VIGAS 16 Quick guide

Gasifying boiler VIGAS
Gasifying boilers
MANUAL FOR INSTALLATION, ASSEMBLY,
MAINTENANCE AN USE
Warranty Certificate
1
VIMAR 2013
VIGAS and VIGAS Lambda Control
with AK 4000 control

Gasifying boiler Vigas
Content
Declaration of conformity...................................................................................................................
1. Technical description...................................................................................................................
2. Technical data..............................................................................................................................
3. AK 4000 control description.........................................................................................................
4. VI AS boiler - basic configuration...............................................................................................
5. VI AS boiler - discharge fan confirguration................................................................................
6. VI AS Lambda Control – basic configuration.......................................................................................
7. Kotol VI AS Lambda Control - discharge fan configuration................................................................
8. Temperature setting.....................................................................................................................
9. Parametres setting.......................................................................................................................
10. Time set-up..................................................................................................................................
11. Harware and software information................................................................................. .............
12. Error notification...........................................................................................................................
13. Configuration setting using PIN 0000..........................................................................................
14. Operating instructions..................................................................................................................
15. Boiler maintenance and repairs...................................................................................................
16. Boiler accessories and assembly.................................................................................................
17. Service departments....................................................................................................................
18. Problems, cause and solution.....................................................................................................
19. Installation instruction..................................................................................................................
Electric scheme ..........................................................................................................................
VI AS Warranty certificate..........................................................................................................
VI AS Commisssion certificate ..................................................................................................
Page
3
4
5
7
9
10
11
13
14
15
16
16
16
17
22
24
26
27
28
30
32
33
33
2

Gasifying boiler VIGAS
ECLARATION OF CONFORMITY
Issued according to § 12 sec. 3 let. a) Act. No. 264/1999 Coll
a 97 / 23 EC
We, Pavel Vigaš - VIMAR,
hereby declare, that the undermentioned products comply with technical regulations and the products are
safe if determined conditions are followed and we took all possible measures to aasure the compliance of
producst with technical documentation, as well as, relevant instruction requirements og government. The
validity of this statement is abolished when an unauthorized changes are made without permission of
VIMAR.
Product: Thermal boiler VIGAS a VIGAS Lambda Control with AK4000 control
Type: VI AS 16, VI AS 16 Lambda Control , VI AS 25, VI AS 25 Lambda Control
VI AS 40, VI AS 40 Lambda Control , VI AS 60, VI AS 60 Lambda Control
VI AS 80, VI AS 80 Lambda Control , VI AS 100, VI AS 100 Lambda Control
VI AS 29 UD
Producer: Pavel Vigaš - VIMAR
M. Čulena 25, 974 11 Banská Bystrica,
SLOVAKIA
Competent statutory codes (CSC)
CSC no. 576/2002 C.s. – Pressure Equipment Directive (97/23/EC)
CSC no. 308/2004 C.s. – Low voltage electric devices (2006/95/ES)
CSC no. 194/2005 C.s. – Electromagnetic Compatibility Directive (2004/108/EC)
Used harmonized standards for CE marking
STN EN 303-5: 2012; STN EN 60335-1: 2012; STN EN 60335-2-102 : 2007
STN EN 61000-6-3: 2007; STN EN 55014-1: 2007; STN EN 61000-3-2: 2006
STN EN 61000-3-3: 2009; STN EN 61000-6-2: 2006
Additional data: Certificates
Design examination Certificate No.812990017, No. 812990016, Certificate
No.0021/104/2/2010, Certificate No. 0023/104/2/2010, Certificate No. 0029/104/2/2009,
Certificate No. 812990019, Certificate No. 101299028
CE marking was proceed according to § 12, par. 3 letter a) Act. No. 264/1999 Coll.
Issued in: Banská Bystrica Name: VI AŠ Pavel
ate of issue: 1.4.2013
3
M. Čulena 25
974 11 Banská Bystrica
SLOVAKIA
VAT no. SK1020548001
Reg. No. 17956145
1299

