Gasifying boilers VIGAS
Ecological Boilers VIGAS
MANUAL FOR INSTALLATION, ASSEMBLY AND USE
VIGAS and VIGAS Lambda Control
with AK 3000
Certificate of warranty
VIMAR 2010

2
Gasifying boilers VIGAS
Content
Declaration of conformity......................................................................................................
1. Technical description......................................................................................................
2. Technical data................................................................................................................
3. Description of AK 3000 control......................................................................................
4. VIGAS boiler in basic configuration...............................................................................
5. VIGAS boiler in configuration with gases thermometer..................................................
6. VIGAS boiler in configuration with gases thermometer and discharge fan....................
7. VIGAS Lambda Control in configuration with gases thermometer..........................................
8. VIGAS Lambda Control in configuration with gases thermometer and discharge fan............
9. Time setting....................................................................................................................
10. Hardware and software information...............................................................................
11. Error messages..............................................................................................................
12. Service settings PIN 0000 protected..............................................................................
13. Operating instructions.....................................................................................................
14. Boiler maintainance and repairs....................................................................................
15. Accesories assembly.....................................................................................................
16. Listo fo guarantee and afterguarantee services.............................................................
17. Problems solving............................................................................................................
18. Assembly instruction......................................................................................................
19. Electric scheme of connection VIGAS boilers................................................................
Letter of guarantee.........................................................................................................
Confirmation of VIGAS boilers commissioning..............................................................
Page
3
4
5
7
9
11
12
13
15
17
18
18
18
21
24
26
28
28
29
31
32
33

3
Gasifying boilers VIGAS
DECLARATION OF CONFORMITY
Issued according to Section 12, par. 3, letter a) Act No. 264/1999 Coll.
and 97 / 23 EC
We, VIMAR Vigaš Pavel
hereby declare that the undermentioned products comply with technical regulations and the
products are safe if determined conditions are followed and we took all possible measures to
assure the compliance of products with technical documentations as well as with relevant
instructions requirements of government.
Product: Thermal boiler VIGAS and VIGASLambda Control with AK 3000 control
Type: VIGAS 16, VIGAS 16 Lambda Control
VIGAS 25, VIGAS 25 Lambda Control
VIGAS 40, VIGAS 40 Lambda Control
VIGAS 60, VIGAS 60 Lambda Control
VIGAS 80, VIGAS 80 Lambda Control
VIGAS 100, VIGAS 100 Lambda Control
VIGAS 29 UD
Producer: VIMAR Vigaš Pavel
M. Čulena 25, 974 11 Banská Bystrica,
SLOVENSKO
The above-mentioned products comply with the following standards:
STN 07 7401, STN 73 4210, STN EN 303-5, STN EN 61000-3-
2:2000+A1:2001+A2:2001, STN EN 61000-3-3:2000.
Supplementary data: Certificates, Test report
Issued in: Banská Bystrica Name: VIGAŠ Pavel
Date of issue: Title: Owner
Signature:
M. Čulena 25
974 11 Banská Bystrica
SLOVAKIA
IČDPH: SK 1020548001

4
Gasifying boilers VIGAS
1. TECHNICAL DESCRIPTION
Thermal boilers VIGAS are designed for combustion of dry wood material, starting from
sawdust up to logs in the length according to the dimensions of gasification chamber,
maximum 20 cm. Sawdust, chippings, splinters and cuttings must be burn together with logs.
Thermal boiler, VIGAS UD 29 is designed for burning brown coal. It is also possible to use dry
wooden material as a substitute fuel.
Boilers are welded from 4- 6 mm steel sheets. Inner boiler sheets that have contact with
boiler waste gases are 6 mm thick, others are made of 4 mm sheet. Heat exchanger is
welded from steel pipes, 57x 5 mm. Exterior boiler shell is made of 0.8 mm sheet. Thermal
insulation of the boiler is made of insulation material, NOBASIL, 20 and 50 mm thick. Boiler
waste gases go away through steel neck to chimney.
Inner boiler space consists of gasification chamber, where fuel is dried and gasified. Then
created gas goes through fireproof /concrete/ nozzle into combustion chamber, where it
burns with the help of secondary air. Boiler waste gasses are intensively cooled in
exchanger. Wood that is not burnt must be removed from combustion chamber. The boiler has a
lighting up damper that is controled by operating rod at the front part of boiler.
In order the boiler complies with the requirements for non-demanding operation, it is equipped
with AK 3000 control unit that is situated in the upper part of boiler. The used system of control
allows very effective combustion of various kinds of fuel. AK 3000 control with grpahical display,
in basic configuration allows:
to control temperature of heated water in range 60 ÷ 85 °C
smooth and automatic control of forced draft fan according to required output and
to connect discharge fan
to connect circulation pump
to connect gases thermometer
to connect and to control boiler by space temperature regulator
to connect extended regulation (EXPANDER) via AK BUS
to connect module with Ethernet interface and SD-card for data saving and concsequtive
evaluation via PC
grpahical scheme indication of hydraulic connection as requested
real time set
In configuration VIGAS Lambda Control also allows :
Utilizes informations from lambda sensor of oxygen overflow in gases, to control the
chimney flap of primary and secundary air.
Gases thermometer as a standard
Boilers are equiped with thermal fuse that ensures disconnection of forced draft fan if boiler
is overheated above 100 0C and safety exchanger against overheating according to the
standard, STN EN 303/5. Its recommended, by producer, to buy a release valve Honeywell TS
130 ¾” for safety exchanger against over heating.

