VOP CeramicMaster E10 User manual

Ceramic Master E10 en v2 1
CeramicMaster
E10
USER MANUAL

Ceramic Master E10 en v2 2
CONTENT
1. INTRODUCTION
2. SAFETY INSTRUCTIONS
3. DESCRIPTION OF THE UNIT
4. INSTALLATION AND INITIAL START-UP
Unpacking
Connections
Temperature corrections by the user
5. PRACTICAL USE
Description of buttons
Description of indication
Parameters and Programming
Description of parameters in order of their
appearance
6. ERRORS AND FOLLOWING ACTIONS
7. IMPORTANT PRACTICAL INFORMATION
8. EXCANGE OF DATA AND FIRMWARE
BETWEEN THE FURNACE AND PC
Transfer of programs from PC to the Ceramic
Master E10 furnace.
Transfer of programs from the Ceramic
Master E10 to PC
Transfer of a LOG file from the Ceramic
Master E10 furnace to PC
Reloading of the control program (flash).
9. TECHNICAL DATA
10. MAINTENANCE
11. SCOPE OF DELIVERY
WARRANTY
3
4
5
6
6
6
6
7
7
8
9
10
12
13
14
14
15
16
17
18
19
19
20

Ceramic Master E10 en v2 3
1. INTRODUCTION
Thank you for having purchased the CERAMICMASTER
E10 furnace which, we are sure will all meet all your
needs and will satisfy your high demands.
This furnace has been designed according to the
requirements of latest industrial standards and we
guarantee that you will use it many years as your closest
assistant.
However, inappropriate use may damage the
equipment and be harmful to personnel. Please observe
the relevant safety instructions and read the Operating
Instructions carefully.
We wish you pleasant and fruitful work with the
CERAMICMASTER E10.
SYMBOLS:
This symbol indicates that there is high
dangerous tension under the bonnet which it is
put on.
This symbol indicates that the machine
complies with the requirements of the Directives
for Low Tension and Electromagnetic
Compatibility as well as for the Standards
harmonized with them.

Ceramic Master E10 en v2 4
2. SAFETY INSTRUCTIONS
The following instructions must be observed in order
to avoid personnel injury or equipment failure.
CAUTION!
the furnace must not be run by an operator who
is not acquainted with these instructions;
before turning on the plug in the net contact
check if the voltage in the electrical network
correspond to the working tension. In case of
discrepancy, consult a specialist;
on no account do not alter the device;
the notices and stickers must be kept in good
condition so that they are easily readable; they
should not be removed!
the machine must not function in case of being
damaged and in position to injure the staff or a
third person;
keep the cables out of heat, oil and coarse
objects; do not catch the device by the cable
when you move it.
switch off the furnace and pull out the plug of
the feeder cable from the contact before each
cleaning or upkeep.
spare parts which are not specified by the
manufacturer cannot be used!
If the machine is used by such means not indicated by
the manufacturer, the provided protection can get worse!

Ceramic Master E10 en v2 5
3. DESCRIPTION OF THE UNIT
1Cover of the chamber
2Ceramic table
3Lift table
4Cooling pad
5Front panel
6Mains switch
7Mains fuses
8Plug of power cord
9Plug of pump’s power cord
10 Fuse for pump
11 Plug of RS232
12 Nozzle of pump’s hose
13 Hose of the pump
14 Adapter
15 Vacuum pump
1
2
3
4
5
7
8
9
10
11
12
13
14
15
16

Ceramic Master E10 en v2 6
4. INSTALLATION AND INITIAL START-UP
UNPACKING
CONNECTIONS
TEMPERATURE CORRECTIONS BY THE USER
IMPORTANT!
Carefully remove modules from packages;
Make sure that the mains voltage is ~230V and
the contact is reliably grounded.
Connect pump supply cable to the terminal with
label "VACUUM PUMP" on the rear panel;
Connect the power supply cable to the terminal
with label "POWER" on the rear panel;
Connect vacuum hose to the vacuum fitting with
label "VACUUM” on the rear panel.
The net switch is on the rear panel, on the right.
Put the furnace in a position which enables its
easy engaging turning off from the master
switch as well as from the contact.
It is possible to calibrate the temperature T within
the limits of plus/minus 50°C. In order to do this you
must proceed with the following steps: open the
furnace; switch it off; switch it on again while
pressing the buttons "RUN" and "STOP" at the same
time. Now you are in service mode. You see the
following indication on the display:
0:00:00 000 0XXX
TERMO CORRECT: + 0000
The current value of the correction can be changed
with the turning of the multi-functional rotary knob.
Push the button “PROG” to store the new value.
After turning on the furnace it will show SELF
TESTING for a few seconds. Do not release the
buttons before you hear the sound of the buzzer -
otherwise you will not enter into the mode for
temperature adjusting but in normal operating
mode.