Gasifying boiler Vigas
Title:
Owner
Signature:
1. TECHNICAL ESCRIPTION
Thermal boilers VI AS are designed for combustion of dry wood materials, using sawdust to wood logs
according to the dimension of gasification chamber, with maximum diameter of 20 cm. Sawdust,
woodchips, splinters and cuttings must be burn together with wood logs. Thermal boiler VI AS 29 UD is
designed to burn brown coal. It is possible to use dry wooden material as a substitute fuel.
Boilers are welded from 4 – 6 mm steel sheets. Inner boiler sheets, which are in contact with boiler waste
gases are 6 mm thick, others are made of 4 mm steel.
Heat exchanger is welded from steel pipes, 57x4,5 mm. Exterior boiler panels are made of 0,8 mm sheet.
Thermal insulation of the boiler is made of isolation material, NOBASIL 20 and 50 mm thickness.
Combustion gases are lead through steel boiler neck to the chimney.
The boiler space consists of combustion chamber, where fuel is dried and gasified. Then accrued gas gets
through fireproof /concrete, cast iron / nozzle into combustion chamber, where it burns with help of
secondary air. Flue gases are intensively cooled in the exchanger. Unburned waste must be removed from
combustion chamber. The boiler has a light up damper controlled by rod at the front of the boiler.
In order, the boiler complies with the requirements for non-demanding operation it is equiped with AK4000
control located on the top panel of the boiler. Designed system allows very effective combustion of various
kinds of fuel. Control AK4000 with graphical display in basic configuration allows :
to control temperature of heated water in range 70 - 85°C
continuous and automatic control of fan according to required output and kind of fuel
connnect and control discharge fan
connect and cotrol circulation pump
to connect gases thermometer
connect room thermostat (room temperature regulator is voltage free )
to connect extended regulation (Expander AK 4000) via BH BUS
to connect module AK 4000M data back-up, followed by PC evaluation
graphical scheme indicating hydraulic boiler connection as requested
real time set
Configuration VI AS Lambda Control offers :
to control the servo flap of primary and secondary air based on data received from lambda sensor
oxygen level reading
during power cut, AA battery types will close servo-operated flap and prevent boiler from natural
burning of boiler without chimney draught
The boilers are equipped with thermal fuse STB, which ensures disconnection of the boiler fan, if
overheated above 100°C and exchanger safety to prevent boiler against overheating by standards, STN
EN 303-5: 2012. Producer recommends to purchase safety valve TS 131 ¾“ and install to exchanger to
avoid overheating.
4

Gasifying boiler VIGAS
5

Gasifying boiler Vigas
2. TECHNICAL ATA Chart.1
THERMAL BOILERS
VIGAS 16 16
LC 25 25 LC 40 40 LC 60 60 LC 80 80 LC 100 100 LC U 29
Nominal boiler output kW 16 25 40 60 80 100 29
Boiler class acc. to EN 303-5: 2012 3 5 3 3 3 5 3 5 3 5 3 5 3
Max. operating pressure bar 3
Fuel Wood, max. moisture 20% of heat value min. 15 MJ/kg Brown coal
Output capacity kW 12 - 18 5 - 31 8 - 41 15 - 72 25 - 92 25-100 8-35(8-29)*
Fuel consumption with
nominal output kg/hrs. 4,5 7,6 11,2 19 25 30,4 7,8 (8,0)*
Alternative fuel wood waste, wood chips, sawdust, sawdust briquettes,
(for UD 29 also wood, max. moisture 20%)
Chimney draught mBar 0,20 – 0,25 0,20 – 0,35 0,30 – 0,40 0,20 – 0,25
Weight kg 400 430 460 760 930 950 430
Height with control A mm 1135 1385 1420 1120
Height of outlet branch B mm 975 1045 1310 1400 1045
Height of inlet branch C mm 115 125 215 110
Height of water-feed valve D mm 55 60 70 135 55
Height of chimney outlet E mm 890 1110 1170 890
Width including rod F mm 645 785 645
Width including panels mm 590 760 590
Depth H mm 840 1070 1260 1650 1070
Exhaust brand I mm 240 520 240
Diameter of chimney outlet J mm 160 200 160
Depth from edge K mm 188 305 880 1210 230
Spacing of insert L mm 405 70 350
Diameter of inlet brand 2“
Diameter of outlet brand 2“
Diameter of water-feed valve ½“ ¾“ ½“
Water volume l 60 75 93 180 205 215 75
ases temperature:
Nominal output
Minimum output
°C
°C
240
150
asification chamber
dimension - Depth mm 370 560 750 1150 1090 490/440
Height mm 490 750 730 500
Width mm 440 575 440
asification chamber
dimension (w-h) mm 435 -255 575 – 318 435 - 255
Max. fuel weight kg 20 30 40 80 150 30
Capacity of chamber dm380 120 185 315 483 457 105
Noisiness dB 45 45,5 47,7 51,4 54,2 45,5
Max. electric input W 70 140 70
Voltage/ frequency V/Hz 230ACV / 50 Hz
Pressure loss of water :
t 10 0C
t 20 0C
mBar
mBar
9,70
1,00
9,75
1,05
10,48
2,55
12,77
3,19
11,83
2,96
11,53
2,84
9,97
1,15
Nominal out burning time hours 4,5 4,20 4,30 4,20 4,20 4,0 5,60 (4,10)
Heat Exchanger
- inlet water temperature
- inlet water pressure
°C
bar 4 – 15
min 1 – max 4
Safety Drain valve for heat exchanger HONEYWELL TS 131 ¾”
Opening temperature 95 °C
STB fuse, blow temperature 100oC (tolerance: -6 °C - 0 °C)
Weight flow of gases kg/s 0,034 – 0,047
* specification for wood fuels
6

