VOX electronics VF 3710 User manual

GBR
MAK
SVN
SRB
BOS
VF 3710
OPERATING INSTRUCTIONS FREEZER
UPUTSTVO ZA UPOTREBU FRIŽIDER
UPUTE ZA UPORABU ZAMRZIVAČ
NAVODILA ZA UPORABO ZAMRZOVALNA OMARA
УПАTСТВА ЗА РАКУВАЊЕ ЛАДИЛНИК
MANUAL DO USUÁRIO ZAMRZIVAČ
HRV

EN - 2 -
Index
BEFORE USING YOUR FREEZER.....................................................3
General warnings ........................................................................................3
Old and out-of-order fridges or freezer........................................................6
Safety warnings...........................................................................................6
Installing and operating your freezer ...........................................................7
Before using your freezer ............................................................................8
Information on No-Frost Technology ...........................................................8
USAGE INFORMATION.......................................................................9
Display and control panel ............................................................................9
Operating your freezer ................................................................................9
Temperature adjustment and activating ..............................................................9
The initial temperature value for Freezer Indicator is -18°C.................................9
Super freeze mode..............................................................................................10
Economy mode ...................................................................................................10
Screen saver mode .............................................................................................10
Function of child lock...........................................................................................11
Warnings about temperature adjustments.................................................. 11
Accessories ................................................................................................12
Making Ice Cubes................................................................................................12
Ice tray.................................................................................................................12
PLACING THE FOOD.........................................................................12
CLEANING AND MAINTENANCE .....................................................16
Defrosting ...................................................................................................16
Replacing LED lighting ...............................................................................16
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION
17
Repositioning the door ...............................................................................17
BEFORE CALLING SERVICE............................................................17
Tips for saving energy ................................................................................19
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ....20
EN FIRE Warning; Risk of re / ammable materials

EN - 3 -
BEFORE USING YOUR FREEZER
General warnings
WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
WARNING: In order to avoid any hazards resulting from the
instability of the appliance, it must be xed in accordance with
the following instructions:
If your appliance uses R600a as a refrigerant (this information
will be provided on the label of the cooler) you should take care
during transportation and installation to prevent the cooler
elements from being damaged. R600a is an environmentally
friendly and natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your fridge away
from open ames or heat sources and ventilate the room where
the appliance is located for a few minutes.
• While carrying and positioning the fridge, do not damage the
cooler gas circuit.
• Do not store explosive substances such as aerosol cans with
a ammable propellant in this appliance.

EN - 4 -
• This appliance is intended to be used in household and
domestic applications such as:
- staff kitchen areas in shops, ofces and other working
environments.
- farm houses and by clients in hotels, motels and other
residential type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug, it must be
replaced by the manufacturer, a service agent or similarly
qualied persons in order to avoid a hazard.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with
a specially grounded socket of 16 amperes. If there is no
such socket in your house, please have one installed by an
authorised electrician.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.
• Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances. Children are not expected
to perform cleaning or user maintenance of the appliance,
very young children (0-3 years old) are not expected to use
appliances, young children (3-8 years old) are not expected
to use appliances safely unless continuous supervision
is given, older children (8-14 years old) and vulnerable
people can use appliances safely after they have been
given appropriate supervision or instruction concerning use

EN - 5 -
of the appliance. Very vulnerable people are not expected
to use appliances safely unless continuous supervision is
given.
• If the supply cord is damaged, it must be replaced by the
manufacturer, an authorised service agent or similar qualied
persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding
2000 m.
To avoid contamination of food, please respect the
following instructions:
• Opening the door for long periods can cause a signicant
increase of the temperature in the compartments of the
appliance.
• Clean regularly surfaces that can come in contact with food
and accessible drainage systems.
• Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto other
food.
• Two-star frozen-food compartments are suitable for storing
pre-frozen food, storing or making ice cream and making ice
cubes.
• One-, two- and three-star compartments are not suitable for
the freezing of fresh food.
• If the refrigerating appliance is left empty for long periods,
switch off, defrost, clean, dry, and leave the door open to
prevent mould developing within the appliance.

