Vornado 660 AE User manual

model
660 AE
vornado.com
WHOLE ROOM CIRCULATOR
OWNER’S GUIDE
READ AND SAVE
THESE INSTRUCTIONS

2English
vornado.com
800-234-0604
[e-mail]
We expect this
product to be
perfect.
If it is not, we
will make it
right.

3
English
Important Safety Instructions ............................................................. 4
Features .............................................................................................. 7
Controls............................................................................................... 8
Getting Started................................................................................... 9
Using Alexa ....................................................................................... 10
Cleaning ............................................................................................ 11
Troubleshooting ............................................................................... 13
Warranty............................................................................................ 14
CONTENTS

4English
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
This owner’s guide and any additional inserts are considered part of
the product. They contain important information about safety, use and
disposal. Before using the product, please familiarize yourself with all
operating and safety instructions. Please keep all documents for future
reference and pass these documents on, together with the product, to
any future owner. See www.vornado.com/circulators-manuals to view,
download and print the most current version of these instructions.
INTENDED USE: This product is intended to circulate the air in indoor
living spaces only in the United States and Canada. This product is not
intended for commercial or industrial use. The manufacturer assumes
no responsibility for damage or injury due to unauthorized use or
product modication. Failure to follow these directions will void the
product warranty.
WARNING: Risk to Children and Impaired Persons
Supervision is required during the installation, operation, cleaning and
maintenance of this product by children 12 years of age and younger
and anyone with reduced physical, sensory or mental capabilities.
Children should be supervised to ensure that they do not play with the
appliance, its parts and packaging material.
INSTALLATION WARNING—To reduce risk of re, electrical shock
and injury to persons, observe the following:
- Place this product away from curtains, draperies, tablecloths and
other fabrics, since they may be drawn into the product, damage the
motor and/or cause a re.
- No part of this product (the appliance, power cord, plug, packaging,
etc.) should be placed near furnaces, replaces, stoves or other high
temperature heat sources. Do not use this product in a window, on
an uneven or unstable surface, or near water.
- The appliance, power supply, power cord and plug cannot come
into contact with water. Do not use this product on wet surfaces.
Do not use this product in a bathtub or shower or position product
where it may fall into a bathtub, laundry, swimming pool or other
water container. Do not use this product outdoors or expose it to
weather or elements.
- Do not run cord under carpeting. Do not cover cord with throw
rugs, runners, or similar coverings. Do not route cord under furniture
or appliances. Arrange cord away from trafc area and where it
will not be tripped over. The cord should not hang over edges of
counters or be placed where it can be crimped or closed in doors.
Place appliance near an easily accessible outlet so the product can
be unplugged quickly during an emergency.
SAFE USE WARNING—To reduce risk of re, electrical shock and
injury to persons, observe the following:
- WARNING: To reduce likelihood of circuit overload, re and electric
shock, do not operate with a solid state speed device, such as a
dimmer control switch.
- Do not operate any fan with a damaged cord or plug. Discard fan or
return to an authorized service facility for examination and/or repair.
- Do not operate unit if the unit has been dropped or damaged. Do
not use this product if it has a damaged power cord or plug. To
avoid risk of electrical shock, do not attempt to repair or replace
parts. Only original replacement parts may be used. If the power
cord is damaged, it must be replaced by the manufacturer, its
service agent, or similarly qualied persons in order to avoid a
hazard. Contact Vornado Consumer Service at 1-800-234-0604
(phone) or [email protected] (email) for further