Gasifying boiler VIGAS
2.1 IMENSION CHART AN THE POSITION OF SAFETY PLATE TO PROTECT EASILY
INFLAMMABLE FLOOR
2.2 BOILER SCHEMATICS
7
LEGEN
1. Control AK4000
2. Upper door
3. Chimney flap operating rod
4. Chamber area
5. Primary air conduction
6. Flap for servo Belimo
7. Fan
8. Fan cover
9. Nozzle
10. Secondary air flap
11. Handle
12. Fireclay bricks
13. Bottom door
14. Chimney output
15. Exchanger cover
16. Light up flap
17. Upper back panel
18. Water outlet
19. Thermal fuse
20. Thermometer
21. Upper front panel
22. Lambda sonda
23. ases thermometer
24. Exchanger pipes
25. Heat proof/concrete filling
26. Secondary air
27. Combustion chamber
28. ases direction
29. Reverse water leak
30. Filling leak
31. Cleaning flap for 29UD
32. Cleaning slot for 29UD
Schema VIGAS 60,80
Schema VIGAS 25 Schema VIGAS 40
Schema VIGAS 100
Schema VIGAS 16
Schema VIGAS 29 U
Pic. 3
Inlet
brand for
drain
valve
Hole for drown valve insert
Outlet brand of cooling water
¾“

Gasifying boiler Vigas
3. ESCRIPTION OF AK4000 CONTROL
3.1 SAFETY INSTRUCTIONS
Please check the cover panels protection before you plug-in the line connector
Avoid any contact of line connector with boiler hot parts (e.g. smoke flue).
Make sure, that upper isolation under the panel remains dry ( risk of short circuit)
Do not stress the line connector.
Always disconnect the line connector when a new electrical components are being connected to the
boiler (e.i. indoor room thermostat, discharge fan, circulation pump)
Do not remove protection (cover panels) when boiler in operating process, especially not fan cover
panel.
Check if voltage displayed on the label is same as your distribution network.
Always keep to the terms of use.
3.2 CONNECTION TO THE POWER SUPPLY
Control AK 4000 is integral part of VI AS boilers.
Control is connected when line connector is plugged into the power supply 220/230V. Display with basic
image is active when connector line is plugged-in (pic.4). Servo-flap used in VI AS Lambda Control is set to
basic position (pic.5).
3.3 SERVICE CON ITIONS
Control AK4000 is designed for operation temperature area from +5 up to +45 C. Control can not be used
in moisty environment or direct sunlight.
3.4 MAINTENANCE AK4000 CONTROL
Keep in clean and dust free environment. Antistatic or wet wipes are recommended to wipe-off dust and
impurities from metal covers and control panel.
3.5 CONTROL PANEL
The part of this electronic control is panel equipped with buttons, pictograms and display. Further
information will be available in the next steps of this manual. The operating system of each button is
compound and it depends on the text description on display and particular boiler configuration set up by
manufacturer.
8
pic.6
Pic.5
1. raphic display 128 x 64 pix.
2. Button ◄ with functions, ENTER
3. Button▲ with functions
4. Button ► with functions, EXIT (ESC)
5. Button (ENTER) with functions
6. LED control (green - OK, red - ERROR)
7. Button switch functions
Pic.4
pic.7
Graphic information Coding line information (chap.13.5)

