Vornado TRANSOM User manual

model
TRANSOM
vornado.com
WINDOW CIRCULATOR
OWNER’S GUIDE
GUÍA DEL PROPIETARIO DEL
VENTILADO DE VENTANA
GUIDE DE L’UTILISATEUR DU
VENTILATEUR DE FENÊTRE
READ AND SAVE
THESE INSTRUCTIONS
LEER Y GUARDAR ESTAS
INSTRUCCIONES
LISEZ ET CONSERVEZ CES
INSTRUCTIONS
Available in Black, Ice White

3
English2English
Important Safety Instructions .............................................................4
Features ..............................................................................................8
Getting Started...................................................................................9
Controls............................................................................................. 10
How To Use.......................................................................................11
Remote Control.................................................................................12
Cleaning ............................................................................................14
Troubleshooting ...............................................................................15
Warranty............................................................................................16
Español p. 17 Français p. 32
CONTENTS
vornado.com
800-234-0604
[e-mail]
We expect this
product to be
perfect.
If it is not, we
will make it
right.

3
English2English
Important Safety Instructions .............................................................4
Features ..............................................................................................8
Getting Started...................................................................................9
Controls............................................................................................. 10
How To Use.......................................................................................11
Remote Control.................................................................................12
Cleaning ............................................................................................14
Troubleshooting ...............................................................................15
Warranty............................................................................................16
Español p. 17 Français p. 32
CONTENTS
vornado.com
800-234-0604
[e-mail]
We expect this
product to be
perfect.
If it is not, we
will make it
right.

