User’s Manual
Thermal Imaging • Uncooled VOx Micro Bolometer • IP67 • IK10 •
360x240 or 720x480 • Smart Stream II • 8-14µm Spectral range
Thermal Bullet
Network Camera
TB9330-E, TB9331-E
Rev. 1.0

VIVOTEK
2 - User's Manual
Table of Contents
Overview ..............................................................................................................................................................3
Revision History ...............................................................................................................................................4
Read Before Use..............................................................................................................................................4
Package Contents ............................................................................................................................................5
Symbols and Statements in this Document......................................................................................................5
Coverage Table ...............................................................................................................................................6
Physical Description ........................................................................................................................................7
Hardware Installation .......................................................................................................................................9
Software Installation .......................................................................................................................................14
Network Deployment ......................................................................................................................................22
Ready to Use..................................................................................................................................................23
Accessing the Network Camera .................................................................................................................... 26
Using Web Browsers......................................................................................................................................26
Using RTSP Players.......................................................................................................................................29
Using 3GPP-compatible Mobile Devices........................................................................................................30
Using VIVOTEK Recording Software .............................................................................................................31
Main Page......................................................................................................................................................... 32
Client Settings .................................................................................................................................................. 38
Conguration.................................................................................................................................................... 43
System > General settings .............................................................................................................................44
System > Homepage layout ..........................................................................................................................46
System > Logs ...............................................................................................................................................49
System > Parameters ....................................................................................................................................51
System > Maintenance...................................................................................................................................52
Media > Image .............................................................................................................................................56
Media > Video ................................................................................................................................................61
Media > Video ................................................................................................................................................62
Media > Audio.................................................................................................................................................69
Network > General settings............................................................................................................................70
Network > Streaming protocols ....................................................................................................................77
Network > SNMP (Simple Network Management Protocol)...........................................................................87
Network > FTP ...............................................................................................................................................88
Security > User accounts ...............................................................................................................................89
Security > HTTPS (Hypertext Transfer Protocol over SSL) ..............................................91
Security > Access List ..................................................................................................................................98
PTZ > PTZ settings ......................................................................................................................................103
PTZ...............................................................................................................................................................107
Mechanical PTZ Operation...........................................................................................................................107
Event > Event settings..................................................................................................................................110
Applications > Motion detection....................................................................................................................124
Applications > DI and DO ...........................................................................................................................127
Applications > Tampering detection .............................................................................................................128
Applications > Audio detection ...................................................................................................................129
Applications > Package management - a.k.a., VADP (VIVOTEK Application Development Platform) .......131

VIVOTEK
User's Manual - 3
Recording > Recording settings .............................................................................................................. 134
Local storage > SD card management..................................................................................................... 139
Local storage > Content management ..................................................................................................... 140
Appendix .................................................................................................................................................... 143
URL Commands for the Network Camera................................................................................................ 143
Technology License Notice....................................................................................................................... 359
Electromagnetic Compatibility (EMC)....................................................................................................... 360
Overview
The outdoor bullet TB9330-E and TB9331-E thermal camera provides a 360x240 or
720x480 resolution. The camera comes with a range of lenses with the 8.8mm (63.4°),
19mm (32°), 35mm (22°), 50mm (15.5° horizontal) horizontal elds of view. A lens with a
shorter focal length can cover a wide eld of view, while a lens with a longer focal length
can be used for targets at a greater distance. The camera enables easy detection of
human activities regardless of lighting conditions, whether in pitch dark or extremely bright
environments.
Compared to optical lens cameras, thermal cameras allow easier detection of people in
a wide surveillance area. When an optical camera’s eld of view is obscured by mist or
smoke, it is often very difcult for users to discern the presence of humans. The thermal
imaging of the TB series cameras allows you to detect targets by seeing through light
snow, dust, smoke, fog, or haze.
Coming in a weather proof housing with PoE power supply, the camera is suitable for video
surveillance as a perimeter protection. The capability of unobstrusive motion detection
in total darkness enables the camera for very early detection of an intruder. For thermal
cameras, false alarms no longer occur due to the effects of elements, such as swaying
vegetation, effects of artificial interferences such as fast light changes or backlights.
Humans wearing camuage, hiding in a bush or deep shadows are all likely to be detected
by thermal cameras, while the optical lens cameras cannot.

