Vortex VE1001-A User manual

Please carefully read this entire manual before using.
USER’S
MANUAL &
WARRANTY
CARD

INDEX
Safety Instruction
Warning & Caution 4
User’s Manual
- Contents 5
- Descriptions & Functions 6
- Assembly Instruction
7
- Operating Instruction 8
- Features and Benets
9 - 10
- Specications
11
Maintenance
12
FAQ 13
Warranty Card 14

Safety Instruction
Warning & Caution
Warning
Caution
WARNING : TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY :
- Use only the adaptor provided with this product.
- Completely insert the AC adaptor/power plug into the power outlet. Failure to do so
may cause electric shock and/or excessive heat resulting in a re.
- Do not use outdoors or near water
- Do not handle plug or appliance with wet hands
- Do not stare directly at the LEDs
- Do not place in direct contact with water and liquids
- Do not place near ammable and toxic products
- Do not attempt to open and/or disassemble
- Do not use solvents or cleaning solutions
- Clean only with a soft dry cloth
- Clean motor lter regularly
- Place on at and secure surface
- DO NOT USE AN EXTERNAL DIMMER WITH THIS LAMP. DOING SO MAY CAUSE
DAMAGE TO THE PRODUCT
- OVERHEATING MAY RESULT IN REDUCED LED LIFESPAN AND IRREPARABLE
DAMAGE. TO AVOID OVERHEATING :
- Keep out of direct sunlight
- Do not obstruct with items such as towels, clothing, curtains
- Remove plastic bags and protection lms from lamp before use
- Recommended ambient temperature : under 77 F

User’s Manual
Contents
LED Desk Lamp Adapter User’s Manual

User’s Manual
Descriptions & Functions
Adjustable Light Angle Joint
Flexible Pivot Angle
Motor Filter
Prevent dust
built up on motor
Adjust light angle : 115 degree
(up & down)
Pivot angle : 24 degee (front & back)
Base
Diameter : 8.27 in
Power Connection
Connect adapter
Control Button
3 steps of dimming light brightness and
2 steps of air purication blow speed.
Samsung SPI Air Purier
Eliminate dust mites, molds,
pet dander, bacteria, viruses
and even MRSA.
42 LEDs
* 50,000 hrs lifespan
* UV and icker free
* No mercury

User’s Manual
Assembly Instruction
1. Plug adapter transformer into power jack underneath the base
2. Make sure not to have the base sit on the cord
3. Plug adapter into the wall

User’s Manual
Operating Instruction
Power Button
On / O
1. Reading Mode (1200 LUX)
Stimulates concentration and reduces eye strain with the choise
of high-range color temperature.
2. Relaxing Mode (600 LUX)
Promotes relaxation along with improved mood with the choice
of mid-range color temperature.
3. Bedtime Mode (150 LUX)
Encourages a deep sleep comfortable with choice of low-range
temperature.
Three dimming levels
Reading Mode Relaxing Mode Bedtime Mode
Samsung SPI
Power On / O
SPI On Low Blow High Blow SPI O
Two blow speed levels
1. Low Blow Speed Level
2. High Blow Speed Level

User’s Manual
Features and Benefits
VORTEX LED Desk Lamp with Built-In Filterless Samsung SPI Air Purier illuminates
your reading, while purifying the air around you.
The energy and cost saving light has three dimming levels, and is perfect for
reading, relaxing and bedtime modes.
Also, the air purier eliminates dust mites, cat/dog allergens, viruses, bacteria,
molds and even MRSA with coverage up to 175 square feet.
* 42 bright-white LEDs (equivalent to a 75W incandescent)
* 12 Watt (saves $286.00 on utility bills over the life of the lamp
based on average of $.11/KwH)
* 50,000 hours lifespan
(lasts up to 28 years based on 5hours/day usage)
* 1200 Lux brightness
* Operates cooler than incandescent and uorescent desk lamps
* Multi-steps of dimming modes
* Does not emit UV radiation
* No ickering
* Environmentally friendly, does not contain toxic mercury
Lighting
- No lter
- Ozone and toxic free
- Very quiet device
- Covers up to 175 sq ft.
- Eliminates over 99% of air contaminants
(viruses, bacteria, molds and even MRSA)
- Eectiveness certied for dust mite and cat/dog allergen
Air Purication

