WaveBox WBP-TP-660 User manual

1
The WaveBox®
The world’s rst portable microwave oven
with removable cooler
and exclusive Tri-Power capability
Model No. WBP-TP-660
871125254949 Wavebox Manual UK.indd 1 08-10-14 15:59

2
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
1. Do not attempt to operate this oven with the door open since open-door ope-
ration can result in harmful exposure to microwave energy. It is important not
to defeat or tamper with the safety interlocks.
2. Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is particularly important that the
oven door close properly and that there is no damage to the:
a) Door (bent).
b) Hinges and latches (broken or loosened).
c) Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except properly qua-
lied service personnel.
871125254949 Wavebox Manual UK.indd 2 08-10-14 15:59

3
Contents
Features......................................................................................................................... 4
Important Safety Instructions........................................................................................ 5
Unpacking and Accessories .......................................................................................... 8
Installation..................................................................................................................... 9
Operation..................................................................................................................... 10
Cooking Times............................................................................................................ 13
Safety .......................................................................................................................... 13
Care and Cleaning....................................................................................................... 14
Troubleshooting .......................................................................................................... 15
Specications .............................................................................................................. 16
871125254949 Wavebox Manual UK.indd 3 08-10-14 15:59

4
Features
• Lightweight,compact,andcompletelyportable
• DCdirecttobattery
• Builttowithstanddailyportability
• Removablecoolersystem
• Heavydutyhandlesystem
• DirecttoBatteryDCCablewithtwoalligatorclamps
• PowerOutletDCCablewithacigarettelighterplug
• LEDdisplay
871125254949 Wavebox Manual UK.indd 4 08-10-14 15:59

5
IMPORTANT SAFETY INSTRUCTIONS READ
CAREFULLY AND KEEP FOR FUTURE REFERENCE
1. ReadallInstructionsbeforeusingthisappliance.
2. Readandfollowthespecic“PRECAUT IONS TO AVOID POSSIBLE EX-
POSURE TO EXCESSIVE MICROWAVE ENERGY” found on page 2.
3. This appliance must be grounded. Connectonly to a properly grounded outlet.
See“GROUNDINGINSTRUCTIONS”foundonpage8.
4. Install or locate this appliance only in accordance with the provided installation
Instructions.
5. Someproductssuchaswholeeggsandsealedcontainers-forexample,closed
glass jars-are able to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as described in this manual. Do not
use corrosive chemicals or vapors in this appliance. This type of oven is spe-
cicallydesignedtoheat,cook,ordryfood.Itisnotdesignedforindustrialor
laboratory use.
7. Aswithanyappliance,closesupervisionisnecessarywhenusedbychildren.
8. Donotoperatethisapplianceifithasadamagedcordorplug,ifitisnotworking
properly,orifithasbeendamagedordropped.
9. This appliance should be serviced only by qualied service personnel. Contact
thenearestauthorizedservicefacitityforexamination,repairoradjustment.
10. Do not cover or block any openings or vents on this appliance.
11. Do not store this appliance outdoors. Do not use this product near water for
example,nearakitchensink,inawetbasement,nearaswimmingpool,orsimi-
lar locations.
12. Do not immerse cord or plug in water.
13. Keep cord away trom heated surfaces.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that comes together on closing the
door,useonlymild,nonabrasivesoapsordetergentsappliedwithaspongeor
soft cloth.
16. To reduce the risk of re in the oven cavity:
 (a)Do not overcook food. Carefully attend appliance when paper, plastic, or
other combustible materials are placed inside the oven to facilitate cooking.
871125254949 Wavebox Manual UK.indd 5 08-10-14 15:59

