VIMCOM ES-2226D User manual

ES-2226C
User's Manual
24-Port L2 Plus Managed Fast Ethernet Switch
+ 2 TP/SFP Gigabit Dual Media
Release 1.01
©2008, RubyTech Corporation. All rights reserved. All brand and product names are trademarks or
registered trademarks of their respective companies.

ii
The information in this document is subject to change without notice. Unless the explicit written permission of RubyTech Corporation, this document in
whole or in part shall not be replicated or modified or amended or transmitted, in any from, or by any means manual, electric, electronic, electromagnetic,
mechanical, optical or otherwise for any purpose.
DURATION OF HARDWARE WARRANTY
HARDWARE: In accordance with the provisions described under, RubyTech Corporation (hereinafter called “RubyTech”) warrants its hardware products
(hereinafter referred to as "Product") specified herein to be for a period of twelve (12) months from the date of shipment.
Should a Product fail to perform during the effective warranty period as described above, RubyTech shall replace the defective Product or part, or delivering
a functionally equivalent Product or part in receipt of customer’s request, provided that the customer complies with the return material authorization (RMA)
procedures and returns all defective Product prior to installation of the replacements to RubyTech.
All defective Products must be returned to RubyTech with issuance of a Return Material Authorization number (RMA number) assigned to the reseller from
whom the end customer originally purchased the Product. The reseller is responsible for ensuring the shipments are insured, with the transportation
charges prepaid and the RMA number clearly marked on the outside of the package. RubyTech will not accept collect shipments or those returned without
an RMAnumber.
RubyTech shall not be responsible for any software, firmware, information or memory data contained in, stored on or integrated with any Product returned to
RubyTech pursuant to any warranty.
EXCLUSIONS. The warranty as mentioned above does not apply to the following conditions, in RubyTech’s judgment, it contains (1) customer does not
comply with the manual instructions offered by RubyTech in installation, operation, repair or maintenance, (2) Product fails due to damage from unusual
external or electrical stress, shipment, storage, accident, abuse or misuse, (3) Product is used in an extra hazardous environment or activities, (4) any serial
number on the Product has been removed or defaced, (5) this warranty will be of no effect if the repair is via anyone other than RubyTech or the approved
agents, or (6) In the event of any failures or delays by either party hereto in the performance of all or any part of this agreement due to acts of God, war, riot,
insurrection, national emergency, strike, embargo, storm, earthquake, or other natural forces, or by the acts of anyone not a party to this agreement, or by
the inability to secure materials or transportation, then the party so affected shall be executed from any further performance for a period of time after the
occurrence as may reasonably be necessary to remedy the effects of that occurrence, but in no event more than sixty (60) days. If any of the stated events
should occur, Party A shall promptly notify Party B in writing as soon as commercially practicable, but in no event more than twenty (20) business days and
provide documentation evidencing such occurrence. In no event shall the maximum liability of RubyTech under this warranty exceed the purchase price of
the Product covered by this warranty.
DISCLAIMER. EXCEPT AS SPECIFICALLY PROVIDED ABOVE AS REQUIRED “AS IS” AND THE WARRANTIES AND REMEDIES STATED ABOVE ARE
EXCLUSIVEAND IN LIEU OFALL OTHERS, ORAL OR WRITTEN, EXPRESS OR IMPLIED.ANYAND ALLOTHER WARRANTIES, INCLUDING IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR APARTICULAR PURPOSE AND NONINFRINGEMENT OR THIRD PARTY RIGHTS ARE
EXPRESSLY EXCLUDED.
RUBYTECH SOFTWARE LICENSE AGREEMENT
NOTICE: Please carefully read this Software License Agreement (hereinafter referred to as this “Agreement”) before copying or using the accompanying
software or installing the hardware unit with pre-enabled software or firmware (each of which is referred to as “Software” in this Agreement). BY COPYING
OR USING THE SOFTWARE, YOU ACCEPT ALL OF THE PROVISIONS AND CONDITIONS OF THIS AGREEMENT. THE PROVISIONS EXPRESSED IN
THIS AGREEMENT ARE THE ONLY PROVISION UNDER WHICH RUBYTECH WILL PERMIT YOU TO USE THE SOFTWARE. If you do not accept these
provisions and conditions, please immediately return the unused software, manual and the related product. Written approval is NOT a prerequisite to the
validity or enforceability of this Agreement and no solicitation of any such written approval by or on behalf of RubyTech shall be deemed as an inference to
the contrary.
LICENSE GRANT. The end user (hereinafter referred to as “Licensee”) of the Software is granted a personal, non-sublicensable, nonexclusive,
nontransferable license by RubyTech Corporation (“RubyTech”): (1) To use the RubyTech’s software (“Software”) in object code form solely on a single
central processing unit owned or leased by Licensee or otherwise embedded in the equipment offered by RubyTech. (2) To copy the Software only for
backup purposes in support of authorized use of the Software. (3) To use and copy the documentation related to the Software solely in support of authorized
use of the Software by Licensee. The License applies to the Software only except other RubyTech’s software or hardware products. Without the prior written
consent of RubyTech, Licensee has no right to receive any source code or design documentation with respect to the Software.
RESTRICTIONS ON USE; RESERVATION OF RIGHTS. The Software and related documentation are protected under copyright laws. RubyTech and/or its
licensors retain all title and ownership in both the Software and its related documentation, including any revisions made by RubyTech. The copyright notice
must be reproduced and included with any copy of any portion of the Software or related documentation. Except as expressly authorized above, Licensee
shall not copy or transfer the Software or related documentation, in whole or in part. Licensee also shall not modify, translate, decompile, disassemble, use
for any competitive analysis, reverse compile or reverse assemble all or any portion of the Software, related documentation or any copy. The Software and
related documentation embody RubyTech’s confidential and proprietary intellectual property. Licensee is not allowed to disclose the Software, or any
information about the operation, design, performance or implementation of the Software and related documentation that is confidential to RubyTech to any
third party. Software and related documentation may be delivered to you subject to export authorization required by governments of Taiwan and other
countries. You agree that you will not export or re-export any Software or related documentation without the proper export licenses required by the
governments of affected countries.
LIMITED SOFTWARE WARRANTY. RubyTech warrants that any media on which the Software is recorded will be free from defects in materials under
normal use for a period of twelve (12) months from date of shipment. If a defect in any such media should occur during the effective warranty period, the
media may be returned to RubyTech, then RubyTech will replace the media. RubyTech shall not be responsible for the replacement of media if the failure of
the media results from accident, abuse or misapplication of the media.
EXCLUSIONS. The warranty as mentioned above does not apply to the Software, which (1) customer does not comply with the manual instructions offered
by RubyTech in installation, operation, or maintenance, (2) Product fails due to damage from unusual external or electrical stress, shipment, storage,
accident, abuse or misuse, (3) Product is used in an extra hazardous environment or activities, (4) any serial number on the Product has been removed or
defaced, or (5) this warranty will be of no effect if the repair is via anyone other than RubyTech or the authorized agents. The maximum liability of RubyTech
under this warranty is confined to the purchase price of the Product covered by this warranty.

