vita VACUMAT 6000 MP User manual

VITA VACUMAT 6000 MP
VITA shade, VITA made.
VITA shade control
VITA shade reproduction
VITA shade communicationVITA shade taking
Date of issue: 01.13
Operating manual

3
VITA VACUMAT 6000 MP
1 Introduction 4
2 Delivery scope 5
2.1 Control unit 5
2.2 Accessories (can be purchased separately) 5
3 Technical information 6
3.1 General description of the VITA VACUMAT 6000 MP furnace 6
4 Technical data 6
4.1 Dimensions / Weights 6
4.1.1 VITA VACUMAT 6000 MP furnace 6
4.2 Electrical specifications 6
4.2.1 Furnace 6
4.2.2 Vacuum pump 6
5 Intended use 7
6 Safety instructions 7
6.1 Pictograms 7
7 Ambient conditions 8
8 Safety features 8
9 Installation and first use 9
9.1 Installation location 9
9.2 Device connections 9
9.3 Compressed air connection 10
9.4 Status display 10
9.5 Fuses 10
9.6 Information about the identification labels 10
9.7 Connecting the device to the mains power supply 11
9.8 Switching off the device, or stopping its operation 11
10 Cleaning the furnace 12
10.1 Cleaning firing for the firing chamber 12
10.2 Firing chamber insulation 12
11 CE mark 12
12 Fan 12
13 Mains power supply failure 13
14 Warranty and liability 13
14.1 Spare parts 13
14.2 Service 13
15 Alphabetical order of contents 14

4
VITA VACUMAT 6000 MP
1 Introduction
Dear Customer,
Thank you for deciding to purchase our VITA VACUMAT 6000 MP with pneumatic
pressing mechanism.
This tried and tested heating system for dental ceramic furnaces, with its quartz/
Kanthal firing muffle and a newly developed insulating material in the firing
chamber, is your guarantee of many years of constant firing results with all types
of ceramic materials.
The high-quality temperature control and automatic temperature adjustment
function ensures an accuracy of plus/minus 1 °C.
Please read this operating manual carefully before first use.
The operating manual is an important aid for the successful and safe operation
of the device.
The operating manual contains important information on how to use the device
safely, correctly and efficiently. Compliance with this information helps to prevent
risks, reduce repair costs and downtime, and increase the reliability
and service life of the device.
All of the illustrations and drawings in this operating manual are intended
for general explanatory purposes and are not authoritative for the detailed
construction of the device.
This operating manual must always be kept close to the device. It must be read
and followed by all persons responsible for working with/on the device, for
example in relation to:
• operation,
• troubleshooting and problem solving during operation,
• cleaning,
• servicing (maintenance, inspection, repairs).
Copyright
The confidentiality of this operating manual must be maintained. It must only
be used by authorized persons. It may only be transferred to third parties with
the written approval of VITA Zahnfabrik H. Rauter GmbH & Co. KG.
The entirety of the documentation is protected by the Copyright Act.
The dissemination or duplication of documents, even in the form of excerpts,
and the use and communication of their content is prohibited except where
expressly permitted.
Violations are punishable by law and will result in obligatory claims for
compensation of damages.
All rights to exercise intellectual property rights are reserved.

5
VITA VACUMAT 6000 MP
2 Delivery scope
Device supplied in a special box with:
• 1 VITA VACUMAT 6000 MP furnace, painted or stainless steel
• 3 firing sockets and 2 sets of pressure discs
• 1 plug-in LED status display
• 1 power supply cord
• 1 pair of furnace tweezers
• 1 pack of firing trays A + B
• 1 pack of firing trays G
• 1 operating manual
• 1 connection cable for the control unit
• pressure regulator to be attached to the vacuum pump
• 1 Pressure tube, vacuum tube
2.1 Control unit
The VITA VACUMAT 6000 MP can be equipped with the following
control units:
• VITA vPad comfort with 7" color touch screen, photo viewer,
memory for 500 firing programs for control of 1 or 2 VITA VACUMAT
6000 M / 6000 MP furnaces.
• VITA vPad excellence with 8.5" color touch screen, photo viewer,
memory for 1000 firing programs for control of 1 to 4 VITA VACUMAT
6000 M / 6000 MP furnaces.
• VITA vPad clinical with 7" color touch screen, photo viewer,
memory for 500 firing programs for control of 1 or 2 VITA VACUMAT
6000 M / 6000 MP.
An additional switchbox and connection cable is required for the operation
of 2 or more VITA VACUMAT 6000 M / 6000 MP with a VITA vPad comfort,
VITA vPad excellence or VITA vPad clinical control unit.
Read the information about this in the operating manual of the
corresponding control unit.
2.2 Accessories (can be purchased separately):
• Lateral cover plates, set of 2
• Firing object storage tables, set of 2
• Vacuum pump: 230/240 volts, 50/60 Hz;
115 volts, 50/60 Hz; or 100 volts, 60 Hz
• FDS (Firing-Data-System) firing data management program for PC
• Magnetic numbers, 1-4, set of 4