Gasifying boiler VIGAS
3.6 SYMBOLY
9
1. Real time indication
2. Coding line – indication of current boiler figures
Modification ▲ or
3. Indication of discharge fan, lambda sensor,
gases thermometer
4. Indication of nominal output when boiler is
switched off.
Boiler Accumulator
tank External boiler
Boiler „ON“ ON DUOMIX Heating Circuit
Boiler „OFF“ OFF Valve with
servomotor
Indoor
thermostat
Flame up ON Pump
3-way
thermostatic
valve
Burning 73 0CDischarge fan LADOMAT
Afterflaming 52 0CLambda Fan
End of burning EN Thermometer TFan change
output
External
thermometer Floor heating
Indoor
thermostat
decay
Indication figure
error xServo-flap position servo 50%
Add fuel Min. exhaust
gas figures min Max. exhaust gas figures max
Temperature
set up
Parameters
set up Time set up
Error
notifications Programm Configuration data
Servise set ups Memory modul Motion
regulation
Schemas
option Installation data Indication option
5. raphic indication of hydraulic connection
schema.
6. Boiler status indication
7. Battery condition (2 units type AA) used to
close servo-flap (only VI AS Lambda Control)
8. Symbols
9. Set figures
10. Current figures

Gasifying boiler Vigas
4. VIGAS BOILER IN BASIC CONFIGURATION
The advantage of exhaust gas thermometer is control of maximum exhaust gas temperature and when
reached by boiler, fan will lower engine RPM. This results in higher boiler effectivity and lower fuel
consumption. If installed with accumulator tank, thermometer will shut down boiler when fuel is burned
down. The water temperature inside boiler and accumulator tank has no influence on boiler shut down.
4.1 VIGAS BOILER CONTROL
4.1.1 Boiler activation
4.1.2 Boiler active – heating phase
4.1.3 Boiler active – burning phase
4.1.4 Add fuel, boiler switch - off (manual control)
10
By pressing „ “ fan will be switched off. Using the rod open chimney
flap, consequently open the upper door. You can add fuel if necessary.
After done with reloading close the upper door and chimney flap
(pic.12.4). By pressing „ “ fuel addition will be ended. Fan will be
switched on automatically.
In heating phase boiler gas exhaust temperature is lower then set up
minimum exhaust gas temperature. Minimum and maximum temperature
can be modified in boiler parameters set up. Minimum standard exhaust
gas temperature is set up to 50 °C and maximum set up temperature is
at 220 °C. The pump works in pulsating wave during flame up,
depending on the boiler water temperature.
If the boiler is in switch-off phase, with symbol „OFF“ on the display, to
retrieve start press short middle button „ENTER“.
The burning phase is active, when the exhaust gas temperature is
( end) +20 °C. The pump works in pulsating wave in this phase. If
pump symbol is flashing, pump works. Boiler is responsive to the indoor
thermostat, when indoor thermostat is switched off, boiler output is slowly
reduced.
Choose one option
OFF Switch off
Add boiler
Cancel display driver
▲Change indicated figure
raphic control is used for this operation. To activate display driver press
short middle button „ENTER“. raphic control offers option to: switch-off
boiler, add fuel or cancel display driver.

Gasifying boiler VIGAS
Choose one option
+60 To start discharge fan for 60 s (use with flame up phase)
ON Switch on
Cancel display driver
▲Change indicated figure
Select „+60“ new graphic drive will appear. Running time of discharge
fan is located in the left upper corner of the display.
+60 You can add extra 60 s - maximum 300 s
ON Switch on
0Discharge fan switched-off
▲Change indicated figure
4.1.5 Boiler shut down (automatic)
5. VIGAS BOILER IN CONFIGURATION WITH ISCHARGE
FAN (without lambda sensor)
The advantage of discharge fan installation is increased comfort during boiler flame up and fuel addition.
Discharge fan significantly helps to reduce smoke in area during fuel feed. In flame-up phase helps to
create quickly heated fuel layer.
5.1 VIGAS BOILER CONTROL
5.1.1 Boiler activation
5.1.2 Boiler active – heating phase
11
When exhaust gas temperature drops under the set up temperature (
end),the boiler is automatically switched-off. Sign „END“ will be
indicated on the display. By pressing 2 times „ENTER“ button boiler will
start working again.
If the boiler is in switch-off phase, with symbol „OFF“ on the display, to
retrieve start press short middle „ENTER button.
By pressing „ON“ discharge fan will be switched-off and boiler will go to
flame-up phase. In flame up phase boiler exhaust gas temperature is
lower then set up minimum exhaust gas temperature. Minimum and
maximum temperature can be modified in boiler parameters set up.
Minimum standard exhaust gas temperature is set up to 50 °C and
maximum set up temperature is at 220 °C. The pump works in pulsating
wave during flame-up, depending on the boiler water temperature.