iii
DISCLAIMER. EXCEPT AS PROVIDED ABOVE, THE SOFTWARE IS PROVIDED “AS IS ” AND RUBYTECH AND ITS LICENSORS MAKE NO
WARRANTIES, EXPRESS OR IMPLIED, WITH REPSECT TO THE SOFTWARE AND DOCUMENTAITON. RUBYTECH AND ITS LICENSORS DISCLAIM
ALL OTHER WARRANTIES, INCLUSIVE OF WITHOUT LIMITATION, IMPLIED WARRANTIES OR MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND NONINFRINGEMENT. FURTHER, RUBYTECH DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS
REGARDING THE USE, OR THE RESULTS OF THE USE, OF THE SOFTWARE OR RELATED WRITTEN DOCUMENTAITON IN TERMS OF
CORRECTNESS, ACCURACY, RELIABILITY, OR OTHERWISE.
CONSEQUENTIAL DAMAGES. IN NO EVENT SHALL RUBYTECH OR ITS AUTHORIZED RESELLER BE LIABLE TO LICENSEE OR ANY THIRD
PARTY FOR (A) ANY MATTER BEYOND ITS REASONABLE CONTROL OR (B) ANY CONSEQUENTIAL, SPECIAL, INDIRECT OR INCIDENTAL
DAMAGES ARISING OUT OF THIS LICENSE OR USE OF THE SOFTWARE PROVIDED BY RUBYTECH, EVEN IF RUBYTECH HAS BEEN NOTIFIED
OF THE POSSIBILITY OF SUCH DAMAGES IN ADVANCE. IN NO EVENT SHALL THE LIABILITY OF RUBYTECH IN CONNECTION WITH THE
SOFTWARE OR THISAGREEMENT EXCEED THE PRICE PAID TO RUBYTECH FOR THE LICENSE.
TERM AND TERMINATION. The License is effective until terminated; however, all of the restrictions in regard to RubyTech’s copyright in the Software and
related documentation will cease being effective at the date of expiration; Notwithstanding the termination or expiration of the term of this agreement, it is
acknowledged and agreed that those obligations relating to use and disclosure of RubyTech’s confidential information shall survive. Licensee may terminate
this License at any time by destroying the software together with all copies thereof. This License will be immediately terminated if Licensee fails to comply
with any term and condition of the Agreement. Upon any termination of this License for any reason, Licensee shall discontinue to use the Software and shall
destroy or return all copies of the Software and the related documentation.
GENERAL. This License shall be governed by and construed pursuant to the laws of Taiwan. If any portion hereof is held to be invalid or unenforceable,
the remaining provisions of this License shall remain in full force and effect. Neither the License nor this Agreement is assignable or transferable by
Licensee without RubyTech’s prior written consent; any attempt to do so shall be void. This License constitutes the entire License between the parties with
respect to the use of the Software.
LICENSEE ACKNOWLEDGES THAT LICENSEE HAS READ THIS AGREEMENT, UNDERSTANDS IT, AND AGREES TO BE BOUND BY ITS TERMS AND
CONDITIONS. LICENSEE FURTHER AGREES THAT THIS AGREEMENT IS THE ENTIRE AND EXCLUSIVE AGREEMENT BETWEEN RUBYTECH AND
LICENSEE.

