VITRA S-5900573 User manual

ACRYLIC HYDROMASSAGE BATHTUBS
User Manual

October 2016
CONTENTS
Foreword ................................................................................................................................................................3
General Characterstcs of the Product ...................................................................................................................3
Matters requrng attenton Durng Shppng and Transportaton...............................................................................3
Bathtub Installaton Applcatons..............................................................................................................................4
• Installaton of Bathtubs wth Panels..................................................................................................................4
• Installaton of Monoblock Bathtubs..................................................................................................................6
Use of Bathtub Systems.........................................................................................................................................7
• Duo Max System............................................................................................................................................7
• Duo Soft System...........................................................................................................................................10
• Aqua Max System.........................................................................................................................................12
• Ar Relax System........................................................................................................................................... 14
• Aqua Soft System..........................................................................................................................................15
• Aqua Soft Easy..............................................................................................................................................16
Suggestons for Usage and Mantenance of Bathtub Systems...............................................................................17
• Suggestons for Usage..................................................................................................................................17
• Matters Requrng Attenton...........................................................................................................................17
• Cleanng of Bathtub Systems........................................................................................................................17
• Dsnfecton of Bathtub Systems....................................................................................................................1 8
• Mantenance of Bathtub Systems..................................................................................................................18
• Problems You May Encounter and Ther Solutons.........................................................................................18
Matters Not Covered Under Warranty....................................................................................................................19
• Transportaton, Storage ................................................................................................................................19
• Installaton.....................................................................................................................................................19
• Use, Cleanng and Mantenance.................................................................................................................... 19
www.vtra.com.tr
Manufacturer Company Consultancy Lne
0850 311 70 70
General Dstrbuton
Central Servce
İntema A.Ş.
Al Kaya Sk. No: 7
Levent 34394 İstanbul
Tel : [phone]
Faks: 0212 350 85 80
Ths user manual apples to all VtrA Acrylc Hydromassage Bathtubs.
Eczacıbaşı Yapı Gereçler
San. ve Tc. A.Ş.-Küvet
Şfa Mah. Yaman Sok. No:10
Tel : [phone] (Pbx)
Tuzla 34941 İstanbul Türkye

Dear customers,
By ensurng a correct and purposeful use of ths product whch you have purchased, we would lke t to delver the best
performance to you.
1- Accept the purchased product by removng t from ts carton at our sales pont and/or at the delvery to address and
checkng ts parts one by one. If any mssng materals or any breakage or damage s detected, nform the nearest Authorzed
Seller or the Authorzed Servce. In such cases, please protect the product n ts orgnal packagng.
2- Have the User Manual of the product whch you have receved wthout any mssng parts or any damages APPROVED by the
Authorzed Seller.
3- We urge you to carefully read ths gude n full before havng our product nstalled and keep t for future reference.
4- For the products offered wth a ‘Free-of-charge Installaton’ to be covered by the warranty, you must have ther nstallatons
performed by a VtrA-Artema Authorzed Servce. You wll not be charged any nstallaton fees for ths.
5- Please call the Authorzed Servce after completng the preparatons for the requred nfrastructure.
6- In the event you need servce for nstallaton, mantenance and repars;
• Ask from our seller for the telephone number of the Authorzed Servce n the area you are lvng n.
• In places where we do not have a seller , you may get the necessary nformaton from the telephone numbers gven n the
gude.
• Ask the servce personnel to dsplay ther “Vtra Artema Authorzed Servce Personnel Card”. Do not let people wthout a
personnel card perform the nstallaton
• At the completon of the process, the techncan s oblged to wrte the 'Servce Form' correctly and n detal and have you
sgn t and gve a copy to you. Please keep the 'Servce Form'.
• Some Authorzed Servces may have been shut down n tme. You can learn the most relable address from our webste at
www.vtra.com.tr , whch s contnuously updated and/or by callng our consultancy lne at 0850 311 70 70
• The tems above have great mportance for determnng people who work under the name of specal servce and who are
not Authorzed Servces. Please take note of these.
7- In case our Seller or our Authorzed Servce cannot satsfy your request or complant please contact the communcatons
means provded wthn the gude.
Sncerely yours,
GENERAL CHARACTERISTICS OF THE PRODUCT
The hghest qualty polymethylacrylate, n other words, "Acrylc" s used as the prmary materal n the producton of VtrA Acrylc
Bathtub Systems. Acrylc whch has a hgh wear resstance s preferred because t can be easly cleaned and does not host
mcroorgansms.Acrylc s known to be one of most accommodatng materals for human nature. Havng a flexble structure,
acrylc mantans ts reslence aganst mpacts and does not deform. Any small scratches whch mght occur on the surface can
easly be elmnated through polshng. Acrylc products do not lose ther shne due to a homogenous dstrbuton of color cells,
and saves the “first day appearance” over years.
The acrylc plates used n the producton of VtrA VtrA Acrylc Bathtub Systems meet the EN 263 Standards for Acrylc Plates
and are suppled from Lucte Internatonal (ICI) whch s one of the leadng producers n the word. The plates are assured aganst
wear and tear through a ten-year agng test conducted by TUBITAK.
As the Acrylc Hydromassage Bathtubs are produced n complance wth EN6035 – 1 / EN60335 -2-60 standards, Vtra meets
the TS 301-DIN 2440 standards n leg sets and EN 274 standards n flushers.
The usage lfe of the product s 10 years as per the communqué on “After-sale Servces of Industral products” publshed by TR
the Mnstry of Industry and Trade.
MATTERS REQUIRING ATTENTION DURING SHIPPING AND TRANSPORTATION
1- The products should be transported and placed accordng to the transportaton and protecton sgns found on the package.
2- Durng the forklft carrage of products shpped n crates or cardboard packagng you should make use of pallets.
3- In order to prevent products from breakng durng ther storage and protecton they should be placed n accordance wth the
drecton ndcated on the packagng and placng them on top of one another should be avoded.
4- Product parts removed from packages opened for the purpose of carryng to floors should be checked and carred n a
protected manner.
5- The protectve film cover over the product should not be removed before transportaton, nstallaton and repar transactons.
CAUTION! Chldren should be allowed to use the product only under supervson.
3
• VtrA Shower Seats are under warranty for 2 years from the purchase date.
• In order that you wll benefit from “2-year warranty” applcaton please have the Warranty Certficate approved by
Intema Store or Intema Authorzed Seller from whch you purchase the shower seat or VtrA - Artema Authorzed
Servce whch nstalled your shower seat.
• In case of any problem, please contact wth the nearest VtrA-Artema Authorzed Servce.

