Visionis VIS-8009 User manual

2.4GHz Indoor Wireless Keypad / Reader Access Control
500 Users Range of 50 Feet Delay and On/Off Toggle
Mode Battery Operated Standalone No Software
VIS-8009 / VIS-8010
User Manual

INTRODUCTION
The keypad is wireless ABS keypad, which operated by 3units of AAA batteries, it can work as long as one year
(bases on 30 times/day)
Specifications
Operating Voltage
3units of AAA batteries (Not included)
Current
Idle Current
Working Current
≤10uA
≤50mA
Communication Frequency
2.4G
Communication Distance
15m Maximum
Relay Contact Load
2Amp Maximum
Environment
Operating Temperature
Operating Humidity
Indoor
-20°C~60°C (-4°F~140°F)
0%~86%RH
Physical
Dimensions
Unit Weight
ABS Shell
L135 × W54 × D19(mm) - 5.31L x 2.12W x 0.74D (in.)
90g
INSTALLATION
Method 1: Stick by 3M stickers
The device packed with 3M double-side Sticker, can easily stick the Wireless Keypad on Metal door, Glass Door, Wooden
Door, or Smooth Wall.
Method 2: Install by screws

Sound and Light Indication
Operation Status
Red LED
Green LED
Buzzer
Standby
-
-
-
Unlock the lock
-
ON for 3 seconds
One beep
Key press under Program Mode
-
-
One beep
Enter into Program Mode
Shines per 1.5 seconds
-
One long beep
Invalid PIN
-
-
-
Exit from the Program Mode
-
-
One beep
Low battery reminding (Keypad)
Orange LED ON
Three beeps
Low battery reminding (Exit button)
Shines from Red to Green twice
-
PROGRAMMING
Enter and Exit Program Mode
Programming Step
Keystroke Combination
1. Enter Program Mode
* (Master Code) #
(Factory default is 123456)
2. Exit
*
Set Master Code
Programming Step
Keystroke Combination
1. Enter Program Mode
* (Master Code) #
2. Update Master Code
0（New Master Code）#（Repeat New
Master Code）#
Master code is any 6 digits
3. Exit
*
Add User PIN(s)
User ID: 0~499
PIN length: 4~8 digits
Programming Step
Keystroke Combination
1. Enter Program Mode
* (Master Code) #
2. Add PIN
1 (User ID) # (PIN) # (Repeat PIN) #
The PINs can be added continuously
3. Exit
*
Add User Card(s)
User ID: 0~499
Card type: 125 KHz EM card

Programming Step
Keystroke Combination
1. Enter Program Mode
*(Master Code) #
2. Add Card: Using Auto ID
(Allows VIS-3200 to assign Card to next
available User ID number)
OR
2. Add Card: Select Specific ID
(Allows Master to define a specific User ID to
associate the card to)
1 (Read Card) #
The cards can be added continuously.
1 (User ID) # (Read Card) #
3. Exit
*
Change PIN Users
Programming Step
Keystroke Combination
Note: Below is done outside programming mode, users can undertake this themselves
2. Change PIN: By Card
(There will auto allocate PIN(8888) to cards
when adding)
* (Read Card) (Old PIN) # (New PIN) # (Repeat New
PIN) #
2. Change PIN: By PIN
* (User ID) # (Old PIN) # (New PIN) # (Repeat New
PIN) #
3. Exit
Exit automatically
Delete Users
Programming Step
Keystroke Combination
1. Enter Program Mode
* (Master Code) #
2. Delete user
OR
2. Delete Card
OR
2. Delete all users
2 (User ID) #
The users can be deleted continuously
2 (Read Card) #
2 (Master Code) #
3. Exit
*
Set Access Mode
Programming Step
Keystroke Combination
1. Enter Program Mode
* (Master Code) #
2. PIN Access
OR
PIN + Card Access
OR
PIN or Card Access
3 0 #
3 1 #
3 2 # (factory default)
3. Exit
*

Set Relay Configuration
The relay configuration sets the behavior of the output relay on activation.
Programming Step
Keystroke Combination
1. Enter Program Mode
*(Master Code) #
2. Pulse Mode
OR
2. Toggle Mode
4 (1-99) # (factory default)
The relay time is 1-99 seconds. (1 is 50mS.)
(Default is 5 seconds)
4 0 #
Set the relay to ON/OFF Toggle mode
3. Exit
*
Set Safety Mode
In safety mode, it can be set to deny access for 10 minutes after 10 failed PIN/card attempts in 10 minutes
(Factory default is OFF).
Programming Step
Keystroke Combination
1. Enter Program Mode
*(Master Code) #
2. Strike-Out OFF
OR
2. Strike-Out ON
6 0 # (factory default)
6 1 #
3. Exit
*
Set Buzzer
Programming Step
Keystroke Combination
1. Enter Program Mode
*(Master Code) #
2. Buzzer OFF
OR
2. Buzzer ON
7 0 #
7 1 # (factory default)
3. Exit
*
OTHERS
Users Operation
Programming Step
Keystroke Combination
PIN User Access
(PIN) #
Card User Access
# (Read Card)
PIN + Card User Access
# (Read Card) (PIN) #

Pair with Controller
Pair Additional Wireless Keypad and Mini Controller
1) They all are already paired when out of factory, if no problem, the users do not need to do this operation in using.
2) One Mini Controller can be connected by five pcs of Wireless Keypad and Exit Button maximum.
To pair the Wireless Keypad and Mini Controller:
Wireless Keypad: * Master Code # 9 0 #
Mini Controller: Remove the back cover, and press the button “Pair”
If pair successfully, there will be one beep from both the controller and the keypad, you can add the keypad continuously
If not, there will be three short beeps, then please repeat the setting.
The keypad does not need to be entered * for exit in this step.
Reset to Factory Default
Open the back cover of the wireless keypad, press the button “RST” on the main board, hold it for 5 seconds, release it
until hear a long beep, means reset to factory default successfully.
After that, all settings except the relay time will be back to factory defaults, the users’ information will still be retained.
At the meanwhile, please pair the wireless keypad and wireless exit button with the mini controller again.
Low Battery Reminding
With 3 pieces 3A (AAA) battery, the wireless keypad can work continuously for at least 1 year, basing 30 times
PIN/card input a day.
If low battery of the wireless keypad, there will be 3 beeps when every key is pressed, and the LED will stay in Orange,
then please replace the batteries within one week.
VIS-8009 - Simplified Instruction
Function description
Operation
Enter the Program Mode
* (123456) #
then you can do the programming
(123456 is the factory default master code)
Change the Master Code
0 (New Code) # (Repeat the New Code) #
(Code: 6 digits)
Add PIN User
1 (User ID) # (PIN) # (Repeat PIN) #
Add Card User
1 (Read Card)
Delete User
2 (User ID) #
2 (Read Card)
Exit from the Program Mode
*
How to release the door
PIN Access
PIN #
Card Access
# (Read Card)
PIN + Card Access
# (Read Card) (PIN) #
