English Manual
Version: 28.05.2003
2 TerraTec HomeArena Stereo (English)
CEDeclaration
We:
TerraTec Electronic GmbH, Herrenpfad 38, D-41334 Nettetal, Germany
hereby declare that the products:
HomeArena Stereo
to which this declaration refers is in compliance with the following standards or
standardizing documents:
EN 50013, EN 50022, EN 60065
The following are the stipulated operating and environmental conditions for said
compliance:
residential, business and commercial environments and small-company
environments.
Thisdeclaration isbased on:
Test report(s) of the EMC testing laboratory
The information in this document issubject to change without notice and shall not be deemed as a
warranty by the seller. No warranties, express or implied, are made with regard to the quality,
suitability or accuracy of thisdocument. The manufacturer reservesthe right to change the contents
of thisdocument and/or the associated productsat any time without the provision of prior notice to
specific persons or organizations. The manufacturer shall not be held liable for damages of any kind
arising from the use, or the inability to use thisproduct or its documentation, even if the possibility of
such damage is known. The information in this document is subject to copyright. All rights are
reserved. No part of this manual may be reproduced or transmitted in any form or for any purpose
without the expresswritten permission of the copyright holders. Product and brand namescontained
in this document are used for identification purposes only. All registered trademarks, product
designations or brand names used in this document are the registered property of their respective
owners.
©TerraTec®Electronic GmbH, 1994-2003. All rightsreserved (28.05.2003).
TerraTec HomeArena Stereo (English) 3
&RQWHQWV
1. Introduction.................................................................................................................4
1.1. What’sin the Package?........................................................................................4
1.2. System Requirements............................................................................................4
2. Installation ...................................................................................................................5
2.1. Front View HomeArena Stereo ............................................................................5
2.2. Back View HomeArena Stereo ............................................................................5
2.3. Installation Instructionsfor HomeArena Stereo .................................................6
3. Operating Instructionsfor HomeArena Stereo.......................................................8
4. Technical.....................................................................................................................9
5. FCC Declaration.......................................................................................................10
6. Limited warranty.......................................................................................................11
4 TerraTec HomeArena Stereo (English)
,QWURGXFWLRQ
:KDWVLQWKH3DFNDJH"
Your package HomeArena Speaker System includesthe following documentation
and hardware:
¾2 x 2 way speakerswith 1 x wire remote control
¾1 x AC-DC Adaptor 230V/12V
¾1 x Quick-I-Guide
¾1 x CD
¾1 x Registration Card
¾1 x Service Request Form
If any componentsare missing or damaged, please contact your dealer.
6\VWHP5HTXLUHPHQWV
PC Soundcard with 3,5 mm stereo output or 3,5 mm stereo build in output
TerraTec HomeArena Stereo (English) 5
,QVWDOODWLRQ
)URQW9LHZ+RPH$UHQD6WHUHR
(picture just for illustration)
%DFN9LHZ+RPH$UHQD6WHUHR
6 TerraTec HomeArena Stereo (English)
SULPDU\VSHDNHUFRQWUROOHU2Q2II9ROXPHFDEOHOHIWVSHDNHU$&'&DGDSWHUOHIW
VSHDNHU
,QVWDOODWLRQ,QVWUXFWLRQVIRU+RPH$UHQD6WHUHR
1. Place the speaker with the controls (primary speaker) on the right side and
other speaker (left speaker) on the left side of the PC monitor .
2. Plug the cable of the left speaker into the connector of the primary speaker.
3. Connect the 3.5 mm chinch cable to the sound card or any other audio
source.
4. Before connecting the power cable, make sure the speaker’spower controller
isin the "off" or "out" position.
5. Plug the power adapter cable into the back connector of the primary
speaker.
6. Connect the power adapter cable to a standard household electrical outlet.
7. Use the controller to turn on the speakers. The green LED Light should
illuminate.
TerraTec HomeArena Stereo (English) 7
8. Activate the audio source to test speakers.
8 TerraTec HomeArena Stereo (English)
2SHUDWLQJ,QVWUXFWLRQVIRU+RPH$UHQD6WHUHR
1. Avoid exposing speakers to environments that are excessively warm and
humid (particularly in unventilated spacesor nearby heaters) or dusty.
2. Do not set speakers near windows exposed to direct sunlight or in areas near
to water
3. Clean speaker housing by wiping with mild cleaning solution. Do not use
solvents!
4. The loudspeakers are magnetically shielded and you can place them also in
the near of your PC monitor.
5. "!" Warning : Before connecting or disconnecting the loudspeakers from the
main electricity make sure that the speaker’s control button is in the " OFF "
position.
TerraTec HomeArena Stereo (English) 9
7HFKQLFDO
2XWSXW3RZHU506 2.5W + 2.5W RMSPer Channel
'ULYHUV 3" Full range
/RDG,PSHGDQFH 4 Ohm
)UHTXHQF\5HVSRQVH 80 Hz~ 18 KHz
3RZHUVXSSO\ INPUTDC SOURCE( DC 12V/800mA )
0DJQHWLFDOO\VKLHOGHG Yes
'LPHQVLRQ:[+[' W 100 mm x H200 mm x D 142 mm
All specificationssubject to change without prior notice.
10 TerraTec HomeArena Stereo (English)
)&&'HFODUDWLRQ
This equipment has been tested and found to comply with the limits for a Class B
digital device in accordance with the specifications in Part 15 of FCC rules. These
specifications are designed to provide reasonable protection against such
interference in a residential installation. This equipment generates, uses, and can
radiate radio-frequency energy. Incorrect use may lead to radio-frequency
interference. However, there is no guarantee that interference will not occur in a
particular installation. You can determine whether this device is causing
interference by turning it off. If the device does cause interference, try to correct
it by using one or more of the following measures:
¾ Turn the television or radio antenna until the interference stops.
¾Move the device farther away from the receiver.
¾Plug the device into an outlet that ison a different circuit from the receiver.
¾Consult your retailer or an experienced radio/television technician for
additional suggestions.
Only devices designated as Class B may be connected and must feature
shielded satellite cables. Changes or modifications to this product not authorized
by the group responsible for the adherence to the regulationscould void the FCC
certification and negate your authority to operate the product. This device
complies with the specifications in Part 15 of FCC rules. Its operation is subject to
the following rules: 1.) The device must not emit dangerous radiation. 2.) The
device must accept interference, including interference that may lead to faulty
operation.