Gasifying boiler Vigas
5.1.3 Boiler active – burning phase
5.1.4 Add fuel, boiler switch-off (manual control)
5.1.5 Boiler shut down (automatic)
6. BOILER VIGAS Lambda Control IN BASIC CONFIGURATION
Boiler VI AS Lambda Control operates with information about oxygen overflow in exhaust gas received from
lambda sensor to control the flap of primary and secondary air. This system allows to burn all kinds of
wood more efficiently and at the same time decrease the fuel consumption by 20-25 %.
12
The burning phase is active, when the exhaust gas temperature is
( end) +20 °C. The pump is pulsating in this phase. If pump symbol
is flashing, pump works. Boiler is responsive to the indoor thermostat,
when indoor thermostat is switched off, boiler output is slowly reduced.
Choose one option
OFF Switch off
Add fuel
Cancel display driver
▲Change indicated figure
By pressing „ “ boiler fan will be switched-off and discharge fan will be
switched-on for 300 s. The time is indicated in the upeer left corner of the
display. By pressing button „+60“ is possible to extend discharge fan running
time. Using the rod, open chimney flap, consequently open the upper
door. You can add fuel if necessary.
After reloading the fuel close the upper door and chimney flap
(pic.12.4). By pressing „0“ discharge fan will be switched off, boiler fan will
start working automatically.
When exhaust gas temperature drops under the set up temperature (
end), the boiler is automatically switched-off. Sign „END“ will be indicated
on the display. By pressing 2 times button „ENTER“, boiler will start working
again.
raphic control is used for this operation. To activate display driver press
short middle „ENTER“ button. raphic control offers option to: switch-off
boiler, add fuel or cancel display driver.

Gasifying boiler VIGAS
Servo-controlled flap will move to open position (servo 100%) when
„ENTER“ button is pressed. Consequently, with next steps ( 100% up to
45%) flap is moved to retain value of lambda sensor ( 1,35). In position
(servo 45%) secondary air is closed, in position (0 %) primary air is also
closed. The flap will move to position 0% only when boiler is „OFF“ or
„END“ phase.
In heating phase boiler gas exhaust temperature is lower then set up
minimum exhaust gas temperature. Minimum and maximum temperature
can be modified in boiler parameters set up. Minimum standard exhaust
gas temperature is set up to 50 °C and maximum set up temperature is at
220 °C. The pump works in pulsating wave during flame-up, depending
on the boiler water temperature.
6.1 VIGAS Lambda Control BOILER CONTROL
6.1.1 Boiler activation
6.1.2 Boiler active – heating phase
6.1.3 Boiler active – burning phase
6.1.4 Add fuel, boiler switch-off (manual control)
13
If the boiler is in switched-off phase, with symbol „OFF“ on the display, to
retrieve start press short middle „ENTER“button.
The burning phase is active, when exhaust gas temperature is ( end)
+20 °C. The servo-controlled flaps works same as in heating phase.
Pump works in pulsating wave (boiler safety against low-temperature
corrosion). If pump symbol is flashing, pump works.
Choose one option
OFF Switch off
Add fuel
Cancel display driver
▲Change indicated figure
By pressing „ “ boiler fan is switched off. Open chimney flap a upper
door. Add necessary fuel. After that, close upper door and chimney flap.
By pressing „ “ finish fuel refilling and fan will be switched on. During fuel
refilling, servo-controlled flap retains in the same position, as before fuel
adding. When fuel refilling is finished, flap moves to the position (servo
100%). Consequently, with next steps (100% up to 45%) flap is moved to
retain value of lambda sensor ( 1,35). In position (servo 45%) secondary
air is closed, in position (0 %) primary air is also closed. The flap will
move to position 0% only when boiler is „OFF“ or „END“ phase.
raphic control is used for this operation. To activate display driver press
short middle button ENTER. raphic control offers option: switch-off
boiler, add fuel or cancel display driver.
.