iv
Table of Contents
CAUTION...............................................................................................................................VII
ELECTRONIC EMISSION NOTICES............................................................................................VII
1.Introduction...........................................................................................................................2
1-1. OVERVIEW OF ES-2226C.................................................................................................2
1-2. CHECKLIST.......................................................................................................................4
1-3. FEATURES........................................................................................................................4
1-4. VIEW OF ES-2226C .........................................................................................................1
1-4-1. User Interfaces on the Front Panel (Button, LEDs and Plugs)...............................1
1-4-2. User Interfaces on the Rear Panel.........................................................................3
1-5. VIEW OF THE OPTIONAL MODULES.....................................................................................3
2.Installation.............................................................................................................................6
2-1. STARTING ES-2226C UP..................................................................................................6
2-1-1. Hardware and Cable Installation ............................................................................6
2-1-2. Installing Chassis to a 19-Inch Wiring Closet Rail..................................................8
2-1-3. Cabling Requirements............................................................................................8
2-1-3-1. Cabling Requirements for TP Ports ..............................................................................8
2-1-3-2. Cabling Requirements for 1000SX/LX SFP Module .....................................................8
2-1-3-3. Switch Cascading in Topology......................................................................................9
2-1-4. Configuring the Management Agent of ES-2226C...............................................13
2-1-4-1. Configuring the Management Agent of ES-2226C through the Serial RS-232 Port....13
2-1-4-2. Configuring the Management Agent of ES-2226C through the Ethernet Port.............16
2-1-5. IPAddress Assignment.........................................................................................17
2-2.TYPICALAPPLICATIONS ...................................................................................................22
3.Operation of Web-based Management............................................................................24
3-1. WEB MANAGEMENT HOME OVERVIEW .............................................................................26
3-1-1. System Information...............................................................................................29
3-1-2. IP Configuration....................................................................................................31
3-1-3. Time Configuration ...............................................................................................34
3-1-4. Account Configuration ..........................................................................................37
3-1-5. Management Security...........................................................................................38
3-1-6. Virtual Stack..........................................................................................................41
3-1-7. DHCP Option 82...................................................................................................43
3-2. IP-MAC BINDING............................................................................................................45
3-3. PORT CONFIGURATION....................................................................................................47
3-3-1.Port Status.............................................................................................................47
3-3-2. Port Configuration.................................................................................................51
3-2-3. Simple Counter.....................................................................................................53
3-3-4. Detail Counter.......................................................................................................55
3-4. LOOP DETECTION ...........................................................................................................58
3-5. SNMPCONFIGURATION..................................................................................................60
3-6. DHCPBOOT..................................................................................................................62
3-7. MULTICAST.....................................................................................................................63
3-7-1. IGMP Setting ........................................................................................................64
3-7-2. IGMP VLAN ..........................................................................................................65
3-7-3. MVR Setting..........................................................................................................66

