Warm4Less Slimline Eco User manual

FarInfrared heating panel
Heat Your Home For Less
User’sManual
www.warm4less.com
Congratulations on your purchase of a warm4less infrared heating product.
It should give you many years trouble free service.

Rated voltage 220-240V/50Hz
Heating material Carbon crystal heating lm
Wave length 8-14μ
Surface temperature 75-90°C(front)
Electric conversion eciency 98.5%
Life expectancy ≥100,000H
Front surface material Powder Coated Aluminium
Ingress protection ration IP54
Over heat protection Yes
Application Commercial, domestic including bathrooms
Installation Wall, Ceiling or Free-standing
Certication CE,EMC,RoHS,SAA,and TUV (Rhineland)
Technicaldata
01
Safety guidance
The surface temperature of far infrared products is far less than for standard
latent heat products, but it is still necessary to exercise caution in use.
Pleasedo not cover the heating panel when in use or place it closer than 20cm (8”)to
curtains and other ammable objects in the home or workplace. Never use under a carpet.
If hanging from ceiling, a panel from our dedicated ceiling range is required. This range
comes with a ceiling xing kit as standard and will allow a safety gap of 2.5cm (1”) from the
ceiling. It is also recommended to position the panel at least 10 cm (4”)from ceiling lights.
Pleasedo not allow young children to play with this product.
Don’t place heavy weights on the panel or bend it out of shape.
Pleasetake care not to damage the power cord.
Whilst the panel is splash resistant, it is not suitable for exposure to continuous or frequent
water.
Do not dismantle the heater. Doing so will invalidate the warranty.
Slight vapour smell may be detectable when rst using the panel heater. Thisis normal and
will soon disappear.
Do not coil up the cable behind the heater.
Before mounting, please remove the blue plastic covering from the back of the heater. This
is purely just to avoid scratching/damageduring transit and is to be removed prior to using
the heater. Some panels may also have a clear plastic covering on the front which will also
need to be removed.

How to install
For wall xing.
For ceiling xing:
Use a paper or card template to mark position of holes for screws.Or measure
the distance between the xing holes on the rear brackets and mark their posi-
tion on the wall. Use a level to ensure the holes are horizontal.
01
02
It is required to use the ceiling xing kits included in the box with ceiling panels. Additional kits are
also available in our accessoriessection. It is not recommended to use the standard screws for wall
xings to mounting the ceiling.This kit will provide a much safer holding of the panel and will be
able to absorb vibration in the ceiling without risk of the panel sliding o the screwsheads.
When xing panels, it is a good policy to give careful consideration to positioning.
It is recommended that wall panels should not be too high or low on a wall, and for maximum eect
should not be obstructed by furniture or other objects.
Drill holes with suitable size masonry drill and insert raw plugs. For plasterboard,
where no wooden stud is found, it is recommended to use specialexpanding
raw plugs that will hold better.
02
02 Fix screws into raw plugs, leaving about 1cm proud, and mount the panel onto
them.
Warranty on your Warm4Less Heating panel
Free repair or replacement of this Warm4Lessheating product that develops an electrical fault within
the warranty period for your panel (refer to below),from the original invoice date of the purchase and
applies only to the name purchaser shown therein. It is required that you present a salesinvoice or
delivery note and must be returned properly packagedin original packagingor of equivalent
specication.
In the event that any of the following have been performed on the item, it will invalidate the
warranty:
1) Modication of the item in any way such as painting, sticking/attaching
objects/items onto it or cutting o the plug.*
2) Taking o any of the manufacturer’s stickers.
3) Carelessnessand negligence or malicious damage.
4) Taking apart the item/removing the rear electrical black box.
5) Transportation excluding the delivery to the customer.
6) Any damage from power surges/electrical outages/incorrect
fuse protection or lack of fused spur.

03
Warm4Less Ltd cannot accept responsibility for damage, loss or injury caused by accidental damage,
ingress of water, adjustment of specication,misuse and failure to follow recommended safety
advice precautions. Scratchesor other marks on product after sale are excluded from warranty, as is
any slight discoloration to polyethylene terephthalate surfaces.Any further claims or liability for loss
are excluded.
In the event you have purchased your product through an authorized third party and need to make
a claim, initial contact must be made to the original seller prior to contacting us.
*Unless otherwise using a fully qualied electrician and supplying a certicate of installation, correctly adhering to manufacturer’s
installation guidelines.
Warranty on our ranges:
Platinum White Range:5 Years
Gold White Range: 3 Years
Picture Panels: 3 Years
Bar Heaters: 3 Years
Controllers: 1 Years
Mirror and Glass Panels: 3 Years
For your warranty to be valid, please complete, sign and return to us the product’s warranty card.
This can be done by either post (address below) or via email to o[email protected]. From
receipt of the item/s you have 30 days to complete the warranty card. If you can’t nd
your warranty card copy please contact us at the earliest opportunity.
Warm4less Ltd
Unit 2A North End BusinessPark
Station road
Boston
LincsPE20 3PW
UK
For more information,
please visit our website
warm4less.com
Or call us on
01205 821 796
