vision trimline TL70SL User manual

INSTALLATION INSTRUCTIONS.
FOR MODELS TL70SL

INSTALLATION INSTRUCTIONS
FOR MODEL
TL70SL

2 Trimline 70 SL
1 INSTALLATION INSTRUCTIONS...........................................................................................................3
1.1 General instructions.......................................................................................................................3
2 INSTALLING THE UNIT............................................................................................................................3
2.1 Connection to the gas pipes ........................................................................................................3
2.2 Preparation and placement .........................................................................................................3
2.3 Installing the unit ...........................................................................................................................4
2.4 Installation.......................................................................................................................................5
3 INSTALLATION OF THE ADDITIONAL HIGH-GLOSS BLACK GLASS WALLS OR
STONE MOTIF WALLSET ........................................................................................................................7
3.1 Mounting instructions for the optional high-gloss black glass set ......................................7
4 INSTALLING THE CERAMIC WOOD SET ............................................................................................7
5 TECHNICAL DETAILS GV60....................................................................................................................9
6 INSTRUCTIONS FOR THE MERTIK MAXITROL GV60...................................................................10
7 GAS-TECHNICAL SPECIFICATIONS...................................................................................................11
8 CONCENTRIC PATHWAYS....................................................................................................................13
9 CONCENTRIC FLUE SYSTEM ..............................................................................................................14
9.1 Componentsoftheconcentricuesystem ...........................................................................14
9.2 Indirect/direct façade connection if applicable (See Chapter 8) ........................................14
9.3 Installationinstructionsregardingexistingues(SeeAppendix2)...................................14
9.4 Parts ...............................................................................................................................................15
9.5 Installation.....................................................................................................................................15
10 PASS-THROUGH POSITIONS AND FUNCTION CORRECTLY......................................................16
11 CLEANING AND MAINTENANCE........................................................................................................17
12 QUICK REFERENCE GUIDE FOR FAULTSSEARCH FOR ENCLOSED
GAS FIRES USING MERTIK GV60 GASCONTROL..........................................................................20
Appendix 1 DIMENSIONAL DRAWINGS........................................................................................................22
Appendix 2 INSTALLATION EXAMPLES REGARDING FLUES..............................................................23
V12112018
Thermocet International B.V.
Laagerfseweg 31
3931 PC Woudenberg
The Netherlands
www.thermocet.nl
CONTENTS

Trimline 70 SL 3
1 INSTALLATION INSTRUCTIONS
NOTE!
The installation may only be carried out by an authorised
person.
1.1 General instructions
•Thegasreplacemustbeinstalled,connectedand
inspectedasaclosedunitbyaqualiedtter,accordingto
national,regional,andlocalstandardsandregulations.
•Theuetubesystemandtheoutletsintheouterwallor
rooffacemustalsomeettherequirementsoutlinedinthe
applicable standards and regulations.
•The temperature of the walls and shelves near the side and
backoftheunitmaynotbemorethan80°Chigherthanthe
ambient temperature.
•The unit has been approved in combination with the
concentricuesystemTHC/HolethermCCØ100/Ø150mm
inaccordancewithEuropeanCEstandardsforgasunits,
andmaythereforeonlybeappliedwiththissystem.
•Theunitneedstobeinspectedbythetterforlocalgas
distribution(gastypeandgaspressure)asindicatedonthe
identicationplate.
•Theinstructionsareonlyapplicableiftherelevantcountry
code is stated on the unit.
•Ifthisisnotthecase,thegastechnicalinformationforthe
relevantcountryneedstobeconsultedandmodications
discussed with the manufacturer.
•Therewillbeairinthegaspipeswhentheunitisrstused.
Thegaspipesthereforeneedtobeventedrst.
•Ignite the heater according to operating instructions and
checkwhethertheburnerameisuniform.Aftertheunit
hasbeenusedforthersttime,anydepositsresultingfrom
convection-curing of the unit must be removed from the
glass pane using a glass cleaner for heaters.
Distance from ammable materials:
Adistanceof1200mmmustbemaintainedfromthefront,
sideandtopoftheunittocurtains,coveringsandfabrics,and/
or other combustible material unless otherwise stated in this
instruction.
Distance to non-ammable materials:
The unit needs to be placed a minimum distance of 10mm
from the wall unless stated otherwise in these instructions.
WARNING
Gasresbecomehotwheninuse.Afterinstallationofthe
unit,theglasssurfaceisconsideredtobeanactivezone.
Theglasssurfacecanbecomeveryhot!
Note! Therefore, you should take care by, for example,
keeping children and those requiring help away from the
immediate vicinity of burning res. Gas res must not be
placed on or against ammable materials (curtains, etc.).
Never install the unit against or within a ammable wall!
NOTE!
Constructionmaterialforreplacesandmantles,etc.,orfor
anassemblymustbemadefromrefractorymaterial.This
alsoappliestooorsandceilings.Followtheinstructions
aboveandneveruseammablematerialsneartheunit.
Please contact your supplier if you are unsure.
2 INSTALLING THE UNIT
NOTE!
Beforeputtingtheunitinplace,werecommendyourst
read Chapter 9 Concentric ue system.
2.1 Connection to the gas pipes
Youcandeterminewherethegaspipeswillbeplaced,depend-
entonthelayout.Ensurecontrolequipmentisnottwisteddur-
inginstallationandthereisnoexcessivetension.Accessibility
of various connection points in relation to components needs
tobemaintained.Afterinstallation,checktheconnectionseals
aregastight.Usea3/8″gastapwithaconnector.Ensurethe
gas pipes are free of dirt and soil or sand and that the gas and
combustion controls in the various components and all appli-
ancefunctionsoperatecorrectly.Thegassupplyshouldonly
beconnectedupwhentheelectricitysupplyisdisconnected.
Failingtodosomaycausedamagetothegascontrol
equipment.
2.2 Preparation and placement
Thereplaceisdeliveredinacrateandliesinthepackagingon
its back. Do not tilt the packaging.
•Remove the packaging and check the unit for possible
damage.
NOTE!
Place the unit on a stable surface.
Do not place the unit on its side.
Put the unit in its place of destination.
The packaging contains the following components:
•Unit
•Remote control
•Log set
•Batteryholder
•4xAAbattery
•2xAAAbattery
•Installation box
•Finishing plate
•Installation manual
•User manual
Beforeremovingtheunitfromthepackaging,rstcheck
whethereverythingiswholeandcomplete.Youmustthenread
and understand the installation manual before starting the
installation.

