Vox CHT5001 User manual

EHB-504
EHB-604
EHT-604
ELECTRICAL FREESTANDING
OVEN
USERS MANUAL

Our Esteemed Customer,
We take offering quality products more than your expectation as
a goal, offers you the products produced in modern facilities
carefully and particularly tested for quality.
Your manual is prepared in order to help you to use your
apparatus that is manufactured by the most recent technology,
with confidence and maximum effciency.
efore use of your apparatus, carefully read this guide that
includes the basic information for right and safe installation,
maintenance and use and contact to the nearest Authorized
Service for mounting of your product.

CONTENTS :
1. PRESENTATION AND SIZES OF PRODUCT
2. WARNINGS
3. INSTALLATION AND PREPARATIONS FOR USE
4. USE OF YOUR OVEN
5. CLEANING AND MAINTENANCE
6. SERVICE AND TRANSPORT

PART 1 : PRESENTATION AND SI ES OF PRODUCT
1112
13
Part of List :
1- Cooktop Cover
2- Cooktop
3- Control Panel
4- Child Lock
5- Oven Door Handle
6- Drawer Cover
7- Supply Leg
8- Oven Door
9- Oven Tray
10- Wire Grid
11- Front esistance
12- Fan Store
13- Oven Lamp
14- Hotplate
15- Highlite element
14
888
1
2
3
4
5
67
8
9
9
10
15
MODEL SIZE(cm
TE 66
TE 56
60*60*85 60*60*90
50*60*85 50*60*90

READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE USING YOUR
APPLIANCE, AND KEEP IT IN A CONVENIENT PLACE FOR REFERENCE WHEN NECESSARY.
THIS MANUAL IS PREPARED FOR MORE THAN ONE MODEL IN COMMON. YOURAPPLIANCE
MAY NOT HAVE SOME OF THE FEATURES THATARE EXPLAINED IN THIS MANUAL. PAY
ATTENTION TO THE EXPRESSIONS THAT HAVE FIGURES, WHILE YOU ARE READING THE
OPERATING MANUAL.
General Safety Warnings
- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
- WARNING: The appliance and its accessible
parts become hot during use. Care should be
taken to avoid touching heating elements.
Children less than 8 years of age shall be kept
away unless continuously supervised.
- WARNING: Unattended cooking on a hob with
fat or oil can be dangerous and may result in
fire. NEVER try to extinguish a fire with water,
but switch off the appliance and then cover
flame e.g. with a lid or a fire blanket.
- WARNING: Danger of fire: do not store items
on the cooking surfaces.
PART 2 SAFETY WARNINGS


- WARNING: If the surface is cracked, switch off
the appliance to avoid the possibility of electric
shock.
- For hobs incorporating a lid, any spillage
should be removed from the lid before opening.
And also the hob surface should be allowed to
cool before closing the lid.
- The appliance is not intended to be operated
by means of an external timer or separate
remote-control system.
- WARNING: In order to prevent tipping of the
appliance, the stabilizing brackets must be
installed. (For detail information please read the
anti-tilting kit set guide.)
- During use, the appliance becomes hot. Care
should be taken to avoid touching heating
elements inside the oven.
- During use, handles held for short periods in
normal use can get hot.
- Do not use harsh abrasive cleaners or sharp
metal scrapers to clean the oven door glass and
other surface since they can scratch the surface,
which may result in shattering of the glass or
damage to the surface.
- Do not use steam cleaners for cleaning the
appliance.


