VM Audio SRPK8R User manual

| 6
6. Ground Cable
Make sure the negative terminal from the battery is
disconnected.
1. Trim half an inch of insulation from the ground cable and
attach to the included ring connector.
2. Install the ring connector to the vehicles metal body, 5 feet
from the amplifier. (Surface must be clean and bare metal)
3. Connect the ground cable to the amplifier’s negative (-)
terminal.
4. Conect the negative cable back onto the battery.
POWER WIRING KIT
Quick Installation
Guide
Rev. 1
SRPK8R
| 7
7. Diagram
Speaker Wire
(not included)
Power Cable
Fuse
Remote Wire
RCA Cable
Car Stereo
Battery
Amplifier
| 8
8. Specifications
Power Cable
Ground Cable
Remote Wire
RCA Cable
Fuse Holder
Fuse
8 Gauge x 17ft (5.2M)
8 Gauge x 3ft (0.9M)
18 Gauge
17ft (5.2M) (Unbalanced, Stereo)
8 Gauge (AGU type)
50A AGU
VM Audio Tech Support
US / Canada
phone: (855) audio-99 / [phone]
email: [email protected]
© VM Audio All rights reserved. All trade names are registered trademarks of
respective manufacturers listed.
POWER WIRING KIT

3. Fuse Installation
| 2 | 3 | 4
4. Power Cable
2. Contents
POWER CABLE
GROUND CABLE
RCA CABLE
CABLE LOOM
Cables, Wires and Accessories
TIE WRAPS
FUSE
(2) BUTT
CONNECTORS
(3) RING
CONNECTORS
(2) SPADE
CONNECTORS
Make sure the negative terminal from the battery is
disconnected.
1. Mount the fuse holder securely approximately 18 inches or
less from the battery.
2. Trim the insulation of the power cable by half an inch and
connect it to the fuse holder screwing down tightly.
Note: Complete this step before installing the fuse.
18” (457mm)
Car Battery
Make sure the negative terminal from the battery is
disconnected for this step.
1. Route the power cable through the vehicle’s firewall from the
fuse holder to the amplifier.
2. Trim the insulation of the power cable by half an inch from
both ends and connect one end of the cable to the fuse
holder and the other to the positive terminal of the amplifier.
| 1
1. Introduction
Thank you for your interest in VM Audio products. Our
goal is to enhance your listening experience.
The Shaker series is designed with the casual users
in mind as the economical solution to a performance
craving consumer. The experts and engineers at
VM Audio meticulously tested and designed this product
with a reasonable price tag to fit any budget. Let the
Shaker series maximize the value of your investment.
| 5
5. Remote & RCA
Make sure the car stereo is turned off for this step.
1. Route the remote wire and RCA cables through the inside
of the vehicle from the car stereo to the amplifier’s location.
(Run the RCA cables from the opposite side of the routed
remote and power cables)
2. Identify the Left and Right channel and connect the RCA
cable to the car stereo.
3. Attach the remote wire to the remote wire on the stereo.
4. Connect the other end of the remote wire and RCA cable to
the amplifier.