4 Trimline 70 SL
Toassembletheunit,proceedasfollows:
Disassemble the frames.
Remove frame with glass pane
There are cover strips on the left and right. Take these strips
outandyouwillseetheassemblyoftheframewithglasspane.
•Partiallyloosenthe2boltsontheleft,twoboltsonthetop
and the two bolts on the right.
•Slightlyslidetheframeandglasspaneupwardsandmoveit
forwards.
NOTE
Thepaintandthecordcansticktogetheratrst.Itis
thereforepossiblethatitmaybemoredifculttoremove
theglasspaneifthisisthersttimeithasbeendoneafter
burning.
Our advice is to remove all the screws and take the glass
paneoffcompletelyaftertherstuseinordertoremove
the glass pane. A second recommendation is to remove the
frameandglasspaneaftertherstburnandcleantheglass
pane. The cleaning of the glass pane is important because
otherwise the deposit will burn on it and it will not be
possibletocleanitproperly.Thisalsoapplieswhenworking
with Black glass wandset and/or AR glass.
Remove the cover frame
•First remove the frame with glass pane.
•There are then four Allen bolts to be loosened.
•Slide the frame forward to release it.
2.3 Installing the unit
The unit can now be put into place. The unit has two mounting
brackets and two adjusting nuts.
Theunitcanbehungonareproofwall.
Finishing example
Theunitcanbebuiltinushwithrefractorymaterials.
There must be no hindrance to the radiant heat at the front
oftheunit.Formoreinformation,seeParagraph1.1 General
regulations.
Typeplate
Cover
strip
Cover
strip
Adjustable mounting brackets
Adjusting nuts
External wall
Cavity
Floor
Refractory insulation
around flue gas pipe
Inner wall
refractory materials
Inner wall
refractory
materials
Support for
non-combustible
material
Do not build
on the fireplace
Space between
wall and
fireplace 10mm
Flue gas
pipe
100/150