Gasifying boiler Vigas
Choose one option
+60 Start up of discharge fan for 60 s (recommended to use with
heating phase)
ON Switch on
Cancel display driver
 Change indicated figure
Select „+60“ new graphic drive will appear. Running time of
discharge fan is located in the left upper corner od the display.
+60 You can add extra 60 s - maximum 300 s
ON Switch on
0Discharge fan turn-off
▲Change indicated figure
+60 Môžete pridať ďalších 60 s - maximálne do 300 s
6.1.5. Boiler shut down (automatic)
7. VIGAS Lambda Control BOILER IN CONFIGURATION
WITH ISCHARGE FAN
Boiler VI AS Lambda Control operates with information about oxygen overflow in exhaust gas received from
lambda sensor to control the flap of primary and secondary air. This system allows to burn all kinds of
wood more efficiently and at the same time decrease the fuel consumption by 20-25 %.
7.1 VIGAS Lambda Control BOILER CONTROL
7.1.1 Boiler activation
7.1.2 Boiler activated – heating phase
14
If the boiler is in switched-off phase, with symbol „OFF“ on the display,
to retrieve start, press short middle button „ENTER“.
By pressing „ON“ button servo-controleed flap will move to open
position (servo 100 %). Consequently with next steps (from 100 % up
to 45 %) pohybuje tak, aby sa hodnota lambdy udržala blízko
nastavenej hodnoty ( 1,35). flap is moved to retain value of lambda
sensor ( 1,35). In position (servo 45%) secondary air is closed, in
position (0 %) primary air is also closed. The flap will move to position
0% only when boile is „OFF“ or „END“ phase.
In heating phase boiler gas exhaust temperature is lower then set up
minimum exhaust gas temperature. Minimum and maximum
temperature can be modified in boiler parameters set up. Minimum
standard exhaust gas temperature is set up to 50 °C and maximum set
up temperature is at 220 °C. The pump works in pulsating wave
during flame up, depending on the boiler the water temperature.
When exhaust gas temperature drops under the set up temperature (
end), the boiler is automatically switched-off. Sign „END“ will be indicated
on the display. By pressing 2 times button „ENTER“ boiler will start
working again.

Gasifying boiler VIGAS
7.1.3 Boiler activated – burning phase
7.1.4 Add fuel, boiler switch-off (manual control)
7.1.5.Boiler shut down (automatic)
8. TEMPERATURE SET UP
15
The burning phase is active, when the exhaust gas temperature is (
end) +20 °C. The servo-controlled flaps works same as in heating phase.
Pump works on pulsating wave (boiler safety against low-temperature
corrosion). If pump symbol is flashing, pump works.
Choose one option
OFF Switch off
Add fuel
Cancel display driver
▲Change indicated figure
By pressing „ “ boiler fan will be switched-off and discharge fan will be
switched-on for 300 s. The time is indicated in the upper left corner of the
display. By pressing button „+60“ is possible to extend discharge fan
running time. Using the rod open chimney flap, consequently open the
upper door. You can add fuel if necessary.
When finished with fuel refilling, close the upper door and chimney flap.
By pressing „0“ discharge fan will be switched off. By pressing „0“
discharge fan will be switched off. By pressing „ “ fuel refilling is finished,
automatically discharge fan is switched off and boiler fan is switched on.
During fuel refilling servo-controlled flap retains in position, as before fuel
refill. After fuel refilling is finished, the flap moves to position (servo
100%). Consequently, with next steps (100% up to 45%) flap is moved to
retain value of lambda sensor ( 1,35). In position (servo 45%) secondary
air is closed, in position (0 %) primary air is also closed. The flap will
move to position 0% only when boiler is „OFF“ or „END“ phase.
When exhaust gas temperature drops under the set temperature( end)
boiler is switched off automatically. Symbol „END“ will appear on the
display. Servo-controlled flap will move to position ( servo 0 %). In this
position primary and secondary air are closed. By pressing 2 times
„ENTER“ button, the boiler will start working again.
raphic control is used for this operation. To activate display driver press
short middle button ENTER. raphic control offers option: switch-off
boiler, add fuel or cancel display driver.
By pressing „ENTER“ button for 2 seconds temperature set up can be change in any phase of the boiler.
In the basic configuration of the boiler (without EXPANDER AK4000), it is only possible to set up heating
temperature. Temperature scale is between 70 0C up to 85 0C.
2 sec.