- WARNING: Ensure that the appliance is
switched off before replacing the lamp to avoid
the possibility of electric shock.
- CAUTION: Accessible parts may be hot when
the cooking or grilling is in use. Young children
should be kept away.
• Your appliance is produced in accordance with all applicable local and international standards and
regulations.
• Maintenance and repair work must be made only by authorized service technicians. Installation and
repair work that is carried out by unauthorized technicians may endanger you. It is dangerous to alter
or modify the specifications of the appliance in any way.
• Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure
or electricity voltage and frequency) and the requirements of the appliance are compatible. The
requirements for this appliance are stated on the label.
• CAUTION: This appliance is designed only for cooking food and is intended for indoor domestic
household use only and should not be used for any other purpose or in any other application, such
as for non-domestic use or in a commercial environment or room heating.
• Do not try to lift or move the appliance by pulling the door handle.
• All possible security measures have been taken to ensure your safety. Since the glass may break,
you should be careful while cleaning to avoid scratching.Avoid hitting or knocking on the glass with
accessories.
• Ensure that the supply cord is not wedged during the installation. If the supply cord is damaged, it
must be replaced by the manufacturer, its service agent or similarly qualified persons in order to
prevent a hazard.
• While the oven door is open, do not let children climb on the door or sit on it.
Installation Warnings
• Do not operate the appliance before it is fully installed.
• The appliance must be installed by an authorized technician and put into use. The producer is
notresponsible for any damage that might be caused by defective placement and installation by
unauthorized people.
• When you unpack the appliance, make sure that it is not damaged during transportation. In case of
any defect; do not use the appliance and contact a qualified service agent immediately. As the
materials used for packaging (nylon, staplers, styrofoam...etc) may cause harmful effects to children,
they should be collected and removed immediately.
•Protectyourapplianceagainst atmosphericeffects.Donotexposeitto effectssuchassun,rain,snow
etc.
• The surrounding materials of the appliance (cabinet) must be able to withstand a temperature of min
100°C.


During usage
• When you first run your oven a certain smell will emanate from the insulation materials and the
heater elements. For this reason, before using your oven, run it empty at maximum temperature for
45 minutes. At the same time you need to properly ventilate the environment in which the product is
installed.
• During usage, the outer and inner surfaces of the oven get hot. While opening the oven door, step
back to avoid the hot steam coming out of the oven. There may be a risk of burns.
•Donotputflammableorcombustiblematerials,inorneartheappliancewhenitisoperating.
• Always use oven gloves to remove and replace food in the oven.
• Do not leave the cooker while cooking with solid or liquid oils. They may catch fire on condition of
extreme heating. Never pour water on to flames that are caused by oil. Cover the saucepan or
frypan with its cover in order to choke the flame that has occured in this case and turn the cooker off.
• Always position pans over the centre of the cooking zone, and turn the handles to a safe position
so they cannot be knocked or grabbed.
• If you will not use the appliance for a long time, plug it off. Keep the main control switch off. Also
when you do not use the appliance, keep the gas valve off.
• Make sure the appliance control knobs are always in the "0" (stop) position when it is not used.
• The trays incline when pulled out. Be careful not to let hot liquid spill over.
• When the door or drawer of the oven is open, do not leave anything on it. You may unbalance your
appliance or break the cover.
• Do not put heavy things or flammable or ignitable goods (nylon, plastic bag, paper, cloth...etc) into
the drawer. This includes cookware with plastic accessories (e.g. handles).
• Do not hang towels, dishcloths or clothes from the appliance or its handles.
During cleaning and maintenance
• Always turn the appliance off before operations such as cleaning or maintenance. You can do it
after plugging the appliance off or turning the main switches off.
• Do not remove the control knobs to clean the control panel.
TO MAINTAIN THE EFFICIENCY AND SAFETY OF YOUR APPLIANCE, WE RECOMMEND YOU
ALWAYS USE ORIGINAL SPARE PARTS AND TO CALL ONLY OUR AUTHORIZED
SERVICE AGENTS IN CASE OF NEED.