5
English
instructions about replacement and repair.
- Before plugging power cord into electrical outlet, be sure that
all electrical information on the rating label, including voltage, is
compatible with your outlet’s power supply.
- Do not sit or stand on product.
- Never use the cord as a handle or otherwise yank, strain or stretch
the power cord.
- While the product is plugged in, do not insert or allow foreign
objects to enter any input or output opening as this may cause risk
of electric shock or re, or damage the product.
- A loose t between wall outlet (receptacle) and plug may cause
overheating and distortion of the plug. Discontinue use of the
product in this outlet. Contact a qualied electrician to replace
loose or worn outlets.
- This appliance has a polarized plug (one blade is wider than the
other.) To reduce the risk of electric shock, this plug is intended to
t in a polarized outlet only one way. If the plug does not t fully in
the outlet, reverse the plug. If it still does not t, contact a qualied
electrician. Do not attempt to defeat this safety feature.
- Before moving, repositioning, servicing, cleaning and when not
in use, use the product controls to turn off the power and then
unplug. Always unplug device to avoid possible injury due to
remote activation of the product. To disconnect from outlet, grasp
and pull only the plug. Also, power off and unplug if the product
will be left unattended for an extended period of time or during
electrical storms.
SERVICING WARNING—To reduce risk of re, electrical shock
and injury to persons, observe the following:
- Always unplug device before servicing or cleaning to avoid possible
injury due to remote activation of the product.
- Clean your product regularly, only as is instructed in this manual.
Prior to cleaning, turn off the power on your product and unplug. Do
not use gasoline, thinners, solvents, ammonias or other chemicals
for cleaning. Refer to the CLEANING instructions provided.
- Do not open appliance housing while product is plugged in. To
avoid risk of shock, all service and/or repairs must be done by a
Vornado Authorized service Center.
- This product employs overload protection (fuse). A blown fuse
indicates an overload or short-circuit situation. If the fuse blows,
unplug the product from the outlet. Replace the fuse as per the user
servicing instructions (follow product marking for proper fuse rating)
and check the product. If the replacement fuse blows, a short-circuit
may be present and the product should be discarded or returned to
an authorized service facility for examination and/or repair.
User Servicing Instructions
1. Using the product controls, turn off the appliance.
2. Grasp the plug (not the cord) and disconnect from the outlet.
3. Risk of Fire. Replace fuse only with 2.5 Amp, 125 Volt fuse as
approved by Vornado Consumer Service. For an authorized
replacement fuse, please contact Vornado Consumer Service.
4. Once the replacement is received, use a small at-head
screwdriver to slide open the fuse cover (located on the plug)
(See Fig. A, next page).
5. Remove fuse by using the screwdriver to gently lift each end of
the fuse (See Fig. B, next page).
6. Install the replacement fuse by using the screwdriver to gently
push each metal end of the fuse into the receptacle one at a
time. Do not push on the center of the fuse—it is fragile and
may break.
7. Slide the fuse cover closed using the screwdriver. When
closed, the cover should t completely in the plug. No part of
the cover should stick out (See Fig. C, next page).

6English
8. Plug your appliance into the outlet and turn the power on.
9. If the replacement fuse blows, a short-circuit may be present
and the product should be discarded or returned to an
authorized service facility for examination and/or repair.
Risk of re. Do not replace attachment plug. Contains a safety device
(fuse, AFCI, LCDI) that should not be removed. Discard product if the
attachment plug is damaged.
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Contact Vornado Customer Service or dealer or an experienced
radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
This device contains license-exempt transmitter(s)/receiver(s) that
comply with Innovation, Science and Economic Development
Canada’s license-exempt RSS(s). Operation is subject to the following
two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
RF Exposure Statement: This equipment complies with FCC/ISED
radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum
distance 20cm between the radiator and your body.
Supplier's FCC Declaration of Conformity
Unique Identier: Vornado Model 660 AE
Responsible Party: Vornado Air LLC
Mailing Address : 415 E. 13th St., Andover, KS 67002
Contact: www.vornado.com
SAVE THESE INSTRUCTIONS
Fig. A Fig. B Fig. C

7
English
FEATURES
REMOVABLE GRILLE
For easy cleaning.
FINGER FRIENDLY DESIGN
Resists curious ngers.
DIRECTABLE
AIRFLOW
Direct the
airow where
you want it.
MULTIPLE SPEEDS
Speed setting for every
comfort level.
AIR INLETS
Signature inlets and
powerful motor to move
more air.
SILICONE FEET
Non-marking feet added for
stability.
Save energy by maximizing the performance of heating and cooling systems. When you use a Vornado Air Circulator, you will not have to
set your summertime thermostat as low or your wintertime thermostat as high.

