Virtuos HT860N Assembly instructions

Programming User’s Manual
HT860N
Ver:0.9 c
English version

Warning
Please use the 5V power adapter .The power adapter must meet the safety
standards. Especially under RS 3 cable using.
Keep away from heat sources. Keep good ventilation.
Pay attention on waterproof protection during storage, transportation and
operation.
Don’t stare at the light when use the Scanner to avoid any discomfort and
damage.
Package Contains：
Barcode X1
USB cable X1
Quick start guide X1
Outline:

Insert / Release Cable
The scanning window can be adjusted forward and
backward for adjustment scan angle but it can’t be
adjusted to the left and right.
Button: White light illumination LED ON/OFF
LED indicators and beeper
state Indicators
Power on Red LED on(always), 3 short beeps
Power off Red LED off
Sleep mode Green LED off
Operation / Standby Green LED Always ON
Good read 1 Green LED flash. 1 short beep
Barcode unsuccessfully decoded 4 beeps

etting:
Note: * Means the Factory Default etting
Enable/Disable etting
Enable Setting: All barcode setting work
Disable Setting: None barcode setting work
*Enable Setting Disable Setting
Factory Default Setting
F/W version

Interface
USB PC KEYBOARD (Default):
RS 3
USB V irtual COM (P le as e ins tal l th e Driver before u sing U S B vi rtu a l COM )

R -232 Communication Parameters
Baud Rate

Keyboard Terminator
Language keyboard etting

Keyboard Wedge Function
ALT Mode

*Caps Lock OFF Caps Lock ON
et Beep frequency
can Mode
*Continuous Auto can

ame Barcode Delay
U B HID speed mode
*
Character Delay (for HID speed Normal mode)

Transmit Data Length
All Digits *
Transmit Leading Digits On Leading Digits Modification
Transmit Last Digits On Last Digits Modification

Prefix
Prefix ON *Prefix OFF
Prefix etting Erase all Prefix
uffix
uffix ON * uffix OFF
uffix etting Erase all uffix

canning Barcode Type /Disable Configuration
1.1 upport canning All Barcodes
Scan the following setup code to enable or disable reading in all supported barcode
types.
All types ON All types OFF
*Turn on default reading types
1.2 EAN/UPC
Scan the following setting code to set the EAN8 Barcode enable/disable reading
* EAN/UPC ON EAN/UPC OFF
Scan the following setting code to configure EAN/UPC additional code to read
*Prohibit reading additional code Allow to read addition code
UPC-A First Digit”0” ON UPC-A First Digit “0” OFF *

UPC-E Convert to EAN13 ON UPC-E Convert to EAN13 OFF*
UPC-E Convert to UPC-A ON UPC-E Convert to UPC-A OFF*
UPC-E First Digit “0” ON* UPC-E First Digit “0” OFF
EAN Convert to I BN ON EAN Convert to I BN OFF *
EAN Truncate Leading 3 digits ON EAN Truncate Leading 3 digits OFF*

1.3 Code128
Scan the following setting code to set the Code1 8 Barcode enable/disable reading
* Code128 ON Code128 OFF
Scan the following setting code to set whether to output the first character non-ASCII code
character of Code1 8 barcode
Enable non A CII code character output Disable non A CII code character output
1.4 Code39
Scan the following setting code to set the Code39 Barcode enable/disable reading
*Code39 ON Code39 OFF
“*” Transmit ON * “*” Transmit OFF

1.5 Code93
Scan the following setting code to set the Code93 Barcode enable/disable reading
*Code93 ON Code93 OFF
1.6 CodaBar
Scan the following setting code to set the CodaBar Barcode enable/disable reading
*CodaBar ON CodaBar OFF
CODEBAR tart/End Character ON* CODEBAR tart/End Character OFF
1.7 QR
Scan the following setting code to set the QR Barcode enable/disable reading
QR ON *QR OFF

1.8 Interleaved 2 of 5
Scan the following setting code to set the Interleaved of 5 Barcode enable/disable
reading
*Interleaved 2 of 5 ON Interleaved 2 of 5 OFF
1.9 Industrial 25
Scan the following setting code to set the Industrial 5 Barcode enable/disable
reading
* Industrial 25 ON Industrial 25 OFF
1.10 Matrix 2 of 5
Scan the following setting code to set the Matrix of 5 Barcode enable/disable
reading
*Matrix 2 of 5 ON Matrix 2 of 5 OFF

1.11 Code11
Scan the following setting code to set the Code11 Barcode enable/disable reading
*Code11 ON Code11 OFF
1.12 M I
Scan the following setting code to set the MSI Barcode enable/disable reading
*M I ON M I OFF
Scan the following setting code to set whether the MSI barcode check bit is output
Output check digit ON *Output of check digit OFF
1.13 G 1-DATABAR
Scan the following setting code to set the GS1-DATABAR Barcode enable/disable reading
*G 1-DATABAR code ON G 1-DATABARcode OFF

1.14 DM
Scan the following setting code to set the DM Barcode enable/disable reading
DM ON * DM OFF
1.15 PDF417
Scan the following setting code to set the PDF417 Barcode enable/disable reading
PDF417 ON *PDF417 OFF
1.16 CODE32
Scan the following setting code to set the CODE3 Barcode enable/disable reading
CODE32 ON *CODE32 OFF

Appendix
A CII Code