v
3-7-4. Group Filtering......................................................................................................67
3-8. VLAN............................................................................................................................69
3-8-1. VLAN Mode ..........................................................................................................69
3-8-2. Tag-based Group..................................................................................................71
3-8-3. PVID .....................................................................................................................74
3-8-4. Port-based Group.................................................................................................75
3-8-5. Management VLAN..............................................................................................77
3-9. MACTABLE ...................................................................................................................78
3-10. GVRPCONFIGURATION................................................................................................84
3-11. STP CONFIGURATION ...................................................................................................90
3-11-1. STP Status..........................................................................................................90
3-11-2. STP Configuration...............................................................................................92
3-11-3. STP Port Configuration.......................................................................................94
3-12.TRUNKING CONFIGURATION...........................................................................................97
3-13. 802.1X CONFIGURATION .............................................................................................104
3-14.ALARM CONFIGURATION..............................................................................................114
3-15. CONFIGURATION.........................................................................................................116
3-15-1. Save/Restore....................................................................................................117
3-15-2. Config File.........................................................................................................120
3-16. SECURITY ..................................................................................................................121
3-17. BANDWIDTH MANAGEMENT .........................................................................................123
3-18. QOS(QUALITY OF SERVICE)CONFIGURATION...............................................................127
3-19.ACL...........................................................................................................................132
3- 20. DIAGNOSTICS ............................................................................................................142
3- 21.TFTPSERVER...........................................................................................................147
3-22. LOG...........................................................................................................................148
3-23. FIRMWARE UPGRADE..................................................................................................150
3-24. REBOOT.....................................................................................................................151
3-25. LOGOUT.....................................................................................................................152
4.Operation of CLI Management........................................................................................153
4-1. CLI MANAGEMENT........................................................................................................153
4-1-1. LOGIN..................................................................................................................153
4-2. COMMANDS OF CLI.......................................................................................................155
4-2-1. Global Commands of CLI..................................................................................156
4-2-2. Local Commands of CLI....................................................................................162
5. Maintenance....................................................................................................................268
5-1. RESOLVING NO LINK CONDITION ...................................................................................268
5-2. Q&A............................................................................................................................268
Appendix A Technical Specifications...............................................................................269
Appendix B Null Modem Cable Specifications................................................................273

vi
Revision History
Release Date Revision
1.0 09/28/2007 A1
1.0 12/07/2007 A2
1.01 04/08/2008 A3
1.01 07/02/2008 A4
1.01 08/25/2008 A4

vii
Caution
Circuit devices are sensitive to static electricity, which can damage their delicate
electronics. Dry weather conditions or walking across a carpeted floor may cause you to
acquire a static electrical charge.
To protect your device, always:
•Touch the metal chassis of your computer to ground the static electrical charge before
you pick up the circuit device.
•Pick up the device by holding it on the left and right edges only.
Electronic Emission Notices
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a class A
computing device pursuant to Subpart J of part 15 of FCC Rules, which are designed to
provide reasonable protection against such interference when operated in a commercial
environment.
European Community (CE) Electromagnetic Compatibility Directive
This equipment has been tested and found to comply with the protection requirements
of European Emission Standard EN55022/EN61000-3 and the Generic European Immunity
Standard EN55024.
EMC:
EN55022(2003)/CISPR-2( 2002) class A
IEC61000-4-2 (2001) 4K V CD, 8KV, AD
IEC61000-4-3( 2002) 3V/m
IEC61000-4-4(2001) 1KV – (power line), 0.5KV – (signal line)