5
English4English
in a bathtub or shower or position product where it may fall into a
bathtub, laundry, swimming pool or other water container.
- Do not run cord under carpeting. Do not cover cord with throw
rugs, runners, or similar coverings. Do not route cord under furniture
or appliances. Arrange cord away from trafc area and where it
will not be tripped over. The cord should not hang over edges of
counters or be placed where it can be crimped or closed in doors.
Place appliance near an easily accessible outlet so the product can
be unplugged quickly during an emergency.
SAFE USE WARNING—To reduce risk of re, electrical shock and
injury to persons, observe the following:
- WARNING: To reduce likelihood of circuit overload, re and electric
shock, do not operate with a solid state speed device, such as a
dimmer control switch.
- Do not operate any fan with a damaged cord or plug. Discard fan or
return to an authorized service facility for examination and/or repair.
- Do not operate unit if the unit has been dropped or damaged. Do
not use this product if it has a damaged power cord or plug. To avoid
risk of electrical shock, do not attempt to repair or replace parts.
Only original replacement parts may be used. If the power cord
is damaged, it must be replaced by the manufacturer, its service
agent, or similarly qualied persons in order to avoid a hazard.
Contact Vornado Consumer Service at 1-800-234-0604 (phone) or
[email protected] (email) for further instructions about
replacement and repair.
- Risk of re. Your appliance may be equipped with a detachable
power supply or a cord/plug with a safety device such as a fuse. Use
only the power cord and plug provided.
- Before plugging power cord into electrical outlet, be sure that
all electrical information on the rating label, including voltage, is
compatible with your outlet’s power supply.
- Never use the cord as a handle or otherwise yank, strain or stretch
the power cord.
- While the product is plugged in, do not insert or allow foreign
objects to enter any input or output opening as this may cause risk
of electric shock or re, or damage the product.
- A loose t between wall outlet (receptacle) and plug may cause
overheating and distortion of the plug. Discontinue use of the
product in this outlet. Contact a qualied electrician to replace
loose or worn outlets.
- This appliance has a polarized plug (one blade is wider than the
other.) To reduce the risk of electrical shock, this plug is intended to
t in a polarized outlet only one way. If the plug does not t fully in
the outlet, reverse the plug. If it still does not t, contact a qualied
electrician. Do not attempt to defeat this safety feature.
- Before moving, repositioning, servicing, cleaning and when not in
use, use the product controls to turn off the power and then unplug.
To disconnect from outlet, grasp and pull only the plug. Also, power
off and unplug if the product will be left unattended for an extended
period of time or during electrical storms.
SERVICING WARNING—To reduce risk of re, electrical shock
and injury to persons, observe the following:
- Clean your product regularly, only as is instructed in this manual.
Prior to cleaning, turn off the power on your product and unplug. Do
not use gasoline, thinners, solvents, ammonias or other chemicals
for cleaning. Refer to the CLEANING instructions provided.
- Do not open appliance housing while product is plugged in. To
avoid risk of shock, all service and/or repairs must be done by a
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
This owner’s guide and any additional inserts are considered part of
the product. They contain important information about safety, use
and disposal. Before using the product, please familiarize yourself
with all operating and safety instructions. Please keep all documents
for future reference and pass these documents on, together with
the product, to any future owner. See www.vornado.com/circulators-
manuals to view, download and print the most current version of
these instructions.
INTENDED USE: This product is intended to circulate indoor and
outdoor air only in a window installation in the United States and
Canada. This product is not intended for commercial or industrial use.
The manufacturer assumes no responsibility for damage or injury due
to unauthorized use or product modication. Failure to follow these
directions will void the product warranty.
WARNING: Risk to Children and Impaired Persons
Supervision is required during the installation, operation, cleaning
and maintenance of this product by children 12 years of age and
younger and anyone with reduced physical, sensory or mental
capabilities. Children should be supervised to ensure that they do not
play with the appliance, its parts and packaging material.
WARNING: Chemical burn hazard. Keep batteries away from
children.
- WARNING: KEEP NEW AND USED BATTERIES AWAY
FROM CHILDREN. This product contains a lithium button/coin
cell battery. If a new or used lithium button/coin cell battery is
swallowed or enters the body, it can cause severe internal burns
and can lead to death in as little as 2 hours. Always completely
secure the battery compartment. If the battery compartment does
not close securely, stop using the product, remove the batteries,
and keep it away from children. If you think batteries might have
been swallowed or placed inside any part of the body, seek
immediate medical attention. In the US call the National Poison
Control Center at 1-800-222-1222 or 202-625-3333. In Canada call
416-813-5900.
INSTALLATION WARNING—To reduce risk of re, electrical
shock and injury to persons, observe the following:
- This product is intended for window installation only. Only use
with product controls facing indoors (not exposed to elements).
Do not use this product in a manner other than indicated by the
manufacturer in the window installation instructions below.
- Pull back and secure all curtains and draperies and place this product
away from tablecloths, blankets, and other fabrics, since they may
be drawn into the fan, damage the motor and/or cause a re.
- No part of this product (the appliance, power cord, plug,
packaging, etc.) should be placed near furnaces, replaces, stoves
or other high temperature heat sources. Do not use this product on
an uneven or unstable surface.
- The power cord and plug cannot come into contact with water.
Do not use this product on wet surfaces. Do not use this product

