VOX electronics LED 40ADS553B User manual

LED 40ADS553B
ENG

High Voltage Do not openRisk of electronic shock, do not open.Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.CAUTIONImportant Safety Instructions and MaintenanceImportant Safety InstructionsIf the following problems occur:Turn off the TV set and unplug the AC power cord immediately if any of the following problems occur. Ask your dealer or service centre to have it checked by qualified service personnel.When:- AC power cord is damaged.- Poor fitting of AC power outlet.- TV set is damaged by being dropped, hit orhaving something thrown at it.- Any liquid or solid object falls throughopenings in the cabinet.The screen and cabinet get warm when the TV is in use. This is not a malfunction.In case of smoke, strange noise or strange smell from the unit:· Turn off the power switch immediately;· Disconnect the power plug from the poweroutlet;· Contact your dealer or servicecentre. Never attempt to makerepairs yourselfbecause this couldbe dangerous.Do not overload wall outlets, extension cords or adaptors beyond their capacity, this can result in fire or electrical shock.Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plug end, adaptors and the point where they exit from the appliance. The mains plug is used as the disconnect device. It shall remain readily accessible and should not be obstructed during intended use. Make sure to plug the power cord in until it is firmly inserted. When removing the power cord, make sure to hold the power plug when pulling the plug from the outlet, do not pull the plug out by the wire. NEVER touch the plug or power cord with wet hands. To disconnect the apparatus from the mains power, the plug must be pulled out from the mains socket, therefore make sure the mains plug is always easily accessible. To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. Never push objects of any kind into the set through the cabinet slots as they may touch dangerous voltage points or short-circuit parts that could result in a fire or electric shock. Never spill liquid of any kind on the set. Use special caution in households where children are present. The apparatus is not suitable for children under 3-year to operate.1To avoid the fire, no naked flame source, such as lighted candles, should be placed on the apparatus.Do not push or scratch the front filter, or place any objects on top of the TV set. The image may be uneven or the screen may be damaged.

2Important Safety Instructions and MaintenanceImportant Safety InstructionsAn outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.Ensuring the television is not overhanging the edge of the supporting furniture.Excessive from earphones and volumeheadphones can cause hearing loss.Do not pull the plug out by the wire; Never touch the plug with wet hands.InstallationWhen not in useIf you will not be using the TV set for several days, the TV set should be disconnected from the AC mains for environmental and safety reasons. As the TV set is not disconnected from the AC power when the TV is turned off at the standby switch, pull the plug from the AC power outlet to disconnect the TV completely. However, some TV sets may have features that require the TV set to be left in standby to function correctly. In the case of lightning, unplug the TV set from the outlet immediately. Never touch the antenna wire during lightning.The ventilation should not be impeded by covering the ventilation opening with items, such as newspapers, tablecloths, curtains, etc.At least 10 cm space should be left around the apparatus for sufficient ventilation.The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat. Place the apparatus in such a position that the screen is not exposed to direct sunlight. It is best to have soft indirect lighting while watching and avoid completely dark environmentsand reflection from the screen as these may cause eye fatigue.Keep the TV set away from any equipment emitting electromagnetic radiation.Do not place the set on an unstable cart, stand, table or shelf. The set may fall, causing serious personal injury as well as damage to the product. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.Do not place this apparatus near water, for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or a swimming pool; and the like;

solventthinnersolventthinnerImportant Safety Instructions and Maintenance3InstallationMoveWhen the TV being moved in from cold place, it needs some right time for dew inside unit evaporating fully before turn on the unit;To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.LED ScreenAlthough the LED screen is made with high precision technology and 99.99% or more of the pixels are effective, black dots may appear or bright points of light (red, blue or green) may appear constantly on the LED screen. This is a structural property of the LED screen and is not a malfunction.If the surface of the LED panel cracks, do not touch it until you have unplugged the AC power cord. Otherwise electric shock may result. Do not throw anything at the TV set. The LED panel may break from the impact and cause serious injury.Precautions When Displaying a Still ImageA still image may cause permanent damage to the TV screen.Do not display still images and partially still images on the LED panel for more than 2 hours as it can cause screen image retention. This image retention is also known as "screen burn". To avoid such image retention, reduce the degree of brightness and contrast of the screen when displaying a still image.Watching the LED TV in 4:3 format for a long period of time may leave traces of borders displayed on the left, right and centre of the screen caused by the difference of light emission on the screen. Playing a DVD or a game console may cause a similar effect to the screen. Damages caused by the above effect are not covered by the Warranty.Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images. To prevent this effect, reduce the 'brightness' and 'contrast' when displaying still images.CleaningCleaning and handling the screen surface and cabinet. Disconnect the unit from the AC outlet before cleaning. To remove dust, wipe gently with a soft, lint free cloth. If required use a slightly damp cloth. MAINS PLUGWipe the mains plug with a dry cloth at regular intervals. Moisture and dust may lead to fire or electrical shock.Use care not to subject the TV's surfaces to detergent. (A liquid inside the TV could lead to product failure, fire or electrical shock.) Use care not to subject surfaces to bug repellent, solvent, thinner, or other volatile substances as this may deteriorate the surface and finish of the cabinet.