5
Gasifying boilers VIGAS
2. Technical data Tab.1
THERMAL BOILERS
VIGAS 16 25 40 60 80 100 UD 29
Nominal boiler output kW 16 25 40 60 80 100 29
Boiler class according to EN 303-5 3
Max. operating pressure bar 3
Fuel Wood, max. moisture 20% ;heating min. 15 MJ/kg Brown coal
Output capacity kW 12 - 18 5 - 31 8 - 41 15 - 72 25 - 92 25-100 8-35(8-29)*
Fuel consumption with
nominal output kg/hod 4,5 7,6 11,2 19 25 30,4
7,8 (8,0)*
Substituite fuel Wood waste, splinters, saw dust, saw dust briquettes (for UD 29 also wood
of max. moisture 20%)
Chimney daught mBar 0,20 – 0,25 0,20 – 0,35 0,30 – 0,40 0,20 – 0,25
Weight kg 400 430 460 760 930 950 430
Height with regulation A mm 1135 1135 1385 1420 1120
Height of exhaust branch B mm 975 1045 1310 1400 1045
Height of inlet branch C mm 115 125 215 110
Height of feed-water valve D mm 55 60 70 135 55
Height of chimney neck E mm 890 1110 1170 890
Width including rod F mm 645 785 645
Width including shell G mm 590 760 590
Depth H mm 840 1070 1260 1650 1070
Exhaust brand I mm 240 520 240
Diameter od draught neck J mm 160 200 160
Dimmension from edge of
boiler K mm 188 305 880 1210 230
Spacing of feed pipes L mm 405 70 350
Diameter of inlet brand G/mm 2“
Diameter of exhaust brand G/mm 2“
Diameter of feed-water valve G ½“ ¾“ ½“
Volume of water l 75 93 180 205 215 75
Gases temperature
With nominal output
With minimal output
0C
0C
240
150
Dimensions of gasification
chamber
Depth
mm 370
560 750 1150 1090 490/440
Height mm 490 750 730 500
Width mm 440 575 440
Dimensions of gasification
chamber
(width-height)
mm 435 -255
575 – 318 435 - 255
Max. weight of fuel kg 20 30 40 80 150 30
Capacity of gasification
chamber dm380 120 185 315 483 457 105
Noisness dB 45 45,5 47,7 51,4 54,2 45,5
Max. electric input W 70 140 70
Voltage/Frequency V/Hz 230ACV / 50 Hz
Pressure loss of water :
Δt 10 0C
Δt 20 0C
mBar
mBar
9,70
1,00
9,75
1,05
10,48
2,55
12,77
3,19
11,83
2,96
11,53
2,84
9,97
1,15
Time of burning with nominal
output
hod 4,5 4,20 4,30 4,20 4,20 4,0 5,60 (4,10)
Cooling exchanger of heat
- temperature of inlet water
- pressure of inlet water
0C
bar
4 – 15
min 1 – max 4
Release valve Honeywell TS 130 ¾” for safety exchanger against over
heating, Opening temperature 95°C
Safety
STB fuse, blow temperature 100oC (tolerance: -6oC –- 0 oC)
Weight flow of gases kg/s 0,034 – 0,047
* specification for wood fuel