Trimline 70 SL 5
NOTE
Ensuretheunitisnottightlyenclosedtotakeexpansionof
the unit into account.
Ensurethereisnoammablematerialoverhanginginfront
above the unit. A windowsill for example. The convection air
isveryhot.
Use
You are advised to read the user manual before use.
A1-0switchhasbeeninstalledtoturnthereplaceoffin
case of emergencies. This switch can also be used during the
summer to save the batteries.
2.4 Installation
Flue gas connection
This unit has a rear outlet. A recess must be made in the
refractorywall.Thewallpass-throughcanthenbeshortened
to the correct length and placed on the outlet of the unit. For
further information see Chapter 9Concentric ue system.
Remove the bafe plate
ThebafeplateisdisassembledbymeansofthreeAllenbolts
at the top. Loosen these bolts and then tilt the plate and holder
forward.Accesstotheuegasoutletisnowavailable.
TherearetwoParkerscrewsattheuegasoutletwherethe
restrictionplatecanbemountedincaseofalongerpathway.
70mm restriction.
Connecting the gas
There is a separate removable panel at the front of the unit to
ease the installation of the gas pipe.
Theunithasaxedpointtowhichthegaspipemustbeconnected.
Therearebreakplatesintheunitthatcanberemoved,
dependingonthepositionofthesupplygasline.
Gas control system GV60 see Chapter 5 Technical data GV60.
NOTE
Ensure that there is a gas valve in the gas circuit and that it
is accessible.
Thexedpointofthegaspipemaynotbetakenapart.
Otherwise,theriskisthattheburnerbasewithtechnical
equipmentcannotberemovedfromtheunit.
Nowtheunithasbeenconnectedtothegas,acheckcanbe
carried out. The check can be carried out without the glass
pane being in place. Check the following points:
•Ensure the pipe is clean before the unit is switched on.
•Venting the pipe.
Gas connection
xedpoint
Breakout plateBreakout plate
On/Off switch

6 Trimline 70 SL
•Seeifthereplaceswitchesonnormally.Theremaybe
someairinthepipelineatrst;thismaycauseadelaytothe
start-up.(Therefore,alwaysstartwithnoglasspanetted.)
•Inspectallgas-carryingpartsforleakswhiletheunitis
burning.
•The blocks can be put in place in accordance with the
images shown in Chapter 4 Placing the ceramic wood set.
•Ifthereisdoubtaboutthepre-pressureandburner,see
Chapter 11 Cleaning and maintenance.
•Nowthereplacehasbeentechnicallyconnectedand
checked,theinstallationcanbecompleted.
Replacing the batteries
Thereisabatteryholderinthebatteryboxwithcoverplate.
Thisincludes4xAAbatteries.Whenthebatteriesarefully
discharged,thecoverplatecanbedisassembledandthe
batteries replaced.
NOTE
Do not connect a 9-Volt block. This will cause the electronics
to fail.
There are 2 AAA batteries in the hand-held remote. The hand-
heldremoteindicateswhenitisempty.
Thebatteryboxisusedinthereconstructionofthereplace.The
batteryholderisplacedinhere.A3-metrecablegoesfromthebattery
holder to the receiver. (See Chapter 5 Technical data GV60)
Power cable



Trimline 70 SL 7
3 INSTALLATION OF THE ADDITIONAL HIGH-GLOSS BLACK
GLASS WALLS OR STONE MOTIF WALLSET
NOTE
Ifyouhaveoptedforahigh-glossblackglass,stonepattern,
youmustrstassembleitbeforeyouputthewoodsetin
place.
3.1 Mounting instructions for the optional
high-gloss black glass set
4 INSTALLING THE CERAMIC WOOD SET
Place the glow material on the burner.
Placetheceramicblocksinsequence,suchasshownin
images 1 through 8.
NOTE
Noglowmaterialsonthegrid,seeFigure1.
InFigure3,thepinsarelocatedinthelogs.
Alwaysensurethepilotlightremainsfreeofanymaterial.
Pin
Pin

8 Trimline 70 SL
1
5
2
6
3
7
4
8
Pin Pin

Trimline 70 SL 9
5 TECHNICAL DETAILS GV60
Gas control block type Mertik GV60 M1
Automatic ignition control type B6R-R8P(WiFiReady)
Ignition RemotecontrolandPiezoignition
Gas connection 3/8" (External) A=Gasinlet B=Gas burner outlet C=Thermocouple connection D=pilot
lightburnerconnection E=Batteryholderpowersupplycable
Unit category C11-C31-C91
Pilot Mertik G30-ZP2M-L
Combustion gas outlet and combustion air inlet Concentric:Ø100/Ø150mm
Adjustment screw
burner pressure
Main
gas control knob
Inlet pressure
Outlet pressure Gas exhaust
Gas intake
Thermocouple
connection
Piezo
connection
Adjustment screw
burner pilot light
Main
adjustment
Pilot Burner
G30-ZP2M
Receiver
B6R-R8(9)P…
Thermocurrent Cable SW
with ON / OFF Switch
G60-ZSKS(L)S…
Thermocurrent Cable TC
G60-ZKIRS…
8 Wire Cable
G6R-C…
Interrupter Block
G60-ZUS…
Ignition Cable
G60-ZKIS…
RESET Button
Main Burner
Combination Control
GV60…
Antenna
Battery
holder
WARNING
Sealed parts must not be adjusted
A
B
C
D
E
D
C
E
B
A
D
C
Pilot light connection