BATHTUB INSTALLATION APPLICATIONS
Installaton of Bathtubs wth panels
1
5
910
6 7 8
234
1- The bathtub should be nstalled to a structurally prepared floor.
2- If the bathtub s purchased wth a packagng on pallets, the leg sets must be nstalled to the bathtub. In ths case the leg profiles are prepared to
be nstalled on the bathtub. The bathtub s placed upsde down on a clean floor and the U shaped legs are nserted to the toggle and fixed to the
bottom of the product va two screws.
3- The toggle screws are tghtened.
4- Remove the protectve folo of the bathtub from Its sdes that are touchng the wall and from the area around the sphon.
(Note: The remanng protectve folo on the bathtub should be removed only after the bathtub nstallaton and other constructon works n the
bathroom are finshed.)
5- Place the bathtub to the nstallaton area.
6- Adjust and level the leg set accordng to the heght of the panel. Check the evenness wth a scale. (See the Techncal Data Sheet for the panel
heght).
7- Tghten the let sets nuts.
8- Mark the leg set nstallaton holes (Cauton! No hole should be drlled on heated and solated floors!).
9- The ponts on the wall tles whch are marked for nstallng the wall hangers are drlled wth a drllng machne (tp 10) and the wall hangers are
fixed (The techncal detals are gven n the "Wall Hanger Detals” secton of the Techncal Data Sheet.)
10- Prepare the bathtub sphon for nstallaton. (At ths stage do not forget to remove protectve folo on the bathtub around the sphon hole.)
4
Ponts that Requre Attenton:
• We recommend the bathtub to be nstalled after tlng the wall tles and other constructon related works n the bathroom are completed.
• The techncal detals of the bathtub s provded n the Techncal Data Sheet.
• Faucets should be nstalled as shown on the Techncal Data Sheet.
• If a wall-mounted bathtub mxer s preferred the approprate mxer should be nstalled on the wall n accordance wth the nstructons
provded n the Techncal Data Sheet.
• It should be ensured that the floor tles are even and the walls are straght (90 °) before startng nstallaton.
• Cold and hot water connectons must already be realzed.
• If ths s a hydromassage bathtub the electrcal connecton should be prepared as shown n the Techncal Data Sheet.

11 12 13 14
11- Apply slcone on the sphon dran seal and the bearng seal,
12- Install the bathtub sphon you’ve prepared.
13- It s not requred to fix the leg set of the bathtub to the floor when wall hangers are used. However for un straght walls. The bathtub leg set
nstallaton holes are drlled wth a drllng machne (tp 7-8) (Cauton: No hole should be drlled on heated and solated floors.)
14- Screw the leg set to the floor.
18 19 20 21
18-19- If the sde panel wll be used wth the product, mark the floor where the panel supports are to be fixed and fix the panel supports to the
floor usng slcone.
20- Remove the protectve folo on the panels.
Note: If ths Is a hydro massage bathtub, the electrcal connecton should be made.
21- For rectangular bathtubs, first the sde panel and later the front panel are nstalled to the bathtub. For corner bathtub panels, fixed metal
clps are avalable for panel nstallaton under the front sde rms of bathtub to fix the panel. The panel’s nstallaton s started from one corner
by attachng the top band of the panel to these clps.
22 23 24
22- Slcone s appled between the bathtub and the wall n order to prevent any leakage
23- Addtonal edge lath applcaton can be carred out f requred. However solaton between wall and bathtub must be ensured before the
applcaton of edge lath. The edge lath s nstalled by applyng slcone along the length of both surfaces of the edge lath whch wll come nto
contact wth the bathtub and the wall.
24- The nstallaton of the bathtub s complete. Any protectve folo remanng on the bathtub should be removed only after all of the constructon
works n the bathroom are finshed.
15 16 17
15- The bathtub s fixed to the wall by tghtenng the cap screws of the wall hangers.
16- Sphon outlet Is connected to the water dran. Perform leak proofing tests.
17- Panel supportng brackets are adjusted and screwed.
5