6
 (b)Removewiretwist-tiesfrompaperorplasticbagsbeforeplacingbaginoven.
Do not heat Chinese food containers or foil lined bags.
 (c)Ifmaterialsinsidetheovenignite,keepovendoorclosed,turnovenoff,and
disconnectthepowercord,orshutoffpoweratthefuseorcircuitbreaker
panel.
 (d)Donotusethecavityforstoragepurposes.Do notleavepaperproducts,
cookingutensils,orfoodinthecavitywhennotinuse.
17. Liquids,suchaswater,coffee,orteaareabletobeoverheatedbeyondtheboi-
ling point without appearing to be boiling. Visible bubbling or boiling when the
container is removed from the microwave oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILNG
OVER WHEN THE CONTAINER IS DISTURBED OR A SPOON OR
OTHER UTENSIL IS INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
(a) Do not overheat the liquid.
(b) Stir the liquid both before and halfway through heating it.
(c) Do not use straight-sided containers with narrow necks.
 (d)Afterheating,allowthecontainertostandinthemicrowaveovenforashort
time before removing the container.
(e) Use extreme care when inserting a spoon or other utensil into the container.
871125254949 Wavebox Manual UK.indd 6 08-10-14 15:59

7
WARNING: When the appliance is operated in the combination mode, children
should only use the oven under adult supervision due to the temperatu-
res generated; Children should be supervised to ensure that they do not
play with the appliance.
WARNING: Ifthedoorordoorsealsaredamaged,theovenmustnotbeoperated
until it has been repaired by a competent person.
WARNING: It is hazardous for anyone other than a competent person to carry out
any service or repair operation that involves the removal of a cover
which gives protection against exposure to microwave energy.
WARNING: Liquidsandotherfoodsmustnotbeheatedinsealedcontainerssince
they are liable to explode.
WARNING: Only allow children to use the oven without supervision when adequate
instructions have been given so that the child is able to use the oven in
a safe way and understands the hazards of improper use.
• Theminimumheightoffreespacenecessaryabovethetopsurfaceoftheovenmust
be more than 30 cm;
• onlyuseutensilsthataresuitableforuseinmicrowaveovens;
• whenheatingfoodinplasticorpapercontainers,keepaneyeontheovenduetothe
possibility of ignition;
• ifsmokeisobserved,switchofforunplugtheapplianceandkeepthedoorclosedin
order to stie any ames;
• microwaveheating ofbeveragescan result in delayederuptiveboiling, therefore
care must be taken when handling the container;
• thecontentsoffeedingbottlesandbabyfoodjarsshallbestirredorshakenandthe
temperaturecheckedbeforeconsumption,inordertoavoidburns;
• eggsintheirshellandwholehard-boiledeggsshouldnotbeheatedinmicrowave
ovenssincetheymayexplode,evenaftermicrowaveheatinghasended;
• theovenshouldbecleanedregularlyandanyfooddepositsremoved;
• failuretomaintaintheoveninacleanconditioncouldleadtodeteriorationofthe
surface that could adversely affect the life of the appliance and possibly result in a
hazardous situation;
• ifthesupplycordisdamaged,itmustbereplacedbythemanufacturer,itsservice
agent or similarly qualied persons in order to avoid a hazard;
• Thetemperatureofaccessiblesurfacesmaybehighwhentheapplianceisoperating;
• Thisapplianceisnotintendedforusebypersons(includingchildren)withreduced
physical,sensoryormentalcapabilities,orlackofexperienceandknowledge,un-
less they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety;
• Thisapplianceisintendedtobeusedfreestanding.
871125254949 Wavebox Manual UK.indd 7 08-10-14 15:59

