Insert the key blade to mechanically open the
trunk.
KEY BLADE
Used to lock/unlock the glove compartment or
the driver’s door if the vehicle has no electrical
current.
REMOTE KEY & KEY BLADE
Locks the doors, trunk, cabin storage
compartments, ski hatch, and arms
the alarm. If the car is locked with the
remote key while the power retractable
hard top is down, the double locking
feature activates after approximately
30 seconds. The doors can then not be
opened from inside the car.
Unlocks the doors, trunk, cabin storage
compartments, ski hatch, and disarms
the alarmA.
Unlocks (but does not open ) the trunk.
Approach lighting illuminates lights in
door mirrors, cabin, footwells, license
plates. Turn signals and parking lights
illuminate.
“Panic” alarm.
– Press and hold to sound the alarm.
Turn off alarm with unlock button.
A. Automatic relock occurs if no door/trunk is opened within 2
minutes after unlock.
NOTE
After cold starts, your engine will idle at a
higher speed for a short time.
Depress the clutch and/or brake pedal. Turn
the key/keyless drive start control to posi-
tion III and release it. The engine will start
automatically.
TURN SIGNALS STEERING WHEEL ADJUSTMENT
A
Lane-change sequence, three flashes.
B
Full turn sequence. WARNING
Never adjust the steering wheel while
driving.
COLD START AUTOSTART

LIGHTING PANEL
Automatic headlights. High beam flash
only.
Parking lights.
Headlights: turn off when ignition is
switched off, high/low beams.
Display & instrument panel lighting.
Front fog lights.
Rear fog light (driver’s side only).
A
High beam flash.
B
Toggle between high/low beams, home
safe lighting.
STORAGE SPACES, 12-VOLT SOCKET & AUX/USB* CONNECTOR
The 12-volt sockets in the cabin function in
ignition positions Ior II.
The 12-volt socket* in the trunk always func-
tions.
AUX/USB* can be used to connect e.g., an
mp3 player to the vehicle’s audio system.
CAUTION
Using the optional 12-volt socket in the trunk
with the engine switched off will drain the
battery.
CAR CARE
Hand washing is gentler on the paint than an
automatic car wash. Since the paint on a new
vehicle may take several months to harden
completely, we recommend washing the vehi-
cle by hand during this period. Use clean water,
a suitable car washing detergent and a sponge.
Keep in mind that dirt or grit on the sponge can
scratch the paint.

AUDIO SYSTEM
1
Press to turn on/off.
Turn to adjust volume.
2
FM1, FM2 or AM radio.
4
Display
5
MODE, CD, Sirius satellite radio*, AUXA
6
Sound settings. Press to select e.g.,
BASS, TREBLE, etc.
Turn to adjust.
9
MENU.AUX, volume and advanced sound
settings.
HD RADIO
HD radio reception is subject to coverage limita-
tions. See your Owner’s Manual for details.
A. AUX connector for e.g., mp3 player. Set mp3 player’s volume
to medium for best sound quality.
RADIO
6
Turn to select a radio station.
8
Search for the next strong station.
10
Search for stations with left/right arrows.
Store up to 20 stations by pressing and
holding one of the preset buttons 0–9in
FM1 and 0–9in FM2, until the stored sta-
tion is confirmed in the display.
Autostore stations by pressing for 2 sec-
onds. AUTOSTORE is displayed during
the search. The 10 strongest stations are
stored. Press 0–9to select a station.
CD PLAYER
3
Press to eject current CD.
Press and hold to eject all CDs.
6
Turn to change tracks.
7
CD selectB. Press 1–6.
10
Change tracks with left/right arrows.
Select CDBwith up/down arrows.
BLUETOOTH®
Make the cell phone searchable/visible.
Press the PHONE button on the audio sys-
tem control panel briefly.
Select ”Add phone” in the audio system
display.
Select the cell phone to be connected.
Enter the numbers shown in the audio sys-
tem display using the cell phone’s keypad.
BOptional CD changer only.
1.
2.
3.
4.
5.
The deep center storage compartment has
room for 10 CD jewel cases. These cases must
be inserted with their spines upward in order
to allow room for 10 CDs.
CD STORAGE

WIPERS AND RAIN SENSOR*
1
Rain sensor On/Off with the lever in the
0position.
2
Turn to adjust intermittent wiper speed or
rain sensor sensitivity where applicable.
A
Single wiper sweep.
0
Off
B
Intermittent wipers. Turn (2) to adjust
interval.
C
Normal wiper speed.
D
High wiper speed.
E
Windshield and headlight washer.
Displayed when the rain sensor is
active.
AUTOMATIC CONTROL
In AUTO mode, ECC controls all functions
automatically and makes driving more pleasant
with optimal air quality.
1
Press AUTO to maintain automatic cabin
temperature, balanced airflow and other
settings.
7
Press to individually adjust the left (L) or
right (R) side.
Turn the dial to the desired temperature,
which is shown in the display.
ELECTRONIC CLIMATE CONTROL (ECC)*
MANUAL CONTROL
1
Blower speed.
2
Defroster to quickly defog on the wind-
shield and side windows.
3
Recirculation
4
Heated rear window and door mirrors.
5
Air distribution.
6
Air conditioning Off/On to cool the cabin
and defog the windows.