Features and Benefits of Samsung SPI
User’s Manual
2010 AHR Expo Innovation Awards
Certications of Samsung SPI (Super Plasma Ion)
Certied Eectiveness of Samsung SPI (Super Plasma Ion)
Neutralizing OH-Radical
Inactive Biological Contaminants
Safe Technology to Human Body
Built-in lterless Samsung SPI air purier has demonstrated the elimination of the biological
contaminants with the collaboration of academic research organizations around the world.
How does SPI eliminate harmful air contaminants?
The SPI generates active hydrogen(H) and the oxygen ions(O2-) which forms hydroperoxy radical(HOO-).
Then, it surrounds the positively charged biological contaminants and reacts with three hydrogen
elements of its protein structure, forming water vapor. Also, the active hydrogen combines with
OH-radical to form a water vapor, neutralizing harmful OH-radical.
The process of eliminating the harmful substances is completely harmless to human body and
SPI improves the air quality.
Samsung’s Cutting
Edge Technology

Specifications
User’s Manual
Product Vortex LED Desk Lamp
Built-In Filterless Samsung SPI Air Purier
Model # VE1001-A
Power
Consumption 12 Watt
Power Input : AC 100 ~ 240V, 50/60Hz(Adaptor)
Output : DC 12V(Adaptor)
Light Output 1200 Lux
LED 42 LEDs
Dimension 18.5 x 8.7 x 8.7 (inch)
Patent Pending 30-2010-0046602
Manufacturer
Vortex Enterprise
10168 Artesia Place
Bellower CA 90706 U.S.A
www.vortexenterprise.com
Environmental
Friendly
Energy
Saving
World Recognized
Technology
Use only the adaptor
provided with this product

Motor Filter
Maintenance
Motor lter prevents contaminants including dust to protect motor
Open the motor
lter cover Rinse with water Place it back after complete dry
Recommend to clean at least twice a year

FAQ
FAQ
Q: Does Vortex LED Desk Lamp heat up a room?
A: No; does not noticeable increase room temperature.
Q: How does Filterless Samsung SPI Air Purier works?
A: Refer to page 10
Q: Are there any side eects from Samsung SPI Air Purier?
A: No, it is tested and certied to be safe with ozone free and toxic free.
Q: What is Samsung SPI Air Purier air cleaning capacity?
A: Its coverage is up to 175 sq. ft.
Q: Will Samsung SPI Air Purier operate alone with LED Desk Lamp o?
A: Yes; it can be operated separately.
Q: What if Samsung SPI Air Purier is not blowing out?
A: Clean the motor lter
Q: Can I use 24 hours constantly?
A: Yes; however, recommend to power o often.
Q: I have other questions.
A: Please contact at 562-206-2505 or email [e-mail]

1 Year Warranty Card
Warranty Card
NEITHER THIS WARRANTY NOR ANY WARRANTY, EXPRESSED OR IMPLIED INCLUDING IMPLIED
WARRANTIES OR MERCHANTABILITY, SHALL EXTEND BEYOND THE WARRANTY PERIOD.
NO RESPONSIBILITY IS ASSUMED FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES,
INCLUDING WITHOUT LIMITATION DAMAGES, SOME STATES DO NOT ALLOW LIMITATION ON
HOW LONG AN IMPLIED WARRANTY LASTS; SOME STATES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU.
VORTEX ENTERPRISE PRODUCTS HEREBY SPECIFICALLY DISCLAIMS ALL EXPRESSED
WARRANTIES NOT OTHERWISE SET FORTH HEREIN AND ANY IMPLIED WARRANTIES OR
MERCHANTABILITY OR IMPLIED WARRANTIES FOR FITNESS FOR A PARTICULAR PURPOSE.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION OF THE FACE HEREOF.
This warranty gives you specic legal rights; you may have other rights, which vary from state to state,
and country to country.
In order to obtain full warranty terms and conditions as stated below, please
ll in and return Warranty Card to Vortex Enterprise. You may also register at
www.vortexenterprise.com
Product
Serial #
Store Name
Address
Model
Date of
Purchase
Customer
Name
Phone #
Vortex LED Desk Lamp VE1001-A
This product is warranted by Vortex Enterprise, to the original purchaser to be free from defects in material
and workmanship under proper use for a period of one year from date of purchase. During this period, and
upon proof of purchase and date of purchase, this product will be repaired or replaced with same or similar
model without charges for parts or labor. To be eligible for the warranty, please register at
www.vortexenterprise.com or complete the warranty card at the time of purchase and mail it Vortex
Enterprise. To obtain warranty service, please send the product sales receipt or proof of purchase.
This warranty does not apply to a product that has been misused, abused, or altered without limiting the
afore-mentioned, bending or dropping the unit, defects in the electrical installation or uctuating power
levels are presumed to be defects resulting from misuse or abuse.
Vortex Enterprise products and its aliates or wholesalers do not make any specic claim as to medicinal
uses of this product nor does the manufacturer warrant that the equipment prevents some kind of diseases.
Vortex Enterprise
Bellower CA
www.vortexenterprise.com
[e-mail]
T. 562-206-2505
F. 562-206-2506

Any contents in this manual may change without prior notice.