8
Unpacking and Accessories
Unpackallaccessoriesfrominsidethecookingcavity,including:
■Cooler Insert
■DC Direct To battery Cable
■DC Power Outlet Cable
■CookingRack
Store the 2 DC cables in a convenient location to be used with any DC battery source.
Use the cooler insert to pack food and beverage inside the cooking cavity and keep it
cold until you are ready to heat things up. The included cooking rack improves cooking
performance and is especially designed for microwave popcorn.
Correct Disposal of this product
This marking indicates that this product should not be disposed with
otherhouseholdwastesthroughouttheEU.
To prevent possible harm to the environment or human health from
uncontrolledwastedisposal,recycleitresponsiblytopromotethesus-
tainablereuseofmaterialresources.Toreturnyouruseddevice,please
use the return and collection systems or contact the retailer where the
product was purchased. they can take this product for environmental
safe recycling.
NOTE: DONOTstoretheDCcablesandACcordinthecoolerinsertastheymay
become soiled with use. They were placed in the cooler insert for initial trans-
portation purposes only.
NOTE: Use of the cooking rack in all cooking modes will enable faster heating of
items.
871125254949 Wavebox Manual UK.indd 8 08-10-14 15:59

9
INSTALLATION
1. Steady,atlocation:Whenpositioningthemicrowaveoven,itshouldbesetonaat,
steady surface.
2. Ventilation:Donotblockairvents.Iftheyareblockedduringoperation,theoven
mayoverheatandeventuallycauseovenfailure.Forproperventilation,keep3in-
chesofspacebetweentheoven’stop,sides,rearandtheareaswheretheunitistobe
installed.
3. RadioandTVreception:Poortelevisionreceptionandradiointerferencemayresult
iftheovenislocatedclosetoaTV,radio,antennaorantennawire.Positlontheoven
as far from them as possible.
A. A short power supply cord is provided to reduce the risks resulting from beco-
ming entangled in or tripping over a longer cord.
 B.Longercordsetsorexercisedcordsareavailableandmaybeusedifcareisexer-
clsed in their use.
C. If a long cord or extension cord is used. (1)the marked electrical rating of the cord
set or extension cord should be at least as great as the electrical rating of the ap-
pliance. (2)the extension cord must be a grounding type 3 wire cord and. (3)the
longer cord should be arranged so that it will not drape over the counter top or
tabletop where it can be pulled on by children or tripped over unintentionally.
4. Examinetheovenforanydamagesuchas:Dents,amisaligneddoor,brokendoor
oradentinthecavity.Ifanyoftheabovearevisible, DO NOT INSTALL THE
UNIT. Notifythedealerimmediately.
871125254949 Wavebox Manual UK.indd 9 08-10-14 15:59

10
Operation
-OR-
DC Battery direct connect:Use ONLYthesupplied DCdirectconnectcablewith
“alligator”clipstoconnectdirecttoany12Vautomotiveormarinetypebattery.This
power source delivers optimum performance.
-OR-
DC power outlet connect:UseONLYthesuppliedDCpoweroutletcabletoconnect
thruanystandard12Vpoweroutlet(20Aminimum)or“cigarettelighterconnection”in
yourvehicle.Thispowersourceisveryconvenient,butsacricessomecookingspeed.
NOTE: A SPARK MAY OCCUR WHEN CONNECTING THIS MICROWA-
VE TO A POWER SOURCE. THIS IS A NORMAL PHENOMENON AND
DOES NOT INDICATEA DEFECTIVE APPLIANCE.
Please only connect to a DC power outlet rated at 20amps or higher. Information on the
amp rating for all your vehicle’s power outlets can be found in the users manual under
“fusediagram”.TheWaveBoxisbuilttobeoperatedwiththevehiclerunningtoreduce
theriskofunintendedbatterydrain,andtodelivermaximumcookingpower.
NOTE: DonotconnecttheWaveBox®to morethan asinglepowersourceatany
giventime.Itwillnotoperate.AfterconnectingyourWaveBox®toasingle
powersource,theunitwillbeeptoletyouknowitisreadyforuse,displaying
zerosinthedisplaywindow.TheWaveBox®isnowreadyforoperation.
NOTE: ForDCoperationbesuretomaintaincorrectpolarity.TheWaveBoxwillnot
operatewithreversepolarity.Torectify,simplyconnectusingcorrectpolarity.
Redalligatorcliptopositive(+)batterypost,andBlackalligatorcliptonega-
tive(-)battery post.
Someforeigncarsandtrucksemployapositivegrounddesign.TheWaveBoxwillnot
operateusingapositivegroundconnection.Ifindoubt,consultwithyourvehicle’sdea-
lership.
Whenconnectingtoanautomobile,smalltruck,boatorvan,theengineshouldberun-
ning in order to prevent discharge of the battery to a point where the vehicle will not
start.Connectthealligatorclipstothevehicle’sbattery,startthevehicle’sengine,and
thenoperatetheWaveBox.TodisconnecttheWaveBox,shutoffthevehicle’sengine,
and remove the alligator clips from the vehicle’s battery. Do not connect or disconnect
the alligator clips with the engine running.When connecting to large trucks, motor
homes or buses the unit may be used without running the engine.
CAUTION: NOT FOR USE IN AIRCRAFT.
871125254949 Wavebox Manual UK.indd 10 08-10-14 15:59