5
English4English
in a bathtub or shower or position product where it may fall into a
bathtub, laundry, swimming pool or other water container.
- Do not run cord under carpeting. Do not cover cord with throw
rugs, runners, or similar coverings. Do not route cord under furniture
or appliances. Arrange cord away from trafc area and where it
will not be tripped over. The cord should not hang over edges of
counters or be placed where it can be crimped or closed in doors.
Place appliance near an easily accessible outlet so the product can
be unplugged quickly during an emergency.
SAFE USE WARNING—To reduce risk of re, electrical shock and
injury to persons, observe the following:
- WARNING: To reduce likelihood of circuit overload, re and electric
shock, do not operate with a solid state speed device, such as a
dimmer control switch.
- Do not operate any fan with a damaged cord or plug. Discard fan or
return to an authorized service facility for examination and/or repair.
- Do not operate unit if the unit has been dropped or damaged. Do
not use this product if it has a damaged power cord or plug. To avoid
risk of electrical shock, do not attempt to repair or replace parts.
Only original replacement parts may be used. If the power cord
is damaged, it must be replaced by the manufacturer, its service
agent, or similarly qualied persons in order to avoid a hazard.
Contact Vornado Consumer Service at 1-800-234-0604 (phone) or
[email protected] (email) for further instructions about
replacement and repair.
- Risk of re. Your appliance may be equipped with a detachable
power supply or a cord/plug with a safety device such as a fuse. Use
only the power cord and plug provided.
- Before plugging power cord into electrical outlet, be sure that
all electrical information on the rating label, including voltage, is
compatible with your outlet’s power supply.
- Never use the cord as a handle or otherwise yank, strain or stretch
the power cord.
- While the product is plugged in, do not insert or allow foreign
objects to enter any input or output opening as this may cause risk
of electric shock or re, or damage the product.
- A loose t between wall outlet (receptacle) and plug may cause
overheating and distortion of the plug. Discontinue use of the
product in this outlet. Contact a qualied electrician to replace
loose or worn outlets.
- This appliance has a polarized plug (one blade is wider than the
other.) To reduce the risk of electrical shock, this plug is intended to
t in a polarized outlet only one way. If the plug does not t fully in
the outlet, reverse the plug. If it still does not t, contact a qualied
electrician. Do not attempt to defeat this safety feature.
- Before moving, repositioning, servicing, cleaning and when not in
use, use the product controls to turn off the power and then unplug.
To disconnect from outlet, grasp and pull only the plug. Also, power
off and unplug if the product will be left unattended for an extended
period of time or during electrical storms.
SERVICING WARNING—To reduce risk of re, electrical shock
and injury to persons, observe the following:
- Clean your product regularly, only as is instructed in this manual.
Prior to cleaning, turn off the power on your product and unplug. Do
not use gasoline, thinners, solvents, ammonias or other chemicals
for cleaning. Refer to the CLEANING instructions provided.
- Do not open appliance housing while product is plugged in. To
avoid risk of shock, all service and/or repairs must be done by a
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
This owner’s guide and any additional inserts are considered part of
the product. They contain important information about safety, use
and disposal. Before using the product, please familiarize yourself
with all operating and safety instructions. Please keep all documents
for future reference and pass these documents on, together with
the product, to any future owner. See www.vornado.com/circulators-
manuals to view, download and print the most current version of
these instructions.
INTENDED USE: This product is intended to circulate indoor and
outdoor air only in a window installation in the United States and
Canada. This product is not intended for commercial or industrial use.
The manufacturer assumes no responsibility for damage or injury due
to unauthorized use or product modication. Failure to follow these
directions will void the product warranty.
WARNING: Risk to Children and Impaired Persons
Supervision is required during the installation, operation, cleaning
and maintenance of this product by children 12 years of age and
younger and anyone with reduced physical, sensory or mental
capabilities. Children should be supervised to ensure that they do not
play with the appliance, its parts and packaging material.
WARNING: Chemical burn hazard. Keep batteries away from
children.
- WARNING: KEEP NEW AND USED BATTERIES AWAY
FROM CHILDREN. This product contains a lithium button/coin
cell battery. If a new or used lithium button/coin cell battery is
swallowed or enters the body, it can cause severe internal burns
and can lead to death in as little as 2 hours. Always completely
secure the battery compartment. If the battery compartment does
not close securely, stop using the product, remove the batteries,
and keep it away from children. If you think batteries might have
been swallowed or placed inside any part of the body, seek
immediate medical attention. In the US call the National Poison
Control Center at 1-800-222-1222 or 202-625-3333. In Canada call
416-813-5900.
INSTALLATION WARNING—To reduce risk of re, electrical
shock and injury to persons, observe the following:
- This product is intended for window installation only. Only use
with product controls facing indoors (not exposed to elements).
Do not use this product in a manner other than indicated by the
manufacturer in the window installation instructions below.
- Pull back and secure all curtains and draperies and place this product
away from tablecloths, blankets, and other fabrics, since they may
be drawn into the fan, damage the motor and/or cause a re.
- No part of this product (the appliance, power cord, plug,
packaging, etc.) should be placed near furnaces, replaces, stoves
or other high temperature heat sources. Do not use this product on
an uneven or unstable surface.
- The power cord and plug cannot come into contact with water.
Do not use this product on wet surfaces. Do not use this product

