Voxx Electronics Prestige APS997Z User manual

1
2
3
4
1 2 3 4
1
2
3
4
1Red/Black Ignition 3 Flex Relay (87)Input
2 PinkIgnition 3 Flex Relay (30)Output
3 YellowStarter Output (+)
4 GreenIgnition 2 Output (+)
5 Red Battery 12VInput (+)
6 Red/White Battery 12VInput (+)
7 PurpleAccessory Output (+)
8 BlueIgnition 1 Input / Output (+)
8 Pin Start
P
P
P
1 White Parking Light (30)Output
2 White/RedParking Light (87)Input
3 White/Black Siren Output (+)
4 Black Ground Input (-)
4 Pin Light
P
1White Data RX
2Black Ground (-)
3 Blue Data TX
4 Red Battery 12V (+)
DBI
1Green Data RX
2Blue Data TX
3 Black Ground (-)
4 Red Battery 12V (+)
RF
1Blue Data TX
2White Data RX
3 Black Ground (-)
4 Red Battery 12V (+)
CarLink
4 Red Battery 12V (+)
3 Black Ground (-)
2White Data RX
1Blue Data TX
Weblink
22
GreenUnlock Output (-) (NOC 11)
21
Dk. BlueTrunkOutput (-) (NOC 9)
20 Red Lock Output (-) (NOC 10)
19 Green/Lt. Blue Ch. 4 AUX Output (-) (NOC 8)
18 Black/White Horn Output (-)
17 Lt. Blue/Green Ch. 5 AUX Output (-) (NOC 7)
16 Red/Black 2nd Unlock Output (-) (NOC 12)
15
Black/Lt. GreenFactory Arm Output (-) NOC 6)
14 Brown/Black Brake Input (+)
13 Black/Blue Factory Disarm Output (-) (NOC 5)
12 Dk. Blue/Black External Activation Input (-)
11 Black/Red Pulse After Shutdown Output (-) (NOC 4)
10 Orange/Black Parking Brake Input (-)
9 Black/Yellow Pulse During CrankOutput (-) (NOC 3)
8 Green/Yellow Diesel Glow Plug Input (+)
7 Green/White DomeLight Output (-) (NOC 2)
6 Purple/Brown DoorTriggerInput (- / +)
5 Lt. Blue Remote Start Status Output (-) (NOC 1)
4 Green/Orange Tach Input (-)
3 Gray/Black Hood Input (-)
2 Lt. Green TrunkTriggerInput (-)
1 Orange Starter Kill Relay/ Anti-Grind Output (-)
22 Pin Input/Output
4 Red Battery 12V (+)
3 Black Data TX
2 Green Warn AwayInput (-)
1 Blue Full TriggerInput (-)
Shock
1 2 3 4
VOXX
FLCART Dock
Replacement Part #4120459
Replacement Part #4120457
Replacement Part #4120462
Replacement Part #4120458
Not Included
Not Included
Not Included
85 Red Ignition Input (+)
86 OrangeStarter Kill Input (-)
87ABlack Starter Interrupt - Key Side
30 White/Black Starter Interrupt - Motor Side
Starter Kill
86 85
87
87A
30
Replacement Part #4360828
Replacement Part #4360830
This Harness is included with the FLCART.
For Wire Information and Diagram Please Refer to Vehicle
Specific FlashLogic Install Guide.
Visit www.FlashLogic.com for More Information.
