Visonic NC543W User manual

Image Sensor
Image sensor: Color CMOS sensor
Minimum illumination: 0.5 lux
Night Vision Distance up to 20m
Lens
Lens type: Board lens
Aperture (F/No): 2.0
Focus length: 6.0 mm
View angle: 60°
Image Processing
Compression: MJPEG
Auto exposure control: Yes
Auto white balance: Yes
Auto gain control: Yes
Image resolution and
frame rate:
VGA (640 x 480): 30 fps
QVGA (320 x 240): 30 fps
QQVGA (160 x 120): 30fps
System
Power: DC12V
Power consumption: 9 watts maximum
Environment: Operating temperature: -14°F to 122°F
Communication
Ethernet: One RJ45 port; IEEE 802.3u compliant 10/100 Mbps fast Ethernet with Auto-MDIX
Antenna: External dipole antenna
Wireless security: WPA (TKIP/AES), WEP (64bit or 128bit), WPA2 (TKIP/AES)
Wireless: IEEE802.11b/802.11g wireless LAN
Other
Reset functions:
* System reboot
* Reset full conguration to factory default values
Reset button: Push and hold for more than 10 seconds: returns to factory default values
Audio: Two-way Audio
Web browser: * Supports Firefox, Safari, Opera, etc.
Advanced Outdoor Camera for use with PowerLink
NC543W
Outdoor Waterproof IP camera with IR Illumination

Cam3200
Wireless Pan/Tilt Network Camera
Cam3100
Wireless Network Camera
Image Sensor
Image sensor 1/4'' color CMOS sensor
Minimum illumination 0.5 lux
Lens
Lens type Board lens
Aperture (F/No.) 1.8 2.6
Focus length 4.0 mm 4.6 mm
View angle 64° 60°
Image Processing
Compression MJPEG
Auto exposure control Yes
Auto white balance Yes
Auto gain control Yes
Image resolution and frame
rate VGA (640 x 480): 30 fps, QVGA (320 x 240): 30 fps QQVGA (160 x 120): 30fps
System
Power DC12V DC5V
Power consumption 9 watts maximum 6 watts maximum
Environment Operation: Temp. 0°C - 45°C Humidity: 20% ~ 85% non-condensing
Storage: Temp. -15°C - 60°C Humidity: 0% ~ 90% non-condensing
Approvals FCC/CE class B
Communication
Ethernet One RJ45 port; IEEE 802.3u compliant 10/100 Mbps fast Ethernet with Auto-MDIX
Antenna External dipole antenna
Wireless security WPA (TKIP)
Wireless IEEE802.11b/802.11g wireless LAN
Pan-Tilt
Pan range +165° to -165° --
Tilt range +90° to -15° --
LEDs
Power LED Orange
Link/Activity LED Green
Reset button -- Push and hold for more than 5 seconds:
returns to factory default values
Other
Night vision IR LED with light sensor control
Reset functions * System reboot
* Reset full conguration to factory default values
and PowerMax are registered trademarks of Visonic Ltd. Other names are the property
of their owners. Visonic reserves the right to change information or specications without notice.
Advanced Cameras for use with PowerLink