EN - 6 -
Old and out-of-order fridges or freezer
• If your old fridge has a lock, break or remove the lock before discarding it,
because children may get trapped inside it and may cause an accident.
• Old fridges and freezers may contain isolation material and refrigerant
with CFC or HFC. Therefore, take care not to harm environment when
you are discarding your old fridges.
Please ask your municipal authority about the disposal of the WEEE
reuse, recycle and recovery purposes.
Notes:
• •Please read the instruction manual carefully before installing and using your appliance.
We are not responsible for the damage occurred due to misuse.
• •Follow all instructions on your appliance and instruction manual, and keep this manual
in a safe place to resolve the problems that may occur in the future.
• •This appliance is produced to be used in homes and it can only be used in domestic
environments and for the specied purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the appliance to be cancelled and
our company will not be responsible for losses incurred.
• •This appliance is produced to be used in houses and it is only suitable for cooling
/ storing food. It is not suitable for commercial or common use and/or for storing
substances except for food. Our company is not responsible for losses to be incurred in
the contrary case.
Safety warnings
• Do not connect your to the mains electricity supply using an extension
lead.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
•
• This appliance is designed for use by adults, do not allow children to play
with the appliance or let them hang off the door.
• Never touch the power cord/plug with wet hands as this could cause a
short circuit or electric shock.
• Do not place glass bottles or beverage cans in the ice-making
compartment as they can burst as the contents freeze.
• Do not place explosive or ammable material in your freezer. Place drinks with high
alcohol content vertically in the freezer and make sure that their tops are tightly closed.
• When removing ice from the ice-making compartment, do not touch it. Ice may cause
frost burns and/or cuts.

EN - 7 -
• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice
cubes immediately after you have taken them out of the ice-making
compartment.
• Do not re-freeze frozen goods after they have melted. This may cause
health issues such as food poisoning.
• Do not cover the body or top of freezer with lace. This affects the performance
of your freezer.
• Secure any accessories in the freezer during transportation to prevent
damage to the accessories.
• When the door of the freezer is closed, a vacuum seal will form. Wait for about 1 minute
before reopening it.
• This application is optional for easy opening of the
door. With this application, a little condensation may
occur around this area and you may remove it.
Installing and operating your freezer
Before starting to use your freezer, you should pay attention to the following points:
• The operating voltage for your freezer is 220-240 V at 50Hz.
• We do not accept responsibility for any damages that occur due to ungrounded usage.
• Place your freezer where it will not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, gas ovens and heater cores,
and at least 5 cm away from electrical ovens.
• Your freezer should never be used outdoors or exposed to rain.
• When your freezer is placed next to a deep freezer, there should be at least
2 cm between them to prevent humidity forming on the outer surface.
• Do not place heavy items on the appliance.
• Do not place anything on your freezer, and install your freezer in a suitable
place so that at least 15 cm of free space is available above it.
• Use the adjustable front legs to make sure your appliance is level and stable. You can
adjust the legs by turning them in either direction. This should be done before placing
food in the freezer.
• Before using your freezer, wipe all parts with a solution of warm water and
a teaspoon of sodium bicarbonate, then rinse with clean water and dry.
Place all parts in the freezer after cleaning.
• Install the plastic distance guide (the part with black vanes at the rear)
by turning it 90° (as shown in the gure) to prevent the condenser from
touching the wall.
• The freezer should be placed against a wall with a free space not
exceeding 75 mm.

EN - 8 -
Before using your freezer
• When using your freezer for the rst time, or after transportation, keep it
in an upright position for at least 3 hours before plugging into the mains.
This allows efcient operation and prevents damage to the compressor.
• Your freezer may have a smell when it is operated for the rst time. This
is normal and the smell will fade away when your freezer starts to cool.
Information on No-Frost Technology
No-frost freezers differ from other static freezers in their operating
principle.
In normal freezers, the humidity entering the freezer due to opening the
door and the humidity inherent in the food causes freezing in the freezer
compartment. To defrost the frost and ice in the freezer compartment, you
are periodically required to turn off the freezer, place the food that needs
to be kept frozen in a separately cooled container and remove the ice
gathered in the freezer compartment.
The situation is completely different in no-frost freezers. Dry and cold air
is blown into the freezer compartment homogeneously and evenly from
several points via a blower fan. Cold air dispersed homogeneously and
evenly between the shelves cools all of your food equally and uniformly,
thus preventing humidity and freezing.
Therefore your no-frost freezer allows you ease of use, in addition to its
huge capacity and stylish appearance.