6
Gasifying boilers VIGAS
2.1 DIMENSION CHART AND THE POSITION OF PROTECTIVE SUPPORT PLATE ON
EASILY IGNITABLE FLOOR
2.2 BOILER SCHEMATICS
Pic.1 Pic.2
KEY
1. AK 3000 control
2. Upper door
3. Chimney flap operating rod
4. Fuel bunker
5. Primary air conduction
6. Flap for Lambda control servo
7. Fan
8. Fan cover
9. Heatproof nozzle
10. Secondary air screen
11. Door closing device
12. Fireclay bricks
13. Bottom door
14. Chimney neck
15. Exchanger cap
16. Lighting up damper
17. Upper back cover
18. Outlet water neck
19. Thermal fuse
20. Thermometer
21. Upper front cover
22. Lambda sensor
23. Gases thermometer
24. Exchanger pipes
25. Heat proof /concrete/ filling
26. Secondary air
27. Combustion chamber
28. Direction of gases
29. Neck of reversible water
30. Fillng neck
31. Cleaning flap for 29UD
32. Cleaning hole for 29UD
Scheme VIGAS 60,80
Scheme VIGAS 25 Scheme VIGAS 40
Scheme VIGAS 100
Scheme VIGAS 16
Scheme VIGAS 29 UD
Pic.3
Inlet water neck
for valve (Danfoss)
Hole for
submersible case
(Danfoss)
Exhaust brand of
cooling water
Exhaust water
neck
Inlet water neck
Filling neck

7
Gasifying boilers VIGAS
3. DESCRIPTION OF AK 3000 CONTROL
3.1 Safety Instructions
Check protection (cover) metal sheet before plug-in the power wire
Avoid any contact of power wire with hot parts of the boiler (f.e. chimney)
Make sure, no water is allowed under the upper isolation (risk of short circuit)
Do not stress the power wire
Always disconnect the power wire when a new electrical components are connecting (f.e.
indoor thermostat, discharge fan or circulation pump)
Do not remove protection (cover) metal sheet during the boiler operation, especially from
fan
Compare working voltage displayed on the label with your distribution network
Always observe safety regulations
3.2 Connecting to the distributing network
AK 3000 control is integral part of VIGAS boilers.
Control is connected when power wire is plugged in to the distributing network 220/230V. Display
is active when power wire is plugged-in (Pic.4). Servo-flat used in VIGAS Lambda Control is set to
base position (Pic.5).
3.3 Working conditions
Operation temperature range of AK 3000 control is +5°C to +45 °C. Control may not be used in
humid enviroment or direct sunlight.
3.4 Maintainance of AK 3000 control
Keep in clean and dust-free enviroment. Antistatic, or wet wipper is adivsed to wipe-off dust and
impurities from metal cover and control panel.
3.5 Control panel
Part of the electronic control is panel, equipped with buttons, pictograms and display. Futher
informations will be available in the next part of this manual.
Pic.
6
Pic.5
1. Graphical display 128 x 64 pixels
2. Button ◄with functions
3. Button ▲with functions
4. Button ►with functions
5. Button (ENTER) with functions
6. LED control
7. Button with functions
Pic.4

8
Gasifying boilers VIGAS
Functionality of each button are composite and their functionality deppends accompanying
description on display and from manufacture settings.
3.6 Symbols
1. Real time indication.
2. Indication of current boiler values.
Modification ▲or .
3. Indication od discharge fan, lambda sensor, gases
thermometer
4. Indication of nominal boiler output when switched off.
5. Graphically indicated hydraulic scheme o
f
connection.
6. Indication of boiler status.
Pic.
7
Boiler Storage tank External boiler
Boiler „ON“ ON DUOMIX Heating circuit
Boiler „OFF“ OFF DUOMIX with
servomotor
Indoor
thermostat
Heating
ON Pump
3-way
thermostatic
valve
Burning
73 0C Discharge fan LADOMAT
Afterflaming
52 0CLambda λFan
End of burning
END Thermometer T Fan change
output
Indoor
termostat
decay Error indication
value x Open flap servo 50%
Adding fuel Minimal value
of gases min Maximal value of gases max
Temperature
settings
Parameter
settings Time setting
Error
messages Program
Konfiguration
informations
Service
message