Installaton of Monoblock Bathtubs
1
4
7
10 11 12
8 9
5 6
2 3
1-2 Bathtub must be carred upsde down. It must never be carred by holdng from ts panel
3- In ths seres a ‘hdden overflow’ s nstalled to plan and hydro massage bathtubs by the manufacturer. Therefore the product comes wth the
sphon nstalled. The bathtub s placed on the nstallaton area and the permeter of ts bottom s marked. Insde the marked area, the 50
mm dameter waste water dran ppe s nstalled from the center shown n the drawng, at the pont ndcated by the letter “A”, and the water
nlet ppes are nstalled to the centerlne of the faucet above the bathtub, at the pont ndcated by the letter “C", as llustrated n the techncal
dagram. If ths s a hydro massage (hydro massage) bathtub, a 220 V phase, neutral and earth electrc lnes are requred to be connected
nsde the marked area, n accordance wth the orentaton of the bathtub (seethe area ndcated by the letter “E").No water dran muff should
be left n the area ndcated by the letter “B”. External faucet applcaton should be carred wth a mnmum dstance of 100mm to the bathtub
and n accordance wth the bathtub placement. The axle dstance between the hot and cold water nlet ppes should be adjusted n
accordance wth the techncal drawng of the faucet. (See the Techncal Data Sheet for the techncal scheme).
7- The parts of the bathtub’s monoblock sdes that touch the floor should be marked. The panel supportng brackets should be pulled nsde at
the thckness of the acrylc and they should be fixed to the floor wth slcone. Accordngly, movement of the bathtub on the floor s
prevented.
8- The sphon dran ppe connecton and also the electrcal connecton (f the product s hydromassage) of the bathtub should be made
9- Tghten the leg set nuts.
10- Apply slcone on the bathtub legs’ parts whch contact the floor.
11- When the nfrastructure nstallaton s completed the taken down from the bearng supports. When deemed necessary apply slcone to
several ponts between the bathtub panel and the floor and complete the nstallaton
12- The nstallaton of the monoblock bathtub s completed. Any remanng protectve folo on the bathtub should be removed only after the
bathtub nstallaton and any other constructon worksn the bathroom are finshed.
4-5 The bathtub s taken nto level usng a scale at the nstallaton area.
6- For the nfrastructure nstallaton, the bathtub s placed on bearng supports at the nstallaton area.
Cauton: Durng the nfrastructure nstallaton, the bathtub should not be tlted sdeways and no weght should be placed on ts sde panels.
6

USE OF BATHTUB MASSAGE SYSTEMS
DUO MAXI SYSTEM
7
Halogen lamp
Water Sucton Flter
Ar Controller
McroWater Jet
Ar Jet
Dsnfectant
Tank Fllng Cap
"Sample layout. See the Techncal Specficatons
for the product you’ve purchased"
McroWater Jet
Ar Controller
Ar Jet Water Sucton Flter
Halogen Lamp (optonal)
DUO MAXI SYSTEM: In the DUOMAXISystem, there are ar and water massage optons whch can work ndvdually or n combnaton.
Whle the water s ntroduced nto the bathtub through 18 mcro water jets va a pump; ar s ntroduced nto the bathtub through 10 ar
jets located on the base of the tub by means of a blower. All of the functons of the system are controlled by an Electronc Control Panel
whch s present only n the DUOMAXI system. The system, where all vsble parts (jet, ar controller, etc.) chrome over brass, has 4 ar
controllers. The bathtub has a safety system (sensor) that prevents the motor from operatng when the tub s empty or the water level s
not 3cm above the topmost jets. 2 halogen lamps can be nstalled f desred. The Electronc Control Panel has 7 or 9 functons,
dependng on whether the system s preferred wth or wthout lamps. These functons are as follows:
• Contnuous Water Massage
• Intermttent Water Massage
• Contnuous Ar Massage
• Intermttent Ar Massage
• Contnuous Lght
• Intermttent Lght (The contnuous and ntermttent lght functons can be used only f the product s suppled wth lamps)
• Water Intensty Adjustment (Automatc and Manual)
• Ar Intensty Adjustment (Automatc and Manual)
• Automatc Dsnfecton Program
IMPORTANT NOTE: The specfied number of jets n the massage system may vary accordng to the bathtub model, due to
techncal reasons.
Cauton: In bathtubs wth DUOMAXISystem, the ‘ar blower’ wll automatcally actvate 20 mnutes after the hydro massage system s
used and the tub starts to empty n order to dry the water that mght reman n the ppes (operaton duraton s 1 mnute). In order for
ths system, whch s present n order to ncrease the hygene of your hydro massage system the breaker must be open. Close the
‘breaker’, whch we have nstalled n order to protect your massage system and recommend you to keep closed when not usng the
system, after the ar blower automatcally actvates and deactvates.
Exquste: Ths s the electronc panel where the functons of the DUOMAXI massage system are controlled from.
Mcro water jet: These are jets located on the nner sde surfaces of the bathtub wth 30 mm dameter, where the water sucked nto
the bathtub are ntroduced back nto the bathtub through a pump. It s possble to mx the ar n the envronment nto the water sprayed
through the jets by means of the ar controllers. There are 18 mcro water jets n the DUOMAXISystem.
Ar jet: These are jets located on the base of the bathtub wth 30mm dameter, where the ar s ntroduced nto the bathtub through a
blower. There are 10 ar jets n the DUOMAXIsystem. Care should be taken not to block the ar jets durng use or cleanng. Snce
blocked ar jets wll prevent ar from extng the heatng that mght occur nsde can damage the blower.
Water sucton filter: Ths s a filter that enables the water nsde the bathtub to be sucked by a pump.Care should be taken to keep
har and clothng away from the filter whle t s n operaton.
Ar controller: It s possble to ntroduce ar from the envronment nto the water pumped nto the bathtub through the water jets, and
thus ncrease the effectveness of the massage. The amount of ar to be mxed wth water can be adjusted through ar controllers. If the
ar controllers are fully closed only water wll ext the jets.The more the ar controllers open, the more ar wll ext the jets. There are 4 ar
controllers n DUOMAXISystem. Each of these effect the jets located n dfferent corners.
Halogen lamp: Each lamp s 50W strong. 2 halogen lamps can be nstalled n DUOMAXISystem, f desred.It s not recommended that
the lamps be used when the bathtub s not full wth water. Long terms use n ths manner can damage the lamp due to overheatng.