EN - 9 -
Display and control panel
USAGE INFORMATION
c
DEMO
1
2
34
56
7
8
1.Enables the setting of freezer to be
modied and super freeze mode to be
activated, if desired. The Freezer maybe
set to -16, -17, -18, -19, -20, -21, -22, -23,
-24 °C.
2.Enables the modes (economy, SF…) to
be activated if desired.
3.Freezer set value screen.
4.Super freezing indicator.
5.Super freeze mode symbol.
6.Child-lock symbol.
7.Economy mode symbol.
8.Alarm symbol.
Recommended Temperature Values for Freezer
When would it be adjusted? Inner Temperature
For minimum freezing capacity -16oC, -17oC
In normal usage -18oC, -19oC, -20oC, -21oC
For maximum freezing capacity. -22oC, -23oC, -24oC
Operating your freezer
Temperature adjustment and activating
The initial temperature value for Freezer Indicator is -18°C.
• Press the mode button once.
• When you press this button, the set value for freezer indicator
starts to ash.
• The value for freezer changes to a lower temperature when you
press this button with the indicator is ashing.
(-16°C, -17°C, -18°C, -19°C, -20°C, -21°C, -22°C, -23°C, -24°C).
• If you wait for 1 second without pressing any buttons after reaching the desired set
value, the set value is activated and your freezer operates at that value.
• If you continue to press the button after reaching -24°C , the temperature will restart
from -16°C.
c

EN - 10 -
Super freeze mode
How would it be used?
• Press the Freezer Set Button until SF is shown on the screen.
The buzzer will sound twice and the mode will be set.
• The Freezer temperature segment will show "SF".
While SF mode is selected
• The temperature of the Freezer and Super Freeze mode may be
adjusted. In this case, Super Freeze Mode continues.
• Economy and Holiday mode cannot be selected.
• Super Freeze mode can be cancelled in the same way that it was selected.
Economy mode
How would it be used?
• Push the “Mode button” until a circle appears around economy
symbol.
• If no button is pressed for 1 second, the mode will be set. The
circle will blink 3 times and the buzzer will sound twice.
• The freezer temperature segment will show "E".
• The circle of the Economy symbol and E will illuminate until the
mode nishes.
During this mode:
• The freezer may be adjusted. When Economy mode is cancelled, the selected setting
values will remain.
• Super freeze mode can be selected. Economy mode is automatically cancelled and the
selected mode is activated.
• To cancel, press on mode button.
Screen saver mode
How to use?
• This mode will be activated when you press the mode button for
5 seconds.
• If no button is pressed within 5 seconds when the mode is active,
the lights of the control panel will go out.
• If you press any button when the lights of control panel are off,
the current settings will appear on the screen, and then you can
maket the adjustment you want. If you do not cancel the screen
saver mode or press any button within 5 seconds, the control
panel will go off again.
• To cancel screen saver mode, press the mode button for 5 seconds again.
• When screen saver mode is active, you can also activate child lock.
• If you do not press any button for 5 seconds after activating child lock, the lights of the
control panel will go off. Then, you can view the previous settings and that child lock is
active by pressing any button.You can cancel child lock as described in the instructions
for that mode.
c

EN - 11 -
Function of child lock
When would it be used?
Child lock is available on the appliance to prevent children from
playing with the buttons and changing the settings you have
made.
Activating child lock
Press the SET button for 5 seconds.
Deactivating child lock
Press the SET button for 5 seconds.
Note: Child lock will also be deactivated if electricity is interrupted or the freezer is unplugged.
c
Warnings about temperature adjustments
• It is not recommended that you operate your fridge in environments colder than 10°C in
terms of its efciency.
• Temperature adjustments should be made according to the frequency of door openings
and the quantity of food kept inside the fridge.
• Do not pass to another adjustment before completing an adjustment.
• Your fridge should be operated up to 24 hours according to the ambient temperature
without interruption after being plugged in to be completely cooled. Do not open doors
of your fridge frequently and do not place much food inside it in this period.
• A 5 minute delaying function is applied to prevent damage to the compressor of your
fridge, when you take the plug off and then plug it on again to operate it or when an
energy breakdown occurs. Your fridge will start to operate normally after 5 minutes.
• Your fridge is designed to operate in the ambient temperature intervals stated in the
standards, according to the climate class stated in the information label. We do not
recommend operating your fridge out of stated temperatures value limits in terms of
cooling effectiveness.
• This appliance is designed for use
at an ambient temperature within the
10°C - 43°C range.
Climate Class Ambient Temperature (°C)
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
T/SN Between 10 and 43 (°C)
Important installation instructions
This appliance is designed to work in difcult climate conditions (up to 43 degrees C or 110
degrees F) and is powered with ‘Freezer Shield’ technology which ensures that the frozen
food in the freezer will not defrost even if the ambient temperature falls as low as -15 °C.
So you may then install your appliance in an unheated room without having to worry about
frozen food in the freezer being spoilt. When the ambient temperature returns to normal, you
may continue using the appliance as usual.