9
Gasifying boilers VIGAS
4. VIGAS BOILER IN BASIC CONFIGURATION
(without discharge fan, gases thermometer and lambda sensor)
4.1 VIGAS BOILER OPERATING
4.1.1 Boiler activation
4.1.2 Boiler activated – heating mode
4.1.3 Boiler activated – burning mode
4.1.4 Adding fuel, Disconnection the boiler (manually)
Using graphical control. To call the graphical control, press central button ENTER. Graphical
control offers option to switch off, adding fuel or cancel the graphical control.
If boiler is in unactive status with symbol „OFF“, as displayed on
the picture, by pressing the central button ENTER the boiler start
the operation.
Choose one option
OFF Switch-off
Add fuel
⌧Cancel the control
bc Change the indicated value
By pressing „ “ fan will be switched off. By using the rod open
the chimney flap, consequently open the upper door. You can add
fuel, if necessary. Close the upper door and chimney flap.
By pressing „ “ adding fuel will be stopped. Fan will be switched-
on automatically.
Boiler is set to heating mode, if temperature of outgoing water is
lower, then set shotdown temperature of the boiler. Shotdown
temeperature is in settings. Usually is set to 500C. Pump is pulse
working in dependence on temperature of the boiler water! The
pump is working, when symbol flash.
The burning mode is active after the shotdown temeprature is
higher + time deviation. In this mode pump is working pulse (bolie
r
protection against low-temperature corrosion), 50C before set
temperature constantly. The pump is working, when symbol flash.
Boiler is responsive to indoor thermostat, when indoor thermostat is
switched off boiler slowly decreasing its output.

10
Gasifying boilers VIGAS
„ENTER“
By ▲buttons set the parameter you want to edit and by
pressing „ENTER“ button, the value starts to flash. ▲buttons
set requested value.
end Choose shotdown temperature of the boiler
„“ Increase or decrease the value, maximal output will be
changed. Is adviced to decrease the value in transition
period (boiler tar level will drop).
ÂBrightness
Roll Press „yes“ will acitivate the value rolling (Pic.6/2)
Help 0s Set the time when graphical control will be indicated
4.1.5 Disconnection the boiler (Automatically)
4.2 TEMPERATURE SETTINGS OF OUTLET WATER
4.3 PARAMETERS SETTING OF VIGAS BOILER
When temperature drops under the shotdown temperature (see
Parameter settings of Vigas boiler in basic configuration) boiler is
switch-off automatically. „END“ will be indicated on the display. By
pressing „ENTER“ boiler will start operating again.
To call temperature setting hold „ENTER“ button at any boile
r
status. Symbol of the temperature setting will be indicated on the
display. Press „ENTER“ again. Symbol of the nominal output will
be indicated on the display with value, together with temperature o
f
outlet water in °C. By pressing the „ENTER“ button, the value start
to flash.
„ENTER“
Temperature is flashing, by using
buttons ▲choose requested
value. Button ►will exit the
temperature settings.
To call parameters setting hold „ENTER“ button at any boile
r
status and by pressing ▲button. Press „ENTER“ again Symbol o
f
the parameters setting will be indicated on the display. By pressing
the „ENTER“ button twice, the values you can set will be indicated
on the display.
„ENTER“ „ENTER“

11
Gasifying boilers VIGAS
5. VIGAS BOILER IN CONFIGURATION WITH GASES
THERMOMETER
(without discharge fan and lambda sensor)
The advantage of the gases thermometer is elimination of the maximal gases temperature, if it will
be reached, it will effect the speed drop of fan. As consequence will be increased efficiency
followed by low fuel consumption. In configuration with storage tank, its used for boiler to
shotdown when burn-out all fuel, water boiler temperature in tank has no influence to shotdown.
5.1 VIGAS BOILER CONTROL
5.1.1 Boiler activation
5.1.2 Boiler activated – heating mode
5.1.3 Boiler activated – burning mode
5.1.4 Adding fuel, Disconnection the boiler (manually)
Using graphical control. To call the graphical control, press central button ENTER. Graphical
control offers option to switch off, adding fuel or cancel the graphical control.
Boiler is set to heating mode, if outgoing gases temperature is
lower, then set minimal gases temperature. Minimal gases
temperature, as well as, maximal gases temperature can be set in
boiler settings. Minimal gases temperature is set on 90°C, maximal
gases temperature is on 200°C, which are standard settings.
Pump is pulse working in dependence on temperature of the boile
r
water!
If boiler is in unactive status with symbol „OFF“, as displayed on
the picture, by pressing the central button ENTER the boiler start
the operation.
The burning mode is active after the gases temeprature is highe
r
(end) + 200C. In this mode pump is working pulse (bolie
r
protection against low-temperature corrosion). The pump is
working, when symbol flash. Boiler is responsive to indoo
r
thermostat, when indoor thermostat is switched off boiler slowly
decreasing its output.
Choose one option
OFF Switch off
Add fuel
⌧Cancell the control
bc Change the indicated value
By pressing „ “ fan will be switched off. By using the rod open
the chimney flap, consequently open the upper door. You can add
fuel, if necessary. Close the upper door and chimney flap.