7
English6English
Vornado Authorized Service Center.
- This product employs overload protection (fuse). A blown fuse
indicates an overload or short-circuit situation. If the fuse blows,
unplug the product from the outlet. Replace the fuse as per the user
servicing instructions (follow product marking for proper fuse rating)
and check the product. If the replacement fuse blows, a short-circuit
may be present and the product should be discarded or returned to
an authorized service facility for examination and/or repair.
User Servicing Instructions
1. Using the product controls, turn off the appliance.
2. Grasp the plug (not the cord) and disconnect from the outlet.
3. Risk of Fire. Replace fuse only with 2.5 Amp, 125 Volt
fuse as approved by Vornado Consumer Service. For an
authorized replacement fuse, please contact Vornado
Consumer Service.
4. Once the replacement is received, use a small at-head
screwdriver to slide open the fuse cover (located on the
plug) (Fig. A).
5. Remove fuse by using the screwdriver to gently lift each
end of the fuse (Fig. B).
6. Install the replacement fuse by using the screwdriver to
gently push each metal end of the fuse into the receptacle
one at a time. Do not push on the center of the fuse—it is
fragile and may break.
7. Slide the fuse cover closed using the screwdriver. When
closed, the cover should t completely in the plug. No part
of the cover should stick out (Fig. C).
8. Plug your appliance into the outlet and turn the power on.
9. If the replacement fuse blows, a short-circuit may be
present and the product should be discarded or returned to
an authorized service facility for examination and/or repair.
Risk of re. Do not replace attachment plug. Contains a safety
device (fuse, AFCI, LCDI) that should not be removed. Discard
product if the attachment plug is damaged.
FCC Compliance Statement
NOTE: This equipment has been tested and complies with Part 15 of
the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This product
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this product does cause harmful interference
to radio or television reception, which can be determined by turning
the product off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the product and the receiver.
- Connect the product into an outlet on a circuit different from that to
which the receiver is connected.
- Contact Vornado Consumer Service or dealer or an experienced
radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Changes or modications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to
operate the product.
Supplier’s FCC Declaration of Conformity
Unique Identier: Vornado Model TRANSOM
Responsible Party: Vornado Air LLC
Mailing Address : 415 E. 13th St., Andover, KS 67002
Contact: www.vornado.com
WARNING: Batteries may pose a choking hazard. Do not let
children handle batteries.
BATTERY DISPOSAL: Please dispose of batteries according to the
local laws and regulations of your region, and while keeping them
away from children. Some batteries may be recycled and accepted
for disposal at your local recycling center. DO NOT DISPOSE OF
BATTERIES IN FIRE. BATTERIES MAY EXPLODE OR LEAK. New
and used batteries may cause injury. Keep new and used cells (or
batteries) away from children.
SAVE THESE INSTRUCTIONS
Fig. A Fig. B Fig. C

7
English6English
Vornado Authorized Service Center.
- This product employs overload protection (fuse). A blown fuse
indicates an overload or short-circuit situation. If the fuse blows,
unplug the product from the outlet. Replace the fuse as per the user
servicing instructions (follow product marking for proper fuse rating)
and check the product. If the replacement fuse blows, a short-circuit
may be present and the product should be discarded or returned to
an authorized service facility for examination and/or repair.
User Servicing Instructions
1. Using the product controls, turn off the appliance.
2. Grasp the plug (not the cord) and disconnect from the outlet.
3. Risk of Fire. Replace fuse only with 2.5 Amp, 125 Volt
fuse as approved by Vornado Consumer Service. For an
authorized replacement fuse, please contact Vornado
Consumer Service.
4. Once the replacement is received, use a small at-head
screwdriver to slide open the fuse cover (located on the
plug) (Fig. A).
5. Remove fuse by using the screwdriver to gently lift each
end of the fuse (Fig. B).
6. Install the replacement fuse by using the screwdriver to
gently push each metal end of the fuse into the receptacle
one at a time. Do not push on the center of the fuse—it is
fragile and may break.
7. Slide the fuse cover closed using the screwdriver. When
closed, the cover should t completely in the plug. No part
of the cover should stick out (Fig. C).
8. Plug your appliance into the outlet and turn the power on.
9. If the replacement fuse blows, a short-circuit may be
present and the product should be discarded or returned to
an authorized service facility for examination and/or repair.
Risk of re. Do not replace attachment plug. Contains a safety
device (fuse, AFCI, LCDI) that should not be removed. Discard
product if the attachment plug is damaged.
FCC Compliance Statement
NOTE: This equipment has been tested and complies with Part 15 of
the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This product
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this product does cause harmful interference
to radio or television reception, which can be determined by turning
the product off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the product and the receiver.
- Connect the product into an outlet on a circuit different from that to
which the receiver is connected.
- Contact Vornado Consumer Service or dealer or an experienced
radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Changes or modications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to
operate the product.
Supplier’s FCC Declaration of Conformity
Unique Identier: Vornado Model TRANSOM
Responsible Party: Vornado Air LLC
Mailing Address : 415 E. 13th St., Andover, KS 67002
Contact: www.vornado.com
WARNING: Batteries may pose a choking hazard. Do not let
children handle batteries.
BATTERY DISPOSAL: Please dispose of batteries according to the
local laws and regulations of your region, and while keeping them
away from children. Some batteries may be recycled and accepted
for disposal at your local recycling center. DO NOT DISPOSE OF
BATTERIES IN FIRE. BATTERIES MAY EXPLODE OR LEAK. New
and used batteries may cause injury. Keep new and used cells (or
batteries) away from children.
SAVE THESE INSTRUCTIONS
Fig. A Fig. B Fig. C