MINUTE SECOND
2 MIN
3 MIN
6 MIN
START/STOP
2 MIN
3 MIN
6 MIN
11
Control Panel
Count down
Cooking timer
(20 min.max.)
Cook time buttons
pre-set time buttons
for popular foods
start/stop button
Controls oven
operation and Child
loCk feature
pull forward to
open oven door
CAUTION: Donotplaceanyobjectsonthedoorwhileitisopen,Damagetothedoor
sealing surfaces may result.
871125254949 Wavebox Manual UK.indd 11 08-10-14 15:59

12
Setting cooking times manually
Press the “Minute”buttononce,andthecookingtimewillbesetforoneminute,with
the Display Window showing “01:00”; Press the “Minute”buttontwice,andthecoo-
kingtimewillbesetfortwominutes,withtheDisplayWindowshowing“02:00”. The
maximum time that can be set by the “Minute” button is 20 minutes.
Press the “Second”buttononce,andthecookingtimewillbesetfor5seconds,withthe
Display Window showing “00:05”;Pressthe“Second”buttontwice,andthecooking
timewillsetfor10seconds,withtheDisplayWindowshowing“00:10”. The maximum
time that can be set by the “Second” button is 55 seconds.
Youmaypressandholdthe“Minute” or “Second” button for 2 seconds and the timer
will automatically increase in increments.
Oncethecookingtimehasbeenset,pressthe“Start/Stop” button once and the Wave-
Box®willbegintowork.
Attheendofthecookingtime,theWaveBoxwillbeepsixtimestosignalthatcooking
has nished.
Ifyouwanttostopcookingpriortotheendofthecookingtime,simplypressthe“Start/
Stop”buttononceandtheWaveBox®willstopcooking.
NOTE: TheWaveBox®isbuiltwithanABSplasticshellwithcompactdesignfor
portability.Aftereachcookingoperationiscompleted,theinternalfanwill
continue to operate for a few more minutes to cool down the system. Then the
fanwillstop.ThisnormaldooropenfanoperationfortheWaveBox®.does
notmeanthattheunitisdefective.PleasedonotreturntheWaveBox®toyour
retailer/distributor due to this unique fan operation.
Child Lock
Forthesafetyofchildren,parentscanpressandholdthe“Start/Stop” button for 5 se-
conds,and“OFF”willbeshownontheDisplayWindow,lockingallbuttons.
Tounlockallbuttons,parentsmustpressandholdthe“Start/Stop” button again.
871125254949 Wavebox Manual UK.indd 12 08-10-14 15:59