Only the and buttons are pressed untl you reach the desred value.
Ths button group operate the functons related wth the lghts
Ths button group operates the functons related wth ar massage
Ths button group operates the functons related wth water massage
Water Massage:
Ar Massage:
Lght:
Starts and stops the water massage
Increases or decreases the ntensty (force) of the water massage
Automatcally ncreases or decreases the ntensty (force) of the water massage
Operates the water massage ntermttently (n ntervals). The ntensty (force) of the massage
can be adjusted usng and buttons
Starts and stops the ar massage
Increases or decreases the ntensty (force) of the ar massage
Automatcally ncreases or decreases the ntensty (force) of the ar massage
Operates the ar massage ntermttently (n ntervals). The ntensty (force) of the massage
can be adjusted usng and buttons
Turns the lghts on/off
Operates ntermttent operaton (n ntervals) of the lght
USING THE DUO MAXI SYSTEM CONTROL PANEL
8
Your bathtubs functons related wth massage are operated usng the ‘Control Panel’ mounted on the bathtub. It s sufficent to
press the relevant button for approxmately 0.5 seconds to actvate the functon you desre to use. You should avod pressng
the buttons for a very long tme.
All buttons belongng to a functon are grouped wth a frame on the control panel and thus made vsbly more functonal. Any
functon’s on/off status can be seen by the “warnng lght” located on the upper-rght corner of the button.

USAGE OF THE DISINFECTION SYSTEM
9
Usage warnngs:
• The dsnfecton procedures should be performed only wth Hydro-Bac dsnfectants. A dfferent dsnfectant could harm the
system. Any malfunctons and/or damages that could occur due to ths are not covered by the ‘Scope of the Warranty’.
Hydro-Bac dsnfectant can be suppled from VtrA-Artema Authorzed Servces.
• It s recommended that your massage bathtub be dsnfected every 3-6 weeks, dependng on your frequency of use. It s
possble to use the water remanng n the bathtub after a bath for ths purpose.
• The dsnfecton procedure can only be performed when the bathtub s full.
The bathtub should be filled wth water before startng dsnfecton(the water level should be at least 3 cm hgher than the level of
the jets located on the sdes). It s possble to use the water remanng n the bathtub after a bath for dsnfecton.Also, t should
be checked whether there’s sufficent dsnfectant n the system or not. If the dsnfectant tank s empty, the “warnng lght” of the
button llumnates.Ths lght turn off after the dsnfectant tank s filled wth 1 lter of a sutable dsnfectant(Hydro-Bac). The
dsnfecton system cannot be operated whle the red warnng lght of the mentoned button s llumnated.
Preparaton:
The button s pressed and held untl the blnkng warnng lght on t llumnates contnuously. (The system start requrng
pressng the button for a long tme s a precauton to prevent the system’s operaton by accdent – for example by chldren).If the
water level s sufficent the dsnfecton operaton starts. If there’s a problem the red warnng lght starts to blnk quckly(Error
Message:In such a case please see ‘Problems and Solutons’ secton).
Startng dsnfecton:
The pump starts to operate and the dsnfecton valve opens.The pump takes dsnfectant from the tank as long as the valve s
open. When the specfied amount of dsnfectant s receved the system automatcally stops. After 10 mnutes have passed the
system agan operates automatcally for 1 mnute, but ths tme t does not take dsnfectant. Ths procedure s repeated untl the
bathtub s dsnfected.The dsnfecton procedure contnues untl the red lght on the button swtches off.However, t s
recommended that the water nsde the bathtub be left n the tub for a few hours or overnght. Afterwards the bathtub s
empted, completely rnsed usng the shower head and agan filled wth cold water. All functons are started a couple of tmes for
short perods of tme. The bathtub s empted agan and the sphon outlet s left open untl the next use of the bathtub.
Dsnfecton procedure:
Manually Stoppng Dsnfecton:
The dsnfecton procedure can be stopped by pressng the button twce.
The error message can be cancelled by pressng the button.
Problems and Solutons:
Problem Soluton
• The pump does not ntroduce dsnfectant
nto the bathtub.
• Please contact VtrA-Artema Authorzed Servce.
• There sn't sufficent dsnfectant n the dsnfecton tank or
no dsnfectant s left. Fll the tank wth Hydro-Bac.
• The red lght next to
the button s on

