Vivitar ViviCam 2750 User manual

Vivicam 2750 User Manual
English
021009

Warranty Policy
This camera is under warranty for one full year from the date of purchase by the orignal purchaser. In
case of defects in materials or workmanship, we will replace or repair the camera free of charge.
This warranty applies to the camera only. This warranty does not include batteries, or other
accessories which have not been manufactured by our company. This warranty will not be honored
if the camera has been mishandled or tampered with, or altered by anyone other than the
manufacturer. Other than for the warranty herein, we are not responsible for loss, damage, or
inconvenience of any kind.
A defective camera being returned under warranty must be accompanied by a brief description of
the difficulties encountered and also by a proof of purchase with the date of purchase clearly
indicated. All related transportation costs and insurances are at the ownerís expense. Any alteration
of this warranty cannot be made without Pretecís written approval.
FCC Notice
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in commerical installation. This equipment generates, uses and can
radiate radio frequency energy and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarentee that
interference will not occur in a particular installation. If this equipment does cause harmful interferece
to radio or television reception, detectable by turning the equipment in question off and on, the user
is encouraged to try to correct the intereference by one or more of the following measures: Reorient
or relocate the receiving antenna; Increase the distance between the equipment and the receiver;
Connect the equipment to an outlet on a different circuit than that which the receiver is connected
to; Or consult the dealer or an experienced radio/TV technician for help.
1

2
Do not place this camera in damp or dusty location.
This may cause a fire or electric shock.
CAUTION
Do not place this camera in a location affected by oil fumes or
steam, such as near a cooking stove or humidifier. This may cause a
fire or electric shock.
Do not leave this camera in places subject to extremely high
temperatures, such as in a sealed vehicle or in direct sunlight. Exposure
to high temperatures may adversely affect the camera case and
internal components and cause a fire.
Do not cover or wrap the camera or the AC power adapter with a
cloth or quilt. This may cause heat to build up and distort the case
or cause a fire. Always use the camera and its accessories in well-
ventilated locations.
Do not move the camera while it is switched on. (if you are using the
AC power adapter, unplug the adapter from the AC power outlet
after you have switched off the camera.) Then ensure that any
connector cords or cables to other devices are disconnected before
moving the camera, Failure to do so may damage the cords or
cables and cause a fire or electric shock.
Ta ke care that the camera is not bumped when it is being moved.
This may cause the camera to malfunction.
When handling the camera, always unplug it from the power source
(batteries or AC power adapter) for safety. (if you are using the AC
power adapter, unplug the adapter from the AC power outlet after
you have disconnected the camera.) Failure to do so could result in
an electric shock.

3
When leaving the camera unused for long periods, such as during a
vacation, always unplug the camera from the power source (batteries
or AC power adapter ) for safety.
(if you are using the AC power adapter, unplug the adapter from the
AC power outlet after you have disconnected the camera.)
Failure to do so could result in a fire.
CAUTION
Contact your dealer or local authorized service facility to request
cleaning of the interior of the camera every two years. Allowing
dust to accumulate in the camera for long periods without cleaning
the camera interior may cause a fire or electric shock.
Cleaning is best performed prior to seasonal periods of high humidity.
Consult with your dealer or local authorized service facility for
information on the cost of cleaning your camera.
Do not use batteries other than those specified for use with
your camera.
The use of unsuitable batteries may result in the batteries splitting or
leaking and causing a fire, injury, or soiling of the battery compartment.
When fitting a battery into the camera, check the polarity markings
on the battery ( and )to ensure that you insert the battery
correctly.
Incorrect battery polarity may result in the batteries splitting or
leaking and causing a fire, injury, or soiling of the battery compartment.
Remove the batteries if the camera will not be used for an extended
period of time. The batteries may leak and cause a fire, injury or
soiling of the battery compartment. If the batteries leak, clean and
wipe the battery compartment carefully and install new batteries.
Wash your hands carefully if you touch the battery fluid.
+