Ceramic Master E10 en v2 7
5. PRACTICAL USE
DESCRIPTION OF BUTTONS
PROG - puts the number of the program which is to be
performed into programming mode.
ESC -cancels all changes.
RUN
starts the chosen program when the indicator of
the button flashes in green;
permits the change of the chosen parameter
value in a programming mode.
STOP
stops the program at any moment;
stops the movement of the table at any position;
cancels all changes of the chosen parameter in a
programming mode;
recovers the normal working mode of the
furnace after error.
- closes manually the furnace. The button can
increase/decrease the chosen parameter value with 100
by pressing it while turning the multi functional rotary
knob.
- opens manually the furnace . The button can
increase/decrease the chosen parameter value with 10
by pressing it while turning the multi functional rotary
knob.
MFRK - Multi Functional Rotary Knob. It is used for
choosing of programs or parameters and set the values.

Ceramic Master E10 en v2 8
DESCRIPTION OF INDICATION
This furnace has 2 LINE LCD display.
The LINE 1 shows following information:
PROGRAM sector shows the number of the chosen
program for execution or the program for entering of
parameters.
°C sector shows the current temperature value in the firing
chamber.
The LINE 2 shows following information:
MODE sector shows information about current stage;
TIME sector shows the time left till the end of the executed
program.
Indicator 1: the furnace is in the phase of drying.
Indicator 2: the furnace is in the phase when the tempera-
ture increases to the value for firing.
Indicator 3: the furnace is in the phase of firing.
Indicator 4: the furnace is in the phase of cooling.
Indicator 5: the vacuum pump is switched on.
54
3
2
1

Ceramic Master E10 en v2 9
PARAMETERS AND PROGRAMMING
In order to change the value of a parameter it is
necessary to do the following steps:
There are two possible ways of leaving the programming
mode after you have finished with the changes in the
parameters’ value:
FIRST EXIT:
SECOND EXIT:
With the multi functional rotary knob MFRK chose
the program which parameters you want to change;
Press button PROG. Indicator of the button RUN
begins to blink green/red and you can see on the
display:
XX : YYYYYYYYYY VIEW
PROGRAM NAME
The letter expressions means:
ХХ - number of program;
VIEW - view data;
YYYYYYYYYY –name of program;
PROGRAM NAMЕ- parameter which to be changed;
PROGRAM NAMЕis the first parameter which is
shown when you enter in PROGRAM mode. Turn
left/right the MFRK in order to chose the parameter
you want to change;
Press button RUN in order to chose the value of the
parameter you want to change. If you have chosen
the first parameter you would see on the display:
XX : YYYYYYYYYY EDIT
PROGRAM NAME
Indicator of the button RUN turns off and the red
indicator on the button STOP begins to blink.
Turn the MFRK to change the parameter value.
Press button STOP in order to leave the programming of
the current parameter. Indicator of the button RUN
begins to blink again in green/red which means that it is
possible to program next parameter.
press button ESC. This will CANCEL all the changes that
are made in the parameters’ value in the program.
press button PROG. This will SAVE all the changes that
are made in the parameters’ value permanent.
The indicator of button RUN will flash in green in working
mode if the temperature defined by the parameter IDLE
TEMP is reached and if the temperature is not
reached it will flash in red