DUO SOFT SYSTEM
10
Mcro water jet
Ar Controller
Ar Jet
Electronc Control Button
Water Sucton Flter
Halogen lamp
Halogen lamp (optonal)
Halogen lamp
Water Sucton Flter
Electronc Control Button Ar Controller
McroWater Jet
Ar Jet
"Sample layout. See the Techncal Specficatons
for the product you’ve purchased"
DUO SOFT SYSTEM: In the DUO SOFT System, there are ar and water massage optons whch can work ndvdually or n
combnaton. Whle the water s ntroduced nto the bathtub through 6 water jets va a pump; ar s ntroduced nto the bathtub through
10 ar jets located on the base of the tub by means of a blower. The system s controlled by an Electronc Control Button. The system,
where all vsble parts (jet, ar controller, etc.) are chrome over brass, has 2 ar controllers. The bathtub has a safety system (sensor) that
prevents the motor from operatng when the tub s empty or the water level s not 3 cm above the topmost jets. 2 halogen lamps can
be nstalled f desred. The Electronc Control Button has 5 or 7 functons, dependng on whether the system s preferred wth or wthout
lamps. These functons are as follows:
•Contnuous Water Massage
•Contnuous Ar Massage
•Contnuous Lght
•Ar Intensty Adjustment
•Intermttent Water Massage
•Intermttent Ar Massage
•Intermttent Lght (The contnuous and ntermttent lght functons can be used only f the product s suppled wth lamps)
IMPORTANT NOTE: The number of jets specfied n the massage system can vary accordng to the bathtub model due to techncal
reasons.
Cauton: In bathtubs wth DUO MAXI System, the ‘ar blower’ wll automatcally actvate 20 mnutes after the hydro massage system s
used and the tub starts to empty n order to dry the water that mght reman n the ppes(operaton duraton s 3 mnutes).In order for
ths system, whch s present n order to ncrease the hygene of your hydro massage system the breaker must be open.Close the
‘breaker’, whch we have nstalled n order to protect your massage system and recommend you to keep closed when not usng the
system, after the ar blower automatcally actvates and deactvates.
Electronc Control Button: Ths button controls the DUOSOFTmassage system functons.
Water jet: These are jets located on the nner sde surfaces of the bathtub wth 67mm dameter, where the water sucked nto the
bathtub are ntroduced back nto the bathtub through a pump. It s possble to mx the ar n the envronment nto the water sprayed
through the jets by means of the ar controllers. There are 6 water jets n the DUOSOFT System.
Ar jet: These are jets located on the base of the bathtub wth 30mm dameter, where the ar s ntroduced nto the bathtub through a
blower. There are 10 ar jets n the DUOMAXIsystem. Care should be taken not to block the ar jets durng use or cleanng. Snce
blocked ar jets wll prevent ar from extng the heatng that mght occur nsde can damage the blower.
Water sucton filter: Ths s a filter that enables the water nsde the bathtub to be sucked by a pump.Care should be taken to keep
har and clothng away from the filter whle t s n operaton.
Ar Controller: It s possble to ntroduce ar from the envronment nto the water pumped nto the bathtub through the water jets, and
thus ncrease the effectveness of the massage. The amount of ar to be mxed wth water can be adjusted through ar controllers. If the
ar controllers are fully closed only water wll ext the jets.The more the ar controllers open, the more ar wll ext the jets. There are 2 ar
controllers n DUOSOFTSystem.
Halogen lamp: Each lamp s 50W strong. 2 halogen lamps can be nstalled n DUOSOFT System, f desred.It s not recommended
that the lamps be used when the bathtub s not full wth water. Long terms use n ths manner can damage the lamp due to
overheatng.

USING THE DUOSOFTSYSTEMCONTROL BUTTON
11
WATER JET
It s used to actvate the 6water jets. When t s first pressed the water jets start to operate contnuously. If t s
pressed whle the water jets are n contnuous operaton they wll start operatng n ntervals.If t s pressed whle
the water jets are n ntermttent operaton they wll stop operatng.
HALOGEN LAMP
It s used n systems wth lamps. When t s first pressed the lamps start to operate contnuously. If t s pressed
whle the lamps are n contnuous operaton they wll start operatng n ntervals.If t s pressed whle the lamps are
n ntermttent operaton they wll stop operatng.
AIR JET
It s used to actvate the 10ar jets. When t s first pressed the ar jets start to operate contnuously. If t s pressed
whle the ar jets are n contnuous operaton they wll start operatng n ntervals.If t s pressed whle the ar jets
are n ntermttent operaton they wll stop operatng.
+ (AIR)
Increases the ar blown through the jets, and thus the effectveness of the ar massage.
- (AIR)
Decreases the ar blown through the jets, and thus the effectveness of the ar massage.

12
AQUA MAXI SYSTEM
Mcro water jet
Ar Controller
Electronc Control
Button Water Sucton Flter Halogen lamp
Halogen lamp
(optonal)
Water Sucton Flter
Electronc Control Button Ar Controller
McroWater Jet
"Sample layout. See the Techncal Specficatons
for the product you’ve purchased"
AQUA MAX SYSTEM: In the AQUA MAX System, the water s ntroduced nto the bathtub through 18 mcro water jets va a
pump.The system s controlled by an Electronc Control Button. The system, where all vsble parts (jet, ar controller, etc.) are chrome
over brass, has 4 ar controllers. The bathtub has a safety system (sensor) that prevents the motor from operatng when the tub s
empty or the water level s not 3 cm above the topmost jets. 1 halogen lamp can be nstalled f desred. The Electronc Control Button
has 4 or 1 functons, dependng on whether the system s preferred wth or wthout lamps. These functons are as follows:
• Contnuous Water Massage
• Contnuous Lght
• Intermttent Water Massage
• Intermttent Lght (The contnuous and ntermttent lght functons can be used only f the product s suppled wth lamps)
IMPORTANT NOTE:
1- The number of jets specfied n the massage system may vary accordng to the bathtub model due to techncal
reasons:
2- If the AQUA MAX System has no lamps the system wll stop automatcally after hydro massage s actvated. Ths
feature s not present n models wth lamps
Electronc Control Button: Ths s the electronc button where the functons of the AQU AMAXI massage system are controlled from.
Mcro water jet: These are jets located on the nner sde surfaces of the bathtub wth 30mm dameter, where the water sucked nto
the bathtub are ntroduced back nto the bathtub through a pump. It s possble to mx the ar n the envronment nto the water sprayed
through the jets by means of the ar controllers. There are 18 mcro water jets n the AQUA MAX System.
Water sucton filter: Ths s a filter that enables the water nsde the bathtub to be sucked by a pump. Care should be taken to keep
har and clothng away from the filter whle t s n operaton.
Ar controller: It s possble to ntroduce ar from the envronment nto the water pumped nto the bathtub through the water jets, and
thus ncrease the effectveness of the massage. The amount of ar to be mxed wth water can be adjusted through ar controllers. If the
ar controllers are fully closed only water wll ext the jets.The more the ar controllers open, the more ar wll ext the jets. There are 4 ar
controllers n AQUA MAXI System.
Halogen lamp: Each lamp s 50W strong. 1 halogen lamps can be nstalled n the AQUA MAXI System, f desred. It s not
recommended that the lamps be used when the bathtub s not full wth water. Long terms use n ths manner can damage the lamp due
to overheatng.