9
English8English
FEATURES GETTING STARTED
WINDOW INSTALLATION
1. We recommend keeping the window
screen in place.
2. Center the TRANSOM in the window,
ensuring that the foam on the bottom
of the product is snugly secured in the
bottom of the window casing.
3. Close the window to secure the product
in place.
4. Tuck the optional Soft-Fit foam blocks
on either side of the product, tucking
them securely into the window casing.
5. Optional: Route the powercord as needed, using the clips provided
to secure cord in place.
NOTE: the TRANSOM has been designed for use with single-hung and double-hung windows. It will accommodate windows 26 to 40 inches
wide and require a window opening of at least 8 inches tall.
FOR HORIZONTAL INSTALLATION ONLY. DO NOT ATTEMPT VERTICAL WINDOW INSTALLATION.
DURING PRODUCT AND FOAM BLOCK
INSTALLATION, KEEP ONE HAND ON
PRODUCT AT ALL TIMES.
INTEGRATED CARRY HANDLE
Easy to carry, easy to install.
ELECTRONIC REVERSIBLE FAN/EXHAUST
One button, quick transition from fan to
exhaust.
SOFT-FIT MODULAR FOAM BLOCK SYSTEM
Easy installation creating barrier against
outside noises & temperatures.
WEATHER RESISTANT ENCLOSURE
LOW PROFILE SILHOUETTE
Allows for greater visibility through window.
AUTO MODE WITH THERMOSTAT
Automatically adjusts air ow as needed
based on temperature.
4 SPEED TOUCH CONTROLS
A setting for every comfort level.
EXTRA LONG 8’ POWER CORD
Ample cord length.
AUTO-DIMMING DISPLAY
All non-essential lights are turned off, cutting
out light pollution PLUS saving on energy.
REMOTE CONTROL
Convenience at your nger tips.
ACCESSORIES
To order replacement foam blocks, please contact Vornado consumer service at [email protected] or 800-234-0604.