Ceramic Master E10 en v2 10
DESCRIPTION OF PARAMETERS IN ORDER OF THEIR
APPEARANCE
PROGRAM NAME
IDLE TEMP
PREDRY TIME
DRY TEMP
DRY TIME
FIRE RATE
FIRE TIME
FIRE TEMP
COOL1 TIME
COOL2 TIME
VRUN TEMP
VRUN TIME
VSTOP TEMP
VSTOP TIME
parameter for set the name for the current program.
Choose the position for desired letter by using buttons
and . Then choose the letter using MFRK.
idle temperature. This is the temperature which the
furnace keeps in STOP mode. Its value is from 150°C to
600°C but it can’t exceed (DRY TEMP-20)°C.
during this time the table stays in lower end position
when the temperature in the chamber is equal to
DRYTEMP. It can be changed from 0 s to 1 h.
drying temperature. Its value is from (IDLE TEMP+20)°C
to (FIRE TEMP-20)°C.
the time for moving the table from lower end position to
the medium position which is about 1cm from the upper
end position of the table. The temperature in the
chamber is DRY TEMP. It can be changed from 0s to 1h.
increase rate of the temperature for the firing. Its value is
from 30°C /min to 200°C /min.
time for maintaining the temperature FIRE TEMP. It can
be changed from 0s to 30min.
temperature for the firing. Its value is from
(DRYTEMP+20)°C to 1100°C.
During this time the table is about 1cm from the upper
end position. It can be changed from 0s to 1h.
time for opening the furnace to the lower end position.
It can be changed from 0s to 1h.
temperature which defines the start of the time VRUN
TIME. Its value is from 0°Cto 1250°C. If its value
exceeds the value of the parameter FIRE TIME, vacuum
will never start.
time which defines the start of the vacuum. It starts after
the firing chamber temperature reaches the value of the
parameter VRUN TEMP. It can be changed from 0s to
1h.
temperature which defines the start of the time VSTOP
TIME. Its value is from 0°Cto 1250°C. If its value
exceeds the value of the parameter FIRE TIME, vacuum
will never start.
time which defines the stop of the vacuum. It starts after
the firing chamber temperature reaches the value of the
parameter VSTOP TEMP. It can be changed from 0s to
1h.

Ceramic Master E10 en v2 11
ATTENTION!
Values of the parameters FIRE RATE, FIRE TEMP и FIRE
TIME can be changed during the execution of the
program. This can be done with the buttons PROG, ESC
and and with the turning of the multifunctional knob
MFRK.
If you press the button PROG during the execution of a
program the value of the parameter FIRE RATE will blink
on the display and with MFRK will be able to change the
programmed value.
Button ESC changes parameter FIRE TEMP, and button
changes parameter FIRE TIME.
When programming the temperature conditions for
parameters IDLE TEMP, DRY TEMP and FIRE TEMP the
program temperature cannot be lower than this of the
previous parameter and at the same time higher than
this of the next parameter.
There is a possibility for fast changing of parameters
which have TEMPERATURE and TIME dimensions. When
you push the button and rotate the MFRK the value
will change by 100 points, and by pushing and rotate
the MFRK the value will change by 10 points.

Ceramic Master E10 en v2 12
6. ERRORS AND CORRECTIVE ACTIONS
General errors
1- Missing signal "mains zero", entry 0
2 - Missing signal "mains zero", entry 1
3- Mains frequency is not 50 Hz or 60 Hz.
Errors concerning the heating
15 - During running of a program: when the
temperature is increasing the needed rate of
increasing cannot be achieved.
19 - The required temperature is not reached for the
selected time.
20 - The required temperature can not be reached
during cooling.
21 - The selected temperature can not be reached
during heating.
22 - Temperature is higher than 1200°С.
23 - Temperature is lower than 5°С.
99 - Interrupted thermo sensor or the temperature is
higher than 1285°С.
Errors concerning the movement of the table
54 - The sensor for the table to position drying is not
reached for a preset time.
76 - The time for opening is over during the program
controlled mode.
84 - The upper position sensor of the table (closing)
is not reached for the required time.
86 - The lower position sensor for the table is not
reached for the required time during opening of
the furnace.
ATTENTION!
Errors concerning the vacuum.
28 - The selected vacuum is not reached for the
required time.
50 - There exists residual vacuum during the initial
power on procedure.
51 - After releasing the vacuum, for the required
time the vacuum is not released entirely.
75 - The vacuum can not be released in programming
mode.
Errors concerning RS232 interface to the PC.
40 - A non-number-type symbol has appeared during
receiving.
41, 42 - A symbol is received which is not = or ~ during
receiving.
160 - Received number for the minutes greater than
59 during receiving.
161 - Received number for the seconds greater than
59 during receiving.
30, 31 - Timeout during receiving of programs.
121 - fault in the value of DRYTEMP
125 - fault in the value of FIRERATE
127 - fault in the value of IDLETEMP
128 - fault in the value of FIRETEMP
131 - fault in the value of VRTEMP
132 - fault in the value of VSTEMP
135 - fault in the value of FIRETIME
When any error appears, it is written on the display and
the furnace produces a sound signal. The button STOP
has to be pressed in order to exit from this state.