1
Low fuel level indicator
When the symbol illuminates, refuel as
soon as possible.
2
Fuel gauge.
The fuel filler door is on the right, as indi-
cated by the arrow.
3
Information display (trip computer infor-
mation, messages, clock and ambient
temperature).
4
A short press toggles between T1 &T2.
A long press resets the displayed odom-
eter.
5
The trip odometer display shows two
separate trip odometers, T1 & T2.
TRIP COMPUTER AND ODOMETER
6
Press to display or erase a message.
7
Turn to show trip computer information
alternatives.
8
A short press resets current function.
A long press resets all functions.
NOTE
The display text MILES TO EMPTY TANK is
an approximation, based on recent average
fuel consumption.
BLIND SPOT INFORMATION SYS-
TEM (BLIS)*
If the BLIS indicator lights illuminate occasion-
ally even when there are no other vehicles in
the blind area, this may be caused by light re-
flected from a wet road surface, the vehicle’s
own shadow against a large, light, smooth
surface, or sunlight directly in the camera
when the sun is low on the horizon.
In the event of a fault, BLIND SPOT SYST.
SERVICE REQUIRED will be displayed. See
the Owner’s Manual for other BLIS-related
messages.
REFUELING
1. Press this button to open the fuel filler door.
2. Hang the fuel filler cap on the hook while
refueling.

6.5 ft
2.0 m
8 in
0.2 m
OPERATING THE POWER RETRACT-
ABLE HARD TOP
PREPARATION
There should be no objects on the parcel
shelf, roof, or trunk lid.
6.5 ft (2 m) free height above the car, and
8 in. (0.2 m) behind.
Flat ground.
Ambient temperature above 14 ˚F (-10 ˚C).
Trunk lid and trunk divider closed.
The car must be at a standstill.
Always have an unobstructed view of the
power retractable hard top when it is in
motion.
The windows open automatically approxi-
mately 1 in. (2 cm) when the power retractable
hard top is operated. They close automati-
cally.
•
•
•
•
•
•
TRUNK DIVIDER
The trunk divider limits the amount of cargo
in the trunk to leave space for the power
retractable hard top.
Raise the divider when loading the trunk.
Close the divider completely (3) before
operating the hard top. See the decal on
the trunk divider.
1.
2.
Raise or lower the folded power retractable
hard top to facilitate loading.
Press the button and wait several sec-
onds for the hard top to rise slightly.
Open the trunk divider, load the cargo,
and close the trunk divider again.
Press the button again to lower the folded
power retractable hard top.
1.
2.
3.
LOAD ASSISTANCE
OPERATION
Engine idling (car parked outdoors).
Press the brake pedal.
Hold down the button (see inset illustra-
tion above) to open or pull up to close
the convertible hard top. Hold until a tone
is audible and the message TOP FULLY
UP/TOP FULLY DOWN is displayed.
Release the button.
1.
2.
3.
4.
AUTOMATIC CAR WASH
Remove the antenna by turning it coun-
terclockwise before washing the car in an
automatic car wash.

TP 11080 (USA & Canada) AT 0920. Printed in Sweden, Göteborg 2009, Copyright © 2000-2009 Volvo Car Corporation
ENTERING THE REAR SEAT
MANUAL SEAT
Moving the seat forward
Remove the seat belt from the guide (A).
Pull up the handle (B) and fold the backrest
forward until it locks in position.
Move the seat forward (C).
Moving the seat rearward
Move the seat rearward until it reaches the
desired position (D).
Pull up the handle (B) and return the back-
rest to the upright position.
Put the seat belt back into the guide (F).
POWER SEAT*
Moving the seat forward
Remove the seat belt from the guide (A).
Pull up the handle (B) and fold the backrest
forward until it locks in position.
Press and hold in the front section of the
button (G).
Moving the seat rearward
Press and hold in the rear section of the
button (G).
Pull up the handle (B) and return the back-
rest to the upright position.
Put the seat belt back into the guide (F).
NOTE
When putting on the seat belt, it is easiest
to reach the lower section of the belt, near
the guide, instead of reaching over your
shoulder.
1.
2.
3.
1.
2.
3.
1.
2.
3.
1.
2.
3.
ADJUSTING THE FRONT SEAT
1
Lumbar support.
2
Backrest tilt.
3
Raise/lower the seat.
4
Raise/lower the front edge of the seat
cushion.
5
Forward/rearward.
6
Access to rear seat.
TIRE PRESSURE MONITORING
SYSTEM (TPMS)
When a low tire pressure warning message
(LOW TIRE PRESS. CHECK TIRES or VERY
LOW TIRE PRESSURE) has been displayed
and the tire pressure warning light ( ) has
illuminated, one or more tires has low inflation
pressure.
Check the inflation pressure of all four tires
with a tire pressure gauge as soon as possible
and pump the tire(s) with low pressure to the
recommended inflation pressure.
Refer to the inflation pressure tables in the
chapter “Wheels and tires” in the Owner’s
Manual.

WELCOME TO THE GLOBAL FAMILY OF VOLVO
OWNERS!
Getting to know your new vehicle is an exciting experience.
This Quick Guide provides a brief overview of the most common
features and functions in your Volvo.
However, for the most up-to-date and detailed descriptions and
instructions, as well as important warnings and other information not
included in this folder, please refer to your Owner’s Manual.
An asterisk (*) indicates optional equipment.
For additional information, contact Customer Service:
U.S.A.: 1-800-458-1552 www.volvocars.us
Canada: 1-800-663-8255 www.volvocanada.com
vOLvO C70
quick guide