4
Do not use the camera if any water has entered the camera. Switch
the camera off, and then disconnect the power source (batteries or
AC power adapter). (if you are using the AC power adapter, unplug
the adapter from the AC power outlet after you have disconnected
the camera.) Then contact your dealer or your local authorized
service facility. Do not continue to use the camera as this may
cause a fire or electric shock.
Do not use the camera if any foreign objects have entered the
camera. Turn the camera off, and then disconnect the power source
(batteries or AC power adapter). (if you are using the AC power
adapter, unplug the adapter from the AC power outlet after you
have disconnected the camera.) Then contact your dealer or your
local authorized service facility. Do not continue to use the camera
as this may cause a fire or electric shock.
If the camera has been dropped or the camera case has been
damaged, switch the camera off, and then disconnect the power
source (batteries or AC power adapter). (if you are using the AC
power adapter, unplug the adapter from the AC power outlet after
you have disconnected the camera.) Then contact your dealer or
your local authorized service facility. Do not continue to use the
camera as this may cause a fire or electric shock.
Do not use this camera when it is emitting smoke, is unusually hot to
the touch, is emitting any unusual odor or noise, or is in any other
abnormal state. Use of the camera in any of these situations may
cause a fire or electric shock. Stop using the camera immediately,
turn the camera off, and then disconnect the power source (batteries
or AC power adapter). (If you are using the AC power adapter,
unplug the adapter from the AC power outlet after you have
disconnected the camera.) After checking that smoke is no longer
being emitted, contact your dealer or your local authorized service
facility and request repairs. never attempt to repair this camera
yourself as this is dangerous.
WARNING
Unplug from
power socket.

5
Do not place the camera in unstable locations such as on a wobbly
table or sloping surface where the camera may fall or tip over and
cause injury.
WARNING
Ta ke care that the camera is not exposed to moisture and that
water does not get into the camera. Take particular care when it is
raining or snowing or when you are using the camera at the beach
or near water.
Water in the camera may cause a fire or electric shock.
Do not insert or drop metallic or inflammable foreign objects into
the camera through access points such as the Compact Flash card
slot.
This may cause a fire or electric shock.
Do not attempt to modify this camera. This may cause a fire or
electric shock.
Do not remove the camera casing. This may cause an electric
shock. Internal inspection, maintenance and repairs should be carried
out by your dealer or local authorized service facility.
Do not use this camera in the bathroom. This may cause a fire or
electric shock.
Do not touch the power plug during a thunderstorm if you are using
the AC power adapter.
This may cause an electric shock.
Do not disassemble
Do not use in wet areas.
Do not touch

6
Never use this camera, look through the viewfinder, or watch the
LCD (liquid crystal display)while you are operating a moving car,
motorcycle or bicycle.
This may cause a traffic accident.
WARNING
Do not attempt to charge the alkaline battery.
This may cause the battery to split or leak, causing fire or injury.
Do not heat or attempt to disassemble a battery, and do not place
a battery in water or in a fire.
Any of these may cause the battery to split or leak, cause fire or
injury.
Do not subject a battery to strong impacts, such as hitting it with a
hammer, stepping on it or dropping it. Any of these may cause the
battery to split or leak, cause fire or injury.
Use only the specified batteries or AC power adapter specified
for use with this camera.
The use of other power sources may cause a fire.
+
Do not carry or store a battery with objects such as metal pens,
necklaces, coins or hairpins. This could short circuit the positive
and negative poles of the battery.
This may cause the battery to split or leak, resulting in fire or injury.