Ceramic Master E10 en v2 13
7. IMPORTANT PRACTICAL INFORMATION
1. Avoid positioning of furnace and pump in the
immediate vicinity of heat sources (radiators).
2. Install the vacuum pump in a well-ventilated
locations. Ensure that the apertures in the frame plate
are free and that no foreign object can fall into the
furnace base.
3. Avoid placing any objects on the frame plate, place
only on the face cooling plate.
4. Ensure that the sealing ring in the furnace head and
the sealing rim of the furnace base are kept clean and
undamaged.
5. Always keep the firing chamber closed between firings.
6. It is strongly recommended to use porous ceramic tray
(on request - № 81022).
WARNING! For the proper work of the furnace it is
necessary to hold the furnace in stand-by mode for at
least 0.5 hours. After switching on the furnace close the
dome and wait 0.5 hours.
7. If the power supply is interrupted during the working
process and:
a. If the temperature in the chamber has not
decreased by more than 15 degrees, the current
program will continue from the stage at which it
has been stopped.
b. If the temperature in the chamber has decreased
by more than 15 degrees, the following message
will appear on the display:
LONG TIME POWER OFF
In this case the program cannot continue. You have to
press the button STOP in order to exit this state.
The total number of the programs is 100 - with numbers
from 0 to 99. Programs from №1 to №20 have
parameters for ceramic NORITAKE.The manufacturer has
entered equivalent parameters in all other programs.
It is responsibility of the customer to enter the data for
the ceramic that he uses before he starts working.

Ceramic Master E10 en v2 14
8. EXCHANGE OF DATA AND PROGRAMS BETWEEN
THE Ceramic Master E10 FURNACE AND PC.
Transfer of programs from PC to the Ceramic Master
E10 furnace.
Switch off the furnace; keep the buttons RUN and STOP
depressed simultaneously and switch on the power
supply.
Wait to appear message:
TERMO CORRECT: - - - -
Press the STOP button.
On the display following message will appear:
STOP SOUND: YES (N0)
Press ESC button.
Following question will appear:
Programs <- PC?
The furnace prompts to enter data from the PC to the
furnace. If no entering of data is needed then press the
ESC button. If entering of data is needed then start the
program Teraterm Pro on the PC.
Go to menu SETUP/Serial Port in this program and
perform following settings:
Com x - Serial port number
Baud Rate - 9600
Data - 8 bit
Parity - none
Stop - 1 bit
Flow Control - none
Transmit Delay - 0ns 1000ms
Enter the menu File/Send File and perform following
settings:
Options - select binary
Enter the file name where the programs are to be
loaded from.
Press the PROG button of the furnace.
Select the function Open from the PC.
A message on the furnace display will appear:
RECEIVING
Programs –xx
This means that the programs are being loaded
currently.
After finishing following question will appear on the
display of the furnace:
Programs -> PC?
Push the ESC button .
Following question on the furnace display will appear:
Log File to PC?
Press the ESC button.

Ceramic Master E10 en v2 15
Transfer of programs from the Ceramic Master E10 to
PC.
Switch off the furnace; keep the buttons RUN and STOP
depressed simultaneously and switch on the power
supply.
Wait to appear message:
TERMO CORRECT: - - - -
Press the STOP button.
On the display following message will appear:
STOP SOUND: YES (N0)
Press ESC button.
Following question will appear:
Programs <- PC?
Press the ESC button and this question will appear on
the furnace display:
Programs -> PC?
The furnace prompts to output the data from the
furnace to the PC. If this is not needed, press the ESC
button. When you wish to start transfer of data from
the furnace to the PC start the program Teraterm Pro.
Open the menu SETUP/Serial Port and perform
following settings:
Com x - Serial port number
Baud Rate - 9600
Data - 8 bit
Parity - none
Stop - 1 bit
Flow Control - none
Transmit Delay - 0ns 1000ms
Go to the menu File/Log and perform following
settings:
Options - select binary
Enter the file name where the programs are to be saved
and select function Open.
Press the PROG button of the furnace.
After the end of the operation following question will
appear on thefurnace display.
Log File to PC?
Push the ESC button.
Close the file with the programs of the computer. This is
done by going to the Teraterm Log window and pushing
the STOP button.

Ceramic Master E10 en v2 16
Transfer of a LOG file from the Ceramic Master E10
furnace to PC.
Switch off the furnace; keep the buttons RUN and STOP
depressed simultaneously and switch on the power
supply.
Wait to appear message:
TERMO CORRECT: - - - -
Press the STOP button.
On the display following message will appear:
STOP SOUND: YES (N0)
Press ESC button.
Following question will appear:
Programs <- PC?
Press the ESC button and this question will appear on
the furnace display:
Programs -> PC?
Press the ESC button and following question will appear
on the furnace display:
Log File to PC?
From the PC start the program Teraterm Pro.
Enter the SETUP/Serial Port menu and perform
following settings:
Com x - Serial port number
Baud Rate - 9600
Data - 8 bit
Parity - none
Stop - 1 bit
Flow Control - none
Transmit Delay - 0ns 1000ms
Go to the menu File/Log and perform following
settings:
Options - binary
Enter the file name where the coded data from the
furnace to be saved and select Open.
Press the PROG button of the furnace.
After the end of the process you can continue to work
with the furnace.
Close the log file in the PC by going to the Teraterm Log
window and pressing the CLOSE button.