PART3 : INSTALLATION AN PREPARATION FOR USE
5
This modern, functional and practical oven, that was manufactured with the most
quality parts and materials, will meet your needs in every respect. You must surely
read this manual in order not to have any problem in future and to be able to have
successfull results. The following information are the required rules for right
installation and service processes. It must be read especially by the technician who
will install the apparatus.
Contact to Authoriz d S rvic for mounting of your ov n.
3. 1 INSTALLATION OF OVEN
There are some factors that must be paid attention to while installing your oven.
Surely pay attention to our below suggestions in order to be able to prevent any
problems and/or dangerous situations that may occur later.
It can be placed close to other furniture on condition that in the area where the oven
is set up, the furnitures height must not exceed the height of the cooker panel.
Pay attention not to place it near the refrigerator, there must be no flammable or
in flammable materials such as curtain, waterproof cloth, ... etc. that will begin to burn
quickly, while selecting place for oven.
It is required there must be at least 2 cm blank space between the back cover of
oven and wall for air circulation.
The furniture close to oven must be manufactured resistant to heat more than
50 C° of the room temperature.
If the kitchen furniture are higher than the pan which the ovens cookers are on,
it must be at least 11 cm away from the ovens side.
The minimum heights from the ovens pan and wall cupboards and paddle boxes
with fan over the oven, are shown as below. Thus, the paddle box must be at
minimum 650 mm height from the cooker pan.
If there is no paddle box, this height must not be less than 700 mm.

3.3 ELECTRIC CONNECTION AN SECURITY
During th l ctric conn ction, sur ly follow th instructions b low.
The earthing cable must be connected to the terminal. You have to ensure the
cable with insulation to be connected to the power source during the connection of
cable. If there is not any appropriate earthed electric outlet in accordance with
regulations in the place where the apparatus will be installed, immediately contact to
our authorized service.
The earthed electric outlet must be close to the apparatus. Surely do not use the
extension cord.
The feeding cable must not touch to the hot surface of the product.
In case the feeding cable is damaged, surely contact to Qualified Service. The
cable must be changed by the authorized service.
The wrong electric connection may damage your apparatus. Such damage is not
in guarantee extent.
The apparatus is adjusted as appropriate for 220-240 Volts and 400V 3N Volts
of electricity. If the network electricity is different than this informed value, immediately
contact to our authorized service.
The electric cable must not touch to the hot parts of apparatus. The electric cable
must not touch the back part of the apparatus. Otherwise the electric cable of
apparatus may be damaged. And this situation may cause short circuit.
The producer firm declares that it has no responsibility against any kind of damages
and losses that emanate from the following security norms.
There is to install an all pole disconnector inside the supply circuit with a contact
opening of at least 3.0mm rated 32A and delay functioning type.
6
3. 2 A JUSTMENT OF FEET
Your oven stands on 4 adjustable feet. As the feet are adjusted in low location, it is
required to control whether it is balanced before installing the oven. You can make
this adjustment as turning the feet clockwise if required. It is possible to raise the
apparatus maximum 15 mm via the feet.
If the feet are adjusted appropriately, it is required not to move the apparatus by
dragging, otherwise it is required to place it by lifting it up. It is required to bring the
ovens drawer out to adjust the apparatuss feet. The feet can be adjusted from inside
via the small change.

Its outside surfaces heat while your apparatus operates. The interior surfaces of
oven, components that ensures the heat and steam that goes out are quite hot. Even
if the apparatus is turned off, these parts hold its heat for a specific time. Do not touch
onto the hot surfaces. Keep children away.
Do not leave the cooker while cooking with solid or liquid oils. There may be flaming
up on condition of extreme heating. Never pour water to the flames occuring from oil.
Cover the saucepan or frypan with its cover in order to choke the flame that was
occured in this case and turn the cooker off.
The oven and heat adjustment switches must be adjusted and ovens clock must
be programmed for cooking in your oven. Otherwise the oven does not operate.
Do not leave anything on it when the door or drawer of oven is open. You may
unbalance your apparatus or break the cover.
Do not put heavy things or flammable, burnable goods (nylon, plastic bag, paper,
cloth . . . etc) into the lower drawer.
Plug it off when you do not use the apparatus and keep the gas valve off.
Protect your apparatus against atmospheric effects. Do not leave it to effcts
such as sun, rain, snow, powder. . etc.
7
3
2
1L
N4
5
PE
L2
L3
5x1.5 mm 380 V ,3N
5x1.5 mm 400 V ,3N
5x1.5 mm 415 V ,3N
3
2
1L
N4
5
PE
3 x 2.5 mm 220 V
3 x 2.5 mm 230 V
3 x 2.5 mm 240 V
The appliance is provided for fixed connection to the power supply. The connection
of the appliance to an electrical source must be done by authorized technician.
Your apparatus is produced in accordance with the related security instructions
connected with electrical apparatus. The maintenance and repair works must be
made just by the authorized service technician who is trained by the producer firm.
The installation and repair works whitout following rules may endanger you.
3. 4 GENERAL WARNINGS AN MEASURES

