VIOMI VH1Z-A User manual

Model : VH1Z-A
Please read the product manual before using and keep it for future use.
Water Filter Pitcher ( )
UV
User Manual

Warning
To reduce the risk of serious personal injury:
1
This product is intended to filter tap water only. Do not use water of unknown quality or that has been
microbiologically impaired.
Use VIOMI filter only, the use of any other filter will produce unknown results and is not recommended.
Children shall not play with the appliance.
Dispose of the disassembled packaging in time and do not let children touch or swallow.
Use this product only as indicated in these instructions.
Caution
Place only cold or room temperature water into the product for filtering.
Avoid passing warm or hot water through the filter.
Do not boil any part of this product.
Do not use harsh or abrasive cleaners or pads on the product.
Do not place any part of this product in dishwasher for cleaning.
If the pitcher or reservoir is broken or cracked, replace the whole product. If the filter is
damaged, replace only the filter.
To reduce the risk of personal injury or product property damage:
VIOMI filter has been tested and verified by independent laboratory testing and also complies with
NSF/ANSI 58 Standard.
Advantages
7-Stages Filter
Advanced filtration system that includes a 7-stage process. This system is more complete than normal
carbon water filtration. It filters all the impurities such as lead, mercury, aluminum, zinc, chlorine, and
chemicals. As a result, the water tastes good, has no odor and still has the beneficial fluoride.
Ultraviolet Disinfection
The pitcher features a unique UV Disinfection Device that can remove from water up to 99% of
Escherichia coli, staphylococcus aureus, klebsiella pneumoniae, salmonella enteritidis, shigella
dysenteriae. So it produces clean and balanced water that has a great taste, free of harmful
contaminants and still rich in healthy minerals.

Product Overview
Accessories
Filter USB Cable
Reservoir Fill Door
Anti Dust Cap
Filter
Reservoir
Pitcher
Ultraviolet
Disinfection Device
Lid
Filter Life Indicator
Reset Button
2
Water Filter Pitcher
VH1Z-A
3.5 L
50 L/ filter
0.1 L/ min
Tap Water
5~38 ℃/41~100.4℉
0~0.1MPa
5~45 ℃/41~113℉
940mAh
1.0kg/2.2lb
26.55x14.55x26.2 CM
Item Name
Filter Capacity
Filter Type
Item Model
Storage Capacity
Filter Flow
Rated Capacity
Working Temperature
Working Pressure
Battery Capacity
Input Voltage
Net Weight
Item Size
Water Temperature
1.5 L/ time
5V 0.5A

Preparations
Unpacking Pitcher, Reservoir and Filter
1
Hand wash pitcher, lid and reservoir with a
soft cloth soaked in mild detergent and water.
Do not use abrasive cleaners. Rinse well.
Prepare the Filter
2
NOTE: Do not wash the pitcher in dishwasher;
Do not immerse it with charging connector in water.
Soak the filter upright in cold water for 10 minutes,
gently shaking it to remove air bubbles. Then rinse
filter under running tap water for a few seconds.
TIP: Use purified water to immerse the filter for
better filtering effect activation.
NOTE: Do not immerse the filter in pitcher to
avoid damage of UV disinfection device.
Installation the Filter
3
Press the filter firmly down into the tube of the
reservoir to ensure a tight seal.
Put the reservoir back to pitcher, and cover
with the lid.
Fill the reservoir with cold tap water and allow
the water to filter through.
Discard your first two pitchers of filtered water
(about 3L water), or use this water for plants.
Set the Filter Life Indicator
4
TIP: It is normal to appear grey water in your first two filterings because of the carbon dust.
Long press the reset button for 3 seconds until
all lights on to turn on the filter life indicator.
3
3.1
3.2
3.3
3.4

Operation Instructions
Filling Water
Fill tap water(about 1.5L) into reservoir
through reservoir fill door (automatically
open with enough water pressure).
12Filtration
Pour tap water on the side of the reservoir
rather than directly on top of the filter.
Allow water to filter completely before pouring
or refilling reservoir.
3Disinfection
When water reaches the level of UV
disinfection device, press the touch button
to turn on the light to work.
It will stop working in 2 minutes, the indicator
will automatically light off.
Then the water in pitcher is ready for drinking.
4Charging UV Disinfection Device
Use the USB charging cable in the package.
Connect the device with 5V output, such as phone
charger or computer USB connector.
The red light will turn on when charging; the blue
light will turn on after full charging.
NOTE: UV disinfection device could not be turn
on if the water did not cover the device. NOTE: DO NOT use the device when charging
4
FOR BEST RESULT: Store the pitcher in the refrigerator or in a cool location. If the water has been leaving for
several days, discard it and refill the pitcher with fresh water.

Replacing Filter
5
Check
1
Press the STATUS button, blue
indicator lights will show the
filter life remain.
For example, when “25%” indicator
flashes quickly, it means the filter
need to be changed soon.
Replace
2
Take out the used filter and follow
the first time use instructions to
prepare and install the new filter.
TIP: New filter is available on Amazon
or any other VIOMI distributors.
Reset
3
Long press the reset button for
3 seconds till all lights on, which
means the new filter reset
successfully and ready to work.
Replacing Indicator
1Hold the Buttons from Two Sides
Two fingers firmly hold the lock buttons
until the indicator could be took out.
NOTE: The filter life indicator contains a non
-replaceable sealed battery designed to last
2 years, depending on usage. After 2 years
the pitcher is still functional, the indicator will
eventually stop working.
2Replace the Indicator
Take out used indicator and replace it
with a new one.
TIP: New filter life indicator is available on
Amazon or any other VIOMI distributors.
SUGGESTION: For maximum efficiency and hygiene, it is suggested to change filter every 6 weeks.

Troubleshooting
6
Problem Cause Solution
Filter does not pass water
or do it slowly
Filter service life expired Replace filter
Filter has not been soaked
for 10 minutes before use
Soak the filter for 10 minutes
before use
Carbon material stuck Take out filter, shake it
and reinstall
Water leakage from filter Sealing gasket has not been
installed well or deformed
Reinstall the dealing gasket
or replace a new one
UV indicator fails to light up
Water does not reaches the
level of UV lamp
Battery is dead
Touch switch is dirty
Fill water to cover UV lamp
and press the button
Charge the battery
Clean switch with cloth
The lid can`t be closed tightly Reservoir does not install
well to the pitcher Reinstall the reservoir
Warranty
VIOMI guarantees the consumer THE PERIOD OF NINETY (90) DAYS from the date of purchase, except for
the filter which is warranted for 30 days.
During this 90-day period, if you discover that any parts of the VIOMI pitcher are damaged or broken, due to
any manufacturing defects, we will replace the parts free of charge.
VIOMI water filter pitcher, when used strictly in accordance with instructions, has the effects on municipally
treated, potable tap water described in the enclosed literature.
Please contact your seller or any other VIOMI distributors if you need any other service or help.