12
Gasifying boilers VIGAS
Choose one option
+60 Discharge fan active for 60s. (Using when heating)
ON Boiler activation
⌧Cancell the control
bc Change the indicated value
If „+60“ is chosen, new graphical control is indicated. In left
corner is running time of discharge fan.
+60 Another 60s. could be added. 300s. maximum
ON Boiler activation
0 Discharge fan disconnection
bc Change the indicated value
5.1.5 Disconnection the boiler (Automatically)
6. VIGAS BOILER IN CONFIGURATION WITH GASES
THERMOMETER AND DISCHARGE FAN
(without lambda sensor)
Advantages of gases thermometer are described in Chapt.5. Main advangate of discharge fan is
increased comfort during heating or adding fuel. When discharge fan is active during adding fuel
there is significant decrease of smudging into boiler-room. During the heating, discharge fan will
accelerate the burning.
6.1 VIGAS BOILER CONTROL
6.1.1 Boiler activation
When gases temperature drops under the set temperature
( end) boiler is switch-off automatically. „END“ will be indicated
on the display. By pressing „ENTER“ boiler will start operating
again.
If boiler is in unactive status with symbol „OFF“, as displayed on
the picture, by pressing the central button ENTER the boiler start
the operation.
By pressing „ “ adding fuel will be stopped. Fan will be switched
on automatically.

13
Gasifying boilers VIGAS
6.1.2 Boiler activated – heating mode
6.1.3 Boiler activated – burning mode
6.1.4 Adding fuel, Disconnection the boiler (manually)
5.1.6 Disconnection the boiler (Automatically)
Boiler is set to heating mode, if outgoing gases temperature is
lower, then set minimal gases temperature ( end). Minimal gases
temperature, as well as, maximal gases temperature can be set in
boiler settings. Minimal gases temperature is set on 90°C, maximal
gases temperature is set on 200°C, which are standard settings.
Pump is pulse working in dependence on temperature of the boile
r
water!
The burning mode is active after the gases temeprature is highe
r
(end) + 200C. In this mode pump is working pulse (bolie
r
protection against low-temperature corrosion). The pump is
working, when symbol flash. Boiler is responsive to indoo
r
thermostat, when indoor thermostat is switched off boiler slowly
decreasing its output.
Choose one option
OFF Switch off
Add fuel
⌧Cancell the control
bc Change the indicated value
By pressing „ “ fan is swithed off and discharge fan is
automatically activaed on 300s. In left corner is running time o
f
discharge fan. If „+60“ is chosen, new graphical control is indicated.
By using the rod open the chimney flap, consequently open the
upper door. You can add fuel, if necessary. Close the upper doo
r
and chimney flap. By pressing „0“ discharge fan is swithed off. By
pressing adding fuel is finished, discharge fan is switched of
f
automatically and fan will switched on.
When gases temperature drops under the set temperature
( end) (boiler is switch-off automatically). „END“ will be
indicated on the display. By pressing „ENTER“ boiler will start
operating again.
Using graphical control. To call the graphical control, press central button ENTER. Graphical
control offers option to switch off, adding fuel or cancel the graphical control.