13
Cooking Times
Cooking times in DC direct connect mode are excellent.
Some cooking speed is sacriced when using DC power outlet mode due to the wiring
ratings of most automobiles and boats. DC power outlet mode requires power outlet
amperageof20ampsorgreater.Seethe“fuseschart”inyourvehicle’sownersmanual
to determine the amperage of your power outlet system.
Safety
• Readallinstructionsbeforeusingtheappliance.
• Donotattempttousethisovenwiththedooropensincethiscanresultinexposure
to microwave energy.
• Donotinterfereortamperwiththesafetysystemsonthisunit.
• Donotplaceanyobjectbetweentheovenfrontfaceandthedoor.
• Donotoperatetheovenifitisdamaged.Itisnecessaryforthedoortocloseproperly
andthatthereisnodamagetothehingesystem,latch,orseal.
• Theovenshouldnotbeservicedbyanyoneotherthanaproperlyqualiedappliance
service technician.
• Sealedglassjarsmayexplodewhenheatedandshouldnotbeheatedinthisoven.
• Usethisovenonlyforitsintendeduse,whichistoheat,cook,ordryfood.Itisnot
designedforanyotheruse,suchasindustrialorlaboratorywork.
• Thisproductisnotforusebychildren.Adultsupervisonisalwaysnecessary.
• Donotoperatethisovenifithasadamagedcord,plug,orcasing.
• Donotcoverorblocktheventilationports.
• Donotimmersecordorunitinwater.
• Donotletcordshandoveredgeoftableorcounter,ornear/onheatedsurfaces.
• Intheunlikelyeventthatmaterialsinsidetheovenshouldignite,keepovendoor
closed,turnovenoff,anddisconnectfromthepowersource.
• Donotusemetalliccookwareintheoven.Useoftheincludedcookingrackisac-
ceptable.
• Donotoperatetheovenwiththecoolerinsertinsidethecavity.
• Donotoperatetheovenwhenitisempty.
• Donottouchinteriorcookingcavitywallsastheymayburn.
871125254949 Wavebox Manual UK.indd 13 08-10-14 15:59

14
• Whenopeningtheovendoor,standatarmslengthashotairorsteammaycause
scalding.
• Donotheatbabyfoodinclosedjars,eggsinshell,nutsorseedsinshell,disposable
bottles,orbottleswithnippleson.
• Alwaysusecautionwhenremovingheatedfoodsandbeveragesfromtheovenas
theseitemsmaybeexcessivelyhotandcauseburns.Letitemsstandandcoolafter
cooking.
CAUTION: After extendedcookingperiodswhileusingthe cookingrack,therack
may become hot to the touch. Please wait a few seconds after ending coo-
king to touch the rack.
CAUTION: NeverusetheWaveBoxwhileoperatingamovingvehicle.Useonlywhen
stationary.
Care and Cleaning
Exterior
Cleanwithmildsoapandwater,rinseanddrywithasoftcloth.Donotuseanyhouse-
holdorabrasivecleaner.Donotimmerseinwater,orgetwaterintheexteriorvents.
Interior
Wipe with a soft cloth and warm water. Do not use any household or abrasive cleaner.
Foranytoughresidue,usebakingsodaandwarmwater.
DO NOT USE ANY OVEN CLEANERS INSIDE THE OVEN.
Door Seals
Alwaysmakesurethatdoorsealsarecleananddebrisfree,allowingthedoortoseal
well.
871125254949 Wavebox Manual UK.indd 14 08-10-14 15:59

15
Troubleshooting
Ifyouhaveanyoftheseproblems,pleasetrythesolutionsgiven.
•Theovendoesnotstart
o Is the door completely closed?
o Is the oven connected to a suitable single power source?
•Thefoodorbeveragesdonotheat
o Is the door completely closed?
o Check the fuse in your AC or DC power system. Do not attempt to check the
fuse inside this microwave oven. Servicing must be performed only qualied
service personnel.
 oIfusingpoweroutletmode,makesurethevehiclewiringisratedat20amps
or greater.
•Thefoodiseitherover-cookedorunder-cooked
o Was the appropriate cooking time selected?
•Sparkingisoccurringinsidetheoven
o Have you put metal inside?
o Is a utensil inside?
o Is aluminum foil inside?
NOTE: ForDCoperationbesuretomaintaincorrectpolarity.TheWaveBox®willnot
operatewithreversepolarity.Torectify,simplyconnectusingcorrectpolarity:
redalligatorcliptopositive(+)batterypost,andBlackalligatorcliptonega-
tive(-) battery post.
Someforeigncarsandtruckemploya positivegrounddesign.TheWaveBox®will
notoperateusingapositivegroundconnection.Ifindoubt,consultwithyourvehicle’s
dealership.
Ifyoucannotgettheunittofunctioncorrectly,contactus.
871125254949 Wavebox Manual UK.indd 15 08-10-14 15:59