VIVOTEK
4 - User's Manual
Read Before Use
The use of surveillance devices may be prohibited by law in your country. The Network Camera
is not only a high-performance web-ready camera but can also be part of a exible surveillance
system. It is the user’s responsibility to ensure that the operation of such devices is legal before
installing this unit for its intended use.
It is important to first verify that all contents received are complete according to the Package
Contents listed below. Take note of the warnings in the Quick Installation Guide before the Network
Camera is installed; then carefully read and follow the instructions in the Installation chapter to
avoid damage due to faulty assembly and installation. This also ensures the product is used
properly as intended.
The Network Camera is a network device and its use should be straightforward for those who
have basic networking knowledge. It is designed for various applications including video sharing,
general security/surveillance, etc. The Configuration chapter suggests ways to best utilize the
Network Camera and ensure proper operations. For creative and professional developers, the URL
Commands of the Network Camera section serves as a helpful reference to customizing existing
homepages or integrating with the current web server.
Revision History
■ Rev. 1.0: Initial release.
NOTE:
1. The camera is only to be connected to PoE networks without routing to outside plants.
2. For PoE connection, use only UL listed I.T.E. with PoE output.
1. La caméra ne doit être raccordée qu’à des réseaux PoE, sans routage vers des installations
extérieures.
2. Pour les raccordements PoE, utilisez uniquement un équipement de TI homologué UL, avec une
sortie PoE.
IMPORTANT:
The product must be installed and protected in a location that is not easily accessible,
and is away from impacts or heavy vibration. For example, at the location where the
surveillance cameras are looking down or installed at high positions such as on a pole,
wall, or at least 3 meters above the ground.
The camera should be installed at least 10 centimeters away from the eave of a building.

VIVOTEK
User's Manual - 5
Symbols and Statements in this Document
i
INFORMATION: provides important messages or advices that might help prevent
inconvenient or problem situations.
NOTE: Notices provide guidance or advices that are related to the functional integrity of
the machine.
Tips: Tips are useful information that helps enhance or facilitae an installation, function,
or process.
WARNING: or IMPORTANT:: These statements indicate situations that can be
dangerous or hazardous to the machine or you.
Electrical Hazard: This statement appears when high voltage electrical hazards might
occur to an operator.
NOTE:
Use the camera only with a DC power supply that is UL listed, and limited power source
(LPS) certied. The power supply should bear the UL listed and LPS marks. The power
supply should also meet any safety and compliance requirements for the country of use.
Package Contents
■ TB9330-E, or TB9331-E [8.8mm (63.4° horizontal), 19mm (32° horizontal), 35mm (22°
horizontal), 50mm (15.5° horizontal)]
■ L-wrench, screws.
■ Sunshield, sunshield extension bracket, and screws.
■ Quick Installation Guide & alignment sticker.
■ AM-719 Junction box.
IMPORTANT:
To prevent thermal damage to the sensor, never point the camera at the sun or other high
tensity light sources (such as a welding arc.)
IMPORTANT:
1. The retention screws for the front lens cover and the camera enclosure itself should be
tightened after installation or maintenance. Make sure they cannot be opened with bare
hands.
2. Please contact VIVOTEK's certied dealers for power adapters.

VIVOTEK
6 - User's Manual
Coverage Table
Calculated with Johnson's criteria and vary in different weather conditions.
TB9330
Maximum
resolution
384x256
Focal length 8.8mm 19mm
FOV Horizontal 38.3º 18.3º
Vertical 26.1º 12.3º
Human
1.8x0.5m (5x1ft)
Detection (1.5 pixels) 262m (859ft) 566m (1856ft)
Recognition (6 pixels) 66m (216ft) 142m (465ft)
Identification (12
pixels)
33m (108ft) 71m (232ft)
Vehicle
4x1.5m (13x4ft)
Detection (1.5 pixels) 800m (2,624ft) 1,729m (5,672ft)
Recognition (6 pixels) 200m (656ft) 432m (1,416ft)
Identication (12
pixels)
100m (328ft) 216m (708ft)
TB9331
Maximum
resolution
720x480
Focal length 8.8mm 19mm
FOV Horizontal 69.6º 35.7º
Vertical 49.7º 24.2º
Human
1.8x0.5m (5x1ft)
Detection (1.5 pixels) 262m (859ft) 566m (1856ft)
Recognition (6 pixels) 66m (216ft) 142m (465ft)
Identification (12
pixels)
33m (108ft) 71m (232ft)
Vehicle
4x1.5m (13x4ft)
Detection (1.5 pixels) 800m (2,624ft) 1,729m (5,672ft)
Recognition (6 pixels) 200m (656ft) 432m (1,416ft)
Identication (12
pixels)
100m (328ft) 216m (708ft)

VIVOTEK
User's Manual - 7
Note that normally you do not need to open the canister of the camera.
Outer View
Sunshield
Lens
SD card slot
Status LED
Reset button
AM-719
Physical Description

VIVOTEK
8 - User's Manual
Some of the sufx syntax used in model naming are listed below:
E w/ heater for extreme weather
Fx Focal length w/ number
T w/ Remote focus lens
R w/ PoE repeater
H w/ High Dynamic Range functionality
NOTE:
IMPORTANT:
The camera comes with an embedded heater and requires an 802.3at PoE switch or
12V/24V 2A power when operating in a cold weather.
1
2
3
4
6
5
8
7
10
LAN/PoE
100~240V
AC
ON
OFF
9
GE LAN GE LAN
802.3at
12/24V 1A or 2A
Operating Temperature Consumption & Power Input
-40ºC ~ 0ºC, heater on PoE - 24W (PoE Plus mid-span or switch)
12V/24V input - 2A
>-10ºC, heater off
-40ºC ~ 0ºC, system off PoE - AF class0
12V/24V input - 1A
≥-10ºC, system on

VIVOTEK
User's Manual - 9
Hardware Installation
0002D10766AD
XXXXXX
1. Jot down the camera's MAC address for later reference.
2.Remove the small access panel to access the SD card slot and install a MicroSD card.
Installl the panel when done.
64GB
10
I
1
3.Use the included alignment sticker to drill holes on the wall, and install the junction box.
If preferred, drill a routing hole on the wall.

