Viper 650xv User manual

650XV

Installation Guide

N436V 10-02

NOTE: This product is intended for installation by a professional installer only!

Any attempt to install this product by any person other than a trained professional

may result in severe damage to a vehicle’s electrical system and components.

Bitwriter™, Code Hopping™, DEI®, Doubleguard®, ESP™, FailSafe®, Ghost Switch™, Learn

Routine™, Nite-Lite®, Nuisance Prevention® Circuitry, NPC®, Revenger®, Silent Mode™,

Soft Chirp®, Stinger®, Valet®, Vehicle Recovery System®, VRS®, and Warn Away® are all

Trademarks or Registered Trademarks of Directed Electronics, Inc.

The Bitwriter®(p/n 998T)

requires chip version 1.4 or

newer to program this unit.

wwwwww..ddiirreecctteecchhss..ccoomm

DDiirreeccttFFaaxx880000--999999--11332299TTeecchhnniiccaallSSuuppppoorrtt880000--775533--00880000

These resources are for authorized Directed Dealer use only.

Directed Electronics, Inc.

Table of Contents

PPrriimmaarryyHHaarrnneessss((HH11))WWiirreeCCoonnnneeccttiioonnGGuuiiddee....................................................................................................................................................44

Primary Harness Wiring Diagram ............................................................................................4

Primary Harness Wiring Instructions .......................................................................................4

DDoooorrLLoocckkHHaarrnneessss((HH22)),,33--PPIINNCCoonnnneeccttoorr..........................................................................................................................................................1100

PPeerriipphheerraallPPlluugg--IInnHHaarrnneesssseess..........................................................................................................................................................................................................1100

Super Bright LED, 2-Pin WHITE Plug .................................................................................10

Valet/Program Switch, 2-Pin BLUE Plug ...............................................................................11

Programmer Interface, 3-Pin BLACK Plug ............................................................................11

Mounting the Receiver/Antenna ............................................................................................11

Shock Sensor Harness, 4-Pin White Plug ...............................................................................12

PPrrooggrraammmmiinnggJJuummppeerr................................................................................................................................................................................................................................1133

Light Flash Jumper ................................................................................................................13

BByyppaassssiinnggSSeennssoorrIInnppuuttss..........................................................................................................................................................................................................................1144

SSyysstteemmFFeeaattuurreessLLeeaarrnnRRoouuttiinnee....................................................................................................................................................................................................1144

SSyysstteemmFFeeaattuurreessMMeennuuss............................................................................................................................................................................................................................1177

Menu #1 - Basic Features .......................................................................................................17

Menu #2 - Advanced Features ................................................................................................17

FFeeaattuurreeDDeessccrriippttiioonnss....................................................................................................................................................................................................................................1188

Menu #1 - Basic Features .......................................................................................................18

Menu #2 - Advanced Features ................................................................................................19

TTrraannssmmiitttteerr//RReecceeiivveerrLLeeaarrnnRRoouuttiinnee....................................................................................................................................................................................2211

TTrraannssmmiitttteerrCCoonnffiigguurraattiioonnss..............................................................................................................................................................................................................2233

Standard Configuration .........................................................................................................23

Single Button Arm/Disarm Configuration .............................................................................23

DDiiaaggnnoossttiiccss................................................................................................................................................................................................................................................................2244

Arm/Disarm Diagnostics ........................................................................................................24

System Status Chirps...............................................................................................................24

Table of Zones .......................................................................................................................24

LLoonnggTTeerrmmEEvveennttHHiissttoorryy....................................................................................................................................................................................................................2255

MMuullttii--LLeevveellSSeeccuurriittyyAArrmmiinngg..........................................................................................................................................................................................................2255

OOppttiioonnaallVVeehhiicclleeRReeccoovveerryySSyysstteemm((VVRRSS))..................................................................................................................................................................2266

NNuuiissaanncceePPrreevveennttiioonn®®CCiirrccuuiittrryy................................................................................................................................................................................................2266

RRaappiiddRReessuummeeLLooggiicc....................................................................................................................................................................................................................................2266

TTrroouubblleesshhoooottiinngg................................................................................................................................................................................................................................................2277

WWiirriinnggQQuuiicckkRReeffeerreenncceeGGuuiiddee......................................................................................................................................................................................................2288

Directed Electronics, Inc.