Gasifying boiler Vigas
9. PARAMETERS SET UP
9.1 MAXIMUM EXHAUST GAS TEMPERATURE SET UP
9.2 EXHAUST GAS TEMPERATURE SET OFF
9.3 LAMB A VALUE SET UP
9.3 FAN OUTPUT SET UP
9.4 FAN MINIMUM OUTPUT SET UP
9.5 ISPLAY INTENSITY SET UP
16
By pressing „ENTER“ button for 2 seconds parametres set up can be change in any boiler operating
phase and by pressing ▲ button. Parametres set up depends on the type of boiler and configuration.
max
Select maximum exhaust gas temperature, which will
result in decreasing fan speed. It is possible to set up
temperature in between 130°C up to 320°C.
Temperature set up depends on quality of fuel and
chimney draught. Recommended value is 220°C.
By pressing ▲ choose parameter to change and by pressing „ENTER“ figure starts flashing. By pressing ▲ choose
required parameter and confirm by pressing „ENTER“.
end
Select exhaust temperature which results in automatic
boiler switch off and pump shut down. It is possible to
set up temperature in between 20 °C up to 130 °C.By
selected temperature it is possible to control the size
of fire base for next heating phase. Recommended
value is 50°C.

Lambda value specifies oxygen surplus in exhaust
gas. Recommended value is 1.35, which is about 6%
of O2. It is possible to set up this value from 1,2 up to
1,5. By increasing value of O2 in the exhaust gas, the
boiler efficiency will decrease, as well as, emmissions.
By increasing or decreasing the value can be changed
nominal boiler output. It is possible to change the
value from -3 to +3. One degree represents about 10%
of boiler output. During low heating season it is
advised to decrease this value.
min
Increasing will change value of minimum fan speed.
Value can be selected between 0% up to 70%. After
reaching set up value fan will be switched off.
Choose value of display intensity. Select value
between 0 up to 100.
2 sec.

Gasifying boiler VIGAS
9.6 ISPLAY CONTRAST SET UP
9.7 SCROLLING MENU SET UP
10. TIME SET UP
11. HAR WARE AN SOFTWARE INFORMATION
12. ERROR NOTIFICATIONS
17
By pressing „ENTER“ button, values start flashing. Pressing ▲ choose
correct time and date. Mon – Moday, Tue – Tuesday, Wed – Wednesday,
Thu – Thursday, Fri – Friday, Sat – Saturday, Sun – Sunday.
Warning : Due to electricity power cut clock will stop.
To retrieve information setting hold „ENTER“ button at any boiler phase and press button . Confirm by pressing
„ENTER“. Use buttons ▲ to choose modul and confirm by „ENTER“. Information about modul will be indicated on
the display. AK4000D – Display, AK4000S – Power board unit, AK4000L – Lambda board modul.
To recall error notification hold „ENTER“ button at any boiler phase and by pressing button twice. By
pressing „ENTER“, error with description will be indicated on the display.
Choose value of display contrast. Select value
between 18 up to 34.
Roll
By choosing „yes“ line on the display (pic.7) option
will show actual boiler values, for example : fan speed,
boiler temperature, exhaust gas temperature, etc. By
choosing „no“ data, option line can be selected with
buttons ▲.
Set up time and date when boiler is first time plugged in. Time is indicated in the upper left corner of the
display. To retrieve parametres setting press longer „ENTER“ at any boiler phase and press ▲ button
twice.
2 sec.
2 sec
2 sec.

Gasifying boiler Vigas
STB
12.1 STB failure
13. SERVICE SETTINGS PIN 0000 PROTECTE
13.1 SERVICE SETTINGS
13.1.1 Boiler type setting
13.1.2 Lambda sensor setting
18
Service settings under password - PIN 0000 can be used only in unavoidable cases. Only trained service
engineer can do the setting (can be done by customer on special occasion). In servise settings can be
selected boiler type with accessories and hydraulic connection scheme, etc. To retrieve the service setting
under the password „PIN 0000“ press hold „ENTER“ button at boiler phase, press ▲button and hold
button ◄ for 4 s. „PIN 0000“ will apear. Press „ENTER“ button 4 times. Service setting symbol will appear
on the display. Press „ENTER“ and by choosing buttons ▲ select service operation.
No error condition: reen LED indicator
Error : Red LED indicator
Error notifications and solutions are described in chapter 18.“
PROBLEMS, CAUSE AND SOLUTIONS“
„STB“ failure is caused by overheating the boiler.
Thermal fuse is activated (see pic.). The fan is
disconnected from power supply. Boiler is again
activated only if „STB“ is reset manually, when boiler
temperature is under 60 °C. To switch on the boiler
press „ENTER“ button, again.
2 sec.
4s 4x
ATTENTION!
Control display unit of the boiler AK4000 is used to operate all types of
VI AS boilers. It is important that display figure is same as boiler type.
When boiler in „OFF“ regime the display shows type of boiler, which is
compliant with its nominal output. For correct boiler operation type of
the boiler must be always the same as type indicated on the
production sticker label. Always check, in case the display AK4000
is replaced!!!
Choose boiler type. Type of the boiler must be identical
with boiler type indicated on the production sticker label.
Marking: V25 - boiler output TVZ – hotair boiler, UD –
wood-coal, DP – wood-pellets, L – Lambda control.