10 Trimline 70 SL
6 INSTRUCTIONS FOR THE MERTIK MAXITROL GV60
WARNING
Ensure the fuel supplied to the unit is clean and free.
The unit must not be turned on if the glass pane(s) is not
present and/or is broken.
Ensure the fuel supplied to the unit is clean and free
from particles and moisture.
Beforeagassupplypipe(neworexisting)isconnectedtothe
main gas pipe at the gas meter and to the gas control block
oftheunit,cleananddrycompressedairneedstohavebeen
blown through it. Copper and aluminium pilot light pipes that
havebeencutmustbedeburredandblowncleanbeforethey
are connected.
Heat, moisture and dust are a threat to all electronic
components.
Protect the electronic gas control untilallconstruction,
plasteringandpaintworkhasbeencompleted.Ifyoucannot
avoidthiswork,thenprotectthecontrolagainstdirtand
moisturepenetrationbycoveringitwithplasticlmfor
instance.
WARNING
Electroniccomponentsbecomepermanentlyfaultywhen
theyareexposedtotemperatureshigherthan60°C.Normal
AAbatterieswillcrackopenattemperatures>54°Cand
thebatterycontentswilldamagetheelectronicswitches
below.Batterieshavethelongestlifespanat<25°C.At
temperatures>50°Cthislifespanwillonlybeapproximately
23weeks,whichwouldmaketheuseofthegasreplace
unnecessarilyexpensive.Only install the gas control block
and receiver as pre-installed at the factory.
Rememberthatcomponentsmayhavetobereplacedor
thatrepairsmayhavetobeperformedatalaterdate.This
mayprovetobemoredifcultifthecontrolisinstalledina
differentwaytohowwehavedescribedininstructions.
Only insert the batteries after the receiver, gas control block
and pilot light set have been wired. Premature connection to
the power source can damage the electronics.
Ensure the ignition cable is not near the antenna wire and
that they do not cross each other. The high voltage released
duringignitionmaydamagethesensitivereceivercircuitofthe
antenna. This could mean the unit becomes less responsive or
totallyunresponsivetocommandsfromthehandset.
NOTE
Do not tighten the contact breaker and the thermocouple
connection too tightly on the gas control block! It is
sufcient to tighten by hand and add a half a turn with
an open-end spanner. Tightening too much will break
the connection to the magnetic coil below and/or the
insulation around the aluminium contact pin in the contact
breaker. This may cause the magnetic coil to not open
the gas supply to the pilot light and prevent the unit from
functioning.
Prevent leakage of ignition spark to parts of the installation
other than the ignition rod on the pilot light. Ensure the ignition
cableisnotincontactwiththebodyorothermetalparts.
Ifacableextensionisused,ensuretheconnectionshave
additional silicone insulation.
The receiver and the control units on the gas control block
should be switched on to ensure automatic start-up via the
manual transmitter.
The oval disc on the gas control block should be turned to
the ON position. The I/0 witch should be set to ‘I’. The ignition
cable should be connected to the ‘SPARK’ connection point on
the receiver box.
Thesystem’sthermostatsensorislocatedinsidethemanual
transmitter.
The manual transmitter operates best at a distance of 2 or 3
metresawayfromtheunit.Althoughcommunicationoccurs
viashortwaveradiosignals,itisrecommendedthatyouplace
thehand-heldtransmitterinthelineofsightofthegasunit,
in a place where the user wishes to experience a pleasant
temperature. Do not place the manual transmitter in direct
sunlight or other warm locations. The thermostat measures
thetemperatureand,accordingly,regulatestheamesizeof
the gas unit.
NOTE
Sealed parts must not be adjusted, to do so would void
thewarranty.
A waiting time of 5 minutes between each start attempt
must be observed.