13
USING THE AQUA MAX SYSTEM CONTROL BUTTON
SYSTEM WITH HALOGEN LAMP
SYSTEM WITHOUT HALOGEN LAMP
WATER JET
It s used to actvate the 18 mcrowater jets. When t s first pressed the water jets start to operate contnuously. If
t s pressed whle the water jets are n contnuous operaton they wll start operatng n ntervals.If t s pressed
whle the water jets are n ntermttent operaton they wll stop operatng.
WATER JET
It s used to actvate the 18 mcrowater jets. When t s first pressed the water jets start to operate contnuously. If
t s pressed whle the water jets are n contnuous operaton they wll start operatng n ntervals.If t s pressed
whle the water jets are n ntermttent operaton they wll stop operatng.
HALOGEN LAMP
It s used n systems wth lamps. When t s first pressed the lamps start to operate contnuously. If t s pressed
whle the lamps are n contnuous operaton they wll start operatng n ntervals.If t s pressed whle the lamps are
n ntermttent operaton they wll stop operatng.

Ar Jet LED Control Button
AIR RELAX SYSTEM
Mcro Ar Jets Control Button
14
AIR RELAX SYSTEM: In the AIR RELAX System the ar s ntroduced nto the water through 24mcro ar jets va a blower. The system
s controlled by an Electronc Control Button whch turns t on and off. The lghtng system dstrbuted to 24 ponts around the edges of
the bathtub softly cycles between the 7 basc colors and the desred color can be selected to fix t. Lghtng synchronzed wth the
bathtub lghts s provded around the control button.
IMPORTANT NOTE:
1- The number of jets specfied n the massage system may vary accordng to the bathtub model due to techncal
reasons.
Electronc Control Button: Ths s the electronc button where the functons of the AİR RELAX massage system are controlled from.
There are two electronc control buttons whch control the lghtng system and the ar massage system n the product. The ar system
button turns the ar massage on and off. The lghtng system button turn the cyclng lghts on and off and fixes t at the desred color.
Mcro Ar Jets: There are 24 mcro ar jets that blow ar located at the base of the bathtub. Care should be gven not to cover the mcro
ar jets durng use and cleanng. Coverng the mcro ar jets wll prevent ar from gettng out and the resultng nternal heatng can
damage the blower n tme.
Water sucton filter: Ths s a filter that enables the water nsde the bathtub to be sucked by a pump.Care should be taken to keep
har and clothng away from the filter whle t s n operaton.
LED Lghtng: There are 24 LED lghts.
Mcro Ar Jet
LED Control Button
Mcro Ar Jets
Control Button

Water Jet Ar Controller Electronc Control Button Water sucton filter
AQUA SOFT SİSTEM
15
AQUA SOFT SYSTEM: In the AQUA SOFT System the water s ntroduced nto the bathtub through 6 water jets va a pump.The
system s controlled by an Electronc Control Button. The system, where all vsble parts (jet, ar controller, etc.) are chrome over brass,
has 2 ar controllers. The bathtub has a safety system (sensor) that prevents the motor from operatng when the tub s empty or the
water level s not 3 cm above the topmost jets.
IMPORTANT NOTE:
1- The number of jets specfied n the massage system may vary accordng to the bathtub model due to techncal
reasons.
2- If the AQUASOFT System, the system wll stop automatcally 20 mnutes after the hydro massage s actvated.
Electronc Control Button: Ths s the electronc button where the functons of the AQUASOFT massage system are controlled from.
It s used to operate 6 water jets. When t s first pressed the water jets start to operate contnuously. If t s pressed whle the water jets
are n contnuous operaton they wll start operatng n ntervals.If t s pressed whle the water jets are n ntermttent operaton they wll
stop operatng.
Water Jet: These are jets located on the nner sde surfaces of the bathtub wth 67mm dameter, where the water sucked nto the
bathtub are ntroduced back nto the bathtub through a pump. It s possble to mx the ar n the envronment nto the water sprayed
through the jets by means of the ar controllers. There are 6 water jets n the AQUA SOFT System.
Water sucton filter: Ths s a filter that enables the water nsde the bathtub to be sucked by a pump.Care should be taken to keep
har and clothng away from the filter whle t s n operaton.
Ar controller: It s possble to ntroduce ar from the envronment nto the water pumped nto the bathtub through the water jets, and
thus ncrease the effectveness of the massage. The amount of ar to be mxed wth water can be adjusted through ar controllers. If the
ar controllers are fully closed only water wll ext the jets.The more the ar controllers open, the more ar wll ext the jets. There are 2 ar
controllers n the classc electronc system.
Water Jet
Water Sucton Flter
Electronc Control Button Ar Controller "Sample layout. See the Techncal Specficatons
for the product you’ve purchased"