It is possible to deactivate lambda sensor from
operation if error occurs. In such case it is possible to
run boiler in standard version untill lambda sensor is
replaced.
yes – boiler with lambda sensor, no – boiler without
lambda sensor

Gasifying boiler VIGAS
13.1.3 Exhaust gas thermometer settings
13.1.4 ischarge fan settings
13.1.4 Maximum chimney temperature settings
13.1.5 Frequency power supply set up
13.1.6 Temperature unit setting
13.1.7 Summer time setting
13.2 MO UL AK 4000M SETTINGS
19
In necessary cases it is possible to connect AK4000 control to modul AK4000M (pic.8). This modul
allows to provide upgrades and back-up data maintenance of the boiler control unit. Modul is equipped
with data - in line with possibility to connect to BH BUS power board.
In case of exhaust gas thermometer error it is possible
to disconnect thermometer from operation. It is possible
to operate boiler untill replaced as a standard model.
Exhaust gas thermometer will not be used. To
deactivated boiler use boiler thermometer, yes – boiler
with thermometer, no – boiler without thermometer.
Discharge fan is an accessory that can be used with
boiler. After connecting to the boiler and into the control
AK4000, it is necessary to choose option „yes“.
yes – boiler with discharge fan, no – boiler without
discharge fan.
MaxT
Maximum chimney temperature setting can be
selected between 75 °C up to 90 °C. Highest value is
used for boiler setting with accumulator tank.
Frequency power supply setting. It is 50 Hz for EU
residents and 60 Hz for USA and Canada residents. If
you are not aware of power supply frequency choose
AUTO. Incorrect frequency can cause clock error.
Temper.
unit
Temperature unit set up. Allows to select °C or F -
Fahrenheit.
Summer

Allows to set up automatic change of clock to summer
time.

Gasifying boiler Vigas
13.3 FUNCTION SERVICE CONTROL
13.4 HY RAULIC SCHEME BOILER SETTING
13.4.1 BASIC CONNECTION SCHEMES
20
By changing hydraulic scheme connection will be changed also control of pump output and boiler configuration.
Therefore, it is very important that software setting of hydraulic schema is identical with existing boiler installation in
central heating system. In the basic memory of control unit are 4 basic schemas and schemas intended for operating
with Expander AK4000E. On demand, it is possible to add Expander schemas via AK4000M modul (pic.8). Updated
schemas for Expander AK4000E can be found on www.vigas.eu
obr.8
config
To load new configuration (connection schema).
Mainly used for systems controlled by EXPANDER
AK4000E, where it is possible to load personal
connection schema.
config
Actual configuration back-up. It is used for boiler
monitoring. It is advised to perform before monitoring.
firmware To load firmware (boiler operating software).
Erase To delete information from modul AK4000M.
mon
Boiler monitoring, to file basic information of the boiler
into memory modul.
AK4000S To load firmware in to the power board AK4000S.
AK4000L To load firmware into the lambda power board
AK4000.
In service settings can be checked function of each boiler components according to the symbols indicated
on the display. By selecting component and pressing „ENTER“ button function will be activated. Displayed
components depend on the boiler configuration.
2x
3x
Using ▲ buttons,
choose required scheme
and press „ENTER“.
Schema 1 is designed for boiler with accumulators tank. „LADOMAT“
provides reverse water protection. Pump is connected to the boiler control
and works continuously at temperature over 40°. Requested temperature
is possible to set up to 85° (chap.13.1.4). T3 input on power board
AK4000S is used to connect thermometer KTY to measure temperature in
accumulator.
Attention: Schema 1 does not allow to connect T3 – indoor thermostat!
Schema 2 is designed for central heating systems, where reverse water
protection provides external control system. Pump is connected to the
boiler control unit and works in pulsating wave depending on the boiler
water temperature. T3 contact on power board AK4000S is used to
connect indoor thermostat.
