Technical data sheet for
ELECTRIC GRIDDLE 1200mm
GP8120E-B, GP8120E-CB, GP8120E-LS, GP8120E-RB
Heavy-duty thermostatic electric griddle
20mm thick griddle plate
Ribbed plate options
Chromed mirror plate options
Top weld sealed plates
16.2kW heating elements
Separate left, centre and right heat zones
3 models of base unit
1 model of ventilated refrigeration base with
drawer/door options
Stainless steel exterior
Easy clean
Easy service
Fully modular
Refrigerated Base (supplied as –RB model)
• Self contained suite matched modular base
• Ventilated system with R134a refrigerant
• -2˚to + 8˚C temperature (Tropical Climate rated)
• Two GN 1/1 drawers and one door standard
• 100mm deep pan drawer capacity
• Heavy-duty European telescopic drawer guides
• Magnetic drawer gaskets (replaceable without tools)
• 50mm fully foamed CFC free insulation
• 304 stainless steel exterior and interior
• Anti-corrosion treated evaporator
• No condensate drain required
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with
adjustable feet
• Condensing unit removable through front of unit for service
• Easy clean interior
Controls
Griddle
• Separate left, centre and right side heat zones
• Three 50-300˚C thermostats
• Large easy use control knob - heat resistant reinforced
• Easy view control settings on knob
• Indicator lights for power and heating
Refrigerated Base
• Digital control electronic thermostat
• Automatic defrost
• Automatic evaporation of defrost water
• -2˚to +8˚C temperature range
Cleaning and Servicing
• All models with easy clean stainless steel external finish
• Plate is finished front and rear with overlap construction to remove
cleaning traps
• Control service through front of unit
Overall Construction
Griddle
• 20mm thick machined top plates standard
• Optional ribbed plate sections
• Optional mirror finish hard chrome plates
• 2.5mm thick 304 stainless steel splash guards sides and rear
• 2.0mm thick grease channel
• Dual thermostatic control zones
• Welded hob surround with 1.5mm 304 stainless steel bull nose
• Splashback and side panels 1.2mm 304 stainless steel
• Front panels 0.9mm 304 stainless steel
• Stainless steel grease drawer
• Overlapping finish at front and rear of plate for easy clean
Bench mount (supplied as –B model)
• Four 63mm dia. heavy-duty 1.2mm 304 stainless steel bench legs
with adjustable feet.
• Adjustable height 80mm – 105mm
Cabinet base (supplied as –CB model)
• Fully modular for match suite finish
• Double skin 0.9mm 304 stainless steel interior and exterior
• Optional GN 1/1 4 position racking kit (1 or 2 cabinet bays)
• Up to eight 65mm GN 1/1 capacity
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with
adjustable feet
Leg stand (supplied as –LS model)
• Fully modular for matched suite finish
• Framed top for connection to Griddle
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with
adjustable feet
• Fully modular framed stand shelf with 0.9mm 304 stainless
steel finish
• Quick assembly design (no tools required)
GP8120E-LS

Australia
Moffat Pty Limited
Victoria/Tasmania
740 Springvale Road
Mulgrave, Victoria 3170
Telephone 03-951 3
Facsimile 03-951 3 33
[email protected]
New South Wales
Telephone [phone]
[email protected]
South Australia
Telephone 03-951 3
[email protected]
Queensland
Telephone [phone]
[email protected]
Western Australia
Telephone [phone]
[email protected]
New Zealand
Moffat Limited
Christchurch
Telephone [phone]
[email protected]
Auckland
Telephone [phone]
[email protected]
Australia
www.moffat.com.au
New Zealand
www.moffat.co.nz
ISO9001
All Waldorf products are designed and
manufactured by Moffat using the
internationally recognised ISO9001 quality
management system covering design
manufacture and final inspection ensuring
consistent high quality at all times.
ISO9001
Quality
Management
Standard
Designed and manufactured by
In line with policy to continually develop and
improve its products Moffat Limited reserves
the right to change specifications and design
without notice.
Specifications
Griddle
Elements
9 x 1.8kw stainless steel sheathed
heating elements
Electrical requirements
16.2kW
400-415Vac, 50/60Hz, 3P+N+E
Phase loading
L122.5A
L2 22.5A
L3 22.5A
Plate
Cooking surface 1192mm x 530mm, 6318cm2
Electrical connection
130mm from LH side, 32mm from rear,
and 655mm from floor
Refrigerated Base
Type
Ventilated system
Refrigerant
R134a (160grams)
Climate classification
T – tropical
Electrical connection
220-240Vac, 50Hz, 1.8A, 1P+N+E
3 pin 10A plug cordset fitted
Dimensions
Bench models
Width 1200mm
Depth 805mm
Height 315mm
Incl. splashback 530mm
All models (excluding Bench model)
Width 1200mm
Depth 805mm
Height 915mm
Incl. splashback 1130mm
Packing data
Bench and Leg Stand models
0.71m3
Width 1240mm
Depth 865mm
Height 665mm
Cabinet Base and Refrigerated Base models
1.37m3
Width 1240mm
Depth 865mm
Height 1255mm
Options at extra cost
Joining caps
Castors
Plinth mounting
Ribbed plate options
Chromed plate options
GP8120E-B
Bench Model
Printed in New Zealand
© Copyright Moffat Limited
Moffat/4639/BH/1M/8.05
Technical data sheet for
ELECTRIC GRIDDLE 1200mm
GP8120E-CB
Cabinet Base
GP8120E-LS
Leg Stand
GP8120E-RB
Refrigerated Base