About this user’s manual
In this user’s manual, it will not only tell you how to install and connect your
network system but configure and monitor the ES-2226C through the built-in CLI
and web by RS-232 serial interface and Ethernet ports step-by-step. Many
explanation in detail of hardware and software functions are shown as well as the
examples of the operation for web-based interface and command-line interface
(CLI).
Overview of this user’s manual
Chapter 1 “Introduction” describes the features of ES-2226C
Chapter 2 “Installation”
Chapter 3 “Operation of Web-based Management”
Chapter 4 “Operation of CLI Management”
Chapter 5 “Maintenance”

ES-2226C User Manual
2
1. Introduction
1-1. Overview of ES-2226C
ES-2226C, 24 Fast Ethernet + 2 Gigabit L2 Managed Switch, implemented
24 10/100Mbps TP + 2 Gigabit dual media ports with TP/SFP(or GBIC), is a
standard switch that meets all IEEE 802.3/u/x/z Gigabit, Fast Ethernet and Ethernet
specifications. The switch can be managed through RS-232 serial port via directly
connection, or through Ethernet port using Telnet or Web-based management unit,
associated with SNMP agent. With the SNMP agent, the network administrator can
logon the switch to monitor, configure and control each port’s activity in a friendly
way. The overall network management is enhanced and the network efficiency is
also improved to accommodate high bandwidth applications. In addition, the switch
features comprehensive and useful function such as DHCP Option 82, QoS (Quality
of Service), Spanning Tree, VLAN, Port Trunking, Bandwidth Control, Port Security,
SNMP/RMON and IGMP Snooping capability via the intelligent software. It is
suitable for both metro-LAN and office application.
• Model Description
Model Port 25, 26 Configurations
ES-2226C Two types of media --- TP and SFP Fiber
ES-2226C Two types of media --- TP and GBIC Fiber
10/100/1000Mbps TP is a standard Ethernet port that meets all IEEE
802.3/u/x/z Gigabit, Fast Ethernet specifications. 1000Mbps SFP Fiber transceiver
is a Gigabit Ethernet port that fully complies with all IEEE 802.3z and 1000Base-
SX/LX standards.
1000Mbps Single Fiber WDM (BiDi) transceiver is designed with an optic
Wavelength Division Multiplexing (WDM) technology that transports bi-directional
full duplex signal over a single fiber simultaneously.
For upgrading firmware, please refer to the Section 3-20 or Section 4-2-2 for
more details. The switch will not stop operating while upgrading firmware and after
that, the configuration keeps unchanged.

ES-2226C User Manual
Publication date: Aug., 2008
Revision A4
3
• Key Features in the Device
DHCP Option 82:
This feature enables the Dynamic Host Configuration Protocol (DHCP)
relay agent information (option 82) (ES-2226C switch) to include
information about itself and the attached client when forwarding DHCP
requests from a DHCP client to a DHCP server via Trust Port. The DHCP
server can use this information to assign IP addresses、gateway、subnet
mask、DNS for each subscriber of a service-provider network.
QoS:
Support Quality of Service by the IEEE 802.1P standard. There are two
priority queue and packet transmission schedule using Weighted Round
Robin (WRR). User-defined weight classification of packet priority can be
based on either VLAN tag on packets or user-defined port priority.
Spanning Tree:
Support IEEE 802.1D, IEEE 802.1w (RSTP: Rapid Spanning Tree
Protocol) standards.
VLAN:
Support Port-based VLAN and IEEE802.1Q Tag VLAN. Support 256 active
VLANs and VLAN ID 1~4094.
Port Trunking:
Support static port trunking and port trunking with IEEE 802.3ad LACP.
Bandwidth Control:
Support ingress and egress per port bandwidth control.
Port Security:
Support allowed, denied forwarding and port security with MAC address.
SNMP/RMON:
SNMP agent and RMON MIB. In the device, SNMP agent is a client
software which is operating over SNMP protocol used to receive the
command from SNMP manager (server site) and echo the corresponded
data, i.e. MIB object. Besides, SNMP agent will actively issue TRAP
information when happened.
RMON is the abbreviation of Remote Network Monitoring and is a branch of
the SNMP MIB.
The device supports MIB-2 (RFC 1213), Bridge MIB (RFC 1493), RMON
MIB (RFC 1757)-statistics Group 1,2,3,9, Ethernet-like MIB (RFC 1643) and
so on.
IGMP Snooping:
Support IGMP version 2 (RFC 2236): The function IGMP snooping is used
to establish the multicast groups to forward the multicast packet to the
member ports, and, in nature, avoid wasting the bandwidth while IP
multicast packets are running over the network.