14
Gasifying boilers VIGAS
7. VIGAS BOILER IN CONFIGURATION WITHLambda Control
(without discharge fan)
Advantages of gases thermometer are described above. VIGAS Lambda Control boiler is delivered with
built-in gases thermometer. VIGAS Lambda Control boiler utilizes informations from lambda sensor of
oxygen overflow in gases, to control the flap of primary and secundary air. This system allows to
burn all kinds of wood more efficiently and at the same time decreaseing the fuel consumption by
20-25%.
7.1 VIGAS Lambda Control BOILER CONTROL
7.1.1 Boiler activation
7.1.2 Boiler activated – heating mode
7.1.3 Boiler activated – burning mode
7.1.4 Adding fuel, Disconnection the boiler (manually)
Using graphical control. To call the graphical control, press central button ENTER. Graphical
control offers option to switch off, adding fuel or cancel the graphical control.
If boiler is in unactive status with symbol „OFF“, as displayed on
the picture, by pressing the central button ENTER the boiler start
the operation.
The burning mode is active after the gases temeprature is highe
r
(end) + 200C. Servo-controled flap wokrs in this mode as in
heating mode. In this mode pump is working pulse (bolie
r
protection against low-temperature corrosion). The pump is
working, when symbol flash.
Servo-controled flap will move to open position (servo 100%)
when „ENTER“ button is pressed. Consequently, futher steps
(from 100% up to 45%) is moved that, value of lambda sensor is
kept close to set value (λ1,35). In position (servo 45%)
secundary air is closed, in position (servo 0%) also primary air is
closed. To position 0% will be moved only if the boiler is „OFF“ o
r
„END“. Boiler is set to heating mode, if outgoing gases
temperature is lower, then set minimal gases temperature (
end). Minimal gases temperature, as well as, maximal gases
temperature can be set in boiler settings. Minimal gases
temperature is set on 90°C, maximal gases temperature is set on
200°C, which are standard settings. Pump is pulse working in
dependence on temperature of the boiler water!
Choose one option
OFF Switch off
Add fuel
⌧Cancell the control
bc Change the indicated value

15
Gasifying boilers VIGAS
Choose one option
+60 Discharge fan active for 60s. (Using when heating)
ON Boiler activation
⌧Cancel the control
bc Change the indicated value
If „+60“ is chosen, new graphical control is indicated. In left corner
is running time of discharge fan.
+60 Another 60s. could be added. 300s. maximum
ON Boiler activation
0 Discharge fan disconnection
bc Change the indicated value
7.1.5 Boiler disconnection (automatically)
8. VIGASLambda Control BOILER IN CONFIGURATION WITH
GASES THERMOMETER AND DISCHARGE FAN
Advantages of gases thermometer and discharge fan are described above. VIGAS Lambda Control
boiler utilizes informations from lambda sensor of oxygen overflow in gases, to control the flap of
primary and secundary air. This system allows to burn all kinds of wood more efficiently and at the
same time decreaseing the fuel consumption by 20-25%.
8.1 VIGASLambda Control BOILER CONTROL
8.1.1 Boiler activation
If boiler is in unactive status with symbol „OFF“, as displayed on
the picture, by pressing the central button ENTER the graphical
control will be called.
By pressing „ “ fan is switched off. By using the rod open the
chimney flap, consequently open the upper door. You can add
fuel, if necessary. Close the upper door and chimney flap. By
pressing „ “ adding fuel will be stopped. Fan will be switched on
automatically. During fuel adding, servo-controled flap is in the
same position as before fuel adding. When adding is finished,
servo-controled flap will be moved to position (servo 100%).
Consequently, futher steps (from 100% up to 45%) is moved that,
value of lambda sensor is kept close to set value (λ1,35). In
position (servo 45%) secundary air is closed, in position (servo
0%) also primary air is closed. To position 0% will be moved only
if the boiler is eighter „OFF“ , „END“ or switched-off fan.
When gases temperature drops under the set temperature
( end) (boiler is switch-off automatically). „END“ will be
indicated on the display. Servo-controled flap will be moved to
position (servo 0%). In this position secondary air is closed as
well as primary air. By pressing „ENTER“ boiler will start
operating again.

