Viking Installation Guide
Side-By-Side &
Bottom-Mount Refrigerator/Free er
UL
C
UL

IMPORTANT–Please Read and Follow!
3
2
Table of Contents
Your safety and the safety of others is
very important.
We have provided many important safety
messages in this manual and on your
appliance. Always read and obey all
safety messages.
This is the safety alert symbol. This
symbol alerts you to hazards that
can kill or hurt you and others.
All safety messages will be preceded by the
safety alert symbol and the word“DANGER”
or “WARNING.” These words mean:
D A N G E R
You will be killed or seriously injured if
you don’t follow instructions.
WARNING
You can be killed or seriously injured if
you don’t follow instructions.
All safety messages will identify the
hazard, tell you how to reduce the chance
of injury, and tell you what can happen if
the instructions are not followed.
Warnings & Important Information_____________________________________________________ 3
Professional & Professional Integrated Side-by-Side
Dimensions & Specifications (Professional 42” & 48”) ________________________________ 6
Dimensions & Specifications (Professional Integrated 42” & 48”) _______________________8
Cutout Dimensions (42”) _________________________________________________________10
Anti-Tip Dimensions (42”) ________________________________________________________11
Cutout Dimensions (48”)_________________________________________________________ 12
Anti-Tip Dimensions (48”)________________________________________________________ 13
Professional & Professional Integrated Bottom-Mount
Dimensions & Specifications (36”)_________________________________________________ 14
Cutout Dimensions (36”)_________________________________________________________ 16
Anti-Tip Dimensions (36”)________________________________________________________ 17
Cabinet Information (Professional) ____________________________________________________ 18
Cabinet Information (Professional Integrated) __________________________________________ 20
Designer Side-by-Side
Dimensions & Specifications (42” & 48”)___________________________________________ 22
Cutout Dimensions (42”)_________________________________________________________ 24
Anti-Tip Dimensions (42”)________________________________________________________ 25
Cutout Dimensions (48”)_________________________________________________________ 26
Anti-Tip Dimensions (48”)________________________________________________________ 27
Designer Bottom-Mount
Dimensions & Specifications (36”)_________________________________________________ 28
Cutout Dimensions (36”)_________________________________________________________ 30
Anti-Tip Dimensions (36”)________________________________________________________ 31
Cabinet Information (Designer)_______________________________________________________ 32
Custom Side Panel Dimensions (Professional) __________________________________________ 34
Custom Side Panel Dimensions (Designer & Professional Integrated) _____________________ 35
General Information ________________________________________________________________ 36
Unpacking & Moving _______________________________________________________________ 38
Installation_________________________________________________________________________ 39
Hinge Adjustment ______________________________________________________________ 40
Kickplate Installation ____________________________________________________________ 42
Door Stop Adjustment __________________________________________________________ 43
Water Filter Installation __________________________________________________________ 44
System Specifications and Data___________________________________________________ 45
Final Installation ________________________________________________________________ 46
Performance Checklist ______________________________________________________________ 47
Control Panels _____________________________________________________________________ 48
Service & Registration_______________________________________________________________ 49
Make sure that incoming voltage is the same
as unit rating. An electric rating plate
specifying voltage, frequency, wattage,
amperage, and phase is attached to the
product.
To reduce the risk of fire, electric shock, or
injury to persons, installation work and
electrical wiring must be done by qualified
people in accordance with all applicable
codes and standards, including fire-rated
construction.
The installer should leave these instructions
with the consumer who should retain them
for local inspector’s use and for future
reference.