Primary Harness (H1)Wire Connection Guide

Primary Harness Wiring Diagram

___

Primary Harness Wiring Instructions

This guide describes in detail the connection of each wire. Also included are possible applications

of each wire. This system was designed with the ultimate in flexibility and security in mind. Many

of the wires have more than one possible function. Please read carefully to ensure a thorough under-

standing of this unit.

H1/1 ORANGE (-) ground-when-armed output

This wire supplies a (-) ground as long as the system is armed. This output ceases as soon as the

system is disarmed. The ORANGE wire is pre-wired to control the 8618 starter kill relay. It can

supply up to 500 mA of current.

NOTE: If using the H1/1 ORANGE wire to activate an add-on accessory such as window

automation, pager or voice module a 1Amp diode must be installed to ensure proper operation.

Insert the diode as shown in the following diagram.

RED/WHITE (-) 200 mA Channel 2 Output

RED (+) Constant Power Input

BROWN (+) Siren Output

YELLOW (+) Switched Ignition Input, Zone 5

BLACK (-) Chassis Ground Input

VIOLET (+) Door Trigger Input, Zone 3

BLUE (-) Instant Trigger Input, Zone 1

GREEN (-) Door Trigger Input, Zone 3

BLACK/WHITE (-) 200 mA Domelight Supervision Output

WHITE/BLUE (-) 200 mA Channel 3 Programmable Output

WHITE (+)/(-) Selectable Light Flash Output

ORANGE (-) 500 mA Armed Output

H1/1

H1/2

H1/3

H1/4

H1/5

H1/6

H1/7

H1/8

H1/9

H1/10

H1/11

H1/12

Directed Electronics, Inc.

H1/2 WHITE (+/-) light flash output

As shipped, the H1/2 WHITE wire should be connected to the (+) parking light wire. If the light flash

polarity jumper is moved to the (-) position (see the Programming Jumper section of this installation

guide), this wire supplies a (-) 200 mA output. This is suitable for driving (-) light control wires in

Toyota, Lexus, BMW, some Mitsubishi, some Mazda, and other models.

NOTE: For parking light systems that draw 10 amps or more, the jumper must be switched to a

(-) light flash output (see the Programming Jumpers section of this guide). P/N 8617 or a standard

automotive SPDT relay must be used on the H1/2 light flash output wire.

IMPORTANT! DO NOT connect this wire to a negative vehicle light flash wire before

changing the programming jumper to the negative polarity position or damage to

vehicle light circuit may occur.

IMPORTANT! Never interrupt any wire other than the starter wire.

Directed Electronics, Inc.

H1/3 WHITE/BLUE 200 mA (-) channel 3 output

This wire provides a (-) 200 mA output whenever the transmitter button(s) controlling Channel 3

is pressed. This output can be programmed to provide the following types of output (see System

Features Learn Routine section of this guide):

➤➤A vvaalliiddiittyyoutput will send a signal as long as the transmission is received.

➤➤A llaattcchheeddoutput will send a signal continuously when the Channel 3 button(s) is pressed and

released. The signal will continue until channel three is pressed again.

➤➤A llaattcchheedd//rreesseettwwiitthhiiggnniittiioonnoutput works similar to the latched output, but will also reset

(output will stop) when the ignition is turned on and then off.

➤➤A 3300sseeccoonnddttiimmeeddoutput will send a signal for 30 seconds when channel three is pressed. This

output can be shut off during the 30-second period by pressing Channel 3 again.

➤➤This output can also be programmed to provide a sseeccoonndduunnlloocckkppuullsseewhen the unlock button

is pressed a second time after disarming the system. This can be used to unlock the passenger

doors when installing progressive door locks.

H1/4 BLACK/WHITE (-) 200 mA domelight supervision output

Connect the H1/4 wire to the optional domelight supervision relay as shown in the following

diagram:

IMPORTANT! This output is only intended to drive a relay. It cannot be connected

directly to the domelight circuit, as the output cannot support the current draw of one

or more bulbs.

IMPORTANT! Never use this wire to drive anything but a relay or a low-current input!

This transistorized output can only supply 200 mA, and connecting directly to a

solenoid, motor, or other high-current device will cause the module to fail.

Directed Electronics, Inc.