Important Information4Table of ContentsIf a television is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as:• Using cabinets or stands recommended by the manufacturer os the television.• Only using furniture that can safely support the television.• Ensuring the television is not overhanging the edge os the supporting furniture.• Not placing the television on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the television to a suitable support.• Not standing the televisions on cloth or other materials placed between the television and supporting furniture.• Educating children about the dangers of climbing on furniture to reach the television or its controls.• Keep small accessories out of reach of children so they are not mistakenly swallowed.
5667899101113131314141516171818192222232324252628282931Accessories-------------------------------------------------------------------------------------------------------------Introduction-------------------------------------------------------------------------------------------------------------Features-------------------------------------------------------------------------------------------------------------------Specifications-------------------------------------------------------------------------------------------------------------Stand and wall-mounting instructions (optional)-----------------------------------------------------------General Description--------------------------------------------------------------------------------------------------Overview of front panel------------------------------------------------------------------------------------------------Overview of back panel------------------------------------------------------------------------------------------------Overview of remote control--------------------------------------------------------------------------------------------Installing Batteries in the Remote Control-------------------------------------------------------------------------External Connection--------------------------------------------------------------------------------------------------Antenna connection-----------------------------------------------------------------------------------------------------Basic operation---------------------------------------------------------------------------------------------------------Turning the TV on and off----------------------------------------------------------------------------------------------First Time Usage -------------------------------------------------------------------------------------------------------Input Source ------------------------------------------------------------------------------------------------------------Home Page --------------------------------------------------------------------------------------------------------------TV Menu -----------------------------------------------------------------------------------------------------------------Main Menu ---------------------------------------------------------------------------------------------------------------Setting Menu ------------------------------------------------------------------------------------------------------------Memory Usage ----------------------------------------------------------------------------------------------------------Backlight ------------------------------------------------------------------------------------------------------------------Wi-Fi -----------------------------------------------------------------------------------------------------------------------Image ----------------------------------------------------------------------------------------------------------------------Sound ---------------------------------------------------------------------------------------------------------------------Channel ------------------------------------------------------------------------------------------------------------------Function ------------------------------------------------------------------------------------------------------------------Time -----------------------------------------------------------------------------------------------------------------------Network -------------------------------------------------------------------------------------------------------------------Digital Media Player---------------------------------------------------------------------------------------------------Troubleshooting--------------------------------------------------------------------------------------------------------

5
Accessories
Please make sure the following items are included with your LED TV. If any items are missing,
contact your dealer.
Remote Control
Owner’s
Instructions
S.PAGE ZO OM
HOLD
REVEA L SIZE INDE X
PVR.List

6
Introduction
Features
TV adopts 40" TFT LED display screen
Zero X radiation complies to green environment protection requirement
Connect to computer directly to realize TV/monitor combo.
Support USB
16:9 wide screen
Auto tuning and fine tuning
Support HDMI
Programmable sleep timer
Wide range voltage input
No-signal automatic power off
Input terminals used for external equipment connection
2x USB Input
1x RJ45 Input
1x Earphone Output
3x HDMI Input
1x COAXI
1x AV Input
1x PC Input
1x Mini YPbPr Input
2x RF Input

S:
≥5 X2W
110-240V~, 50/60Hz
48.25~863.25MHz
Digital: DVB-T/T2 , DVB-C, DVB-S/S2
Analog: PAL/SECAM
<0.5W
o o
0 C-40 C
40” Diagonal(max.)
75W
1920X1080
LED 40ADS553B
PAL/NTSC

8How to assemble the standIf you need to remove or assemble the stand please read the following instructions.- Before attaching/detaching the stand, make sure to turn off the TV.- Before performing work, spread cushioning over the base area to lay the LED TV on. This will prevent it from being damaged.Assembling instruction: Step1: Take out two stands from package, and insert them into bottom of TV;Step2: Take out four screws provided with TV set and tighten them into screw holes;- To disconnect the stand from the TV, perform the above steps in reverse order.Stand and wall-mounting instructions (optional)

9
General Description
Overview of front panel
Increase the volume, corresponding to the ordinary seven button button "volume +" button.
Reduce the volume and press the "volume -" button on the keypad with the normal five keys.
Backward switching channels, corresponding on the five key for keypad channel "∧" button.
Forward channel switch, corresponding on the five key for keypad ∨"channel" button.
The OK button is a confirmation function
Display \ hidden button menu: when no button menu pops up, press the button and the button menu pops up,
as shown in the figure below. The button menu will close automatically after the button is pressed for 5 seconds.
Key function selection: press the button short, the focus moves to the right, and select the corresponding function,
such as pressing the button short 3 times, the focus position is as shown in the picture below in red. At this point,
continue to press the short button and focus back to the position shown above.
Key function execution: long press button can perform the function corresponding to the focus, such as
the focus in the position shown in the figure above, the channel reduction function will be performed.
Icon function description:
Shutdown function, corresponding to the menu "power" button.
Open the menu, corresponding to the remote "menu" button.
Open the signal source menu, corresponding to the remote control "signal source" button.
Five key button function description