IMPORTANT–Please Read and Follow!
5
IMPORTANT–Please Read and Follow!
4
WARNING
ELECTRICAL SHOCK
HAZARD
Disconnect power or turn
power disconnect switch to
OFF position before removing
top grille. Failure to do so can
result in death or electrical shock.
WARNING
TIP OVER HAZARD
Appliance is top
heavy and tips easily
when not completely
installed. Keep doors
closed until appliance
is completely installed
and secured per installation instructions.
Use two or more people to move and
install appliance. Failure to do so can
result in death or serious injury.
Most of the unit’s weight is at the top. Extra care is needed when moving the unit to prevent
tipping. Use cardboard shipping material or plywood under unit until it is installed in the
operating position to protect floor surface.
It is your responsibility to:
comply with installation specifications and dimensions.
properly install unit.
remove any moldings or decorative panels that prevent the unit from being serviced.
make sure that you have these materials (not provided with your unit), which are necessary
for proper installation:
1/4” (6 mm) copper tubing with shutoff valve
6– #8 x 3” (7.6 cm) wood screws (longer screws may be required)
1– Saddle valve (do not use self-piercing feature of the valve)
assure that floor will support unit, door panels and contents (approximately 1200 pounds [540 kg]).
provide a properly grounded electrical outlet.
assure that location will permit appliance doors to open 90° minimum.
A GFI shall be used if re uired by NFPA-70 (National Electric Code), federal/state/local
laws, or local ordinances.
The required use of a GFI is normally related to the location of a receptacle with respect to
any significant sources of water or moisture.
Viking Range Corporation will NOT warranty any problems resulting from GFI outlets which
are not installed properly or do not meet the requirements below.
If the use of a GFI is re uired, it should be:
Of the receptacle type (breaker type or portable type NOT recommended)
Used with permanent wiring only (temporary or portable wiring NOT recommended)
On a dedicated circuit (no other receptacles, switches or loads in the circuit)
Connected to a standard breaker of appropriate size (GFI breaker of the same size NOT
recommended)
Rated for Class A (5 mA +/- 1 mA trip current) as per UL 943 standard)
In good condition and free from any loose-fitting gaskets (if applicable in outdoor situations)
Protected from moisture (water, steam, high humidity) as much as reasonably possible

Specifications (Professional Side-By-Side)
7
24–11/16”
(62.7cm)
41”
(104.1cm)
75–15/16”
(192.9 cm)
3–19/32”
(9.1cm)
42”
(106.7 cm)
9–5/32”
(23.3 cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7 cm)
22–3/16”
(56.4 cm)
24–11/16”
(62.7 cm)
47”
(119.4cm)
75–15/16”
(192.9cm)
3–19/32”
(9.1 cm)
48”
(121.9 cm)
9–5/32”
(23.3cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7 cm)
1–1/2”
(3.8cm)
22–3/16”
(56.4 cm)
27–1/4”
(69.2 cm)
1–1/2”
(3.8cm)
27–1/4”
(69.2 cm)
Dimensions (Professional Side-By-Side)
6
42” Professional Side-By-Side
Description VCSB542 VCSB542D
Overall width 42” (106.7 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 22-3/16” (56.4 cm)
To front of top grille: 24-11/16” (62.7 cm)
To front of handle endcap: 27-1/4” (69.2 cm)
Cutout width 41-1/2” (105.4 cm) min. to 41-3/4” (106 cm) max.
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; 1/4” copper tubing inlet waterline;
Requirements minimum 20 psi; maximum 120 psi minimum 35 psi; maximum 120 psi
Overall interior dimensions
Refrigerator 15.0 cu. ft. (425 liters) 15.0 cu. ft. (425 liters)
Freezer 9.0 cu. ft. (255 liters) 8.6 cu. ft. (243 liters)
Total capacity 24.0 cu. ft. (680 liters) 23.6 cu. ft. (668 liters)
Approximate shipping weight 652 lbs. (293.4 kg) 676 lbs. (304.2 kg)
48” Professional Side-By-Side
Description VCSB548 VCSB548D
Overall width 48” (121.9 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 22-3/16” (56.4 cm)
To front of top grille: 24-11/16” (62.7 cm)
To front of handle endcap: 27-1/4” (69.2 cm)
Cutout width 47-1/2” (120.7 cm) min. to 47-3/4” (121.3 cm) max.
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; 1/4” copper tubing inlet waterline;
Requirements minimum 20 psi; maximum 120 psi minimum 35 psi; maximum 120 psi
Overall interior dimensions
Refrigerator 18.5 cu. ft. (524 liters) 18.5 cu. ft. (524 liters)
Freezer 8.9 cu. ft. (252 liters) 8.6 cu. ft. (243 liters)
Total capacity 27.4 cu. ft. (776 liters) 27.1 cu. ft. (767 liters)
Approximate shipping weight 715 lbs. (321.8 kg) 735 lbs. (330.8 kg)
42” Professional
48” Professional