9
English8English
FEATURES GETTING STARTED
WINDOW INSTALLATION
1. We recommend keeping the window
screen in place.
2. Center the TRANSOM in the window,
ensuring that the foam on the bottom
of the product is snugly secured in the
bottom of the window casing.
3. Close the window to secure the product
in place.
4. Tuck the optional Soft-Fit foam blocks
on either side of the product, tucking
them securely into the window casing.
5. Optional: Route the powercord as needed, using the clips provided
to secure cord in place.
NOTE: the TRANSOM has been designed for use with single-hung and double-hung windows. It will accommodate windows 26 to 40 inches
wide and require a window opening of at least 8 inches tall.
FOR HORIZONTAL INSTALLATION ONLY. DO NOT ATTEMPT VERTICAL WINDOW INSTALLATION.
DURING PRODUCT AND FOAM BLOCK
INSTALLATION, KEEP ONE HAND ON
PRODUCT AT ALL TIMES.
INTEGRATED CARRY HANDLE
Easy to carry, easy to install.
ELECTRONIC REVERSIBLE FAN/EXHAUST
One button, quick transition from fan to
exhaust.
SOFT-FIT MODULAR FOAM BLOCK SYSTEM
Easy installation creating barrier against
outside noises & temperatures.
WEATHER RESISTANT ENCLOSURE
LOW PROFILE SILHOUETTE
Allows for greater visibility through window.
AUTO MODE WITH THERMOSTAT
Automatically adjusts air ow as needed
based on temperature.
4 SPEED TOUCH CONTROLS
A setting for every comfort level.
EXTRA LONG 8’ POWER CORD
Ample cord length.
AUTO-DIMMING DISPLAY
All non-essential lights are turned off, cutting
out light pollution PLUS saving on energy.
REMOTE CONTROL
Convenience at your nger tips.
ACCESSORIES
To order replacement foam blocks, please contact Vornado consumer service at [email protected] or 800-234-0604.

11
English10 English
1. Touch to power unit ON or OFF.
2. Select desired speed setting by pressing or . There are four
(4) speeds: 1- LOW, 2- MEDIUM, 3- HIGH & 4- TURBO. Speed is
indicated by number show on display.
3. Touch to change from direct airow to exhaust. Touch the
button again to change from exhaust to direct airow.
DIRECT MODE
EXHAUST MODE
Note: When rst plugged in and turned on, the unit will move to
DIRECT MODE. After that, the unit will remember user settings
when powered ON/OFF.
4. The product includes an integrated thermostat and the indoor
room temperature will be illuminated on the display only when the
thermostat is activated (in AUTO MODE). Touch to activate AUTO
MODE.
• Touch or button to set your ideal temperature, between
60 - 90° F, holding either button for 3 seconds will allow for quick
temperature adjustment.
• While in this adjustment mode, the temperature display will
momentarily ash and then return to display the current indoor
room temperature.
• Touch the to deactivate AUTO MODE. The icon will turn white
to indicate AUTO MODE is deactivated.
Note: Temperature display is Fahrenheit only.
Note: Your TRANSOM is equipped with auto-dimming controls. All
non-essential lights will turn off after a few seconds of inactivity. Only
the power button will remain illuminated. The rst touch to the control
panel or remote will wake up the unit, allow for setting adjustment and
will go dark again after a few seconds of inactivity.
HOW TO USECONTROLS
AUTO MODE
BUTTON
TEMPERATURE
DISPLAY
TEMPERATURE
ADJUSTMENT BUTTONS
DIRECT MODE
BUTTON
SPEED CONTROL
BUTTONS
SPEED
DISPLAY
POWER
BUTTON
AUTO DIRECT SPEED POWER

11
English10 English
1. Touch to power unit ON or OFF.
2. Select desired speed setting by pressing or . There are four
(4) speeds: 1- LOW, 2- MEDIUM, 3- HIGH & 4- TURBO. Speed is
indicated by number show on display.
3. Touch to change from direct airow to exhaust. Touch the
button again to change from exhaust to direct airow.
DIRECT MODE
EXHAUST MODE
Note: When rst plugged in and turned on, the unit will move to
DIRECT MODE. After that, the unit will remember user settings
when powered ON/OFF.
4. The product includes an integrated thermostat and the indoor
room temperature will be illuminated on the display only when the
thermostat is activated (in AUTO MODE). Touch to activate AUTO
MODE.
• Touch or button to set your ideal temperature, between
60 - 90° F, holding either button for 3 seconds will allow for quick
temperature adjustment.
• While in this adjustment mode, the temperature display will
momentarily ash and then return to display the current indoor
room temperature.
• Touch the to deactivate AUTO MODE. The icon will turn white
to indicate AUTO MODE is deactivated.
Note: Temperature display is Fahrenheit only.
Note: Your TRANSOM is equipped with auto-dimming controls. All
non-essential lights will turn off after a few seconds of inactivity. Only
the power button will remain illuminated. The rst touch to the control
panel or remote will wake up the unit, allow for setting adjustment and
will go dark again after a few seconds of inactivity.
HOW TO USECONTROLS
AUTO MODE
BUTTON
TEMPERATURE
DISPLAY
TEMPERATURE
ADJUSTMENT BUTTONS
DIRECT MODE
BUTTON
SPEED CONTROL
BUTTONS
SPEED
DISPLAY
POWER
BUTTON
AUTO DIRECT SPEED POWER