PART 4 : USE OF YOUR OVEN
8
4. 1 GENERAL APPEARENCE AN TECHNICAL FEATURES OF YOUR OVEN
TE 56
LOWER HEATER
UPPER HEATER
GRILL
TUR O HEATER
1000 WATT
1000 WATT
1600 WATT
2000 WATT
TE 66
LOWER HEATER
UPPER HEATER
GRILL
TUR O HEATER
1100 WATT
1200 WATT
2000 WATT
2000 WATT
4. 2 PRESENTATION AN FEATURES OF THE CONTROL PANELS
TE 56/66
150
250
8888
Timer Oven Function
Switch
Oven Thermostat
Switch
50
100
200
Max
Mode 2
1
34
5
6
Left ack Heater
Left Front Heater
Right Front Heater
Right ack Heater
2
1
34
5
6
2
1
34
5
6
2
1
34
5
6
4. 3 USE OF HOTPLATES AN VITROCERAN COOKERS
The electrical cooker is co anded by 7 graded switches. 0 of the grades is off location. The
use fields in response to other 6 grades are below.
1
2
34
5
6
Hotplates
6
5
43
2
1
Vitroceramic Cooker
1..........Keeping hot location
2-3......Heating locations at low heat
4-5-6..Cooking - roasting and boiling
locations

9
The upper part of hotplates is covered by a protective material resistant to heat. Turn
the switch of the electrical cooker to 3 and then operate the cooker for 5 minutes
in order to burn and so to toughen the protective layer at first use.
During use of electrical cookers, it is required to pay attention to the used saucepans
to have smooth bases. If appropriate sized and smooth based saucepans are used,
you can get the most efficiency from your cooker. It is not suggested to use the little
size saucepans on the big size cooker, because this will cause heat loss and so energy
will be wasted.
RIGHT WRONG
circular saucepan base
WRONG
small saucepan diameter
WRONG
saucepans base had not settled
Surely control that your cooker is off, the control switch is at 0 location after cooking.
Also never touch it as the cooker will be hot for a speific time after it was turned off.
Do not let children to come close to it.
Clean the electrical cooker with a wet cloth after using the electrical cooker. If there
is excessively getting dirty situation, you can clean it with water with detergent rather
well.
Heat for a few minutes for the upper part to dry after cleaning. If you will not use its
upper part for a while, ensure to occur a thin oil layer as oiling with machine oil.
6
5
43
2
1
ual or Oval Vitroceramic Cooker
Dual or vitroceramic cookers can heat in two different position. For
operating the big diameter of dual cooker turn the switch to
 . oth big and small diameter of the cooker will operate.
For operating the oval part of the oval cooker, turn the switch
to  . oth oval and round parts will operate.