Ceramic Master E10 en v2 17
Reloading of the control program (flash)
Form the PC start the program Teraterm Pro.
Go to the menu Setup/Serial Port and perform
following settings:
Com x - Serial port number
Baud Rate - 9600
Data - 8 bit
Parity - none
Stop - 1 bit
Flow Control - none
Transmit Delay - 0ns 1000ms
When the furnace is switched off push and hold the
ENTER button and switch on the furnace.
In the window of Teraterm Pro a message will appear:
VOP Co.
Press Space 1 –Here the program will count
down 10 sec.
If within 10 seconds the SPACE bar (of the PC ) is not
pressed, the furnace will exit from the procedure.
However, if the SPACE bar is pressed within 10 sec. then
the internal program of the furnace will be deleted and
the furnace will wait to load the new program, which is
in HEX format file.
This is done in the following way:
In the program Teraterm Pro go to the menu File/Send
File menu and perform following settings:
Options - select binary
Select the file containing the new program and press
the Open button.
After finishing the data transfer the furnace will start
automatically with the new control program.

Ceramic Master E10 en v2 18
9. TECHNICAL DATA
1. Electrical supply
2. Power consumption
2.1. Furnace with vacuum pump
2.2. Furnace without vacuum pump
3. Category of overtension
4. Vacuum pump data
4.1. Suction capacity
4.2. Regulated vacuum level
5. Maximal firing temperature
6. Effective firing chamber dimensions
7. Overall dimensions of closed furnace:
7.1. Width
7.2. Length
7.3. Height
8. Model Weight
9. Number of programs
10. Working temperature
11. Level of environment pollution
12. The device is designed for usage in normal dental
premises up to 2000 m altitude above sea level.
13. The maximum relative humidity of the air must
be 80% for temperatures up to 31°С, decreasing
lineally to 50% relative humidity for temperature
40°С.
14. Working modes
14.1. Programming mode
Programming of the parameters is fully
described in chapter 7. PROGRAMMING.
14.2. Working mode
It shows the number of the executed program
and the parameters’ value of the ongoing
program phase.
The values of all parameters could be seen if
you use the Multi Functional Rotary Knob
MFRK.
~230 V, ±10%, 50Hz
1700 W
1550 W
ІІ
22 l/min
от 0.1 до 0.9 bar
1100°С
Ф 95 мм; h 46 мм
370 мм
380 мм
570 мм
20 кg
100
5°С - 40°С
2

Ceramic Master E10 en v2 19
10. MAINTENANCE
11. DELIVERY SCOPE
Clean only with a dry or slightly moist cloth (no solvents!).
Change the safety locks with the announced valus only,
namely:
1.25A, slow (class T).
8A, slow (class T).
No repair activity by a service technician who is not
authorized by the manufacturer is allowed!
The lifting and carrying should be made only with the both
hands from below as the furnace stands on end.
No carrying and transportation in another state except for
vertical position is allowed!
Furnace CERAMICMASTER E10 1 pc.
Vacuum pump PVD-M22 1 pc.
Power cable 1 pc.
Flexible tube for the vacuum 1 pc.
Spare fuses
1.25А/250V 1 pc.
8A/250V 2 pc.
User Manual
PRODUCER: “VOP” Ltd.
2140 IZ “Microelectronika”
Botevgrad, Bulgaria
Теl. 0723 66303
Теl./Fax [phone]

Ceramic Master E10 en v2 20
Serial Number __________________
Invoice number _________________
Date __________________________
_______________________________________
CLIENT:
MANAGER of “VOP” Ltd.
_______________________________________
Serial Number _____________
Invoice number __________________
Date _____________________
Voucher Manufacturer
“VOP” Ltd.
Mikroelectronika
2140 Botevgrad
Tel. [phone]
Tel./Fax [phone]
Ceramic Master E10
WARRANTY SHEET
“VOP” Ltd. warrants the consumer for proper operation of all parts and materials in this product
during a period of 12 months since the day of its purchase.
During this period VOP Ltd. or its authorized persons will repair on its own account all defects
which have occur during the normal operation of the machine.
Defects caused by improper transportation, storage and manipulation of the product or due to
malfunction of the electrical mains supply are repaired on the account of the customer.
This warranty shall become void if attempts are made to repair the product by persons not
authorized by the producer.