H1/5 GREEN (-) door trigger input

Most vehicles use negative door trigger circuits. Connect the GREEN wire to a wire showing

ground when any door is opened. When connecting to newer model vehicles there is generally a

need to use individual door triggers. See DirectFax document 1076 for wiring instructions. This

wire will report Zone 3.

NOTE: If using a door trigger wire that has a delay, Advanced Menu 2, feature 6, or the 998T

Bitwriter can be used to turn Bypass Notification off.

H1/6 BLUE (-) instant trigger input

This input will respond to a negative input with an instant trigger. It is ideal for hood and trunk pins

and will report on Zone 1. It can also be used with Directed single-stage sensors. The H1/6 BLUE

instant trigger wire can also be used to shunt sensors during operation of auxiliary channels or remote

start. (See Bypassing Sensor Inputs section of this guide.)

H1/7 VIOLET (+) door trigger input

This type of dome circuit is used in many Ford products. Connect the VIOLET wire to a wire that

shows (+)12V when any door is opened. This wire will report Zone 3.

NOTE: If using a door trigger wire that has a delay, Advanced Menu 2, feature 6, or the 998T

Bitwriter can be used to turn Bypass Notification off.

Directed Electronics, Inc.

H1/8 BLACK (-) chassis ground connection

Connect this wire to a clean, paint-free sheet metal location (driver kick panel) using a factory bolt

that DOES NOT have any vehicle component grounds attached to it. A screw should only be used

when in conjunction with a two-sided lock washer. Under dash brackets and door sheet metal are

not acceptable ground points. It is recommended that all security components be grounded at the

same location.

H1/9 YELLOW (+) ignition input

Connect this wire to the (+) 12 volts ignition wire. This wire is pre-wired to the starter kill relay and

must show (+) 12 volts with the key in RUN position and during cranking. Take great care that this

wire cannot be shorted to the chassis at any point.

\\\\\\\

H1/10 BROWN (+) siren output

Connect this to the RED wire of the Revenger® siren. Connect the BLACK wire of the siren to (-)

chassis ground, preferably at the same point you connect the control module’s BLACK ground wire.

Directed Electronics, Inc.

H1/11 RED (+)12V constant power input

Before connecting this wire, remove the supplied fuse. Connect to the battery positive terminal or

the constant 12V supply to the ignition switch.

NOTE: Always use a fuse within 12 inches of the point you obtain (+)12V. Do not use the 15 fuse

in the harness for this purpose. This fuse protects the module itself.

H1/12 RED/WHITE 200 mA (-) channel 2 output

When the system receives the code controlling channel 2 for longer than 1.5 seconds, the

RED/WHITE will supply an output as long as the transmission continues. This is often used to

operate a trunk/hatch release or other relay/driven function.

IMPORTANT! Never use this wire to drive anything but a relay or a low-current input!

The transistorized output can only supply 200 mA of current. Connecting directly to a

solenoid, motor, or other high-current device will cause it to fail.

Directed Electronics, Inc.

Door Lock Harness (H2), 3-PIN Connector

___

NOTE: For detailed instructions about connecting to the vehicle’s power door lock systems, refer

to the Door Lock Wiring guide (Document No. 1041) available to authorized dealers only from the

technical resources listed at the front of this guide.

Peripheral Plug-In Harnesses

Super Bright LED, 2-Pin WHITE Plug

The super bright LED operates at (+) 2 volt DC and plugs into the two-pin WHITE port. Make

sure the LED wires are not shorted to ground as the LED will be damaged. Multiple LED’s can be

used, but they must be wired in series. The LED fits into a 9/32-inch mounting hole. Be sure to

check for clearance prior to drilling the mounting hole.

NOTE: Never use a BLUE LED in combination with a RED LED.

DIA-41

IMPORTANT! The door lock outputs are low current and should not be attached

directly to any high current device; they are only to be used to activate relays

Blue (-) Unlock, (+) Lock Output

Empty Unless Using 451M

Green (-) Lock, (+) Unlock Output

H2/A

H2/B

H2/C

Directed Electronics, Inc.

Valet/Program Switch, 2-Pin BLUE Plug

The Valet/Program button should be accessible from the driver’s seat. It plugs into the BLUE port

on the side of the unit. Since the system features Valet® by using the remote transmitter, the button

can be well hidden. Consider how the button will be used before choosing a mounting location.