4.4 USE OF OVEN PART
4. 4. 1 Use of Electronical Programming Clock
Adjustment of ay Hour
A symbol will start to flash after it is connected to the electrical resource.
Press (+) and (-) keys at the same time. It is also possible to adjust (to increase or
to reduce ) the time by pressing to these keys.
-+
MODE
A
Alarm / Time Setup
This function can be used as time set up and alarm when wished. Mode key must
be pressed until   led indicator lamp will start to light. The wished period interval is
adjusted via + and - keys. The wished time remains on screen after it was adjusted
and   sign that flashed in the past remains fixed. It is possiple to make time set up
between 0-23.59 hours. At the end of cooking period an alarm is heard and
  symbol flashes. You can press any key to stop the alarm.
Programming as etermining the Cooking Period
This function is used to adjust to cook at wished period interval.
To adjust the cooking period, Mode  key is pressed until Dur indicator lamp
will start to flash. The wished cooking period is adjusted by using + and - keys.
Once the time is adjusted, it is registered automatically in 5 seconds following the
adjustment and A and  symbols start to light continuously. The screen returns
to the current time. An alarm (sound) is heard when the cooking period ended and
A and   symbols start to flash. Press onto any switch stops the signal and the
lamp to flash.
It is possible to adjust cooking period between 0-10 hours.
-+
MODE
A
du r
10

Programming as determining the Finish Time
This function is used to adjust finishtime of the cooking period. To adjust the finish
time of cooking Mode key is pressed until End indicator lamp will start to flash.
The wished finish time is adjusted by using + and - keys. When the finish time
is reached an alarm is heard and you can press any kay to stop the alarm.
-+
MODE
A
En d
Programming as determining the Cooking Period and Finish Time
This function is used to adjust the cooking period by using of automatically cooking
function.
oth cooking period and ending time have to be adjusted to adjust the ending of
cooking period. The cooking period is adjusted as determined above.
 Mode key was pressed until End indicator lamp will flash in order to adjust the
ending time. + and - keys must be used at the end of wished cooking period.
Once the time is adjusted , it is registered automatically in 5 seconds following the
adjustment and A and  symbols starts to light continuously. The screen returns to the
current time. An alarm sound is heard at the end of the time and A symbol starts to
flash. Pressing any switch stops the signal and lamp to flash.
10
20
30
40
50
70
80
90
60
100
M
0
30
40
10
20
50
70
80
90
60
100
M
0
Manual Operation
When you set the timer
knob to M position as
seen in the illustration
on left side, the oven
can be operated
continuously. The oven
can never be operated,
when the timer knob is
in 0 position.
4.4.2 Use of Mechanical Timer
Operation with time set
Turn the timer knob in
clockwise direction in
order to set time between
0-100 minutes as seen
in figure on right side.
When the adjusted time
ends, oven is turned off
and a single warning
sound is heard.
11

4. 4. 3 Use of Oven Function Switches
This switch allows you to select the oven functions. The functions and their grades
are shown at the following table. Also, the detailed instructions and their uses will
also be explained in details in the next pages.
Your ovens lamp starts to operating.
Your ovens lamp, red warning lamp and fan start to operating.
It performs the function of defrosting your frozen food.
Your ovens thermostat and warning lamps and lower and upper heaters
start operating.
Your ovens thermostat and warning lamps and turbo heater, fan are put into
use.
Your ovens thermostat and warning lamps and fan, upper and lower
heaters start operating.
Your ovens thermostat and warning lamps and grill heater and chicken turning
function start operating.
Your ovens thermostat and warning lamps and upper heater, grill heater and
chicken turning functions start operating.
Your ovens thermostat and warning lamps and upper heater, grill heater and
chicken turning and fan functions start operating.
Your ovens thermostat and lamps, lower heater operate
Your ovens thermostat and warning lamps, turbo heater, lower heater and
fan start operating.
Your ovensthermostat and warning lamps,lower heater and start operating.
12