ES-2226C User Manual
4
1-2. Checklist
Before you start installing the switch, verify that the package contains the
following:
⎯ES-2226C 24 Fast Ethernet + 2 Gigabit L2 Managed Switch
⎯Modules (optional)
⎯Mounting Accessory (for 19” Rack Shelf)
⎯This User's Manual in CD-ROM
⎯AC Power Cord
⎯RS-232 Cable
Please notify your sales representative immediately if any of the aforementioned
items is missing or damaged.
1-3. Features
The ES-2226C, a standalone off-the-shelf switch, provides the
comprehensive features listed below for users to perform system network
administration and efficiently and securely serve your network.
• Hardware
• Supports 24-port 10/100M TP ports with Nway and auto MDIX function
• In ES-2226C, it supports 2 Gigabit dual media ports(TP/SFP) and 2 slots for
removable SFP module supporting 1000M SFP fiber module
• In ES-2226C, it supports 2 Gigabit dual media ports(TP/GBIC) and 2 slots for
removable GBIC module supporting 1000M GBIC fiber module
• Supports on-line pluggable fiber transceiver modules
•Supports 256KB packet buffer and 128KB control memory
• Maximal packet length can be up to 1536 bytes
• Full-duplex flow control (IEEE802.3x) and half-duplex backpressure
• Extensive front-panel diagnostic LEDs; System: Power, CPURUN, ACT / FDX /
SPD(LEDSET), 10/100Mbps TP Port1-24:LINK/ACT, FDX, SPD,
10/100/1000Mbps/Fiber port 25, 26: LINK/ACT, FDX, SPD
• Management
•Supports concisely the status of port and easily port configuration
•Supports per port traffic monitoring counters
• Supports a snapshot of the system Information when you login
• Supports port mirror function
• Supports the static trunk function

ES-2226C User Manual
Publication date: Aug., 2008
Revision A4
5
• Supports 802.1Q VLAN with 256 entries.
• Supports user management and limits three users to login
• Supports DHCP Broadcasting Suppression to avoid network suspended or
crashed
• Supports to send the trap event while monitored events happened
•Supports default configuration which can be restored to overwrite the current
configuration which is working on via web browser and CLI
• Supports on-line plug/unplug SFP/GBIC modules
• Supports 5 kinds of QoS, are as follows, MAC Priority, 802.1p Priority, IP TOS
Priority, and DiffServ DSCP Priority.
• Built-in web-based management and CLI management, providing a more
convenient UI for the user
• Supports port mirror function with ingress/egress traffic
•Supports rapid spanning tree (802.1w RSTP)
• Supports 802.1x port security on a VLAN
• Supports user management and only first login administrator can configure the
device. The rest of users can only view the switch
• SNMP access can be disabled and prevent from illegal SNMP access
• Supports Ingress, Non-unicast and Egress Bandwidth rating management
• The trap event and alarm message can be transferred via e-mail and mobile
phone short message
• Supports diagnostics to let administrator knowing the hardware status
•Supports external loopback test to check if the link is ok
• TFTP for firmware upgrade, system log upload and config file import/export
• Supports remote boot the device through user interface and SNMP
• Supports network time synchronization and daylight saving
• Supports 120 event log records in the main memory and display on the local
console