6
VITA VACUMAT 6000 MP
3 Technical information
3.1 General description of the VITA VACUMAT 6000 MP furnace
• High-performance technology with highest temperature accuracy
for optimal firing results
• Convenient time-saving operation, modest spatial requirements
• Sheet steel casing with a painted or stainless-steel finish
• Extendable firing object storage tables
• Display of operating mode
• Firing chamber lined with high-quality insulating material
• Quartz firing muffle
• Temperature sensor (platinum / rhodium-platinum)
• Automatic temperature calibration before the start of each program
• Temperature accuracy to plus/minus 1 °C (33.8 °F)
• Pneumatic pressing mechanism
4 Technical data
4.1 Dimensions/weights
4.1.1 VITA VACUMAT 6000 MP furnace
• Width: 230 mm
• Depth: 370 mm
• Height: 630 mm
• Casing, Weight: painted steel 18.7 kg, stainless steel 20.1 kg
• Usable measure (firing chamber): Diameter: 90 mm, Height: 55 mm
• Firing chamber temperature: max. 1200 °C
4.2 Electrical specifications
4.2.1 Furnace
• Power supply: 230 volts AC, 50 Hz
or 100/110 volts AC, 50/60Hz
• Power consumption: max. 1,500 watts
4.2.2 Vacuum pump
• Power supply: 230 volts, 50/60 Hz
or 100/110 volts, 50/60 Hz
• Power consumption: max. 200 watts
• End vacuum: < 960 mbar
• Dimensions: 320 x 110 x 220 mm
• Weight: approx. 6.4 kg

7
VITA VACUMAT 6000 MP
5 Intended use
Basic information on the device construction
The device is constructed according to a state of the art design and recognized
safety regulations. However, if it is used inappropriately, hazards for the health
and safety of the user or third parties may arise as well as the risk of damaging
the device and other valuable assets.
Unauthorized modes of operation
The operation of the device with power sources, products, etc. which are
considered hazardous or capable of negatively impacting the health of the
operating personnel is not permitted. The use of equipment modified
by the user is also prohibited.
Authorized modes of operation
The operation of the device is only permitted if this operating manual has
been read and understood thoroughly and the procedures described in it have
been observed. Any other or additional use, e.g. the processing of products
other than those intended as well as the handling of hazardous materials or
substances injurious to health is considered to be contrary to the recommended
use. The manufacturer/supplier will not be liable for any damage resulting from
such unauthorized use. The risk of such use is borne exclusively by the user.
6 Safety instructions
6.1 Pictograms
This pictogram warns of hazardous voltage.
Before opening the device, it must be disconnected from
the mains power supply by pulling out the mains switch.
This pictogram warns against the presence of hot surfaces.
Burn injuries may occur.
Observe separate disposal of electrical and electronic devices;
do not dispose of them with household waste.
The black bar under the "Trashcan" icon means that the device
was sold after 13.08.2005.
Please note that the device is subject to European Community
Directive 2002/96/EC (WEEE) and the national laws in force
in your country and must be handed over for appropriate disposal.
Contact your dealer when the device needs to be disposed of.
This pictogram warns of hazardous situations involving
the possibility of personal injury or damage to the device.
This pictogram highlights useful tips, explanations and additional
information concerning the operation of the device.
Hazardous voltage
Hot surface
Seperate disposal
Note
Information

8
VITA VACUMAT 6000 MP
7 Ambient conditions
• Indoor use
• Ambient temperature: 2 °C to 40 °C
• Relative humidity: 80% at 31 °C
• Maximum altitude: 3,800 m
• Rated voltage fluctuations must not exceed
plus/minus 10% of the rated voltage.
8 Safety features
The furnace is operated with a control unit
VITA vPad comfort or
VITA vPad excellence or
VITA vPad clinical
and has the following safety and monitoring features:
• Temperature sensor monitoring
• Temperature monitoring
• Vacuum monitoring
• Power failure protection
• Lift monitoring
• Monitoring of press stroke

