viveroo Square User manual

User manual
square
!
viveroo GmbH
Wewelsburger Straße 4
33154 Salzkotten
Germany
www.viveroo.de
REV20160408

Safety information
! WARNING
Please read the assembly instructions included carefully. Please
read this square user manual completely before using your square.
Please follow the instructions and recommendations to ensure
proper use and maximum enjoyment.
Safety
information
square and all square mounting sets are intended for use in
enclosed and dry living spaces.
The following conditions must be provided:
- Operating temperature between 0° C (32° F) and 35° C (95° F).
- Relative humidity (during use): 20 % to 90 %, non-condensing.
- No external environmental influences such as oil, chemicals, salt,
extensive dust, etc.
Installation, service or repairs, if necessary, may only be performed
by authorized persons.
The installer is responsible for selecting the proper mounting
location and safe installation of square. This also applies to
installation in movable parts, such as doors. The installer is
responsible for performing and documenting all necessary safety
tests.
All electrical installation work may only be conducted by
authorized, trained electricians, always adhering to the general
rules and regulations applying to electrical installation.
Should it become apparent that safe operation of square is not
assured, then square must immediately be taken out of service and
secured against potential misuse. If the square functions are
limited, blocked or disabled, if an unusual odor is present, if noises
such as scratching are audible or damage is visible, safe operation
can no longer be guaranteed.
!

Technical Data
Measurements
Measurements design cover
364 x 294
Depth square
36
Size of opening (for furniture installation)
Size of opening (for flush-mounted box)
367 x 296,5
344 x 271
Installation depth (for furniture installation)
Installation depth (for flush-mounted box)
36
76
Weight in kg
square
3,8
Electrical
connections
Low voltage
Power consumption
12 Vdc!
18 Watt
Removal from
power supply
square may be removed from the power supply via the circuit
breaker in the respective rooms.
CE & Co.
All squares have CE certification. square is quality "Made in
Germany". We use only high quality parts and components
produced by market leaders. square customers are proud of their
iPad Garage.
Technical changes and mistakes are excepted.
iPad is a registered trademark of Apple Inc.
Product
contents
-User manual square
-square
Please note! External cable, power supply and mounting screws
are included in square MountingSet.
Compatability
Electrical operation of square is permitted only in connection with
square MountingSet and power supply and cable included in the
Mounting Set. Operation of square without a MountingSet will lead
to immediate loss of guarantee and warranty.

Operation
Functions
Click It! Opening the iPad shelf
Open the iPad resting shelf by using the square button. Now you can
remove or insert your iPad.
! IMPORTANT: square can be either installed vertically or horizontally.
The suspension of the resting shelf has been set to wall position. For
horizontal (i.e. table) or diagonal (i.e. lectern, teacher's desk, control
panel) installation, special adapter sets are available on request.
Care and
Cleansing
Cleanse your square as needed with a soft micro fiber cloth and clear
water only. Dampen the micro fiber cloth and wipe the surfaces gently. If
necessary, you may remove the rubber pads (see "Mounting").
The glass surfaces of DeepBlack and ClearWhite may also be cleaned with
standard glass cleaners.
! WARNING: The interior of the square must remain dry. To ensure this,
use only a damp cloth for cleansing.
! WARNING: Never scratch, scrape or scrub square surfaces with abrasive
materials.

Installation
Use the corresponding MountingSet to install your square. All MountingSets come with
specific mounting instructions.
Step 1
Carefully remove the lower rubber pad first and then the upper
rubber pad.
Proceed as follows:
-Open the iPad resting shelf by pressing the button down
completely. If the square is in a horizontal position, the shelf
must be gently lifted manually.
-Lift the lower rubber pad starting from the center of the square
(see photo). When the inlay has reached approximately a 45°
angle it can be carefully pulled out.
-Close the resting shelf and gently pull the upper rubber cushion
out.
Step 2
Carefully remove the four screws on the cover (see photo - green).
! IMPORTANT: Hold cover tightly when removing the final screw to
avoid damage from falling down.
Step 3
Carefully remove the cover by lifting it towards you and place the
cover in a safe spot.
Step 4
Plug the connecting cable from the MountingSet into the square
plug contact.
! WARNING: When inserting the square, make sure that the
connecting cable is not pinched or pulled, as this may damage the
cable.
! WARNING: If a power supply is located close to the square, please
connect the protective grounding wire (yellow) to the protective
conductor of the power supply. (for example InWall MountingSet)
Step 5
The various fastening points for the square are easily identifiable
(red). Using the screws included in the MountingSet, fasten the
square.
! IMPORTANT: Please follow the instructions included with the
MountingSet.
Step 6
Place the cover on the square. The correct positioning is dictated
by the button. Thread the cover into place there. Fasten the cover
with the four screws and put the rubber pads back in place.

Warranty
Warranty
square comes with a two year warranty from date of purchase by the
original end customer, unless the device was repaired or replaced
during the warranty period. In this case, the warranty is valid until the
end of the regular two year warranty or six months following the
repair/replacement, whichever comes first.
Warranty claims
and verification
Should your square for any reason not perform as expected, please
contact your dealer and provide the original invoice with serial number
as well as a brief description of your complaint.
Warranty claims
and verification
The following devices are excluded from the warranty
Devices with damages caused by:
-acts of nature,
-misuse, including but not limited to disregarding the user manual
and mounting instructions,
-inappropriate handling,
-connection to an incorrect power supply,
-repairs or attempted repairs by unauthorized persons,
-use of the device in connection with third party products,
-devices on which the serial number of the producer has been
changed, deleted, removed or made illegible.