16
Gasifying boilers VIGAS
8.1.2 Boiler activated – heating mode
8.1.3 Boiler activated – burning mode
8.1.4 Adding fuel, boiler disconnection (manually)
Using graphical control. To call the graphical control, press central button ENTER. Graphical
control offers option to switch off, adding fuel or cancel the graphical control.
Servo-controled flap will moves to open position (servo 100%)
when „ON“ button is pressed. Consequently, futher steps (from
100% up to 45%) is moved that, value of lambda sensor is kept
close to set value (λ1,35). In position (servo 45%) secundary air is
closed, in position (servo 0%) also primary air is closed. To position
0% will be moved only if the boiler is „OFF“ or „END“. Boiler is set
to heating mode, if outgoing gases temperature is lower, then set
minimal gases temperature ( end). Minimal gases temperature,
as well as, maximal gases temperature can be set in boile
r
settings. Minimal gases temperature is set on 90°C, maximal
gases temperature is set on 200°C, which are standard settings.
Pump is pulse working in dependence on temperature of the boile
r
water!
The burning mode is active after the gases temeprature is highe
r
(end) + 200C. Servo-controled flap wokrs in this mode as in
heating mode. In this mode pump is working pulse (bolie
r
protection against low-temperature corrosion). The pump is
working, when symbol flash.
Choose on option
OFF Switch off
Add fuel
⌧Cancell the control
bc Change the indicated value
By pressing „ “ fan is swithed off and discharge fan is
automatically activaed on 300s. In left corner is running time o
f
discharge fan. If „+60“ is chosen, new graphical control is indicated.
By using the rod open the chimney flap, consequently open the
upper door. You can add fuel, if necessary. Close the upper doo
r
and chimney flap. By pressing „0“ discharge fan is swithed off. By
pressing adding fuel is finished, discharge fan is switched of
f
automatically and fan will switched on. During fuel adding, servo-
controled flap is in the same position as before fuel adding. When
adding is finished, servo-controled flap will be moved to position
(servo 100%). Consequently, futher steps (from 100% up to 45%)
is moved that, value of lambda sensor is kept close to set value (λ
1,35). In position (servo 45%) secundary air is closed, in position
(servo 0%) also primary air is closed. To position 0% will be moved
only if the boiler is eighter „OFF“ , „END“ or switched-off fan.

17
Gasifying boilers VIGAS
By ▲buttons set the parameter you want to edit and by
pressing „ENTER“ button, the value starts to flash. ▲buttons
set requested value.
max Choose maximal gases temperature that will result in
decreasing the operating speed
end Choose shotdown temperature of the boiler
λLambda value, that servo-controled flap keeps.
Recommended is 1,35.
„“
Increase or decrease the value, maximal output will be
changed. Is adviced to decrease the value in transition
period (boiler tar level will drop).
ÂBrightness
Roll Press „yes“ will acitivate the value rolling (Pic.7/2)
Help 0s Set the time when graphical control will be indicated
8.1.5 Boiler disconnection (automatically)
8.2 PARAMETERS SETTING VIGASLambda Control BOILER AND VIGAS BOILER
WITH GASES THERMOMETER
9. TIME SETTING
Set time and date, when boiler is pluged first time. In left corner is time is indicated.
When gases temperature drops under the set temperature
( end) (boiler is switch-off automatically). „END“ will be
indicated on the display. Servo-controled flap will be moved to
position (servo 0%). In this position secundary air is closed as
well as primary air. By pressing „ENTER“ boiler will start
operating again.
To call parameters setting hold „ENTER“ button at any boielr status
and by pressing ▲button.
„ENTER“
To call parameters setting press longer „ENTER“ button at any
boielr status and by pressing ▲button twice.
By ◄button set date or time, that will be edited. ▲buttons
choose date and time. Button ►will exit the settings.
Mon – Monday, Tue – Tuesday, Wed – Wednesday, Thu –
Thursday, Fri – Friday, Sat – Saturday, Sun – Sunday

18
Gasifying boilers VIGAS
STB
10. HARDWARE AND SOFTWARE INFORMATION
11. ERROR MESSAGES
11.1 STB failure
At „STB“ failure boiler is overheated. Thermal
fuse is activated (Pic.3/21). The fan is
disconnected from voltage. Boiler is activated
again only if „STB“ protection is mechanical
pressed. Boiler is need to be switch-on by
„ENTER“ button.
12. SERVICE SETTINGS PIN 0000 PROTECTED
To call informations setting hold „ENTER“ button at any boiler
status and by pressing button.
▲buttons choose modul and confirm „ENTER“. Information
about the module will be indicated on display.
To call error messages hold „ENTER“ button at any boielr status
and by pressing 3 times. By pressing „ENTER“ error with
description will be indicated on display.
Service settings PIN 0000 protected can be used only in restricted
cases. Only trained service engineer can do these settings. (In
necessary cases client can do also). In service settings are
adjusted boiler type with accessories and hydraulic connection
scheme, etc.
To call the service setting PIN 0000 protected as follows:
1. Hold „ENTER“ button at any boielr status
2. Press ▲button
3. Hold ◄button for 4s - „PIN 0000“ will be indicated
4. Press „ENTER“ 4 times
5. Service settings symbol will be indicated on display
6. Press „ENTER“ and buttons ▲choose service setting of
boiler type, hydraulic connection scheme, micro SD card,
service operation and press „ENTER“ .