13
English12 English
1. Press to power unit ON or OFF.
2. Select desired speed setting by pressing or button.
3. Press to change from direct airow to exhaust. Press the
button again to change from exhaust to direct airow.
4. Press to activate AUTO MODE. The icon will turn green to
indicate AUTO MODE is activated.
• Press or button to set your ideal temperature, holding
either button for 3 seconds will allow for quick temperature
adjustment up or down by 5 degrees per second.
• While in this adjustment mode, the temperature display will
momentarily ash and then return to display the current indoor
room temperature.
• A single press of the button, when AUTO MODE is activated,
will change display from room temp back to SET TEMP ashing if
adjustments are needed.
• Press the button twice to deactivate AUTO MODE. The icon
will turn white to indicate AUTO MODE is deactivated.
Note: The remote requires a line-of-sight path to allow for the signal
to be received by the product. Position the product so the receiver
lens (located near near the control panel) is visible from the remote
control.
REMOTE CONTROL
REMOTE FUNCTIONS
REMOTE CONTROL
BATTERY REPLACEMENT Screwdriver required.
1. For battery replacement, the remote requires one coin style 3V CR2032 battery. Always use the correct size and grade of battery for this
product.
2. To replace battery, open battery door on the back side of the remote control (you will need to loosen the small screw on door using a #1 Phillips
screwdriver). If necessary, clean the battery contacts and also those of the device prior to battery installation. Remove any plastic protection
from the battery and place it in the remote with the + side facing out. Ensure the battery is installed correctly with regard to polarity. Replace
the battery door and screw.
Note: Remove battery from the remote control when not in use for an extended period of time and always remove dead battery immediately and
replace with fresh. Do not store dead battery in remote.
Your circulator remote includes (1) coin style 3V CR2032 battery. Battery comes pre-installed. Remove battery pull tab before rst use. The pre-
installed battery has a 1 year life expectancy (dependent on usage) after the tab has been pulled from the remote.
WARNING: This product contains a button battery. If swallowed,
it could cause severe injury or death in just 2 hours. Seek medical
attention immediately.

13
English12 English
1. Press to power unit ON or OFF.
2. Select desired speed setting by pressing or button.
3. Press to change from direct airow to exhaust. Press the
button again to change from exhaust to direct airow.
4. Press to activate AUTO MODE. The icon will turn green to
indicate AUTO MODE is activated.
• Press or button to set your ideal temperature, holding
either button for 3 seconds will allow for quick temperature
adjustment up or down by 5 degrees per second.
• While in this adjustment mode, the temperature display will
momentarily ash and then return to display the current indoor
room temperature.
• A single press of the button, when AUTO MODE is activated,
will change display from room temp back to SET TEMP ashing if
adjustments are needed.
• Press the button twice to deactivate AUTO MODE. The icon
will turn white to indicate AUTO MODE is deactivated.
Note: The remote requires a line-of-sight path to allow for the signal
to be received by the product. Position the product so the receiver
lens (located near near the control panel) is visible from the remote
control.
REMOTE CONTROL
REMOTE FUNCTIONS
REMOTE CONTROL
BATTERY REPLACEMENT Screwdriver required.
1. For battery replacement, the remote requires one coin style 3V CR2032 battery. Always use the correct size and grade of battery for this
product.
2. To replace battery, open battery door on the back side of the remote control (you will need to loosen the small screw on door using a #1 Phillips
screwdriver). If necessary, clean the battery contacts and also those of the device prior to battery installation. Remove any plastic protection
from the battery and place it in the remote with the + side facing out. Ensure the battery is installed correctly with regard to polarity. Replace
the battery door and screw.
Note: Remove battery from the remote control when not in use for an extended period of time and always remove dead battery immediately and
replace with fresh. Do not store dead battery in remote.
Your circulator remote includes (1) coin style 3V CR2032 battery. Battery comes pre-installed. Remove battery pull tab before rst use. The pre-
installed battery has a 1 year life expectancy (dependent on usage) after the tab has been pulled from the remote.
WARNING: This product contains a button battery. If swallowed,
it could cause severe injury or death in just 2 hours. Seek medical
attention immediately.