Check for rear clearance before drilling a 9/32-inch hole and mounting the button.The GRAY wire

in the two-pin plug may also be used as a (+) ghost switch input and can be connected to any (+)

switch in the vehicle. (See Feature Descriptions section of this guide.)

Programmer Interface, 3-Pin BLACK Plug

The BLACK three-pin port is provided for programming of the unit. When using the 998T

Bitwriter, it is possible to configure any and all of the programmable functions. For more infor-

mation please refer to the guide packaged with the programmer. This port can also be used to interface

with Directed Video components for on-screen security system programming and trigger information.

Mounting the Receiver/Antenna

Receiver/antenna position should be discussed with the vehicle’s owner prior to installation, since

the antenna may be visible to the vehicle’s operator.

The best location for the receiver/antenna is centered high on either the front or rear windshield.

For optimal range, the antenna should be mounted vertically. It can be mounted horizontally in

relation to the windshield or under the dashboard away from metal, but range will be diminished.

Metallic window tint can also affect range, so this should be a consideration when determining the

mounting location.

After determining the best mounting location, follow these steps:

1. Clean the mounting area with a quality glass cleaner or alcohol to remove any dirt or residue.

2. Plug the receiver/antenna cable into the receiver/antenna.

Directed Electronics, Inc.

3. Mount the receiver/antenna using the supplied double-sided tape.

4. Route the receiver/antenna cable to the control module and plug it into the four-pin antenna

connector.

Shock Sensor Harness, 4-Pin White Plug

GREEN (-) Multiplex Input

Inputs shorter than 0.8 seconds will trigger the Warn Away® response, while inputs longer than 0.8

seconds will trigger full alarm sequence and report Zone 4.

NOTE: If installing an optional Directed dual-stage sensor, connect to the GREEN wire. The

following diagram eliminates the need for diodes to isolate the sensors, as well as providing a

separate zone for each sensor.

Diagram for adding optional Directed dual stage sensor to GREEN wire (zone 4).

IMPORTANT! To achieve the best possible range, DO NOT leave the antenna cable

bundled under the dash. Always extend the cable full length during installation,

regardless of the antenna mounting location.

Directed Electronics, Inc.

BLUE (-) Multiplex Input

Inputs shorter than 0.8 seconds will trigger the Warn Away® response, while inputs longer than 0.8

seconds will trigger full alarm sequence and report Zone 2.

RED (+) 12V Constant and BLACK (-) Ground

Do not use these for anything besides the plug-in shock sensor.

Programming Jumper

Light Flash Jumper

This jumper is used to determine the light flash output. In the (+) position, the on-board relay is

enabled and the unit will output (+)12V on the WHITE wire, H1/2. In the (-) position, the on-

board relay is disabled. The WHITE wire, H1/2, will supply a 200 mA (-) output suitable for

driving factory parking light relays.

NOTE: For parking light circuits that draw 10 amps or more, the jumper must be switched to a (-)

light flash output. P/N 8617 or a standard automotive SPDT relay must be used on the H1/2 light

flash output harness wire.

IMPORTANT! DO NOT connect the H1/2 light flash wire to a negative vehicle light

flash wire before changing the programming jumper to the negative polarity position or

damage to vehicle light circuit may occur.

Directed Electronics, Inc.

Bypassing Sensor Inputs

There are times when you need to temporarily bypass all sensor inputs to the unit, such as when

remote starting the vehicle. Anytime an auxiliary channel output is used, all inputs are bypassed for

five seconds. During the five second bypass period, ground can be supplied to the H1/6 BLUE wire

without triggering the unit. When the five second bypass period ends, if the unit sees ground on

the H1/6 BLUE wire, all trigger inputs except the door trigger input will remain bypassed until five

seconds after ground is removed from the BLUE wire. This can be done using the status output of

a Directed Electronics remote engine starting unit as shown in the following diagram:

System Features Learn Routine

The System Features Learn Routine dictates how the unit operates. Due to the number of steps,

they have been broken up into two menus. It is possible to access and change any of the feature

settings using the Valet/Program switch. However, this process can be greatly simplified by using the

998T Bitwriter. Any of the settings can be changed and then assigned to a particular transmitter, up

to four, a feature called Owner Recognition. Each time that particular transmitter is used to disarm

the system, the assigned feature settings will be recalled. Owner Recognition is only possible when

programming the unit via the 998T Bitwriter.