Trimline 70 SL 11
7 GAS-TECHNICAL SPECIFICATIONS
Type of indication(s) TRIMLINE 70 SL (1023)
Unit type C11, C31, C91
Concentric extraction system Holetherm CC 100-150
Gas type G25.3 G20/G25 G20 G20/25
Pre-pressure in mBar 25 20 20 20/25
Country/Countries NL DE AT/CH/CY/CZ/DK/EE/ES/FI/
FR/GB/GR/HR/IE/IT/LT/LU/
LV/NO/PT/RO/SE/SI/SK/TR
BE/FR
Category I2EK
I2(43,46-45,3MJ/m3)
I2ELL I2H I2E+
Primary air 2x5mm 2x5mm 2x5mm 2x5mm
Pre-pressure mBar 25 20 20 20/25
Burner pressure - high position mBar 22 14,6 14,6 14,6/18,2
Burner pressure - low position mBar 11,2 8,2 8,3 8,3/10,3
Injector orice Ø mm 1.8 1.8 1.8 1.8
Pilot light injector CODE 272 272 272 272
Small position orice mm 1.8 1.8 1.8 1.8
Load Hs kW 5.3 5/4.2 5 5
Hi load kW 4.74 4.5/3.77 4.5 4.5
Gas consumption m³/h 0.57 0.48/0.46 0.48 0.48
Nominal power - high position kW 3.97 3.8/3 3.8 3.8
Nominal power - low position kW 2.7 2.8/2.2 2.8 2.8
NOx Hs mg/kWh 75.5 83/75 83 83
Efciency class NE613 1 1 1 1
Useful return (NCV) system**
For nominal heat output % 83.7 83.7/81.4 83.7 83.7
For minimal heat output % 81.3 80.5/79.5 80.5 80.5
Supplementary electricity consumption
Nominal kWh 0 0 0 0
Stand-by kWh 0 0 0 0
Energy efciency**
Energy efciency index EEI % 78 77.8/75 77.8 77.8
Energy label C C/D C C
NOx Hi class 5 5 5 5
Heat output type/room temperature control
Indirectheatfunctionality No
Singlestageheatoutput,noroomtemperaturecontrol No
2ormoremanually-adjustablestages,nocontroloftheroomtemperature No
Withmechanicalcontrolofroomtemperaturebythermostat No
With electronic control of room temperature Yes
Withelectroniccontrolofroomtemperatureplusday-timeswitch Yes
With electronic control of room temperature plus week-time switch Yes
Other control options
Control of room temperature with presence detection* Yes
Control of room temperature with open window detection* Yes
With remote control option Yes
*in combination with home automation
**shortestsystempath

12 Trimline 70 SL
Type of indication(s) TRIMLINE 70 SL (1023)
Unit type C11, C31, C91
Concentric extraction system Holetherm CC 100-150
Gas type G30/31 G30
Pre-pressure in mBar (28-30)-37 30/50
Country/Countries BE/CH/CY/CZ/ES/FR/GB/GR/IE/IT/LT/PT/SI/SK NL/CH/CY/FR/GB/IT/LT/ SI/SK/AT/CH/DE/FR/
SK/PL
Category I3
+I3B/P
Primary air 2xØ8mm+1xØ14mm 2xØ8mm+1xØ14mm
Pre-pressure mBar (28-30)-37 30/50
Burner pressure - high position mBar 23.1/29.3 23.1
Burner pressure - low position mBar 9/11.5 9
Injector orice Ø mm 1 1
Pilot light injector CODE 221 221
Small position orice mm 1 1.1
Load Hs kW 4.3 4.3
Hi load kW 4 4
Gas consumption m³/h 0.124 0.124
Nominal power - high position kW 3.3 3.3
Nominal power - low position kW 2 2
NOx Hs mg/kWh 72.5 72.5
Efciency class NE613 1 1
Useful return (NCV) system**
For nominal heat output % 82.4 82.4
For minimal heat output % 77.5 77.5
Supplementary electricity consumption
Nominal kWh 0 0
Stand-by kWh 0 0
Energy efciency***
Energyefciencyindex EEI 76.3 76.3
Energylabel C C
NOx Hi class 5 5
Heat output type/room temperature control
Indirectheatfunctionality No
Singlestageheatrelease,noroomtemperaturecontrol No
2ormoremanually-adjustablestages,nocontroloftheroomtemperature No
Withmechanicalcontrolofroomtemperaturebythermostat No
With electronic control of room temperature Yes
Withelectroniccontrolofroomtemperatureplusday-timeswitch Yes
With electronic control of room temperature plus week-time switch Yes
Other control options
Control of room temperature with presence detection* Yes
Control of room temperature with open window detection* Yes
With remote control option Yes
*in combination with home automation
**shortestsystempath
*** EU directive 2015-1186/1188