8English
CONTROLS
Manual controls are located on the back of the product.
Press to power unit ON or OFF.
There are four speeds:
Press (I) for low speed.
Press (II) for medium speed.
Press (III) for high speed.
Press (IIII) for turbo speed.
You can also control the product with Amazon Alexa.
See GETTING STARTED and USING ALEXA for instructions.

9
English
Before product setup, download or update the Amazon Alexa app from your mobile device's app store and ensure your phone is connected to
your 2.4 GHz WIFI network.
1. Plug in your Vornado 660 AE.
2. Open the Alexa app and tap the MORE icon to add a device. Follow the on-screen instructions. If prompted by the app, scan the
2D barcode located on the product.
3. Once successfully connected, a message will appear. Fan is ready to use.
FACTORY RESET: If for any reason, there is a problem with your product or you wish to disconnect the product from your network
you can reset it to factory settings. Simply press and hold the TURBO and POWER buttons for 10-15 seconds or until the product
beeps 4 times. To reconnect your Vornado 660 AE, follow steps above.
GETTING STARTED

10 English
USING ALEXA
Once connected to Amazon Alexa, your 660 AE can be controlled via your voice with any Alexa Echo device or the Alexa
App on your phone. To control your product, use simple voice controls like:
"Alexa, turn ON / OFF the fan."
"Alexa, set speed on the fan to TURBO / HIGH / MEDIUM / LOW."
"Alexa, INCREASE / DECREASE the speed on the fan."
You can also use the Amazon Alexa app as a remote control for your 660 AE. See app for details.
You can unplug fan from wall to immediately disconnect from Alexa device control. Follow FACTORY RESET instructions
(page 9) to permanently disconnect device from network, if needed.

11
English
1. To release the Front Grille, remove the
3 screws on the back of the inlet grille,
located at roughly 10, 2 and 6 o'clock
positions.
2. Dust or wash Front Grille with a mild
dishwashing soap. Do not place grille in
the dishwasher. The excessive heat can
distort the plastic.
3. To reattach - position the Front Grille
so the Vornado logo in the center of the
Front Grille is straight. Replace all the
screws.
CLEANING
GRILLE REMOVAL Screwdriver required.
WARNING: Always unplug device before servicing or cleaning to avoid possible injury due to remote activation of the product. To
reduce the risk of electrical shock and injury to persons, unplug the circulator before removing grille.
Screw
Screw
Screw
Use the brush attachment on your household
vacuum cleaner to vacuum any accumulated
dust off the Front Grille and Air Inlets.
Note: The motor
is permanently
lubricated and
requires no oiling.

12 English
1. First, remove the nut from the shaft
by turning the nut clockwise to
loosen. Remove the washers. Pull the
blade straight out from the shaft.
2. Wipe the Blade with a damp cloth.
If your circulator is used in a greasy
environment, such as a kitchen, mild
soap or a common household cleaner
may be necessary. Do not use sol-
vents. Do not place blade in the dish-
washer. The excessive heat can distort
the plastic.
3. To reattach - be certain the at side
of the shaft aligns directly with the
corresponding at side on the blade’s
socket. Push the blade all the way on
the shaft until it bottoms out. Do not
use a hammer as this could result in
bearing damage. Reinstall at wash-
er, spring washer, and then nut.
WARNING: Always unplug device before servicing or cleaning to avoid possible injury due to remote activation of the product. To
reduce the risk of electrical shock and injury to persons, unplug the circulator before removing blade.
Remove Nut
Clockwise
CLEANING
BLADE REMOVAL Pliers recommended.

