ViewSonic NextVision VPW505 User manual

Beautiful images with large-screen impact.
Experience larger-than-life images with the ViewSonic VPW505 50" HD
plasma TV. With a built-in TV tuner this plasma DELIVERS BEAUTIFUL
IMAGES FROM ANY TV SIGNAL, INCLUDING HDTV. ViewSonic’s
XtremeView®ultra-wide viewing angles ensure your entire audience has
a great seat. Built-in speakers, progressive scan, advanced picture-in-
picture, split-screen technology and 3:2 pull down make this plasma TV
IDEAL FOR HOME ENTERTAINMENT. Get ready for the ultimate
viewing experience with the
ViewSonic VPW505
plasma TV.
>Bright and beautiful at any angle
1000 cdm2 brightness (typ) and 1000:1 (typ) contrast ratio ensure
your images are brilliant, vivid and life-like. The flat screen and anti-
glare screen coating eliminate image distortion and reflection for a
stunning picture at any angle.
>Image is everything
Delivers bright, well saturated video images. 1366x768 resolution
shows every detail, making movies, TV and pictures crystal clear.
>Multiple window capability
Picture-in-picture and split-screen capability keep you in control —
allowing you to enjoy a movie while checking your local news or
watching the game.
>Multimedia stereo audio
BBE®sound maximizer delivers surround sound capability and an
audio out connection that allows you to connect your TV to an
external stereo system.
>Improve your view
The anti-glare screen optimizes your viewing experience in virtually
any setting.
>Ready to go out of the box
Includes built-in TV tuner, multiple TV and video inputs and all cables.
View VHF/UHF and CATV or enjoy true HDTV.
>Free 24/7 technical, customer
support and on-site service†
Brilliant wide-screen entertainment.
>
Up to THREE FULL YEARS of coverage!
>
FREE 1-year limited warranty
>
2ND AND 3RD year extended warranty
>
NEW on-site service
2nd and 3rd year extended warranty available for purchase
in U.S. and Canada. A repair technician will be dispatched
to your location within 48 hours* of your call, so you’ll be
up and running again in no time!
VPW505 Plasma TV
50" NextVision® high Definition Plasma TV
The big picture

VPW505 Plasma TV
50" NextVision® high Definition Plasma TV
specifications
3
24
1
Optional Accessories and Services
Tilt Wall Mount PLS-AWM-004
Flush Wall Mount PLS-AWM-005
Ceiling Mount Kit PLS-BUN-001
ATA Shipping Case PLS-HCA-001
Extended Warranty PLS-XTWTY-42HD-02
1. One-touch buttons to control all major functions.
2. RF input for built-in NTSC TV tuner.
3. Component video inputs.
4. Composite and S-video inputs.
Hang it virtually anywhere with the optional wall
or ceiling mount.
For more product information, visit us on the web at ViewSonic.com
*Excluding major U.S. and Canadian holidays. **Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks stat-
ed herein are the property of their respective companies. Copyright © 2004 ViewSonic Corporation. All rights reserved. [11630-00B-01/04] VPW505-1
ViewSonic Corporation •381 Brea Canyon Road, Walnut, CA 91789
Phone [phone] or [phone] •In Canada [phone] •Fax [phone] •[email protected] •ViewSonic.com
50" WIDE-SCREEN PLASMA TV WITH NEXTVISION TECHNOLOGY
PANEL Resolution 1366x768, 1080i, 720p, 480p
Aspect Ratio 16:9
Display Area 43.5" horizontal x 24.5" vertical x 50.0" diagonal
Viewing Angle 160ºhorizontal, 160ºvertical
Brightness 1000 cd/m2(typ)
Contrast Ratio 1000:1
Color Depth 8-bits/color (16.7 million)
CONNECTOR Video Input NTSC TV tuner (RF), S-video, composite signal (RCA jack), YCbCr or YPbPr
signal (component 1 & 2), RGB signal, DVI signal, tuner, RS-232C, RCA jack
(x2), DVI audio interface, stereo mini jack (x2), component video 1 & 2 (stereo
RCA x2), sub woofer input (RCA jack x1), external speaker SW (mini phono
plug for external speaker)
Video Output RGB signal
Audio Output Output RCA jack (x2), speaker (internal connection), L/R 5W + 5W
VIDEO INPUT Frequency Fh: 31~91kHz; Fv: 50~85Hz
COMPATIBILITY PC/Mac®** VGA (expanded), SVGA (native), XGA (expanded), wide XGA
(expanded), SXGA (compressed)
Video NTSC, PAL, SECAM, NTSC 4.43
Scanning Format SDTV: 480i, EDTV: 480p, HDTV: 720p, 1080i
POWER Voltage AC 90–240 VAC +/- 10%
Frequency 50–60 Hz
Consumption 370W (1W in standby)
OPERATING Temperature 23–113°F (0–40°C)
CONDITIONS Humidity 20–80% (non-condensing)
DIMENSIONS Physical 48.0" x 28.9" x 4.3"; 1220mm x 735mm x 110mm (display only)
(W X H X D) 48.0" x 30.7" x 11.4"; 1220mm x 780mm x 290mm (including display stand)
WEIGHT Net 92.6 lb. (35.0 kg) w/out stand; 77.2 lb. (35.0 kg) w/ stand
Gross 121.2 lb. (55.0 kg)
REGULATIONS UL, cUL, CE, EMC Report, CB, TUV/GS, CCIB/CCEE, FCC-B, CSA
ACCESSORIES Power cord 3m, remote control, AA battery (x2), RGB cable 3m,
INCLUDED DVI cable, RCA video audio cable 3m, S-video cable, RCA component, cable,
ViewSonic Wizard, Quick Start Guide and plasma stand
WARRANTY One-year limited parts and labor. Extended warranty available. On-site service
available in U.S. and Canada.†
ViewSonic Corporation’s QMS & EMS have been registered to
ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