EN - 12 -
PLACING THE FOOD
• The freezer compartment is used for freezing fresh food, for storing frozen foods for the
period of time indicated on packaging and for making ice cubes..
• Do not put fresh and warm food next to frozen food as it can thaw the frozen food.
• While freezing fresh foods (i.e. meat, sh and mincemeat) divide them in portions you
will use in a single serving.
• For storing frozen foods, the instructions shown on frozen food packages should always
be followed carefully. If no information is provided, food should not be stored for more
than 3 months from the purchased date.
• Maximum load: if you want to store large quantities of food and use the maximum net
capacity of the freezer, you can remove all the sliding drawers but you should keep
the upper shelf aps. Thanks to this, it is possible to store bulky items directly on the
shelves.
• When buying frozen food ensure that these have been frozen at suitable temperatures
and that the packing is intact.
Accessories
Making Ice Cubes
• Pull the lever towards you and remove the ice maker
tray
• Fill with water to the level of line
• Hold the left end of the lever and set the ice-tray on
the icebox
• When ice cubes are formed, twist the lever to drop ice
cubes into the ice box.
Do not ll the icebox with water in order to make ice.
It can break.
(In some models)
Ice tray
• Fill the ice tray with water and place in freezer compartment.
• After the water completely turned into ice, you can twist the tray as shown below to get
the ice cube.
(In some models)
Visual and text descriptions in the accessories section may vary according
to the model of your appliance.

EN - 13 -
Dairy Products Preparation Maximum Storing
time (months) Storing Conditions
Packet
(Homogenize) Milk In its own packet 2 - 3 Pure Milk – In its own packet
Cheese-excluding
white cheese In slices 6 - 8
Original package may
be used for short storing
period. It should be
wrapped in foil for longer
periods.
Butter, margarine In its package 6
A+ models
If there is a power cut or malfunction, do not open the door. This will help maintain the
temperature inside the freezer, ensuring that foods are conserved for about 15 hours at
25°C. Do not re-freeze food that is defrosting or that has already been defrosted. These
foods must be cooked and eaten.
• Frozen food should be transported in appropriate containers to maintain the quality of
the food and should be returned to the freezing surfaces of the unit in the shortest
possible time.
• If a package of frozen food shows signs of humidity and abnormal swelling it is probable
that it has been previously stored at an unsuitable temperature and that the contents
have deteriorated..
• The storage life of frozen foods depends on the room temperature, thermostat setting,
how often the door is opened, the type of food and the length of time required to transport
the product from the shop to your home. Always follow the instructions printed on the
packaging and never exceed the maximum storage life indicated.
If you would use maximum freezing capacity of your freezer:
• While freezing fresh foods, the maximum amount of fresh food (in kg) that can be
frozen in 24 hours is indicated on the appliance label. (your refrigerator has the
capacity to freeze 25 kg at 25°C ambient)
• For optimum appliance performance to reach maximum freezing capacity, activate
Super Freeze (SF) mode 24 hours before placing fresh food into the freezer.
• After placing fresh food into the freezer, 24 hours is generally sufcient for freezing.
”Super Freeze” mode will be deactivated automatically in 2-3 days to save energy.
If you would freeze a small amount (up to 3 kg) in your freezer:
• Place your food without touching already frozen food and activate “Fast Freezing” mode. You
can put your food next to other frozen food after it is completely frozen (after minimum 24 hours).
• Do not re-freeze frozen food after it has thawed. This may cause health issues, such as food
poisoning.
• Allow hot food to completely cool down before placing it in the freezer.
• When buying frozen food ensure that these have been frozen at suitable temperatures and that
the packing is intact.