VIVOTEK
10 - User's Manual
4.If you need to route cables through a conduit, remove the plastic stopper underneath the
junction box.
5.Route cables through the conduit, and install a 3/4" conduit to the junction box. Note that
the conduit is user-supplied. Even if you route cables through the center hole, a conduit
is still recommended for water-proong.
OR
3/4”

VIVOTEK
User's Manual - 11
6. Install the sunshield rst by installing an extension bracket, and then secure the
sunshiled to the mount holes on the bracket by driving 2 screws.
7.Connect the safety tether to the anchor point at the back of the camera.

VIVOTEK
12 - User's Manual
8.If used, connect the AC/DC power, DI/DO, or audio wires to the terminal connectors.
5.5 ~ 6.5mm
9.Pass an Ethernet cable through the waterproof cable gland components, and through the
rubber seal as shown below. Connect the Ethernet cable to the camera's RJ45 onnector.
icro
MIC P
AC24V
AC24V
DC+ (12V)
DC-
MIC-
MIC+
AU-
AU+
NC
485N
485P
NC
DI1-
DI1+
DO1-
DO1+ (5V)

VIVOTEK
User's Manual - 13
x4
10. Secure the camera to the junction box using 4 included screws.
Browser
LAN
Shepherd
11. Please visit VIVOTEK’s website to Install the "Shepherd” software utility. The program
will search for VIVOTEK Video Receivers, Video Servers or Network Cameras on the
same LAN.
Double-click on the camera’s MAC address to open a web console to the camera.

VIVOTEK
14 - User's Manual
Software Installation
12. Install the Shepherd utility, which helps you locate and congure your Network Camera
in the local network. If your camera comes without the CD, go to VIVOTEK’s website,
and locate the utility in the Downloads > Software page.
12-1. Run the Shepherd utility.
12-2. The program will conduct an analysis of your network environment.

VIVOTEK
User's Manual - 15
0002D1730202
IB8360-W 192.168.4.151 00-02-D1-73-02-02
TB9330-E
Network Camera
Model No: TB9330-E
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
MAC:0002D1730202
R o H S
12-3. The program will search for all VIVOTEK network devices on the same LAN.
12-4. After a brief search, the installer window will prompt. Click on the MAC and model
name that matches the one printed on the product label. You can then double-click on
the address to open a management session with the Network Camera.
Forceful Password Conguration
13. The first time you log in to the camera, the firmware will prompt for a password
conguration for security concerns.
13-1. Since your camera is used for the rst time, there is no password. Enter “root” as the
user name, and nothting for the password.

VIVOTEK
16 - User's Manual
Some, but not all special ASCII characters are supported: !, $, %, -, ., @, ^, _, and ~.
You can use them in the password combination.
13-3. Another prompt will request for the password you just congured. Enter the password
and then you can start congure your camera and see the live view.
13-2. Enter the combination of alphabetic and numeric characters to fulll the password
strength requirement. The default name for the camera administrator is “root”, and can
not be changed.

VIVOTEK
User's Manual - 17
12
3
14. Loosen, but not completely remove, the retention screws on the wall-mount bracket to
adjust the camera’s shooting direction. You can pan, tilt, or rotate the camera.
1
2
3

VIVOTEK
18 - User's Manual
12
3
15. Tighten the retention screws when you are statisfied with the field of view.

VIVOTEK
User's Manual - 19
1. The DO+ pin provides a 5V output, and the max. load is 50mA.
2. The max. voltage for DO- pins is 30VDC (External power).
In order to control AC devices, the following diagram can be taken into consideration.
This diagram uses a relay to control the ON/OFF condition of the AC device.
3. An external relay can be triggered by using the DO+ or by an external power source,
depending on the type of relay you use.
4. In case of using an individual relay (instead of using a relay module), for protection
against voltage or current spikes, a transient voltage suppression diode must be
connected in parallel with the inductive load.
DI-
DO+
DI+
DO-
Switch
External Device
External DC power
Dry contact with external DC power source to supply a relay. Dry contact is the safest connecon
to protect devices.
NC
NO
Relay
Coupler
DC
DC 0V
DC 0V
External AC power
with Protected Earth
AC
PE
PE
DI/DO Diagram

VIVOTEK
20 - User's Manual
DI-
DO+
DI+
DO-
Switch
External Device
External DC power
Wet contact with external DC power source to supply a relay.
NC
NO
Relay
DC
External AC power
with Protected Earth
AC
PE
PE
DC 0V
DI-
DO+
DI+
DO-
Switch
External Device
Dry contact and using camera’s DO+ to supply a relay.
NC
NO
Relay
AC
External AC power
with Protected Earth
PE
PE
