Wall-Smart WS FOR TSW-1050 BACK-INST User manual
www.wall-smart.com All rights reserved to Wall-Smart Ltd.
info@wall-smart.com Page 1/3
Wall-Smart wall mount preliminary installation instructions for
WS FOR TSW-1050 BACK-INST mounting adapter
D/N 10-04-163-INS REV. DATE
P/N 10-01-163 A 16/Mar./2014
Preliminary installation instructions for “WS FOR TSW-1050 BACK-INST” P/N 10-01-163 :
1. Route an opening in the wooden wall using the routing frame and a ¼” routing bit.
2. Insert (from the back of the wall), center (approximately) and retain the mounting adapter. Pay
attention to the correct up/down orientation of the mounting adapter.
www.wall-smart.com All rights reserved to Wall-Smart Ltd.
info@wall-smart.com Page 2/3
Back view: Front view:
3. Insert the TSW1050 touch screen and observe how much the adapter should be adjusted to make the
screen flush with the wall.
4. Remove the touch screen by pressing in the top edge of the touch screen.
www.wall-smart.com All rights reserved to Wall-Smart Ltd.
info@wall-smart.com Page 3/3
5. Adjust the depth of the mounting adapter by rotating the 4 screws visible in the front of the
mounting adapter.
6. Insert the touch screen and verify it is flush with the wall.