EN - 14 -
Meatandsh Preparation
Maximum
Storing time
(month)
Steak Wrapping in a foil 6 - 8
Lamb meat Wrapping in a foil 6 - 8
Veal roast Wrapping in a foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packages without using spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/salami Should be packaged even if it has
membrane
Chicken and turkey Wrapping in a foil 4 - 6
Goose and Duck Wrapping in a foil 4 - 6
Deer, Rabbit, Wild Boar In 2.5 kg portions and as llets 6 - 8
Fresshwatershes(Salmon,
Carp, Crane, Siluroidea) After cleaning the bowels and
scales of the sh, wash and dry
it; and if necessary, cut off the tail
and head.
2
Leansh;bass,turbot,
ounder 4
Fattyshes(Tunny,Mackarel,
bluesh,anchovy) 2 - 4
Shellsh Cleaned and in bags 4 - 6
Caviar In its package, aluminium or
plastic container 2 - 3
Snails In salty water, aluminum or plastic
container 3
Note: Frozen meat should be cooked as fresh meat after being thawed. If the meat
is not cooked after being thawed, it must not be re-frozen.
Maximum Storing
time (months)
Thawing time in
room temperature
(hours)
Thawing time in oven
(minutes)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)
Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)

EN - 15 -
Vegetables and Fruits Preparation
Maximum
Storing time
(months)
String beans and beans Wash and cut into small pieces and boil in
water 10 - 13
Beans Hull and wash and boil in water 12
Cabbage Cleaned and boil in water 6 - 8
Carrot Clean and cut to slices and boil in water 12
Pepper Cut the stem, cut into two pieces, remove
the core and boil in water 8 - 10
Spinach Washed and boil in water 6 - 9
Cauliower
Take the leaves apart, cut the heart into
pieces, and leave it in water with a little
lemon juice for a while
10 - 12
Eggplant Cut to pieces of 2cm after washing 10 - 12
Corn Clean and pack with its stem or as sweet
corn 12
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the stone 4 - 6
Strawberry and
Blackberry Wash and hull 8 - 12
Cooked fruits Adding 10 % of sugar in the container 12
Plum, cherry, sourberry Wash and hull the stems 8 - 12

EN - 16 -
CLEANING AND MAINTENANCE
evaporating container
• Disconnect the unit from the power supply before cleaning.
• Do not clean the appliance by pouring water.
• Make sure that no water enters the lamp housing and other electrical
components.
• The freezer should be cleaned periodically using a solution of bicarbonate
of soda and lukewarm water.
• Clean the accessories separately with soap and water Do not
clean them in the dishwasher.
• Do not use abrasive products, detergents or soaps. After washing, rinse
with clean water and dry carefully. When you have nished cleaning,
reconnect the plugto the mains supply with dry hands.
• Clean the condenser with a broom at least twice a year. This will help
you to save on energy costs and increase productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.
Defrosting
Your freezer has fully automatic defrosting. The water
formed as a result of defrosting passes through the
water collection spout, ows into the vaporisation
container below the condenser and evaporates there.
Replacing LED lighting
If your refrigerator has LED lighting, contact the help desk as this should be changed by
authorized personel only.

EN - 17 -
BEFORE CALLING SERVICE
Repositioning the door
• It is not possible to change the opening direction of your freezer door, if the door handle
on your freezer are installed from the front surface of the door.
• It is possible to change the opening direction of the door on models without any handle.
• If the door opening direction of your freezer may be changed, you should contact the
nearest authorised service to have the opening direction changed.
TRANSPORTATION AND CHANGING OF INSTALLATION
POSITION
• The original packages and foamed polystyrene (PS) can be retained if required.
• During transportation, the appliance should be secured with a wide string or a strong
rope. The instructions written on the corrugated box must be followed while transporting.
• Before transporting or changing the installation
position, all the moving objects (ie, drawer, Ice trays,
…) should be taken out or xed with bands in order
to prevent them from getting damaged.
Carry your freezer in the upright position.
Check Warnings;
Your fridge warns you if the temperatures for freezer are in improper levels or when a
problem occurs in the appliance.
WARNING
TYPE MEANING REASON REMEDY
Sr Failure warnings
Appears when one or
more of the freezer
parts fail or there is a
problem in the cooling
system.
Call an authorised service
agent immediately.
LF
Freezeing
compartments
are not cold
enough
This warning appears
if there has been a
power failure for a long
period and when the
freezer is operated for
the rst time.
1. If your frozen food is
thawed, consume it as
soon as possible and do
not re-freeze
2. Temporarily increase the
freezer temperature setting
to the desired level or
switch the appliance to
super freeze mode.
LP Low voltage
Freezers switches
to the standby mode
when the supply
voltage falls below 170
Volts.
This feature prevents the
compressor from getting
damaged due to low
voltage. The freezer will
start operating automatically
when the voltage reaches the
required level.

