Voweek VW-VC07 User manual
INSTRUCTION MANUAL
VACUUM CLEANER
For any questions and
malfunctions of the appliance
during use, please contact our
customer service email:
Model: VW-VC07
WHAT'S IN THE BOX
OVERVIEW
ASSEMBLY
OPERATING INSTRUCTIONS
SPECIFICATION
CLEANING AND MAINTENANCE
CLEAR A CLOG
IMPORTANT SAFETY INSTRUCTIONS
TROUBLESHOOTING
WARRANTY
01
02
03
04
04
05
07
11
12
13
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
1. To protect against electrical
shock, do not immerse power
cord or plug in water or any other
liquid. To avoid the risk of
electrical shock or serious
personal injury, always operate
with dry hands.
2. Close supervision is necessary
when any appliance is being used
by or near children. This vacuum
is not intended for use by persons
(including children) with reduced
physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or
instruction concerning the use of
the vacuum by a person
responsible for their safety.
3. Do not use the vacuum outdoors.
It is for household use only.
4. Do not use the vacuum if it has
been dropped, damaged, left
outdoors, or dropped in water.
Please contact customer service
for help when the appliance or the
adapter is damaged.
5. Use the vacuumonly as described
in this manual. The use of
accessory attachments not
recommended may cause damage
to the vacuumorpersonalinjuries.
6. Do not use abrasive materials to
clean the vacuum. Do not use
spirits or other solvents to clean
the appliance.
7. Do not use the appliance to
vacuum all the below things:
● Water, flammable or combustible
liquids such as gasoline;
● Lighted stub, matches, hot ashes
and other combustible things;
● Needles, pins and other sharp
things;
● Wood pieces, gesso, cement,
calcimine and other tiny granules;
● Pieces of string or fabrics.
8. Do not pick up liquids with the
vacuum or use on wet floors. Do
not immerse the vacuum in water.
9. Do not use the vacuum on
concrete, tar, or similar rough
surfaces.
10. Do not vacuum frayed carpets
or tassels on carpets.
11. Do not use the vacuum without
the dust cup in place.
12. Do not put any object into
openings of the vacuum. Do not
use when any opening is
blocked. Keep free of dust, lint,
hair and anything that may
reduce air flow.
13. Keep hair, loose clothing,
fingers, and all parts of body
away from openings and moving
parts.
14. Store the vacuum indoors. Store
after use to prevent accidents.
15. Keep the vacuum cleaner away
from stoves and heat-emitting
appliance. Heat can deform and
discolor the plastic parts of unit.
Please use the vacuum in 0 to
40 degrees temperature
environment.
16. Always remove the adapter from
the power socket when the
appliance is not in charging.
17. Unplug charging cord from the
appliance and power it off before
cleaning or performing
maintenance, making tool
adjustments, changing
accessories or storing to avoid
powering it accidentally.
18. The battery must be removed
from the appliance before it is
scrapped.
19. The battery has to be disposed
of safely.
20. The appliance includes Li-ion
batteries, do not incinerate the
batteries or expose to high
temperatures, as they may
explode.
21. The thermal cutout will switch
off the vacuum automatically
when it overheats. If this should
happen, turn off the power
switch, wait for 45 minutes to
restart the vacuum.
22. Only the adapter provided by
the manufacturer can be used.
-01-
Please keep the adapter
away fromliquids.
Do not vacuum large
piece of paper.
Do not vacuum fire or
flammable substances.
Do not vacuum water
or liquids.
Do not remove plug
by grasping the cord.
IMPORTANT SAFETY INSTRUCTIONS
When using an electric appliances, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS
BEFORE USING (THIS APPLIANCE)
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, DAMAGE OR INJURY:
-02-
CAUTION: Assemble the vacuumaccordingtochapter "Assembly".