Specifications (Professional Side-By-Side)
9
24”
(61.0cm)
41”
(104.1cm)
75–15/16”
(192.9 cm)
3–19/32”
(9.1cm)
42”
(106.7 cm)
9–5/32”
(23.3 cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7 cm)
23–3/8”
(59.4 cm)
24”
(61.0 cm)
47”
(119.4cm)
75–15/16”
(192.9cm)
3–19/32”
(9.1 cm)
48”
(121.9 cm)
9–5/32”
(23.3cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7 cm)
1–1/2”
(3.8cm)
23–3/8”
(59.4 cm)
26–1/2”
(67.3 cm)
1–1/2”
(3.8cm)
26–1/2”
(67.3 cm)
Dimensions (Professional Side-By-Side)
8
42” Professional Integrated
48” Professional Integrated
42” Professional Integrated Side-By-Side
Description VISB542 VISB542D
Overall width 42” (106.7 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 23-3/8” (59.4 cm)
To front of top grille: 24” (61.0 cm)
To front of handle endcap: 26-1/2” (67.3 cm)
Cutout width 42” (106.7 cm)
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; 1/4” copper tubing inlet waterline;
requirements minimum 20 psi; maximum 120 psi minimum 35 psi; maximum 120 psi
Overall interior dimensions
Refrigerator 15.0 cu. ft. (425 liters) 15.0 cu. ft. (411 liters)
Freezer 9.0 cu. ft. (255 liters) 8.6 cu. ft. (244 liters)
Total capacity 24.0 cu. ft. (680 liters) 23.6 cu. ft. (668 liters)
Approximate shipping weight 625 lbs. (293.4 kg) 676 lbs. (304.2 kg)
48” Professional Integrated Side-By-Side
Description VISB548 VISB548D
Overall width 48” (121.9 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 23-3/8” (59.4 cm)
To front of top grille: 24” (61.0 cm)
To front of handle endcap: 26-1/2” (67.3 cm)
Cutout width 48” (121.9 cm)
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; 1/4” copper tubing inlet waterline;
requirements minimum 20 psi; maximum 120 psi minimum 35 psi; maximum 120 psi
Overall interior dimensions
Refrigerator 18.5 cu. ft. (524 liters) 18.5 cu. ft. (507 liters)
Freezer 8.9 cu. ft. (252 liters) 8.6 cu. ft. (243 liters)
Total capacity 27.4 cu. ft. (776 liters) 27.1 cu. ft. (767 liters)
Approximate shipping weight 715 lbs. (321.8 kg) 735 lbs. (330.8 kg)

Two 2”x 4” Mounting Boards
3” (7.6 cm) x 3-1/2” (8.9 cm)
NOTE: If unit is installed deeper than
24” (61.0 cm),then shim behind the mounting
boardby the difference.
One 2”x 4” Mounting Board
3” (7.6 cm) x 3-1/2” (8.9 cm)
NOTE: If unit is installed deeper than
24” (61.0 cm), then shim behind the mounting
boardby the difference.
Bottom of anti-tip board is3–7/8” (9.8 cm) below opening height.
NOTE: Top of unit must be placedfirmly under anti-tip board.
Professional Anti-Tip Location
Professional Integrated Anti-Tip Location
79–3/8”
(201.6 cm) min.
tobottomof
anti-tipboard
80–1/2”
(204.6 cm) max.
tobottomof
anti-tipboard
35”
(88.9cm)
3–1/2”
(8.9cm)
3”
(7.6 cm)
35”
(88.9 cm)
3–1/2”
(8.9 cm)
1.5”
(3.8 cm)
Anti-Tip Dimensions (Professional Side-By-Side)
11
9”
(22.9cm)
73-3/8”
(186.4cm)
82–7/8”
(210.5cm)min.
anti-tipboard&
openingheight
84–1/16”
(213.5cm)max.
anti-tipboard&
openingheight
41–1/2”
(105.4cm)min.
to
41–3/4”
(106.0cm)max.
42”
(106.7cm)
ProfessionalIntegrated
modelsonly
24”
(61.0cm)
Electric Outlet Location
Water Line Entry Area
6–3/4”
(17.1cm)
7–5/8”
(19.4cm)
3”
(7.6cm)
5/8”
(1.6cm)
5/8”
(1.6cm)
10–1/2”
(26.7cm)
5/8”
(1.6cm)
10–3/4”
(27.3cm)
1”
(2.5cm)
3–5/8”
(9.2cm)
Optionalfloor
waterlineentry
42”
(106.7cm)
ProfessionalIntegrated
modelsonly
41–1/2”
(105.4cm)
SeeAnti-Tipboardinstallation
6”
(15.2cm)
9”
(22.9cm)
Cutout Dimensions (Professional Side-By-Side)
10
42” Professional & Professional Integrated 42” Professional