If the system was previously programmed using the 998T Bitwriter, the learn routine may be

locked. If the siren generates one long chirp when attempting to program the unit, the learn routine

is locked and must be unlocked using the 998T Bitwriter.

1. OOppeennaaddoooorr..(The H1/5 GREEN wire or the H1/7 VIOLET wire must be

connected.)

Directed Electronics, Inc.

2. IIggnniittiioonn..Turn the ignition on, then back off: (The H1/9 YELLOW wire must

be connected.)

3. SSeelleeccttaaMMeennuu..Press and HOLD the Valet/Program switch: (The

Valet/Program switch must be plugged into the blue port.) After three seconds

the siren will chirp once indicating entry to the Basic Features Menu #1. If this

is the menu you wish to access, release the button and go on to Step 4. If the

button is not released, you will jump to the Advanced Features Menu #2 and

the siren will chirp twice. Once you have selected the desired menu, release the

Valet/Program button and then proceed to Step 4.

4. SSeelleeccttaaFFeeaattuurree..Press and release the Valet/Program switch the number of

times corresponding to the feature you wish to change. For example, to access

the third feature, press and release the switch three times. Then press the switch

once more and HOLD it. The siren will chirp the number of times equal to

the step you have accessed.

5. PPrrooggrraammtthheeFFeeaattuurree..While HOLDING the Valet/Program switch, you can

toggle the feature on and off using the remote transmitter. Pressing will

select the one chirp setting. Pressing will select the two chirp

setting. (See System Features Menus section of this guide.)

NOTE: The Valet pulse count feature (2-5) and the Channel three timed

output (2-9) have five possible settings each. Pressing will toggle through

all the two-chirp settings.

6. RReelleeaasseetthheeVVaalleett//PPrrooggrraammSSwwiittcchh..

Once a feature is programmed:

➤➤Other features can be programmed within the same menu.

➤➤Another menu can be selected.

➤➤The learn routine can be exited if programming is complete.

Directed Electronics, Inc.

To access another feature in the same menu:

1. Press and release the Valet/Program switch the number of times necessary to advance from the

feature you just programmed to the next one you want to program.

2. Then press the Valet/Program switch once more and HOLD it.

For example, if you just programmed the third feature in the menu and you would like to program

the seventh feature in the menu, you would press and release the Valet/Program switch four times

and then press it once more and HOLD it. The siren would chirp seven times to confirm access to

the seventh feature.

To select another menu:

1. Press and HOLD the Valet/Program switch.

2. After three seconds, the unit will advance to the next menu and the siren will chirp, indicating

which menu has been accessed.

For instance, if you just programmed some features in Menu #1 (Basic Features) and you wish to

program a feature in Menu #2, you press and HOLD the Valet/Program button. After three

seconds, the siren chirps twice indicating access to Menu #2.

To exit the learn routine do one of the following:

➤➤Close the open door.

➤➤Turn the ignition on.

➤➤No activity for longer than 15 seconds.

➤➤Press the Valet/Program switch too many times.

Directed Electronics, Inc.

System Features Menus

Menu #1 - Basic Features

Items in bold text have been programmed to the default setting at the factory.

Menu #2 - Advanced Features

Feature One Chirp Two-Chirp

Number Setting Setting

2-1 Siren Horn honk

2-2 30-second siren duration 60-second siren duration

2-3 Nuisance Prevention®Circuitry on Nuisance Prevention®Circuitry off

2-4 Progressive door trigger Instant door trigger

2-5 Valet switch input: 1 pulse Valet switch input: 2-5 pulses

2-6 Bypass Notification ON Bypass Notification OFF

2-7 Ignition-controlled domelight ON Ignition-controlled domelight OFF

2-8 Single unlock pulse Double unlock pulse

2-9 Channel 3:Validity Channel 3: latched/latched, reset

with ignition/30-second timed/

second unlock output*

*Second unlock is only available if Feature 2-8 is programmed to single pulse.