WHAT'S IN THE BOX
Cleaning brush
Vacuum main body
2-in-1 brush
Extension tube
Wall hanger
Adapter
Floor brush
Screws and wall anchors
HEPA filter
OVERVIEW
-03-
Battery pack release
button
Power switch
Battery indicator
Air outlet
Release button
Release button
Floor brush
Extension tube
Vacuum main body
Battery pack
Filter case
Wall hanger
Dust cup lid lock
button
Dust cup
ASSEMBLY
-04-
SPECIFICATION
Name
Model
Adapter Input Voltage
Adapter Output Voltage
VACUUM CLEANER
VW-VC07
100~240 V 50/60 Hz
26 V
CAUTION:
It is important to fully chargeyour machine before using for the first timeand after every use.
Charge the battery pack alone
OPERATING INSTRUCTIONS
Charge with the vacuum main body
Charging Instruction
-05-
1Press the release button at the side of the
battery pack.
3Plug the adapter into wall outlet and charging head into the battery pack for charging the it.
2Hold the button and pull it out to detach.
Plug the adapter into wall outlet and charging head into the vacuum for charging. The battery indicator
will be in a cycle of illuminating while the vacuum gets charged. When the vacuum is fully charged, all
battery indicators will be solid on.When the vacuum is fully charged, all battery indicators will be solid
on.
The flashingindicator light shows the battery power is low. Please charge the vacuumwhen
the last light flashes.
-06-
2-in-1 Brush Instruction
Press the conversion button to pull the bristle back to
use as a crevice tool.
Holdandpush out the bristle rectangle to use as a
brush.
Wall Hanger Instruction
Use the screws andwallanchors to fix the wallhanger at the certainheight to mount the vacuum with tube attached.
After fixing the wallhanger, store the vacuum on it when not in use.
Dust Cup and HEPA Filter Cleaning
-07-
CLEANING AND MAINTENANCE
2
3
CAUTION:
Always be sure that the vacuum is switched to OFF before attempting to empty the dust cup.
Remove the extension tube from the main body before maintaining and cleaning dust cup and HEPA filter.
Open the dust cup lid to dump dust. Holdand turn the filter case clockwise to detach it.
4
1Empty the dust cup when dust inside is paralleled with the lower rim of filter case. Otherwise, the suction
may be weakened.
-08-
≥140°F
Pull up the HEPA filter out of the mesh shell. Brush the HEPA filter with cleaning brush
before rinsing it.
5 6
Rinse both the HEPA filter and the mesh shell
under tap water.
Air dry them for at least 24 hours. Do not
assemble it back until completely dry.
7 8
before rinsing it.
9
wet dry
CAUTION:
Filter is suggested to be washed (air dry
before installing back) every 2 weeks, to be
replaced every 2 months, otherwise, it will
result in insufficient filter system and loss of
suction.
Assemble the mesh shelland the HEPA filter back in
place. Do not assemble them until completely dry.
Floor Brush Cleaning
-09-
CAUTION:
1
4
Press the release button and hold to pull out to detach the tube from floor brush.
3Grab the roller brush head and remove it out
from the floor brush.
Use cleaning brush to remove hair and strings
entangled on the roller brush.
When the floorbrush stopsspinningsuddenlyandall the floor
brush block indicators get flashing, theremaybeclogs on the
rollerbrush. Please checkandclearclogs on the rollerbrush.
2Push the release switch toward the " " icon at the side of the floor brush to detach the buckle.
-10-
click
5 6
7 8
Check the roller brush and make sure the
round side of it attach onto the plastic axle
first when assembling it back.
On the otherside of the rollerbrush, please
make sure the arc-shapedpart of it is downward
when assemblingitback.
Insert the buckle back to place as the picture
shown.
A "click" will be heard if the buckle is inserted
in place.
-11-
CLEAR A CLOG
Low suction or vacuum stopped caused by overheat may be due to a clog in the vacuum. Please
check and clear clogs in the dust cup, HEPA filter, extension tube and floor brush.
CAUTION:
Check the floor brush and clear the clog on the
roller brush with the blade.
Check and empty the dust cup.
Check if there are any clogs inside the extension
tube.
Check and rinse the HEPA filter. Do not assemble
them until completely dry.