Ice Melter Function ( Defrost )
You can start the defrosting process by placing the frozen food into your oven and
turning the switch onto the determined sign. This is a program that does not cook the
food, just helps to defrost them in a very short time. Place the food that will be
defrosted on the third shelf support from the bottom, on a wire shelf. Place a tray into
the bottom of the oven in order to collect the water that occurs because of defrosting.
Lower - Upper Heater Function ( Static Cooking )
At this cooking that is defined as the traditional method, the heat that is spreaded
from the lower and upper heating elements into your oven equally, ensures the foods
buttom and top to be cooked equally.
It is recommended to make pre heating for 10 minutes. Leave the food that was put into
the available cooking dish to be cooked in recommended period case. The Lower-Upper
Heater location is the function that is preferred to cook cake, sponge cake, flan,
spaghetti in oven, lasagna, pizza.
At the end of cooking process, turn the ovens switch and heat set up switch off and
cancel the time program. Take the cooked food from the oven, put onto a safe place
and open the ovens door and ensure the oven is cool completely. As the oven will be
hot at that moment, stay away from the oven and keep your children
away from the oven.
Fan and Lower - Upper Heater Function ( Static Cooking with Fan)
The location where the air comes from lower and upper heating elements is distributed
into the oven via the fan motor and fanner.
The heat adjsutment switch is adjusted to the degree that is recommended at the
cooking table. Turn the ovens switch as it will show the symbol of this function and the
ovens time is adjusted to the recommended time for cooking, the oven is pre heated
for 10 minutes. The food that had been put into the available cooking dish is placed
into the oven and then cooked. In general, this location is a location where a very
nice results are taken for cooking of pastries. Every part of the food will be cooked
equally at this location. It is appropriate for cooking of single tray.
At the end of cooking, turn off the ovens switch and heat adjustment switch. Cancel
the ovens time program and take the cooked food from oven and leave it on a safe
place. Open your ovens lid and leave it to cool. Do not come close to it until it cools
and keep children away.
13

Turbo Fan and Lower heater Function
Turbo fan and lower heater function is an ideal function to cook pizza. The lower
heater ensures the pizza paste to be cooked while Turbo fan spreads the heat of
oven equally. Adjust the heat adjustment switch of your oven to the wished degree,
also turn the function switch as it will show this functions sign and adjust the ovens
time to the offered time for cooking and pre heat the oven for 10 minutes. This function
is appropriate for cooking of one dish.
At the end of cooking process, turn off the ovens switch and heat set up switch.
Cancel the ovens time program and take the cooked food from oven and leave onto
a safe place. Open your ovens door and leave it to cool. Do not come close to the
oven until it cools and keep children away.
Warning: Max. s t of th rmostat 1900C
Grill and chicken Turning Function
This function is used to grill and to turn chicken, cooked food on a skewer.
To make turning, use the turning skewer. To grill, place the food onto the grill, also
the grill onto the shelf at toppest level. You can start to grill after placing the oven tray
onto the 3rd Shelf. The tray that is placed onto the 3rd Shelf will ensure the collection
of oils that drop from food.
14
Turbo Fan Function
Turbo fan function spreads the ovens heat equally. The food on all shelves will be
cooked equally during the use of this function.
Top of the oven will not be hotter than the bottom of it. Adjust the heat adjustment
switch of your oven to the wished degree, also turn the function switch as it will show
Turbo function symbol. Place your food that had been put into the available cooking
dishes into the oven after pre heating of 10 minutes. This function is appropriate for
cooking more than one dish.
If you have two trays of food that you will cook in your oven; you must use that heat
for your oven, heat of which of the heats that are appropriate for your food while
adjusting the cooking heat. Cooking two trays of food requires additional cooking
period according to the single tray cooking. In general, food in two trays are not cooked
at the same time. So, take the tray that you observed that is cooked, from the oven,
go on cooking for the other tray of food. As there will be heat transfer between two
trays during the cooking of two trays of food, the cooking quality will be lower than
the single tray. While cooking double trays, you can get a better cooking result by
changing theplaces and ways of trays if needed. The processes that will be applied
at the end of cooking, are same for all the functions.Open your ovens cover and leave
it to cool after you put your trays in oven onto a safe place.