Feature One Chirp Two-Chirp

Number Setting Setting

1-1 Active arming Passive arming

1-2 Chirps ON Chirps OFF

1-3 Ignition controlled door locks ON Ignition controlled door locks OFF

1-4 Active locking only Passive locking

1-5 Panic with ignition on No panic with ignition on

1-6 0.8 second door lock pulses 3.5 second door lock pulses

1-7 Forced passive arming ON Forced passive arming OFF

1-8 Automatic Engine Disable ON Automatic Engine Disable OFF

1-9 Armed When Driving (AWD) Vehicle Recovery System (VRS)

1-10 Code Hopping™on Code Hopping™off

Directed Electronics, Inc.

Feature Descriptions

The features of the system are described below. Features that have additional settings that can be

selected only when programming with the 998T Bitwriter are indicated by the following

icon:

Menu #1 - Basic Features

1-1 ACTIVE/PASSIVE ARMING: When active arming is selected, the system will only arm when

the transmitter is used. When set to passive, the system will arm automatically 30 seconds after the

last door is closed. To alert the consumer of passive arming, the siren will chirp 20 seconds after the

door is closed. This provides the consumer with an audible indication prior to the system actually

arming. At the 30 second mark, the system will arm but the siren will not chirp.

1-2 CHIRPS ON/OFF: This feature controls the chirps that confirm the arming and disarming of

the system.

1-3 IGNITION CONTROLLED DOOR LOCKS ON/OFF: When turned on, the doors will

lock three seconds after the ignition is turned on and unlock when the ignition is turned off.

The 998T Bitwriter will display separate steps for ignition lock and ignition unlock. They can be

programmed on or off independently.

1-4 ACTIVE/PASSIVE LOCKING: If passive arming is selected in step 1-1, then the system can be

programmed to either lock the doors when passive arming occurs, or only lock the doors when the

system is armed via the transmitter. Active locking means the system will not lock the doors when

it passively arms. Passive locking means that the system will lock the doors when it passively arms.

NOTE: Remember, when passive arming is selected, the unit will chirp 20 seconds after the last

door is closed. The system does not actually arm or lock the doors until 30 seconds after the door

has been closed.

1-5 PANIC WITH IGNITION ON: This step controls whether or not the Panic Mode is available

with the ignition on. In some states, there are laws prohibiting a siren from sounding in a moving

vehicle. This feature makes the system compliant with these regulations.

1-6 DOOR LOCK PULSE DURATION: Some European vehicles, such as Mercedes-Benz and

Audi, require longer lock and unlock pulses to operate the vacuum pump. Programming the system

to provide 3.5 second pulses, will accommodate the door lock interface in these vehicles. The default

setting is 0.8 second door lock pulses.

Directed Electronics, Inc.

1-7 FORCED PASSIVE ARMING ON/OFF: To use this feature, passive arming must be selected in

step 1-1. When turned on, forced passive arming will ensure that the system will passively arm, even

if a zone is left open or invalid. Forced passive arming occurs one hour after the ignition is turned

off.

1-8 AUTOMATIC ENGINE DISABLE (AED) ON/OFF: AED is a full-time, passive starter disable

that works independently of the security system. When turned on, the orange, ground-when-armed

output (H1/1) will go active 30 seconds after the ignition is turned off. The LED will flash at half

its normal rate when the ignition is turned off to indicate that AED is active and will interrupt the

starter in 30 seconds. AED does not occur in Valet mode and can be bypassed using the emergency

override procedure. The transmitter can also be used to disarm AED.

1-9 ARMED WHILE DRIVING/VEHICLE RECOVERY SYSTEM: In the default setting (Armed

While Driving), the system can be armed with the ignition on. When armed, the ground-when-

armed is not active and the sensors are bypassed. The door triggers will remain active. If

programmed to the Vehicle Recovery System (VRS®®) setting, VRS®®will be activated.

1-10 CODE-HOPPING™ ON/OFF: The system uses a mathematical formula to change its code

each time the transmitter and receiver communicate. This makes the group of bits or “word” from

the transmitter very long. The longer the word is, the easier it is to block its transmission to the unit.

Disabling the Code-Hopping™ feature lets the receiver ignore the Code-Hopping™ part of the

transmitted word. As a result, the unit may have better range with Code-Hopping™ off.