-12-
TROUBLESHOOTING
The vacuum
can not be
charged
The vacuum
can not be
powered on
The vacuum
stops
working
suddenly
The cleaning
results are
not good
There is static
during vacuum
working
The electric
floor brush
stops working
Please charge the vacuum with the original adapter
Please contact the customer service for help
Please charge the vacuum with the original adapter
Remove and attach back the battery pack and make sure it
is attached in place
Please contact the customer service for help
Please contact the customer service for help
Clean foreign objects entangled on the floor brush
Please contact the customer service for help
1. It is recommended to use high suction mode for cleaning
complicated environments
2. It is recommended to use the crevice tool for better
pickup for vacuuming heavy objects such as beans
3. It is recommended to use the floor brush for cleaning
stain
It'snormal that theremaybemuch static in the airinwinter
anddryregions
Clean foreign objects entangled on the floor brush
Clean the floorbrush, extension tube, dust cupand the HEPA
filter regularly
The used adapter is not the
original one
The battery pack/adapter
malfunctions
The battery pack is not
attached correctly
Other malfunctions
Other malfunctions
The battery runs out
The floor brush gets stuck
The battery runs out
1. The air duct is blocked
2. The dust cup is full
Clean the floorbrush, extension tube, dust cupand the HEPA
filter regularly
1. The air duct is blocked
2. The dust cup is full
There is too muchdust inside
the dust cup
The vacuumruns at an
environment full of static
The floor brush gets stuck
Other malfunctions
Please empty the dust cup
Use the originaladapter for charging. It is recommended to
charge the vacuum after each timeuseanduse the low
suctionmode for longruntime
Incorrect use of the vacuum
The HEPA filter is not dried
completely
Please charge the vacuum fully and try to turn it on againThe battery runs out
PROBLEM POSSIBLE REASONS SOLUTIONS
Detach andair dry the HEPA filter completely. It is recommended
to cleanandreplace it regularly
WARRANTY
1. According to the requirements outlined in thisinstructionmanual, the warranty is subject to the following
conditions and exclusions.
2. This warranty provides, at no extra cost to you all labor and parts necessary to ensure your machine
is in proper operating condition during the warranty period.
3. We provide the repair or replacement of your Voweekapplianceifyour Voweekappliance is found
to be defective due to faulty materials, workmanship function within 1 year of purchase or delivery. ( If
any part is no longer available or out of manufacture, we will replace it with a functional replacement
part).
1. Under your Voweek guarantee, Voweek shall not be liable for costs of repair or replacement of a
product incurred as a result of: Accidental damage, faults caused by negligent use or care, misuse,
neglect, careless operation or handling of the Voweek appliance which is not in accordance with
this Voweek Instruction Manual.
2. Machines purchased from an unauthorized dealer.
3. Use of parts and accessories other than those produced or recommended by Voweek.
4. Repairs or alterations carried out by unauthorized parties or agents.
5. Use of the machine other than for normal domestic purpose, e.g. for commercial or rental purposes.
6. Reduction in battery run time due to battery age or use.
The 1-year Limited Warranty is valid for products purchased from our Voweek only, starting from the
date of the original retail purchased. We will provide customer service for any defects in quality or
materials under normal, non-commercial use.
-13-
CUSTOMER CARE
WHAT IS NOT COVERED
1. If you have a query about your Voweek appliance, please contact the Voweek customer service
email:
2. Please inform us your model name/number, purchase date, order number, machine problem and your
requirement.
3. Your model number can be found on rating plate.
4. Please keep your purchase receipt in a safe place to ensure you have this information.
Service under this warranty will not extend the available time of warranty.
WARRANTY SERVICE
Manufacturer:Shenzhen Yibai Net w ork Technology Co., Lt d
Address: Blgd1-101,TOD Tech Center, Lipu Rd 7,
DafapuCommunity, Bantian St.Longgang Dist.,
Shenzhen, China
Email: [email protected]
This device complies with Part 15 of the FCC Rules:
Operation is subject to the following two conditions:
1)This device may not caus harmful intererence, and
2)This device must accept any interferencereceived,including interference that may causeundesiredoperation
Table of contents