Trimline 70 SL 13
8 CONCENTRIC PATHWAYS
Table of concentric pathways
Pathway Illustration X total in metres Y total in metres Restriction
x = vertical and y = horizontal min* max* min* max* 1023
Direct façade outlet G20/25.3/G30 A 0 0 0.5 0.5 No
Indirect façade outlet G20/25.3/G30 B 1 4 0.1 0.5 X – Y > 2 metres: 50mm
Roof pass-through without slope C 2 9 See provisions
Roof pass-through with 45º slope** D 3 9 0 4 from X total - Y > 6 metres: 50mm
Roof pass-through with 90º slope*** E 3 9 0 2 from X + X1 - Y > 6 metres: 50mm
45 bend: calculation length 1 metres
90 bend: calculation length 2 metres
* length including roof or exterior wall outlets. Always adhere to a starting length of 1 metre!
** Ratio vertical : horizontal X + X1 + X2: Y ≥ 2: 1
*** Ration vertical : horizontal X + X1: Y ≥ 2: 1
Restriction provisions all gas types
Vertical pathways
Distance Bafe plate Restriction
min 2 - 5 m Yes 50mm
5 - 9 m Yes 70mm
Direct façade outlet
Direct façade outlet Yes No
Y
X
X1
X
X1
Y
X
Y
X
X1
X
X1
Y
X
Y
X
X1
X
X1
Y
X
X
Y
X
A
X
Y
X
B
C D E

14 Trimline 70 SL
9 CONCENTRIC FLUE SYSTEM
Theconcentricuesystemiscomposedofaninnerueandanouterue.Theseueshavebeensetupconcentricallysothe
combustiongaseswillbedischargedviatheinternaluewhilethefreshcombustionairissuppliedviathegapbetweentheinner
andouterues.
9.1 Components of the concentric
uesystem
Differentconnectionsarepossibleusingtheconcentricue
system.Theseare:
Through the roof face and through the exterior wall
Thepathwayusedforthissystemcanbelaidindifferentways,
but there are a few important conditions:
•Thetotalallowedverticaluelengthmustnotexceed
9metres(thesumoftheuelengthandcalculationlengths
for the bends).
•90°bendshavea2-metrehorizontalcalculationlength.
•45°bendshavea1-metrehorizontalcalculationlength.
•Theoutletcanbeinstalledatanypointontherooffaceor
exteriorwall(supplyanddischargeinanidenticalpressure
area),butmustmeetapplicableregulations.
•Fluepathwaysmustnotbeinsulated.
NOTE
Ensure the restriction plate is mounted in the correct
manner,asindicatedintheseinstructions.
The correct restriction plate will provide the unit with the
mostoptimalefciency,ameimageandcombustion.
Mountinganincorrectlyplacedrestrictionplatemaycause
malfunction of the unit.
9.2 Indirect/direct façade connection if
applicable (See Chapter 8)
Theoutletmayalsobeinstalledabovetheexhaustinthe
wall,takinganyhindrancetothesurroundingareainto
consideration,inaccordancewithnational,regional,local
standards and regulations.
NOTE
Ensurewindpressureontheoutletisnotexcessive,
suchasinlocationswithabalcony,atroof,cornersand
verynarrowalleys,etc.,asthiscannegativelyaffectthe
performance of the unit.
•Make a recess in the façade of around 155mm when using
Ø100-150ues(keepanextraspaceof50mminanon-
re-prooffaçadearoundtheoutertube)andtthefaçade
pass-through with the wall plate on the inside of the wall.
The wall plate of the exterior façade pass-through must be
sealedsufcientlyagainstthewallontheoutsidetoavoid
moistureand/oruegasleaksleakingintothelivingspace.
We recommend our clearance box use as a direct façade
pass-throughthroughanon-re-resistantfaçade.
•Theueshouldbeencasedifnecessary.Eveniftheue
istobeinstalledalongnon-refractorymaterials,sufcient
re-resistantmeasuresmustbetaken.
•Determine the position of the unit and outlet and begin
constructionoftheuewiththeconnectiononthe
unit,payingattentiontothedirectionofinstallationand
connectingtheelementsbymeansofclampstrips.
•Thettedpipecanbeusedbetweenthebendsorwhen
connectingtotheunit.Ifnecessary,usewallbrackets
tosupporttheue.
Mounting using the roof pass-through option
•Theueoutletcanbelocatedatanyrandomplaceonthe
roofface(supplyandexhaustinidenticalpressureareas)
and must meet the applicable rules and regulations.
•Aroongsheetforaatrooforaroongsheetleadfor
sloping tiled roofs can be used for a watertight duct. Use
variousbendsfortheslope,ifrequired.Therecessinthe
roof decking should be 5cm larger all around to ensure
sufcientreresistance.
•One needs to take into account the regulation regarding
reresistancebetweenrooms(Seenational,regional,local
standardsandregulations).Acasingofreproofmaterial
(forexample,12mmPromatectre-resistantplate)should
beappliedupto25mmfromtheouterue.
•Determine the position of the unit and the outlet and begin
theconstructionoftheuewiththeconnectionontheunit
(always1metreverticalrst)payattentiontothedirection
ofinstallation.Theinneruemustbeinstalledfordraining
purposes. Connect the elements using the clamping straps.
Ensure all connections are gastight.
•Attedpipecanbeusedbetweenthebendsorwhen
making the connection to the unit and/or the roof pass-
through.Use2wallbracketstosupporttheueoneach
oor.
9.3 Installation instructions regarding
existing ues (See Appendix 2)
Instructions
Theuegasexhaustsystemfallswithincategory:C91and
must be built in accordance with national rules and regulations
andtheinstructionsofthemanufacturer,asspeciedinthe
documentation and installation instructions.
Thismeans,amongotherthings,thatthechimneypass-
throughmustnotbesmallerthan150mmround/square,
butnolargerthan200mm,andnotventilatedbygrilles,etc.In
thecaseoflargerchimneypass-throughs,aexiblehoseof
around150mmmaypossiblybeusedincombinationwitha
exiblehoseofaround100mm,asdescribedbelow.Forother
situations,consultyoursupplier/manufacturer.