Not Included
19
17
15
13
11
9
7
5
3
1 2
4
6
8
10
12
14
16
18
20
21 22
19 20
17 18
15 16
13 14
11 12
910
7 8
5 6
3 4
1 2
1 3 5 7
2 4 6 8
1 3
2 4
1
2
3
4
Replacement Part #4120464
APS997Z
Security and Remote Start
System Layout
2018 Voxx Electronics. All Rights Reserved.
Shock Sensor
Part #4700033
4180075 18LCDSP 185SP

APS997Z
Security and Remote Start
Quick Installaon Guide
For Complete Installaon Guide and Technical Support
Please Visit
www.voxxuniversity.com
Or Call
1-800-225-6074
Nocaons Feature Programming
Remote Programming
1 Chirp 2 Chirp
3 Chirp 4 Chirp 5 Chirp 6 Chirp
1Lock / Unlock Function 500ms 3.5sec
500ms L, DBL UL DBL L, 500ms UL DBL L, DBL UL 500ms L, 350ms UL
2 Ignition Lock OFF ON
3 Ignition Unlock OFF Unlock All
Unlock Driver
4 Exterior Illumination OFF With Arm
With Disarm With Arm & Disarm
5 Auto Relock OFF Auto Lock Only
Auto Lock & Arm
6 Auto Arming / Locking OFF Auto Arm Only
Auto Lock & Arm
7 Notification SoundBoth Siren
Horn
8 Horn Timing 16ms 30ms
40ms 50ms 10ms
9 Valet Override MethodValet Custom Code
Stand Alone Valet
10 Driver Priority Unlock OFF ON
11 Silent Choice OFF From Transmitter
OEM Style
12 Security ProfileAll On Doors off
Hood / trunk Off All Off
13 Door TriggerInputNegative Positive
14 Park Light / Trunk Swap OFF ON
15 Data Port Protocol ADSDBI
1 Chirp 2 Chirp
3 Chirp 4 chirp 5 Chirp 6 Chirp
1 Defrost OutputPulsed10min
RS Runtime
2 RS Start Notification ON OFF
3 RS Runtime 5min 10min
15min 20min 45min 60min
4 RS Parking Lights Steady Flashing
5 Engine Confirmation TachVoltage
Data Hybrid
6 Voltage Level >0.5v B4 Start <0.5v B4 Start
7 Ignition 2 OutputIgnition Accessory
Start
8 Ignition 3 OutputIgnition Accessory
Start
9 Accessory OutputAccessory Ignition
Start
10
Transmission Auto Manual
11 Max Crank Time 0.8sec1.0sec
1.5sec 2.0sec 3.0sec 4.0sec
12 Diesel Delay OFF Diesel 10
Diesel 15 Diesel 20 Diesel 30
13 Temperature Start OFF ON
14 Crank Duration Averaging Preset
15 RS Shock Override Shunt until ClearShunt RS Cycle
Shunt From TX
16 Turbo Timer OFF 3min
5min 10min
17 Start Activation Two PressOne Press
Three Press
18 RS Lock Function No ChangeUL Before L After
UL Before Start Lock After Start
19 Factory Disarm OutputSingle Pulse Double Pulse
350ms 500ms 800ms Same As Bank 2, F1
20 Additional Unlock Pulse No Pulse IGN, ACC, GWR
IGN,ACC,GWR,PASD
Features
Feature Bank 2
Options
Features
Feature Bank 3
Options
1 Second Pulse
10 Second Pulse
15 Second Pulse
20 Second Pulse
30 Second Pulse
Push & Hold
Latch ON/OFF
Latch 10min
Latch Runtime
5 Second Pulse
Ch. 4 AUX
Lock
Unlock
2nd Unlock
Trunk
Remote Start Status
Ignition
Pulse After Shutdown
Domelight
Headlight
Defrost
LED
Ch. 5 AUX
Ch. 6 AUX
Ch. 7 AUX
Pulse During Crank
Accessory
Factory Arm
Factory Disarm
2018 Voxx Electronics. All Rights Reserved.
Tach Programming
Dome Delay Programming
1Runtime Expired
2 Remote Shutdown
3 Brake On
4 Manual Mode
5 Hood Open
6Low / No Tach
7 Tach Programming
8High Tach
1 Shock
2 Trunk/ Hood
3 Door
Negave Output Control (NOC) AUX Output Control
Shock Sensor
The APS997Z includes two (2) programmed remotes. If required, addional remotes can
be programmed to the system. Remote Programming is located in Feature Bank 1. To enter
Remote Auto Programming:
1. Turn the ignion key to ON.
2. Press and release the valet buon 3x. System will beep and ash the parking lights 1x.
Press the lock buon on each remote. The system will beep 1x to indicate the remote has
been programmed. If programming one (1) buon remotes, press the Start buon. Only
primary remote funcons are auto programmed. This Includes Lock, Unlock, and Trunk/
Start.
If using AUX output control, the remote channel must be manually programmed to
the system AUX output. Please see the complete installaon guide for manual remote
programming instrucon.
Note: If programming 2-Way remotes, wait for remote to beep before programming
another remote. This beep is conrmaon that a 2-Way response has been received from
the main module.