13
English
TROUBLESHOOTING
POSSIBLE CAUSE AND SOLUTIONPROBLEM
Unit is not plugged in. Plug Power Cord into electrical outlet.
Ensure unit fan speed setting is selected.
Plug fuse has blown. Replace fuse (See USER SERVICING INSTRUCTIONS on page 5).
Unit is damaged or in need of repair. Cease usage and unplug. Contact Consumer Service for assistance.
The outlet is worn or damaged. Try another outlet or contact a qualied electrician.
Unit set to a low speed setting. Adjust to a higher speed setting.
Airow is blocked. Remove obstruction.
Adjust direction of airow towards the user.
Under certain conditions, it is possible for a reset GFCI (Ground Fault Circuit Interrupter) outlet to trip when the
user is changing speeds on a Vornado circulator. In this event, change to an outlet that is not connected to a
GFCI device. It could also indicate a weak or defective GFCI outlet. Contact a qualied electrician to check the
GFCI outlet.
You might be connected to a 5 GHz WiFi network. Disconnect and reconnect to a 2.4 GHz network and try the
setup again.
Your WiFi signal might not be strong enough. Move closer to your WiFi router and try the setup again.
Device might already be registerd to another user. Please follow factory reset instructions on page 9 and try the
setup again.
The unit fails to power on.
Airow is weak or slow.
GFCI has tripped.
Cannot connect unit to my
Amazon Alexa account.

14 English
Vornado Air LLC (“Vornado”) warrants to the original consumer or purchaser this Vornado®
Whole Room Circulator (“Product”) is free from defects in material or workmanship for a
period of ve (5) years from the date of purchase. If any such defect is discovered within
the warranty period, Vornado, at its discretion, will repair or replace the Product at no cost.
For warranty or repair service: Call 1-800-234-0604 or email [email protected] to obtain
a Return Authorization (“RA”) form. Please have or include your Product’s model number
and serial number, as well as your name, address, city, state, zip code and phone number
when contacting Vornado for warranty service. To le a contactless warranty claim, visit
vornado.com/contact-us.
After receiving the RA form, ship your Product to: Vornado Air LLC Attn: Warranty & Repair
415 East 13th Street Andover, KS 67002. For your convenience, please have your model
number and serial number when contacting Vornado with service inquiries. To assure
proper handling, packages must be clearly marked with the RA number. Packages not
clearly marked with the RA number may be refused at the receiving dock. Please allow 1-2
weeks for repair and return of your Product after the Product is received.
Repairs not covered by the warranty or outside the warranty period will require a fee to
cover the cost of materials, labor, handling and shipping.
This warranty does not apply to defects resulting from abuse of the Product, modication,
alteration, mishandling, improper maintenance, commercial use or repair or service of the
Product by anyone other than Vornado; damages which occur in shipment or are attributed
to acts of God. Improper product use, which includes using an external device that
alters or converts the voltage or frequency of electricity, or shipping a Vornado product
to a country not intended for use will void all warranties. Any unauthorized product
modication, repair by unauthorized repair center, or use of non-approved replacement
parts is not recommended and any consequences will not be covered by support services
or product warranties. The product warranty will be honored only on models that are being
used in the country intended. REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER. VORNADO SHALL NOT
BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT
PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN
DURATION TO THE DURATION OF THIS WARRANTY. Some states do not allow the
exclusion or limitation of incidental or consequential damages, or allow limitations on how
long an implied warranty lasts, so the above limitations or exclusions may not apply to you.
This warranty gives you specic legal rights, and you may have other rights that vary from
state to state. The manufacturer assumes no responsibility for damage caused by failure
to follow these instructions or improper product use. Any such actions will invalidate the
product warranty.
All company names and product names are trademarks of their respective owners. ©
All rights reserved. All technical information, data, and instructions for the installation,
connection, and operation contained in these instructions for use correspond to the latest
available information at time of printing. The contents of this manual may differ slightly
from the actual product. Observe any additional supplements.
WARRANTY
We expect this product to be perfect. If you’re not satised with this product, let us know.
We’re Here To Help
800.234.0604
vornado.com
[email protected]
© 2021 Vornado Air LLC Andover, KS 67002 U.S. Specications subject to change without notice.
Vornado® is a trademark owned by Vornado Air LLC.
Designed, engineered and supported in Andover, KS

CL3-0766 R-, V01
Vornado Air, LLC
415 East 13th Street, Andover, Kansas 67002
800.234.0604 | vornado.com
Amazon, Echo, Alexa, and all related logos are
trademarks of Amazon.com, Inc. or its afliates.