1-4. View of ES-2226C
1-4-1. User Interfaces on the Front Panel (Button, LEDs and Plugs)
There are 24 TP Fast Ethernet ports and 2 slots for optional removable
modules on the front panel of the switch. LED display area, locating on the front
panel, contains a CPURUN, Power LED and 26 ports working status of the switch.
Fig. 1-1 Full View of ES-2226C with SFP/GBIC Module
Fig. 1-2 Front View of ES-2226C with SFP Module
Power Indication
Fast Ethernet
LED SET Mode: ACT/FDX/SPD
Gi
g
abit Dual Media Port:
TP Port Status:
TP Port Status: Link
LEDSET Button
LEDSET button
is used to
change the LED
dis
p
la
y
mode
RESET Button:
RESET button is used to
reset the management
system.

ES-2226C User Manual
2
• LED Indicators
LED Color Function
System LED
CPURUN Green Lit when CPU is on and good
POWER Green Lit when AC power is on and good
ACT Green Lit when LEDSET set on active mode
FDX Green Lit when LEDSET set on full-duplex mode
SPD Green Lit when LEDSET set on speed mode
10/100Mbps Ethernet TP Port 1 to 24 LED
LNK Green
Lit when connection with remote device is good
Off when cable connection is not good
ACT/FDX/ SPD
Amber
(TP Port 1 to
24 LED)
a. LEDSET set on ACT (active) mode:
Blinks when any traffic is present
b. LEDSET set on FDX (full-duplex) mode:
Lit when full-duplex mode is active
Blinks when any collision is present
c. LEDSET set on SPD (speed) mode:
Lit when 100Mbps speed is active
Off when 10Mbps speed is active
10/100/1000Mbps Gigabit TP/Fiber Port 25, 26 LED
LNK Green
Lit when connection with remote device is good
Off when cable connection is not good
FB Green
Lit when Fiber port is active
Off when TP port is active
ACT/FDX/ SPD
Green
(Port 25,
26 LED)
a. LEDSET set on ACT (active) mode:
Blinks when any traffic is present
b. LEDSET set on FDX (full-duplex) mode:
Lit when full-duplex mode is active
Blinks when any collision is present
c. LEDSET set on SPD (speed) mode:
Lit when 1000Mbps speed is active
Off when 10/100Mbps speed is active
Table1-1

ES-2226C User Manual
Publication date: Aug., 2008
Revision A4
3
1-4-2. User Interfaces on the Rear Panel
One RS-232 DB-9 interface is offered for configuration or management. And
there is one AC power input socket for having the switch powered on or off.
1-5. View of the Optional Modules
In the switch, Port 25, 26 includes two types of media --- TP and SFP Fiber
(LC, BiDi LC…); this port supports 10/100/1000Mbps TP or 1000Mbps SFP Fiber
with auto-detected function. 1000Mbps SFP Fiber transceiver is used for high-
speed connection expansion; the following are optional SFP types provided for the
switch:
⎯1000Mbps LC, MM, SFP Fiber transceiver (SFP.0LC.202)
⎯1000Mbps LC, SM 10km, SFP Fiber transceiver (SFP.0LC.212.10)
⎯1000Mbps LC, SM 30km, SFP Fiber transceiver (SFP.0LC.212.30)
⎯1000Mbps LC, SM 50km, SFP Fiber transceiver (SFP.0LC.212.50)
⎯1000Mbps BiDi LC, type 1, SM 20km, SFP Fiber WDM transceiver
(SFP.0BL.621.201)
⎯1000Mbps BiDi LC, type 2, SM 20km, SFP Fiber WDM transceiver
(SFP.0BL.621.202)
⎯1000Mbps LC, SM 10km, SFP Fiber transceiver with DDM
(SFP.DLC.212.10)
Fig. 1-3 Rear View of ES-2226C
RS-232 DB-9 Connector
A
C Line 100-240V 50/60 Hz
Fig. 1-4 Front View of 1000Base-SX/LX LC, SFP Fiber Transceiver

ES-2226C User Manual
4
Fig. 1-5 Front View of 1000Base-LX BiDi LC, SFP Fiber Transceiver