Water Jet (Chrome) Water Jet (ABS) On / Off Button Ar Controller Water sucton filter
16
AQUA SOFT EASY SYSTEM: In the AQUA SOFT EASY the water s ntroduced nto the bathtub through 6 water jets va a pump. The
system s controlled va the on/off button. The system, where the jets are ABS or chrome accordng to preference and the on/off button
s whte ABS, has 1 ar controller.
IMPORTANT NOTE: The number of jets specfied n the massage system may vary accordng to the bathtub model due to
techncal reasons.
Control Button: Ths s the ON/OFF button of the AQUASOFTEASYmassage system.
Water Jet: These are jets located on the nner sde surfaces of the bathtub wth 67mm dameter, where the water sucked nto the
bathtub are ntroduced back nto the bathtub through a pump. It s possble to mx the ar n the envronment nto the water sprayed
through the jets by means of the ar controllers. There are 6 water jets n the AQUA SOFT EASY System.
Water sucton filter: Ths s a filter that enables the water nsde the bathtub to be sucked by a pump.Care should be taken to keep
har and clothng away from the filter whle t s n operaton.
Ar controller: It s possble to ntroduce ar from the envronment nto the water pumped nto the bathtub through the water jets, and
thus ncrease the effectveness of the massage. The amount of ar to be mxed wth water can be adjusted through ar controllers. If the
ar controllers are fully closed only water wll ext the jets.The more the ar controllers open, the more ar wll ext the jets.
Water Jet
Water Sucton Flter
Electronc Control
Button Ar Controller "Sample layout. See the Techncal Specficatons
AQUA SOFT EASY SİSTEM
for the product you’ve purchased"

SUGGESTIONS FOR USE AND MAINTENANCE OF THE BATHTUB SYSTEMS
17
MATTERS THAT REQUIRE ATTENTION!
• Acrylc s durable aganst acds and alkalnes.However do not let organc solutons used n dry cleanng, pant remover substances,
acetone or other solvents to your compact system.
• Keep lghted cgarettes away from the product.
• If the constructon actvtes n the bath wll contnue after nstallaton, do not remove the folo layer on the product and apply full
protecton to the product.
IMPORTANT:
• Protect you product wth a fuse. Keep the fuse closed when not usng your massage system.
• In bathtubs wth the Duo Max and Duo Soft systems, the ar blower automatcally operates 20 mnutes after the massage system s
used and the bathtub begns emptyng and dres the water remanng n the ppes. For ths system to work close the breaker of your
Duo Max and Duo Soft system after the ar blower operates and stops.
Important
• The electrcal nstallaton to whch you wll connect your product must have a 40A-30mA leak current relay.
• A “grounded lne” s mandatory for the electrcal connecton of hydro massage bathtubs.
• The cablng of the hydro massage bathtubs should be done as shown below.
• Persons (ncludng chldren) who lack the approprate physcal, sensory or mental capabltes; experence and/or knowledge
should be prevented from usng such applances wthout supervson or nstructon.
• Chldren should be prevented from playng wth the applance.
• The deal duraton for the hydro massage s 15-20 mnutes. We suggest you not to stay longer n the massage bathtub.
• If you have a serous medcal condton such as a heart problem you must consult your doctor before usng the massage bathtub.
• Wat for at least 1 hour after meals to use the massage bathtub.
• Addng bath bubbles, herbal aroma, etc. nto your bathtub durng hydro massage can damage the hydro massage system.
• The temperature of the water n the bathtub should be near body temperature (37C) for hydro massage.
• If you’re pregnant or have a heart condton you must consult a doctor regardng the condtons for usng hydro massage.
• After hydro massage, dry wth quck and lvely movements and use a mosturzng body loton.
CLEANING THE BATHTUB SYSTEMS
• Rght after you use your bathtub, clean t wth a lqud bath cleaner or a decalcfier and a soft cloth and warm water. Otherwse
unwanted soap products, drt and hard water wll create a thn layer on the acrylc surface and t wll become more dfficult to clean.
• Do not use hydrochlorc acd, abrasves, powdered detergents and cream detergents that contan powders, soft soap and
hard/scratchng cleanng sponges for cleanng your bathtub.
• All of the chrome parts on your product are removable. In order to prevent the corroson that mght occur due to usng excessvely
hard water t s recommended that these parts be dsassembled and cleaned wth decalcfyng cleanng agents once per month. Ths
procedure s shown n the Mantenance of Bathtub Systems secton.
Note: When products wth cabns, partcularly patterned productsare concerned, clean the glasses wth a soft cloth and warm water. Do
not use hydrochlorc acd, abrasve / powdered / lqud detergents soft soap or hard/scratchng cleanng sponges. Do not let organc
dlutons, pant removers, acetone and other solvents contact the glass.
• For products wth massage functonalty, ensure that the yellow-green groundng cable whch s connected to the metal parts under at
the undersde of the bathtub s connected to all of the feet.
BROWN PHASE
NEUTRAL
GROUND
BLUE
YELLOW-GREEN
Blower
Breaker Current (Amps)
Voltage (Volts)
Input
Power
(KW)
Pump
MASSAGE SYSTEM

