Waters Fitness Tsunami Elite User manual

1section
INDOOR CYCLE OWNER’S MANUAL
ELITE/PRO/SPORT

3
Thank you for choosing WATERS FITNESS to assist you in meeting
your tness goals. The information in this manual will help you
with the assembly, operation and maintenance of your WATERS
FITNESS Indoor Cycle.
Please review this Owner’s Manual carefully before you use
your Indoor Cycle. As always, please check with your physician
before beginning any exercise program. Your new Indoor Cycle
is designed to provide active aerobic exercise, so it is possible
to over-exert yourself. If you experience chest pains, feel
faint, dizzy or have shortness of breath, stop exercising and
immediately consult a physician.
If you have any questions or require service on your Indoor Cycle,
your professional WATERS FITNESS Retailer would be more than
happy to assist you. Should your issue require more assistance
than your WATERS FITNESS Retailer can provide, please contact
us for further assistance.
Waters Fitness, LLC 740 Pierce St., Waterloo WI 53594
888.850.9973 f: 262.923.1000 www.waterstness.com

4 www.waterstness.com
Warranty
WATERS FITNESS warrants to the original owner that our products
will be free of all defects in materials and workmanship.
Frame – 10 years
Parts – 3 years
Wear Items, such as pedals, seat, and brake pad – 1 year
Labor – 1 year
Stated warranty periods are from the date of original purchase.
Warranty is valid only in Canada and the United States of America.
Limitations and Exclusions
This warranty only applies to the original owner. This warranty
is expressly limited to the repair or replacement of a defective
frame or defective part and is the sole remedy of the warranty.
This warranty does not apply to any defects caused by normal
wear and tear, negligence, misuse, accident, alteration, improper
maintenance or discoloration/cosmetic damage of paint or
plastic. WATERS FITNESS shall not be responsible for incidental
or consequential damages. Any replacement part shall be
warranted for the remainder of the original warranty term.
WATERS FITNESS expressly disclaims all other warranties,
expressed or implied, in connection with the sale, service, or
shipment of our products. This warranty gives you specic rights,
and your rights may vary from state to state.
Important Information to Retain in your Records.
1) Copy of Sales Receipt
2) Model Name
3) Serial #
4) Date Purchased

5table of contents
Table of Contents
Warranty ............................................................ 4
Safety Instructions ................................................ 6
Assembly.......................................................... 7-9
Installing the Front Foot ............................... 7
Installing the Rear Foot ................................ 7
Installing the Handlebar Assembly .................... 8
Installing the Seat Assembly ........................... 8
Installing the Pedals .................................... 9
Installing the Water bottle Cage ...................... 9
Operational Instructions .................................... 10-12
Seat Adjustments ....................................... 10
Handlebar Adjustments................................ 10
Pedal Strap Adjustments .............................. 11
Resistance Control ..................................... 11
Dismounting the Indoor Cycle ........................ 12
Preventative Maintenance ...................................... 12
Warranty Registration ........................................... 13

6safety instructions
Safety Instructions
Important: Read all safety instructions before using the Indoor Cycle.
1. Keep children off the Indoor Cycle at all times.
2. Keep children and pets away from the Indoor Cycle while in use.
3. The maximum weight on the Indoor Cycle is 350 lbs.
4. Ensure all adjustment knobs (seat & handlebar) are properly set
and allow for proper range of motion during exercise.
5. Keep hands or feet away from all moving parts, including the
ywheel and drive system. Never attempt to turn the pedal
cranks by hand.
6. The Indoor Cycle has a weighted ywheel with a xed gear,
which means that the pedals will continue to turn as long as
the ywheel is still moving. To stop the unit quickly, push down
on the resistance knob to stop the ywheel. Do not attempt to
remove your feet from the pedals while they are in motion.
7. Always maintain control of the ride. Practice any technique at
slower speeds before executing at faster speeds.
8. If you experience chest pains, feel faint, dizzy or have shortness
of breath, stop exercising and immediately consult a physician.
9. Wear proper footwear when using the Indoor Cycle; never
operate with bare feet.
10. Only use the Indoor Cycle on level, stable ooring.

7assembly
Assembly
1) Install the Front Foot
Using the 5mm Allen key and a 13mm open end wrench, attach
the front foot using the bolts, washers and nuts provided. The
wheels on the foot should be facing forward.
2) Install the Rear Foot
Using the 5mm Allen key and a 13mm open end wrench, attach
the rear foot using the bolts, washers and nuts provided.