Contents
Getting Started ...............................................................................9
What’s Inside: ...........................................................................................9
System Requirements (Windows) ..................................................10
System Requirements (Macintosh) ................................................10
Getting to know the camera ................................................11
Using the camera .............................................................................12
Power Supply ..........................................................................................12
Inserting Batteries ...............................................................................12
Flash Memory .........................................................................................13
Extended Flash Memory ...............................................................13
Using AC Power ...................................................................................14
Auto Power Off .....................................................................................14
Taking Pictures ..................................................................................15
Using the LCD Display ............................................................16
Adjusting LCD Brightness ...........................................................16
Viewing Pictures on the LCD ....................................................16
Viewing Thumbnails ...........................................................................17
Menu Mode ............................................................................................17
Erasing Pictures from Memory .......................................19
7

Defining Picture Quality ........................................................19
Using the Flash ..................................................................................20
Using the Self-Timer ...................................................................20
Memory Full ..........................................................................................20
Connecting to Your Computer .........................................21
The Digital Interface ....................................................................21
Installing Capture Software ...............................................22
Appendix 1 : LCD Icons ...........................................................23
Appendix 2 : Record Mode Icons ................................23
Appendix 3 : Digital Camera Specifications ..24
Appendix 4 : Specifications and Operation
of FotoPrint 600 ..........................................25
8

Getting Started
Congratulations on purchasing your new Digital Camera. This camera is a
state-of-the-art camera bringing to you the ease of use of traditional
cameras combined with such high-tech functionality as full-color LCD
(Liquid Crystal Display) photo previewing, allowing you to immediately see
the pictures you have just taken; a built-in, non-expiring flash, up to 512k
bytes or more of digital memory for storing your pictures; and an auto-
flash sensor, which automatically detects whether the flash should be
engaged or not while taking a photo.
Once you have finished taking your pictures, and have uploaded them to a
computer, you can then use image editing software to enhance them before
sending them off to print or you can print the pictures you took through the
direct printing interface.
What’s Inside:
■ 1 Digital Camera
■ Quickstart Guide
■ Owner’s Manual
■ Serial cable ( PC or Macintosh.)
■ Image editing software
■ 4 x AA alkaline batteries
Optional Items:
■ 6.0V power adaptor
■ FotoPrint 600 direct printing interface (See as appendix:4)
■ 2MB,4MB,8MB,16MB compact flash card.
CD-ROM Contents
■ Photo image editing software - allows you to quickly and easily touch up
any photo captured with your camera.
■ TWAIN Acquire module - lets you download pictures from all TWAIN-
compliant devices straight into your computer.
9

System Requirements (Windows)
■ Personal computer with minimum 486, 33MHz processor
■ Microsoft Windows operating system (version 3.1 and higher, Windows95
Windows98 ready)
■ 8MB or more of RAM
■ 30MB of hard disk space
■ available serial port and CD-ROM drive
■ color display (800x600 24-bit or higher recommended)
System Requirements (Macintosh)
■ Power PC or above
■ System 7.5 or higher
■ 8MB or more of RAM
■ 30MB of hard disk space
■ available serial port and CD-ROM drive
■ color display (800x600 24-bit or higher recommended)
10

11
Getting to know the camera
5 Erase
6 Menu
7 Play/Record
8 Power
9 View Finder
10 Display
11 Forward/Self-Timer
12 Backward/Flash
13 LCD Display
1 Macro/Normal Mode switch
2 Icon mode
3 Multiple Display
4 Shutter Release

12
Using the camera
Power Supply
This camera features a two-way power supply that lets you use either
batteries (AA-size Alkaline) or a household AC current.
Inserting Batteries
1 Place your thumb on the battery door.
2 Slide the battery door away from the
camera.
3 Insert the batteries as indicated on the inner
side of the battery door.
Notes:
■ If you are not going to be using the camera for an extended length of time,
then you should remove the batteries to prevent leaks or corrosion.
■ Never use manganese batteries.
■ Never mix old and new batteries.
■ Low temperature (under 0 c) may reduce the output efficiency of batteries
, then shortening the operation time of camera.
■ The recommend battery is PANASONIC ALKALINE or rechargable battery.
Botton view of the camera