Turn your ovens heat set up switch as it will show the sign of this function. Place
your food into the oven after pre heating of 5 minutes.
At the end of cooking, as in all other cooking processes; turn off the ovens switch
and heat set up switch. Cancel the ovens time program and take the cooked food from
oven and leave onto a safe place. Do not come close to the oven until it will cool and
keep children away.
Warning: Max. s t of th rmostat 1900C
Upper heater, Grill and Roast Chicken Function
This function is used to grill rapidly and to roast chicken, cooked food on a skewer.
To make roasting, use the roasting skewer. To grill, place the food onto the grill, also
the grill onto the shelf at toppest level. You can start to grill after placing the oven tray
onto the 3rd Shelf. The tray that is placed onto the 3rd Shelf will ensure collection of
oils that drop from food.
Turn your ovens heat set up switch as it will show the sign of this function. Place your
food into the oven after pre heating of 5 minutes.
At the end of cooking process, as in all other cooking processes; turn off the ovens
switch and heat set up switch. Cancel the ovens time program and take the cooked
food from oven and leave onto a safe place. Do not come close to the oven until it
cools and keep children away.
Warning: Max. s t of th rmostat 1900C
15
Grill, Chicken Roasting and Fan Function
In this function, grill and upper heater and the fan that ensures to roast
perfectly, operate together and cook. It is also used to grill, to roast chicken and
cooked food on a skewer.
To make roasting; use the roasting skewer. To grill, place the food onto the grill, also
the grill onto the shelf at the toppest level. You can start to grill after placing the oven
tray onto the 3rd Shelf. The tray that is placed onto the 3rd Shelf will ensure collection
of oils that drop from food.
Turn your ovens heat set up switch as it will show the sign of this function. Place your
food into the oven after pre heating of 5 minutes.
At the end of cooking process, as in all other cooking processes; turn off the ovens
switch and heat set up switch. Cancel the ovens time program and take the cooked
food from oven and leave onto a safe place. Do not come close to the oven until it
cools and keep children away.
Warning: Max. s t of th rmostat 1900C

16
Lower Heater Function
At this cooking the best is spreaded from the lower heating element. Lower
heating function is appropriate for heating the food instead of cooking.
Lower Heater and Fan Function
At this cooking, the heat is spreaded from the lower heating element and fan
motor. This function can be used to heat the food equally in a short time.
4. 4. 4 Accessories Used in Oven
You can use glass dishes, cake molds, special oven trays that are appropriate for use
in oven, that you are able to assure in market, apart from the oven trays and grill wire
chicken roasting skewer that are given together with your oven. Pay attention to the
information related to the subject that were given by the manufacturer firm.
In case small size dishes are used, place the dish onto the grill wire, as it will
completely be on the middle part of the wire. The following information must also be
followed for the enameled dishes.
If the food that will be cooked does not cover the oven tray completely, if the food is
taken from the deep freezer or the tray is being used for collection of foods juices that
flow during grilling, the form changes can be observed in tray because of the high
heat that occur during cooking or roasting.
The tray will return to its old form only when the tray cooled after cooking. This is a
normal physical event that occurs during heat transfer.
Do not leave this tray or dish in cold environment right away after cooking in glass tray
or dish. Do not put onto the cold and wet grounds. Place on a dry kitchen cloth or dish
cross, ensure it to cools slowly. Otherwise the glass tray or dish may be broken.
If you will grill in your oven; we recommend you to use the grill that was given in tray
together with product. ( If your product includes this material ) So, the oils that spatter
and flow, will not dirty the inside of oven. If you will use the big wire grill; put a tray onto
one of the lower shelves for oils not to be collected. Also put some water into it for
cleaning easiness.
Use 4th and 5th shelves while grilling and oil the grill for the ingredients that you will
grill not to stick to the grill.
WARNING- Fit the grid correctly
into any rack in the
oven cavity and push it to the end.
corresponding