9
VITA VACUMAT 6000 MP
9 Installation and first use
9.1 Installation location
• Install the device in a dry, heated room. The distance to the closest wall
should be at least 25 cm. (see sect. 7. Ambient conditions)
• When the temperature is below 15 °C (59 ºF) (e.g. after transport),
leave the device to stand for approx. 30 minutes before using it
for the first time at room temperature.
• Ensure that the device is on a heat-resistant surface.
The radiation and heating of the device is in the non-hazardous range.
However, heat-sensitive surfaces of furniture and veneers could become
somewhat discolored over time due to the constant influence of heat.
• Prevent direct sunlight from coming into contact with the device.
• Do not place any flammable objects in the vicinity of the device.
Do not place the control unit directly in the heat radiation area
of the firing chamber.
• Do not set up the device in such a way that it becomes difficult
to press the main switch and pull out the power supply cord.
Before using for the first time, read the corresponding operating manual
for the control unit
9.2 Device connections
Status display
(see sect. 9.4)
Compressed air connection
max. 5 bar
Connection for control unit
VITA vPad comfort or
VITA vPad clinical or
VITA vPad excellence or
Switchbox
Vacuum tube connection
Device fuses (see sect. 9.5)
Vacuum pump connection
(see sect. 4.2.2)
Pressure regulator 3 bar
Mains power supply connection
Main switch

10
VITA VACUMAT 6000 MP
9.3 Compressed air connection
The vacuum pump features a pressure regulator.
The inlet pressure from the lab's compressed air supply should not exceed
6 bar.
The pressure supplied to the device should be adjusted to a maximum of 5 bar.
About the settings for the press pressure see operating manual of
VITA vPad excellence / comfort (see sect. 18.3)
9.4 Status display
The status display indicates following operation status:
• green – furnace in standby-mode
• blue – program active
• red – error
Please see operating manual of the corresponding control unit.
9.5 Fuses
On the back of the device (see sect. 9.2), there are 2 device fuses.
The identification plates show information about the fuse ratings used
in the device. Fuses with other ratings must not be used.
230-volt model
T 8 H 250 V
100/110-volt model
T 15 H 250 V
The manufacturer is not liable for accidents to the user occurring
when the device is open!
9.6 Information about the identification labels
This pictogram warns of hazardous voltage. Before opening the
device, it must be disconnected from the mains power supply by
pulling out the mains switch.
After the back-plate has been removed, a voltage of up to 400 volts
may still exist in components in the area of the power supply unit
on the circuit board, even when the device is switched off.
Do not place any objects in the area of the lift plate.
When the device is switched on, the lift will move down to the
lower position. When putting down the firing objects, use the
laterally extendable storage plates.
Hazardous voltage
Residual voltage
Note

11
VITA VACUMAT 6000 MP
Never start up the device without the firing socket attached.
In continuous operation (max. final temperature, max. firing time), some parts
of the firing chamber may reach high temperatures (above 70 °C (158 ºF)).
Do not reach into the open firing chamber when the device is switched on.
There is a risk of touching electrically live or hot parts.
9.7 Connecting the device to the mains power supply
Important: Before first use, read sect. 6 on safety signs!
For information about the connections, see sect. 9.2
• Attach the connection cable to the control unit and the furnace.
• Plug in the status display.
• Connect the vacuum pump, power supply and tube connection.
• Connect the device to the mains power supply using the supplied
mains power cable.
• Install pressure tube for pressing mechanism.
Important: Avoid connecting to multiple-outlet power strips with
extension cords. In the event of overloading, a risk of fire exists.
• Switch on the device at the main switch.
The lift moves to the lower position.
• Clean or wipe the lift plate and the lift plate gasket (dust particles from
the insulation are deposited during transportation of the device).
• Attach the firing socket to the lift plate.
• To accommodate the investment ring, 2 firing sockets are provided,
each with 2 pressure discs of different diameters.
Important: For the purposes of pressing, always insert both
pressure discs into the firing socket.
Important: Never start up the device without the firing socket
attached!
9.8 Switching off the device, or stopping its operation
When the device is not in operation, the lift should be moved into the
firing chamber and the device must be switched off at the main switch
(see sect. 9.2). Closing the firing chamber protects the insulation and prevents
the absorption of moisture.
For instructions on how to do this, please read the operating manual
of the corresponding control unit.