19
Gasifying boilers VIGAS
12.1 Settings for micro SD card
AK 3000 control can be extenended by SD modul (Pic.8). Micro SD card of different capacity is
plugged into SD module.
12.2 Service settings boiler type with accessories
WARNING
Graphical control unit AK 3000 is used to control all types of VIGAS
boilers. It is important, software settings must be same as type of
the boiler. In deactivated boiler status „OFF“ boiler type is
indicated on the display, that is equal to boiler nominal output. For
correct boiler operation, boiler type must match with boiler
type marked on boiler label.
In case of control unit exchange, always must be AK 3000
checked!!!
Continue Chapt.14
7. Press „ENTER“, display indicates :
Boiler type V- VIGAS, xx – nominal output, L – lambda
TVZ – hot-air, UD – coal – wood, DP – wood – pellets
λyes – boiler with lambda sensor, no – boiler without
lambda sensor
yes – boiler with gases thermometer, no – boiler
without gases thermometer
yes – boiler with discharge fan, no – boiler without
discharge fan
8. Buttons▲choose parameter and press ENTER
9. Button ►will exit the settings
Boiler List
V 16 V 80
V 16L V 80L
V 25 V 100
V 25L V 100L
V 40 V 25TVZ
V 40L V 29UD
V 60 V 18DP
V 60L
By pressing „ENTER“ symbols that micro SD cards allows will be
indicated on the display. Buttons ▲choose the task, you want to
realize and then press „ENTER“.
Pic.
8
Micro SD card allows:
Loading of back-up software to control unit of the boiler
Software back-up to SD card
Loading of updated software from SD card to control unit o
f
the boiler
Selected parameters boiler back-up (f.e. boiler temperature,
fan speed, lamdba sensor value, etc.)
SD card erasing

20
Gasifying boilers VIGAS
12.3 Service settings hydraulic scheme connection
12.4 Service tools
WARNING
The output contol of the pump will be changed by hydraulic
connection. It is important, that software setting of hydraulic pump
match the setting of the boiler in connection with central heating
system. Basic memory of control contains 4 schematics. It is
possible to add more schematics if necessary. Schematics that are
used for additional module „EXPANDER“ are delivered on mini
SD card, or will be available on www.ers.sk , free to download,
through PC to memory card that will be inserted to the module of
the boiler control (Chapt.13).
If necessary, is it possible to return to last scheme to press „last“
Continue Chapt.14
7. Press „ENTER“, scheme 1 indicates on the display
8. Buttons ▲choose requested scheme and press ENTER.
9. Button „ENTER“ confirm „Yes“ – to save scheme
10. To exit use ►button
Scheme 1 :
Scheme is dedicated for boiler with storage tank. „LADOMAT“
provides reverse water protection. Pump is connected to boiler
control and working over 40 oC. Requested temperature is possible
to set up to 90 oC. T3 contact on mother board AK 3000 S is used
for connection to thermometer PT 1000, which is able to measure
temperature in stogare tank.
Warning: It is not possible to connect indoor thermostat to T3
contact.
Scheme 2 :
Scheme is dedicated to central heating systems, where reverse
water protection provides external control system. Pump is
connected to the control and it is working pulse in dependence of
boiler water temperature. T3 contact on mother board is used to
connect indoor thermostat.
Scheme 3 :
Scheme with 3-way thermostatic valve. Pump is connected to the
control and it is working pulse in dependence of boiler water
temperature. T3 contact on mother board is used to connect indoor
thermostat.
Scheme 4 :
Scheme is set as a standard. Pump is connected to the control and
it is working pulse in dependence of boiler water temperature. T3
contact on mother board is used to connect indoor thermostat.
Funcionality of each system can be check in service settings by
symbols indicated on display. Press „ENTER“ and selected
system will be activated.