Any AUX output can be congured using the AUX Control Menu. This feature is only
accessible via FlashLogic Weblink or Weblink Mobile.
Negave output control allows any NOC to be programmed for any one of nineteen (19)
opons. This feature is accessible via FlashLogic Weblink or Weblink Mobile.
Alarm
When the alarm is triggered the system will provide feedback to the user. Upon disarm,
the system will beep 4x and ash the LED to indicate the Alarm Trigger Zone.
Chirp Delete
System ARM/DISARM chirps can be toggled ON or OFF without entering the Feature
Bank programming.
1. Turn the ignion key ON/OFF.
2. Press and release the valet buon 3x.
The system will respond with one (1) chirp for ON and two (2) Chirps for OFF. This
feature will not aect alarm trigger or programming.
User Programmable LED
System LED nocaons can be turned ON or OFF without entering Feature Bank
programming.
1. Turn the ignion key ON/OFF, ON/OFF.
2. Press and hold valet buon for ve (5) seconds.
The LED will ash 1x for ON, 2x for OFF. This feature will not aect LED ash during
programming.
Remote Start
If the remote start fails to start the vehicle, the system will ash the vehicle parking
lights to indicate the cause.
The installer must manually congure the Engine Conrmaon method in Feature Bank
3, Feature 5. The default method is “Tach”. This method requires using the Green/Orange
tach input wire. When using the default “Tach” method, the vehicle tach rate must be
programmed. To enter tach rate programming:
1. Turn the ignion key ON.
2. Press and release the valet buon 3x.
3. Turn the ignion key OFF.
4. Press and hold valet buon.
5. While holding valet buon, start the engine using the key.
6. Hold the valet buon for approximately ten (10) seconds. If connected to the vehicle
Tach source, the system will ash the parking lights 1x every second.
7. Release the valet buon. The system will turn on the parking lights for two (2)
seconds to indicate the tach rate is programmed.
The APS997Z Feature Banks can be programmed by using the valet buon and remote. To
enter Feature Bank programming:
1. Turn the ignion key to ON.
2. Press and release the valet buon 3x. System will beep and ash lights 1x for Feature
Bank 1, Remote Programming.
3. Cycle ignion key OFF/ON. System will beep and ash lights 2x for Feature Bank 2.
4. Press valet buon to cycle features. LED will ash to display feature number.
5. Press lock buon to cycle opons. System will beep to indicate opon number.
6. Cycle ignion key OFF/ON. System will beep and ash lights 3x for Feature Bank 3.
7. Press valet buon to cycle features. LED will ash to display feature number.
8. Press lock to cycle opons. System will beep to indicate opon Number.
To exit Programming cycle ignion key OFF and wait ten (10) seconds. The System will also
automacally exit programming aer sixty (60) seconds of no acvity.
Important Update
The default Data Port Protocol of this system is ADS. If using an FLCAN or
other external integraon module be sure to choose iDatalink 2-Way when
ashing.
This system will also support DBI. This will require programming Feature
Bank 2, Feature 15 to DBI.
The shock sensor should be mounted to a solid surface in the center of the vehicle. Once
mounted the shock sensor will require adjustment.
To increase sensivity: Turn adjustment dial clockwise.
To decrease sensivity: Turn adjustment dial counter clockwise.
To test sensivity, strike the vehicle with an open palm. Adjust the dial to provide coverage
to as much of the vehicle as possible.
This system can be programmed to ignore the vehicle’s theater dimming dome light. This
feature will be used when connecng the door trigger input to the dome light circuit for
alarm trigger. Note: Vehicle windows should be open to prevent accidental locking of keys
in the vehicle.
Start with all doors closed and the vehicle dome light o.
1. Press Lock, Unlock, Lock, Unlock, Lock, Unlock, Lock. LED will light solid.
2. Open and close the driver door.
The system will monitor the dome light circuit. When the dome light turns o the system
will set the delay me and add an addional two (2) seconds.
Dome Delay Reset
1. Key ON/OFF, ON/OFF, ON/OFF.
2. Press and hold valet buon for ve (5) seconds.
The system will beep 1x to indicate reset is complete.
The Feature Banks below can also be programmed using the FlashLogic Weblink or Weblink Mobile.
Please visit www.FlashLogic.com for more detail.