8www.waterstness.com
3) Installing the Handlebar Assembly
Tsunami Elite/Pro: Make sure the
Quick Release handle is in the up
position (loose) prior to installing
the handlebar assembly.
Slide the handlebar post into the
front frame opening; the handlebar
should be facing forward. Make
sure the handlebar post is into the
frame deeper than the minimum
insertion mark. Tighten the
handlebar assembly into the frame
by closing the Quick Release handle
(push it down).
Tsunami Sport: Insure the
adjustment pin is seated into a
hole and tighten the adjustment
knob clockwise when tightening
the handlebar.
4) Installing the Seat Assembly
Tsunami Elite/Pro: Make sure the
Quick Release handle is in the up
position (loose) prior to installing
the seat assembly.
Slide the seat post into the back
frame opening; the seat should
be facing forward. Make sure the
seat post is into the frame deeper
than the minimum insertion mark.
Tighten the seat assembly into
the frame by closing the Quick
Release handle (push it down).
Tsunami Sport: Insure the
adjustment pin is seated into a
hole and tighten the adjustment
knob clockwise when tightening
the seat assembly.

9assembly
5) Installing The Pedals
Important: Each pedal is marked
with either an “R” (right) or an
“L” (left) on the pedal shaft.
Installing the pedal on the wrong
side of the bike may damage the
pedals and/or the crank arms.
An easy way to know if you are
attaching the pedals properly is to
always thread the pedals towards
the front of the bike. Pedals are
designed this way so they don’t
loosen during use. Be careful to
align the treads properly to avoid
damage.
Using the 15mm open end wrench,
tighten the pedals rmly.
6) Installing The Water Bottle Cage
The water bottle screws are already
attached to the frame. Simply
remove them with a 4mm Allen key
and reinstall them with a cage.

10 www.waterstness.com
Operational Instructions
1) Seat Adjustments
The easiest way to start this
adjustment is to stand next to the
bike and raise the seat to hip height.
Mount the bike and check to see if
you have a slight bend in your knee
when the pedal is in the 6 o’clock
position. Once you have the correct
height, it is time to review the fore/
aft position of the seat. The proper
fore/aft position is when your
knee is over the pedal axle in the
3 o’clock pedal position. After you
complete the fore/aft adjustment,
you may need to review the seat
height one more time to insure
proper positioning.
2) Handlebar Adjustments
Handlebar height is really a matter of preference. It is best to
start with a height similar to the seat. If a more comfortable
position is desired, move the handlebar higher to achieve a more
upright position. Many experienced bike riders may prefer a
lower handlebar setting which places them in a prone position
similar to their road bike. On the fore/aft positioning of the
handlebar, it is generally recommended that your arm is at a 90
degree angle when in a triathlon tuck position. A more aggressive
position would put your arms further in front of you.

11operational instructions
3) Pedal Strap Adjustments
The balls of your feet should be positioned over the axle of the
pedal. Rotate the pedals until one of your feet is in the 12 o’clock
position. Pull on the strap so it tightens the clip snugly against
your shoe. Repeat this process with the other foot. To loosen the
clip, simply push outward on the adjustment tab.
4) Manual Resistance Control
Pedaling resistance is controlled
by the resistance knob behind
the handlebars. Resistance can
be adjusted while riding by
simply turning the knob. To
increase resistance, turn the
knob clockwise; to decrease
resistance, turn the knob coun-
ter-clockwise. To quickly stop the
ywheel, press down directly on
the resistance knob.
Magnetic Resistance Control
on the Tsunami Elite – see
supplemental manual provided
with this model.

12 www.waterstness.com
5) Dismounting the Cycle
This product has a weighted ywheel with a xed gear, meaning
the pedals will continue to turn as long as the ywheel is still
moving. To stop the ywheel, push down on the resistance knob.
Once the pedals have stopped moving, it is safe to dismount
the cycle.
Important: Do not attempt to remove your feet from the pedals
while they are in motion.
Preventative Maintenance
Daily – Wipe down the cycle at the end of each usage. This will
keep the unit clean and prevent rust/corrosion. It is best to
use a liquid non-abrasive cleaner. It is also best to remove the
resistance tension from the ywheel after each usage by turning
the resistance knob counter-clockwise.
Weekly – Inspect and tighten all bolts, assemblies and parts.
Monthly – Inspect frame for rust/corrosion and wear items
for adjustment. Frame should receive a complete inspection
including a tilt-up to view the bottom side of the Indoor Cycle.
Remove any rust with a cloth or small brush. Wear items such as
pedals, seat, and brake pad should be inspected for adjustment
or replacement.

13warranty registration
WATERS FITNESS Warranty Registration
Please complete and return this Warranty Registration Card
within 30 days of receipt.
Last Name
First Name
Address
City
State
Country
Postal Code
Phone Number
Email Address
Date Purchased
Serial Number
Purchased From
City
State
Signature of Purchaser
Detach and mail to WATERS FITNESS.

Place
Stamp
Here
Waters Fitness, LLC 740 Pierce Street, Waterloo WI 53594

Waters Fitness, LLC 740 Pierce St., Waterloo WI 53594
888.850.9973 f: 262.923.1000 www.waterstness.com