POSSIBLE PROBLEMS AND THEIR SOLUTIONS
DISINFECTION OF THE MASSAGE BATHTUB
MAINTENANCE OF COMPACTSYSTEMS
• As a result of usng hard water, lme can
accumulate on the chrome sectons of
the VtrA Compact Systems.
• The chrome sectons on the products
should be regularly dsassembled as
shown on the figures and cleaned wth
a decalcfyng lqud cleanng agents.
(Fgure 5)
- Water Jets (Fgure 1-2)
Ar jets (Fgure 3)
Water sucton filter (Fgure 4)
- Cleanng (Fgure 5)
18
• It s recommended to dsnfect the system once a month(once per 3-6 weeks accordng to use frequency) n bathtubs wth massage
functonalty
• Ths s carred out through usng the ‘automatc dsnfecton program’ n bathtubs wth Duo Max systems. Detaled nformaton
regardng the use of ths program s gven n page 6.
• In bathtubs employng one of Duo Soft, Aqua Max, Aqua Soft and Aqua Soft Easy systems, the dsnfecton procedure can be
carred out manually by followng the steps gven below.
1- The bathtub s filled wth water. (The water level should not be hgher than the jets.)
2- Recommended amount of a dsnfectant that does not harm the skn (Hydro-Bac) s placed nsde the water filled bathtub (ths
amount s 200 ml for Hydro-Bac).
3- The system s operated for 3 mnutes and the dsnfectant s allowed to reach every part of the system.
4- The system s stopped and 10 mnutes s allowed to pass.
5- The system s agan operated for 3 mnutes.
6- The system s stopped and 10 mnutes s allowed to pass.
7- The system s operated for 3 mnutes for a last tme.
8- The water nsde the bathtub s empted and the bathtub s re-filled wth clean water.
9- The system s operated for 2-3 mnutes wth the clean water and empted agan.
Problem Soluton
• The surface of the product s dull and/or
scratched.
• Ths s not a problem. In the bathtubs wth Duo Max and Duo Soft systems, the
“ar blower” wll automatcally start operaton 20 mnutes after the hydro massage
system s used and the tub starts emptyng n order to dry the water that could
reman n the ppes. Ths system s n place to ncrease the hygene of your hydro
massage system.
• If you force the control handle too much the sphon wre could break. Therefore
heght adjustment should be made by turnng the plug counter clock wse wthout
forcng the handle.
• Har, soap, etc. could clog the sphon n tme. Clean the sphon dran wth a dran
opener from tme to tme.
• Check the slcone applcaton between the bathtub and the wall
• Check f the Wall hangers are nstalled on the wall or not.
• The wall hangers must be used n order to preserve the rgdty of the bathtub
• Make sure that the water s filled to rse 3cm over the topmost jets
• Check the electrcal connecton.
• If your product s new, the protectve film layer on t mght not have been
removed.
• If dullness/scratches occur after a certan perod of use, you may be usng
ncorrect cleanng materals. See the 'Cleanng’ secton.
• The massage functon of my bathtub s not
workng.
• My bathtub stretches
• Water leakage under the bathtub
• The sphon dran of my bathtub clogs frequently.
• The sphon plug does not open even though the
control handle s forced.
• My Duo Max and/or Duo Soft bathtub operates
on ts own after usng and emptyng the water.
If your problems persst please contact the nearest VtrA-Artema Authorzed Servce.

Use, Cleanng and Mantenance
1- Deformatons and falures on the surface, electronc parts due to practces other than the use functons specfied n the User
Gude,
2- Deformatons and dullness occurrng on the surface of products wped wth cleanng substances contanng acd and cleanng
substances contanng abrasve powders,
3- Deformatons and dullness occurrng on the surface of products wped wth rough cleanng substances (wre sponge, hardened
sponge, etc.),
4- Deformatons that weldng electrode sparks, flammable substances durng alteratons made n the bathroom spaces and
cgarettes may cause on the product surface,
5- Falures occurrng due to use of parts other than orgnal spare parts,
Shppng, Storage
1- Deformatons to the product surface durng the shppng and transportaton carred out after the products are delvered or any
shall be treated out of scope of the warranty.
breakages whch may occur as the result of mpacts,
2- Deformatons and breakages on the surfaces of products whch reman at the constructon ste for a long tme wthout
protecton,
3- Damage to the product as the result of effects of the water and/or humdty n the envronment durng the storage and use of the
products,
4- Products damaged by each other due to stackng on top of each other durng storage,
shall be treated out of scope of the warranty.
Installaton
1- Falures whch occur as the result of ncorrect nstallaton, mantenance, repars and dsassembly performed by unauthorzed
persons,
2- Factors whch mpact the nstallaton of the product, resultng from the wall or floor not beng level,
3- Surface deformatons and falures occurrng due to small partcles n the plumbng (stone, sand, gravel, etc.) and encrustaton,
4- Falures occurrng due to the wall structure beng dfferent than the specfied types
5- Falures occurrng due to the utlty system pressure not beng at the requred value.
6- Falures occurrng due to faulty electrcal nstallment (such as unearthed cable, voltage fluctuatons)
shall be treated out of scope of the warranty.
7- Falures occurrng due to the holes requred for over-bathtub applcaton beng opened by people other than the manufacturer or
the authorzed servces.
8- Falures occurrng due to the ventlaton cover or outlet, whch s mandatory for bult-n applcatons, not beng establshed.
DEFECTS NOT COVERED UNDER WARRANTY
shall be treated out of scope of the warranty.
Eczacıbașı Yapı Gereçler San. Ve Tc. A.Ș.
S-5900573
Reserves the rght to make any techncal changes on the product wthout pror notce
K-5900573