Two 2”x 4” Mounting Boards
3” (7.6 cm) x 3-1/2” (8.9 cm)
NOTE: If unit is installed deeper than
24” (61.0 cm), then shim behind the mounting
boardby the difference.
NOTE: If unit is installed deeper than
24” (61.0 cm), then shim behind the mounting
boardby the difference.
One 2”x 4” Mounting Board
3” (7.6 cm) x 3-1/2” (8.9 cm)
Bottom of anti-tip board is3–7/8” (9.8 cm) below opening height.
NOTE: Top of unit must be placedfirmly under anti-tip board.
Professional Anti-Tip Location
Professional Integrated Anti-Tip Location
79–3/8”
(201.6 cm) min.
to bottomof
anti-tipboard
80–1/2”
(204.6 cm) max.
to bottomof
anti-tipboard
41”
(104.1cm)
3–1/2”
(8.9cm)
3”
(7.6cm)
41”
(104.1 cm)
3–1/2”
(8.9cm)
1-1/2”
(3.8 cm)
Anti-Tip Dimensions (Professional Side-By-Side)
13
9”
(22.9 cm)
73-3/8”
(186.4cm)
82–7/8”
(210.5cm)min.
anti-tipboard&
openingheight
84–1/16”
(213.5cm)max.
anti-tipboard&
openingheight
47–1/2”
(120.7cm)min.
to
47–3/4”
(121.2cm)max.
48”
(121.9cm)
ProfessionalIntegrated
modelsonly
24”
(61.0cm)
Electric Outlet Location
Water Line Entry Area
6–3/4”
(17.1cm)
7–5/8”
(19.4cm)
3”
(7.6cm)
5/8”
(1.6cm)
5/8”
(1.6cm)
10–1/2”
(26.7cm)
5/8”
(1.6cm)
10–3/4”
(27.3cm)
1”
(2.5cm)
3–5/8”
(9.2cm)
Optionalfloor
waterlineentry
47–1/2”
(120.7cm)
48”
(121.9cm)
ProfessionalIntegrated
modelsonly
SeeAnti-Tipboardinstallation
6”
(15.2cm)
9”
(22.9cm)
Cutout Dimensions (Professional Side-By-Side)
12
48” Professional & Professional Integrated 48” Professional & Professional Integrated

Specifications (Professional Bottom-Mount)
15
24–11/16”
(62.7cm)
35”
(88.9cm)
52”
(132.1cm)
23–1/16”
(58.5cm)
3–19/32”
(9.1cm)
36”
(91.5cm)
9–5/32”
(23.3cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7cm)
22–3/16”
(56.4cm)
1–1/2”
(3.8cm)
27–1/4”
(69.2cm)
24”
(61.0cm)
35”
(88.9cm)
52”
(132.1cm)
23–1/16”
(58.5cm)
3–19/32”
(9.1cm)
36”
(91.5cm)
9–5/32”
(23.3cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7cm)
23–3/8”
(59.4cm)
1–1/2”
(3.8cm)
26–1/2”
(67.3cm)
Dimensions (Professional Bottom-Mount)
14
36” Professional
36” Professional Integrated
36” Professional Botto -Mount
Description VCBB536
Overall width 36” (91.5 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 22-3/16” (56.4 cm)
To front of top grille: 24-11/16” (62.7 cm)
To front of handle endcap: 27-1/4” (69.2 cm)
Cutout wdth 35-1/2” (90.2 cm) min. to 35-3/4” (90.8 cm) max.
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; minimum 20 psi;
requirements maximum 120 psi
Overall interior dimensions
Refrigerator 15.2 cu. ft. (431 Liters)
Freezer 5.1 cu. ft. (145 Liters)
Total capacity 20.3 cu. ft. (576 Liters)
Approximate shipping weight 565 lbs. (254.3 kg)
36” Professional Integrated Botto -Mount
Description VIBB536
Overall width 36” (91.5 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 23-3/8” (59.4 cm)
To front of top grille: 24” (61.0 cm)
To front of handle endcap: 26-1/2” (67.3 cm)
Cutout wdth 36” (91.4 cm)
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; minimum 20 psi;
requirements maximum 120 psi
Overall interior dimensions
Refrigerator 15.2 cu. ft. (431 Liters)
Freezer 5.1 cu. ft. (145 Liters)
Total capacity 20.3 cu. ft. (576 Liters)
Approximate shipping weight 565 lbs. (254.3 kg)