16
Specications
(see product spec lable on rear panel)
DC Voltage: 24V
Input Current:
  DCBatteryDirect.....................15A
DC Power Outlet.....................27.5A
Output Power:
  DCBatteryDirect....................425W
DC Power Outlet..................... 155W
  (at2,460MHZ)
Weight: 7.5 kgs
NOTE: Unauthorized modications to this device could void the user’s authority to
operate it.
871125254949 Wavebox Manual UK.indd 16 08-10-14 15:59

1
The WaveBox®
Die weltweit erste tragbare Mikrowelle
mit abnehmbarem Kühler
und exklusiver Tri-Power-Funktion
Model No. WBP-TP-660
WaveBox®
871125254949 Wavebox Manual DE.indd 1 08-10-14 16:03

2
VORSICHTSMASSNAHMEN, UM EINE MÖGLICHE BELASTUNG
DURCH ÜBERMÄSSIGE MIKROWELLENENERGIE ZU VERMEIDEN
1. Versuchen Sie nicht, die Mikrowelle bei geöffneter Tür zu betreiben, da dies
zu schädlichen Belastungen durch Mikrowellenenergie führen kann. Die Si-
cherheitsverriegelung darf nicht umgangen oder manipuliert werden.
2. Stellen Sie keine Objekte zwischen die Vorderseite der Mikrowelle und die
Tür, und stellen Sie sicher, dass sich kein Schmutz und keine Reinigungsmit-
telrückstände an den Türdichtungen oder anderen Dichtungen ansammelt.
3. Verwenden Sie die Mikrowelle nicht, falls diese beschädigt ist. Es ist bes-
onders wichtig, dass die Tür der Mikrowelle richtig schließt und dass keine
Schäden vorliegen, insbesondere an:
a) Tür (z. B. Verbiegen/Verzug).
b) Scharnieren und Verriegelungen (z. B. defekt oder locker).
c) Türdichtungen und Dichtächen.
4. Die Mikrowelle darf nur von qualiziertem Kundendienstpersonal einge-
stellt oder repariert werden.
871125254949 Wavebox Manual DE.indd 2 08-10-14 16:03

3
Inhaltsverzeichnis
Einführung ................................................................................................................... 2
Merkmale ...................................................................................................................... 4
Wichtige Sicherheitshinweise....................................................................................... 5
Auspacken und Zubehör ............................................................................................... 9
Erdung und Installation............................................................................................... 10
Verwendung ................................................................................................................ 13
Zubereitungszeiten...................................................................................................... 15
Sicherheit .................................................................................................................... 16
Reinigung und Pege.................................................................................................. 17
Störungssuche ............................................................................................................. 18
Technische Daten........................................................................................................ 19
Garantie ..........................................................................................................................
871125254949 Wavebox Manual DE.indd 3 08-10-14 16:03

4
Merkmale
• Leicht,kompaktundabsolutmobil
• EntwickeltfürdentäglichenmobilenEinsatz
• AbnehmbaresKühlsystem
• BesondersrobustesGriffsystem
• KabelmitzweiKrokodilklemmenfürAnschlussdirektanBatterie
• KabelmitSteckerfürZigarettenanzünder
• LED-Anzeige
871125254949 Wavebox Manual DE.indd 4 08-10-14 16:03