EN - 18 -
If you are experiencing a problem with your freezer, please check the following before
contacting the after-sales service.
Your freezer is not operating
Check if:
• There is power
• The plug is correctly placed in the socket
• The plug fuse or the mains fuse has blown
• The socket is faulty. Examine this by plugging your freezer into a working socket.
A rise in the temperature may be caused by:
• Opening the doors frequently for long periods of time
• Loading the appliance with large quantities of warm foods
• A high ambient temperature
• An error with the appliance.
Your freezer is operating noisily
Normal noises
Cracking (ice cracking) noise occurs:
• During automatic defrosting
• When the appliance is cooled or warmed (due to expansion of appliance material).
Short cracking noise occurs: When the thermostat switches the compressor on/off.
Motor noise: Indicates the compressor is operating normally. The compressor may
cause more noise for a short time when it is rst activated.
Bubbling noise and splash occurs: Due to the ow of the refrigerant in the tubes of
the system.
Waterowingnoiseoccurs:Due to water owing to the evaporation container. This
noise is normal during defrosting.
Air blowing noise occurs: In No-Frost freezers during normal operation of the system
due to the circulation of air.
The edges of the freezer in contact with the door joint are warm
Especially during summer (warm seasons), the surfaces in contact with the door joint may
become warmer during the operation of the compressor, this is normal.
There is a build-up of humidity inside the freezer
Check if:
• All food is packed properly. Containers must be dry before being placed in the freezer.
• The freezer door is opened frequently. Humidity of the room enters the freezer when
the doors are opened. Humidity increases faster when the doors are opened more
frequently, especially if the humidity of the room is high.
• There is a build-up of water droplets on the rear wall. This is normal after automatic
defrosting (in Static Models).
The door does not open or close properly
Check if:
• There is food or packaging preventing the door from closing
• The door compartments, shelves and drawers are placed correctly
• The door joints are broken or torn

EN - 19 -
Tips for saving energy
1.Install the appliance in a cool, well ventilated room , but not in direct sunlight and not near
a heat source (radiator, cooker.. etc). Otherwise use an insulating plate.
2.Allow warm food and drinks to cool down outside the appliance.
3.Cover drinks or other liquids when placing them in the appliance Otherwise humidity
increases in the appliance. Therefore, the working time gets longer. Also covering drinks
and other liquids helps to preserve smell and taste.
4.Try to avoid keeping the doors open for long periods or opening the doors too frequently
as warm air will enter the cabinet and cause the compressor to switch on unnecessarily
often.
5.Keep the covers of the different temperature compartments (crisper, chiller ...etc ) closed
6. The door gasket must be clean and pliable. In case of wear, if your gasket is detachable,
replace the gasket. If not detachable, you have to replace the door.
• Your freezer is on a level surface.
IMPORTANT NOTES:
• In the event of a power cut, to prevent any damage to the compressor we recommend
that you unplug the freezer. Your appliance will start after 5 minutes, there is nothing to
worry about.
• If the appliance is not used for long time (for example during holidays) unplug it. Clean
your freezer according to Chapter 4 and leave the door open to prevent humidity and
smell.
• If the problem persists after you have followed all the instructions above, please consult
to the nearest Authorised service.
• The lifetime of your appliance stated and declared by the Department of the Industry
is 10 years (the period for retaining parts required for the proper functioning of the
appliance).

EN - 20 -
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
1
3
2
4
5
6
1. ICE TRAY / ICE MATIC *
2. FREEZER FLAPS
3. FREEZER BIG DRAWER
4. FREEZER DRAWERS
5. FREEZER BOTTOM DRAWER
6. LEVELLING FEET
In some models there is a shelf
with icematic in the top basket.
* In some models