Menu #2 - Advanced Features

2-1 SIREN/HORN HONK: The system can be programmed to output pulses instead of a

continuous output when the system is triggered. This is useful to honk the factory horn in applica-

tions where a siren is undesirable. Remember that the unit is only capable of supplying 1 amp of

current. A relay will be required to interface with most factory horn systems.

2-2 SIREN DURATION 30/60 SECONDS: It is possible to program the unit to sound for 30

or 60 seconds during the triggered sequence. Some states have laws regulating how long a

security system can sound. When using the 998T Bitwriter, the siren can be programmed to sound for

any length of time ranging from 1 to 180 seconds. Using the SELECT button of the 998T Bitwriter

will adjust the siren duration in one second increments.

Directed Electronics, Inc.

2-3 NUISANCE PREVENTION®CIRCUITRY (NPC®) ON/OFF: NPC®®stops repeated triggering

of the same zone. If one zone is triggered three times in one hour, that zone is bypassed for one hour,

starting from the time of the third trigger. During that hour, if the system detects a trigger on that

zone again, the system resets the one hour timer. If one hour passes and the zone has not triggered

again, the zone is activated and can trigger the system again. NPC®®monitors sensor inputs and the

door trigger, but does not bypass the ignition trigger at any time. If NPC®®is turned off, the system

will respond to repeated triggers on the sensor inputs and will do so indefinitely. Some states have

laws regulating how many times a security system can trigger before it is considered a nuisance and

the vehicle is towed away.

2-4 PROGRESSIVE DOOR TRIGGER ON/OFF: The system responds to a door trigger input with

a progressive response. When the door is opened with the system armed, the siren will chirp 10

times prior to the full triggered sequence. The door trigger is still treated as an instant trigger and

closing the door quickly will not prevent a full triggered sequence from occurring. If the progressive

door trigger is programmed off, the full siren output will occur the moment the door is opened.

2-5 VALET PULSE COUNT ONE TO FIVE PULSES: The system can be programmed to count

the number presses of the valet button before disarming the security system or VRS®®. The factory

default setting is one pulse. The unit can be set for two to five pulses using the two-chirp setting to

select the pulse count.

Ghost Switch Option: For added security, the GRAY wire on the two-pin Valet/Program can be

connected to any switch in the vehicle that provides a positive (+) momentary pulse.

2-6 BYPASS NOTIFICATION ON/OFF: when programmed on, any active zone input to the

system during arming will generate a bypass notification chirp. When programmed OFF, no bypass

notification chirps will be generated if any zone is active during arming.

2-7 IGNITION-CONTROLLED DOMELIGHT SUPERVISION ON/OFF: If turned on, the

system will turn on the domelight for 30 seconds when the ignition is turned off. The optional

domelight supervision feature must be installed.

2-8 DOUBLE PULSE UNLOCK ON/OFF: Some vehicles require two pulses on a single wire to

unlock the doors. When the double pulse unlock feature is turned on, the BLUE H2/C wire will

supply two negative pulses instead of a single pulse. At the same time, the GREEN H2/A wire will

supply two positive pulses instead of a single pulse. This makes it possible to directly interface with

double pulse vehicles without any extra parts.

Table of contents

Popular Car Alarm manuals by other brands

ENFORCER

ENFORCER SLI762PP-ISS installation manual

Gemini

Gemini 7201 user manual

Omega

Omega K9-150 Owner's guide & installation instructions

Clifford

Clifford Concept 100 owner's manual

Clifford

Clifford intelliGuard 750 installation guide

Ungo

Ungo MS2000 installation manual

Westfalia

Westfalia 80 67 52 instruction manual

Audiovox

Audiovox Prestige Platinum APS-250-A owner's manual

Phobos

Phobos Mistral Max 2 user manual

Clifford

Clifford Centurion owner's manual

Saint

Saint ST 2004 user manual

Auto Page

Auto Page Car-Pro CPX-2500 Operation manual

Autostart

Autostart AS-1725 SH Wiring schematic

Auto Page

Auto Page C3-RS-900LCD Operation manual

Auto Page

Auto Page RF-420LCD installation manual

Auto Mate

Auto Mate 4104A owner's guide

Auto Mate

Auto Mate 435 installation guide

AME

AME MM3 user guide

Viper 650XV User manual

Popular Car Alarm manuals by other brands