Two 2”x 4” Mounting Boards
3” (7.6 cm) x 3-1/2” (8.9 cm)
NOTE: If unit is installed deeper than
24” (61.0 cm), then shim behind the mounting
boards by the difference.
NOTE: If unit is installed deeper than
24” (61.0 cm), then shim behind the mounting
boards by the difference.
One 2”x 4” Mounting Board
3” (7.6 cm) x 3-1/2” (8.9 cm)
Bottom of anti-tip board is 3–7/8” (9.8 cm) below opening height.
NOTE: Top of unit must be placedfirmly under anti-tip board.
Professional Anti-Tip Location
Professional Integrated Anti-Tip Location
79–3/8”
(201.6 cm) min.
to bottomof
anti-tipboard
80–1/2”
(204.6 cm) max.
to bottomof
anti-tipboard
29–1/2”
(74.9cm)
3–1/2”
(8.9cm)
3”
(7.6cm)
29–1/2”
(74.9 cm)
3–1/2”
(8.9cm)
1.5”
(3.8 cm)
Anti-Tip Dimensions (Professional Bottom-Mount)
17
9”
(22.9 cm)
73-3/8”
(186.4cm)
82–7/8”
(210.5cm)min.
anti-tipboard&
openingheight
84–1/16”
(213.5cm)max.
anti-tipboard&
openingheight
35–1/2”
(90.2cm)min.
to
35–3/4”
(90.8cm)max.
36”
(91.5cm)
ProfessionalIntegrated
modelonly
24”
(61.0cm)
Electric Outlet Location
Water Line Entry Area
6–3/4”
(17.1cm)
7–5/8”
(19.4cm)
3”
(7.6cm)
5/8”
(1.6cm)
5/8”
(1.6cm)
10–1/2”
(26.7cm)
5/8”
(1.6cm)
10–3/4”
(27.3cm)
1”
(2.5cm)
3–5/8”
(9.2cm)
Optionalfloor
waterlineentry
35–1/2”
(90.2cm)
36”
(91.5cm)
ProfessionalIntegrated
modelonly
SeeAnti-Tipboardinstallation
6”
(15.2cm)
9”
(22.9cm)
Cutout Dimensions (Professional Bottom-Mount)
16
36” Professional & Professional Integrated 36” Professional & Professional Integrated

Top View
1–13/16”
(4.6 cm)
Space if 24”
standard
cabinet
depth is
used
Door
24”
(61.0 cm)
Standard
Cabinet
Depth
Wall
3/4”
(1.9 cm)
Full End
Panel
2–1/2”
(6.4 cm) Offset
Countertop
Overhang
Cabinet Information (Professional)
19
Top View
Top View
Door
Wall
1–13/16”
(4.6 cm)
Space if 24”
standard
cabinet
depth is
used
3/4”
(1.9 cm)
Full End
Panel
24”
(61.0 cm)
Standard
Cabinet
Depth
2–1/2”
(6.4 cm) Offset
5/16”
(0.8 cm)
1–13/16”
(4.6 cm)
Space if 24”
standard
cabinet
depth is
used
Door
24”
(61.0 cm)
Standard
Cabinet
Depth
Wall
3/4”
(1.9 cm)
Full End
Panel
2–1/2”
(6.4 cm) Offset
Partial Overlay
Cabinet Door
Cabinet Information (Professional)
18
Professional models fit “semi-flush” in standard 24” (61.0 cm) deep cabinet openings. The door
face protrudes 2-1/2” (6.4 cm) from the cabinet face. The handle protrudes an additional
2-1/2” (6.4 cm) into the room.
Professional models fit “semi-flush” in standard 24” (61.0 cm) deep cabinet openings. The door
face protrudes 2-1/2” (6.4 cm) from the cabinet face. The handles protrude an additional
2-1/2” (6.4 cm) into the room.
