cap keypad is
unlocked.
7. WiFi Indicator
8. Bluetooth Indicator
9. Power button
10. Keyboard
11. Right-key
12. Left-key
13. Touch Pad
14. Charge Indicator
Light is orange during being charged
and is green when the battery is fully
charged or discharged; light flashes
when the battery is weak.
15. Power Indicator