13
Battery Life Indicator
When the camera has sufficient power, the Low Power icon on the LCD
display of the camera remains dark. When the power is low, the Low Power
icon is visible to indicate that the batteries are weak and need to be replaced.
Also, do not use the Flash or Auto-Flash features while battery power is
low. Generally, once the Low Power icon comes on, 10 minutes of operation
time is available. (When the batteries are completely dead, the camera will
not turn on.)
Flash Memory
The camera features flash memory for storing image information. This
memory does not require electrical power to function, so you will not lose
any pictures you took when the camera is turned off or low on power. If the
batteries go dead, simply insert a new set or connect the AC power supply
and you will be able to retrieve and view the previously captured photos.
Extended Flash Memory
Yo u can extend the capabilities of your camera by adding the Compact
Flash Memory card accessory to it. This card is a removable ATA-compatible
memory device that gives your camera additional memory. With 2M memory,
for example, you can take 32 extra pictures in Normal mode, or 16 pictures
in Fine mode. To insert the Compact Flash Memory card, open the card slot
on the bottom of the camera and insert the card with the back side facing
you and heading inward. Next, close the card slot cover and the camera
memory is updated automatically. To remove the card, push the Eject key.

14
Using AC Power
To run the camera on standard AC power, use the 6.0V/2.5AC Adaptor.
■ Always be sure to use the AC adaptor which comes with the camera; or
optional from the manufacture. Any other inappropriate adaptor may cause
damage to the camera which is not covered under the warranty.
■ Grasp the adaptor, not the cord, when unplugging the adapter from a wall
socket.
■ If the power cord becomes damaged (exposed wires, disconnection, etc.)
please purchase a new AC adaptor. Use of a damaged cord may cause
fire or electrical shock.
■ Switch off the power to the AC adaptor before unplugging it from the wall
socket.
Auto Power Off
Power automatically turns off whenever you do not perform any camera
operations for a specific interval of time. You can set the interval up to 99
minutes.

4 The LCD screen pauses and in a few seconds a static copy of the image
appears while the camera saves it to memory. Once the LCD resumes
previewing, you can take another picture or switch to the PLAY mode
to view the image you just recorded.
15
Taking Pictures
1 Turn the camera on by pressing the
Power button for at least one second.
When the camera is activated, you will
see a small LED light on beside the
Viewfinder. If you would like to use the
LCD display, you can turn it on by
pressing the Display button.
2 Set the camera to Normal if the object
or view is 40cm or more away from
the camera, and to Macro if the object
or view is between 10 and 30cm away.
This is set using the Macro/Normal
mode switch. Then press the Play/
Rec button to set the camera to
Recording mode.
3 Using the LCD display, or the
viewfinder, compose your image.
When you are ready, press the
Shutter Release button.
Note: Image Storage capacity is as follows:
With 512K memory, in Normal mode - 8
images; in Fine mode - 4 images, With 2MB
memory in Normal mode -32 images; in Fine
mode-16 images.
1
2
3

16
Note: You need not activate the LCD to
take pictures - however, using it while
capturing shortens the lifespan of your
batteries.
Using the LCD Display
Using the built-in Liquid Crystal Display (LCD), you can view pictures in a
few seconds after capturing them. The following section describes how to
use the LCD and its various functions.
Note: To remove all icons from the LCD display, press the Icon mode button on top of
the camera. Pressing it a second time returns all icons to the screen.
Adjusting LCD Brightness
The LCD display comes with the a brightness feature that allows you to
change how images are displayed on the LCD screen. To turn the brightness
of the LCD either up or down, turn the camera over so that the bottom side
is facing up. In the center of the camera’s bottom side is a radial dial. Turning
the dial with your fingernail or a small coin adjusts the brightness up and
down.
Viewing Pictures on the LCD
The Display button turns the LCD display on, allowing you to see each
picture as it is taken.
1 After turning on the Power, press the Play/Record button to switch to
the Play mode. The LCD display warms up and then displays the last
picture taken. If there are no pictures in the camera, then a message
displays informing you of this.