15
English14 English
CLEANING
Because your product moves a substantial amount of air, it will need
regular cleaning. If service is required, return your unit to Vornado
(see WARRANTY for instructions).
WARNING: To reduce the risk of electrical shock and injury to
persons, unplug the unit before cleaning.
REGULAR CLEANING
1. Unplug unit before cleaning.
2. Use the brush attachment on your household vacuum cleaner to
vacuum any accumulated dust off the unit.
3. Wipe down the entire unit with a soft cloth.
Note: Do not use gasoline, thinners, solvents or other chemicals for
cleaning. The motor is permanently lubricated and requires no oiling.
TROUBLESHOOTING
POSSIBLE CAUSE AND SOLUTIONPROBLEM
Unit is not plugged in. Plug Power Cord into electrical outlet.
Unit is damaged or in need of repair. Cease usage and unplug. Contact Consumer Service for assistance.
Fuse needs to be replaced. See IMPORTANT INSTRUCTIONS for how to replace the fuse or contact
Consumer Service.
Ensure unit is set to highest setting for maximum air circulation.
Allow the unit to fully circulate the air throughout the room, this may take several minutes.
Ensure all air inlets and outlet grille are unobstructed.
The battery is dead. Replace with new 3 volt CR2032 battery. Refer to REMOTE CONTROL - Battery
Replacement for instructions.
The remote requires a line-of-sight path to allow for the signal to be received by the unit. Position the unit
so the receiver lens (located just above the product controls) is visible from the remote control.
Switch the direction of the airow from DIRECT to EXHAUST (or EXHAUST to DIRECT). If problem
persists, turn unit OFF and ON and adjust settings as needed.
Preset temperature in AUTO might be set too high. Lower the set temperature or turn AUTO off.
Unit fails to
power on.
Unit is not producing
sufcient amount of air.
Remote Control is not
working.
Air is not moving in the
desired direction.
Unit is on but there is no air
moving.

15
English14 English
CLEANING
Because your product moves a substantial amount of air, it will need
regular cleaning. If service is required, return your unit to Vornado
(see WARRANTY for instructions).
WARNING: To reduce the risk of electrical shock and injury to
persons, unplug the unit before cleaning.
REGULAR CLEANING
1. Unplug unit before cleaning.
2. Use the brush attachment on your household vacuum cleaner to
vacuum any accumulated dust off the unit.
3. Wipe down the entire unit with a soft cloth.
Note: Do not use gasoline, thinners, solvents or other chemicals for
cleaning. The motor is permanently lubricated and requires no oiling.
TROUBLESHOOTING
POSSIBLE CAUSE AND SOLUTIONPROBLEM
Unit is not plugged in. Plug Power Cord into electrical outlet.
Unit is damaged or in need of repair. Cease usage and unplug. Contact Consumer Service for assistance.
Fuse needs to be replaced. See IMPORTANT INSTRUCTIONS for how to replace the fuse or contact
Consumer Service.
Ensure unit is set to highest setting for maximum air circulation.
Allow the unit to fully circulate the air throughout the room, this may take several minutes.
Ensure all air inlets and outlet grille are unobstructed.
The battery is dead. Replace with new 3 volt CR2032 battery. Refer to REMOTE CONTROL - Battery
Replacement for instructions.
The remote requires a line-of-sight path to allow for the signal to be received by the unit. Position the unit
so the receiver lens (located just above the product controls) is visible from the remote control.
Switch the direction of the airow from DIRECT to EXHAUST (or EXHAUST to DIRECT). If problem
persists, turn unit OFF and ON and adjust settings as needed.
Preset temperature in AUTO might be set too high. Lower the set temperature or turn AUTO off.
Unit fails to
power on.
Unit is not producing
sufcient amount of air.
Remote Control is not
working.
Air is not moving in the
desired direction.
Unit is on but there is no air
moving.