Trimline 70 SL 15
9.4 Parts
Check all parts for damage before commencing the
installation.Fortheconversionofabrickuetoconcentric
ue,connectedtoCCuesystem,youneedthecomponents
described in Appendix 2.
Comment: The renovation/sanitation set consists of parts:
4. Interiormountingplate
5. Slidingelement
8. Chimneymountingplate
9.5 Installation
•Guidetheexiblehose(6)throughtheexistingue(7).
•Attachtheslider(5)tothebottomoftheexiblehoseand
secure this in place using two Parker screws.
•Keep the bottom of the slider at the same height as the
bottomoftheueorceiling.
•Shortentheexiblehosetoapproximately100mmabove
thechimneycoping.
•Attachthemountingplatetotheexiblehoseontheroof
(8),clampitwithahosebracket.
•Stainlesssteelround90to165,securethewholewith
Parker screws.
•Attachthemountingplatetothechimneycopingwatertight
on the roof (8) using silicone sealant and stainless steel
screws.
•Install the roof pass-through (9) and secure it in place using
the supplied clamping strip (10).
•Theslider(5)willprotrudeapproximately100mm
underneaththeueorceilingafterinstallation.
•Attach the inner mounting plate (4) gastight against the
bottomofthestructuralueoragainstthebottomofthe
concreteoorusingsiliconesealantandscrews.
•Position the unit in accordance with the instructions of the
unit manufacturer
•Installaminimumof1metreofconcentricuetype
THCCC(2).
•Extendtheconcentricueusingsections(2)uptoa
minimumof100mminthestructuralduct.Finally,turn
theclampingstripbyhandinthemountingplateinside(3).

16 Trimline 70 SL
10 PASS-THROUGH POSITIONS AND FUNCTION CORRECTLY
Plot boundary
External extension pipe
Roof pass-through
Dimensions Outlet positions Distance mm
A Distance to ventilation openings Room*
B Distance to ventilation openings Room*
C Distance to ventilation openings Room*
D Gutter channel base pipes or outlet pipes below here 500
E Under the eaves 500
FUnderacarport,rooforbalcony,insideandoutsidecorners 500
G From vertical ground pipes or drain pipes 300
H Inside and outside a corner 500
I Above an external gas pressure regulator 1000
Side of a gas pressure regulator 500
J Conictdistancefaçadeoutlet Room*
K Roof drain centre to centre 1000
L From the centre of both roof drains 450
M Two wall drains above each other 1000
N Two wall drains next to each other 1000
* In accordance with local building codes