Viewing Thumbnails
In addition to previewing single frames on the LCD screen, you can also
view 9 thumbnail images of the pictures in the storage queue. This gives
you the advantage of being able to see at once all the pictures you have
already taken rather than having to scroll through them all one by one.
To view image thumbnails:
1 Press the Play button.
2 Next, press the Multiple Display button to enter the Thumbnail mode (if
there are more pictures than thumbnails, use the Self/+ or Flash/- to
scroll to the next or previous screens.)
3 Press the Multiple Display button again to exit Thumbnail mode.
Menu Mode
To enter the Menu Mode, press the Menu button and release it. The LCD
image is replaced by the built-in functions menu containing options and
features to set the camera status. To use the functions, simply select the
one you want to engage with the Self/+ or Flash/- buttons, and then press
the Shutter Release button.
The seven functions
in Menu Mode are:
2 Press the Forward or Backward buttons to scroll through the pictures
stored in memory.
3 Press the Display button again to turn off the LCD display.
17

18
■ Move To Card - copy the images in the internal memory to the
Compact Flash Card , if you have it inserted into the card slot.
■ Erase All - erases all the image in the built Flash Memory and in the
Memory Card. Before the erase procedure takes place, you will be
asked to confirm it first.
■ Set Date/Time - allows you to set the time and date that appear on
your pictures. Use the Shutter Release button to increase the number
in the selected field, and the Self/+ or the Flash/- button to select a
field. Selecting the OK option to accept the setting or the Exit to
return to the main menu.
■ Auto Power Off - allows you to set the interval for auto shut off.
Press the Shutter Release button to increase the interval of shut off
time. Selecting the OK option to accept the setting or the Exit to
return to the main menu. Note that you can set the interval up to 99
minutes.
■ Auto Play - defines the interval between images when viewing them
on the LCD screen. Press the Shutter Release button to increase the
auto play interval. Selecting the OK option to accept the setting or
the Exit to return to the main menu. If no value is set then the images
must be scrolled manually in Play mode using either the Self/+ or
Flash/- buttons.
■ Image Quality - toggles between Normal and Fine mode. With 512 K
memory, Normal allows you to capture up to 8 images at standard
compression, while Fine allows you to capture up to 4 uncompressed
images. All images are captured at 640x480 monitor resolution. With
2MB memory,32 images will be captured in Normal mode, while 16
images will be captured in Fine mode.
■ Lock./Unlock - allows you to lock the current image being displayed
in the LCD so that it can not be erased. You can also unlock currently
locked images.

19
Erasing Pictures from Memory
The Erase button allows you to remove any unwanted pictures from the
memory. To remove pictures, please note that the LCD must be turned on.
1 After turning the camera on, press the Play/Record button to enter the
PLAY mode.
2 To remove a picture, scroll to the picture then press the erase button .
A dialog asking you to confirm the deletion appears on the LCD. Press
the Self/+ button for Yes and the Flash/- button for No. After erasing a
picture, exit to the preview screen by pressing the Play/Record button
again.
3 To erase all the pictures in memory, press the Menu button. When the
options screen appears, cycle through them using the Self/+ button or
the Flash/- button until you come to the Erase All icon. Pressing
the Shutter Release button reformats both the memory card and flash
memory.
Defining Picture Quality
Your digital camera can take pictures at two different modes: Normal
(compressed) and Fine(less compressed). Both modes take pictures at 640
x 480 monitor resolution. Note, however, that your camera can only store 8
images in Normal mode or 4 images in Fine mode with 512K built-in flash
memory. (For the 2MB memory built in the camera can store up 32 images
in Normal mode or 16 images in Fine mode.)
To define your picture quality:
1 Click the Menu button to display the menu options in the LCD display.
2 Using the Self/+ or the Flash/- buttons, cycle through the options until
you have selected the Quality icon.
3 Press the Shutter Release button to change the Quality setting.