Trimline 70 SL 17
11 CLEANING AND MAINTENANCE
Thisunitmustbeinspectedandmaintainedbyaqualied,
recognisedandregisteredpersonatleastonceayear.As
aminimum,theinspectionandmaintenancemustensure
theunitworkscorrectlyandsafely.Itisadvisablethatthe
unitbecleanedofdustanddirtregularlyduringtheheating
season,andespeciallywhentheunithasnotbeenusedfor
an extended period of time. This can be done with a soft
brushandvacuumcleaner,oradampclothandnon-abrasive
detergentifnecessary.Donotuseaggressiveorcorrosive
substances to clean the unit.
Theconcentricuesystemmustbecleanedevery2years.
Also check:
1 The seal of the gas combustion products and combustion
airsupplycircuit.
2 The seal of the pressure hatches at the top and bottom of
thereplace,controlofthegasket.
3 Theoperationofthepressurehatches;thattheycanopen
andclosefreely.
4 Correct operation of the gas control block and ignition of
theburner.
5 The seal of the explosion hatch must be checked and/or be
replaced after it has been activated.
6 Cleantheconvectionspaceonceayear.
Service and repair
Ifthisunitneedstobeinspectedand/orrepaired,youcan
completelyremovetheburnerwithbase.
Removingtheburnerbaseandtechnicalequipment.
Disassembletheglasspanewithframeandpossiblythe
coverframe.
Bylooseningthecoverframe,alittlemorespacewillbecreated.
Take the ceramic blocks out of the unit and then the grate.
Standing this up straight is easiest. The burner and burner
support on the left is then visible. There is a Parker screw here.
Partlyloosenit,andthenslidetheburnertotheleft.Theglow
material can therefore remain on the burner. We see the base
uponwhichthetechnicalequipmentislocated.
There are Parker screws on the outer edge. These must be
unscrewed;thebaseplatecanthenberemoved.Leftsideup
rst,andthenremovetheentirethingwithaslighttwistupto
the left. The base is now loose. There is also a gas hose on the
technicalequipment.Disconnectthishose,thebasecanthen
becompletelyremovedwiththetechnicalequipment.Replace
in reverse order.
Measuring nipples
Iftheplanisonlytodisassembletheburner,asquareplate
under the gas pipe can be seen. Remove the four Parker screws
andreleasetheplate.Lookthroughtheholeandyoucansee
asmall,silver-colouredplate.Thisplatecanbeturnedcounter
clockwise. The measuring nipples are now visible. The left
nippleisforthepre-pressure,andtherightnippleistheburner
pressure. You can now insert a hose through the convection
chamber towards the measuring nipples and use a set of
combination pliers to slide the hose onto the measuring nipple.
The detached plate can then be replaced with the burner.
Turnthereplaceontocheckthegaspressure.Thenput
everythingbackinreverseorder.Theburnerpressurecanonly
beadjustedifthereplaceisnotyetinstalled.Removethe
frontpanel;thismakesinstallationeasier.
Iftheburnerpressureistobeadjustedafterinstallation,
thiscanbedonebyremovingtheburnerandthebase.
Injector
Unscrew for
access panel for
measuring nipples
Disassemble
burner base
Disassemble
burner base
Disassemble
burner base
Pivot panel
for measuring
nipples

18 Trimline 70 SL
Reset button accessible
byremovingtheframe
with glass with a small
hexkey.
Hose mounted on burner
pressure
This access has been made available to aid checking the pre-pressure
and the burner pressure after installation. The burners are tuned and
sealedbythefactory.Ifacorrectionisnecessary,theburnerbasewill
have to be disassembled in order to reach the adjusting screw.
Explosion
hatch
Thermocouple
Adjustment screw
burner pressure

Trimline 70 SL 19
AR glass (Anti-Reective glass) cleaning
instructions
General
ARglassisanon-reectingceramicglass.Thisglasshasan
ARcoatingonbothsidesoftheglass.Theanti-reectionlayer
reducesthereectiontoaminimalgloss.Itisaknownfact
thatthecoatinglayersaremoresensitivethantheceramic,
thereforeitisnecessarytofollowspecialcleaningprocedures.
Important
Donotuseanyofthefollowingcleaningagents:
•Hardorabrasivesponges,steelwool,abrasives
•Cleaning agents with ammonia or acid (even citric acid)
•Papertowels,ceramichobcleaner.
Only use water or a suitable detergent surfactant
We recommend our thermoCet Cleaner.
Remove frame with glass pane
See Paragraph 2.2 Preparation and placement on page 3.
Important
Aftertherstuse,therewillbeawhitehazeontheinsideofthe
glasspane;thiswhitehazemustberemovedimmediatelyafter
therstusewhentheunithascooleddown.
Thehigherthefrequencyofuse,themoreoftencleaningis
required.Aftermorefrequentuse,morefrequentcleaningof
theglasswillbenecessary.Bynotcleaningtheglassintime,
itwillbecomedullandincreasinglydifculttoclean.
Information
IfaunitwithARglassisplacednearwindows,orifthereisa
lotoflightontheglass,itispossiblethereectionofbright
colourswillbeseen.Forexample,theARglassmayreectthe
coloursfromaredsofa,whitetableoraoor.
IftheARglassiscleanedregularly,orbyfrequentlyusing
productsthatarenotrecommended,theAReffectwillfade
over time.
