WaveRider MMT9000 User manual

MMT9000
Installation Guide
APCD-WM001-1.0

:
APCD-WM001-1.0 ii
Copyright
© 2005 by WaveRider Communications Inc. You
may copy and/or print as many copies of this manual
as you wish, as long as the software license
agreement and this copyright statement are included.
Vers. 1.0, July 2005
The following are trademarks or registered trademarks of their respective companies or organi-
zations:
Windows XP/Microsoft
Windows 2000/Microsoft

:
APCD-WM001-1.0 iii
Software License Agreement
This is a legal agreement between you (either an individual or an entity) and WaveRider Communica-
tions Inc. for the use of WaveRider computer software, hereinafter the “LICENSED SOFTWARE”.
By using the LICENSED SOFTWARE installed in this product, you acknowledge that you have
read this license agreement, understand it, and agree to be bound by its terms. You further
agree that it is the full and complete agreement between you and WaveRider Communications
Inc., superseding all prior written or verbal agreements of any kind related to the LICENSED
SOFTWARE. If you do not understand or do not agree to the terms of this agreement, you will
cease using the LICENSED SOFTWARE immediately.
1. GRANT OF LICENSE—This License Agreement permits you to use one copy of the LICENSED
SOFTWARE.
2. COPYRIGHT—The LICENSED SOFTWARE is owned by WaveRider Communications Inc. and
is protected by copyright laws and international treaty provisions; therefore, you must treat the
LICENSED SOFTWARE like any other copyrighted material (e.g., a book or magazine).
3. LIMITS OF FEATURE AVAILABILITY—The LICENSED SOFTWARE is sold with limitations as
to certain feature availability and use. These limits are governed by the terms of the purchase
agreement. Any actions resulting in the exceeding of these limits is not permitted, and can result
in unpredictable performance.
4. OTHER RESTRICTIONS—You may not rent or lease the LICENSED SOFTWARE. You
may not reverse engineer, decompile, or disassemble the LICENSED SOFTWARE.
5. LIMITED WARRANTY—The LICENSED SOFTWARE is provided “as is” without any warranty of
any kind, either expressed or implied, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. The entire risk as to the quality and
performance of the LICENSED SOFTWARE is with you, the licensee. If the LICENSED
SOFTWARE is defective, you assume the risk and liability for the entire cost of all necessary
repair, service, or correction.
Some states/jurisdictions do not allow the exclusion of implied warranties, so the
above exclusion may not apply to you. This warranty gives you specific legal
rights, and you may have other rights, which vary from state/jurisdiction to state/
jurisdiction.
WaveRider Communications Inc. does not warrant that the functions contained in
the LICENSED SOFTWARE will meet your requirements, or that the operation of
the LICENSED SOFTWARE will be error-free or uninterrupted.
6. NO OTHER WARRANTIES—To the maximum extent permitted by applicable law, WaveRider
Communications Inc. disclaims all other warranties, either express or implied, including, but not
limited to, the implied warranties of merchantability and fitness for a particular purpose, with
regard to the LICENSED SOFTWARE and the accompanying written materials.
7. NO LIABILITY FOR CONSEQUENTIAL DAMAGES—To the maximum extent permitted by
applicable law, in no event shall WaveRider Communications Inc. or its suppliers be liable
for any damages whatsoever (including, without limitation, damages for loss of business
profits, business interruption, loss of business information, or any other pecuniary loss)
arising from the use of or inability to use the LICENSED SOFTWARE, even if WaveRider
Communications Inc. has been advised of the possibility of such damages, or for any claim
by any other party.
Because some states/jurisdictions do not allow the exclusion or limitation of liability for
consequential or incidental damages, the above limitation may not apply to you. In no event will
WaveRider’s liability exceed the amount paid for the LICENSED SOFTWARE.

:
APCD-WM001-1.0 iv
Warranty
In the following warranty text, “WaveRider®” shall mean WaveRider Communications Inc.
This WaveRider product is warranted against defects in material and workmanship for a period
of one (1) year from the date of purchase. During this warranty period WaveRider will, at its
option, either repair or replace products that prove to be defective.
For warranty service or repair, the product must be returned to a service facility designated by
WaveRider. Authorization to return products must be obtained prior to shipment. The WaveR-
ider RMA number must be on the shipping documentation so that the service facility will accept
the product. The buyer shall pay all shipping charges to WaveRider and WaveRider shall pay
shipping charges to return the product to the buyer within Canada or the USA. For all other
countries, the buyer shall pay shipping charges as well as duties and taxes incurred in shipping
products to or from WaveRider.
WaveRider warrants that the firmware designed by it for use with the unit will execute its pro-
gramming instructions when properly installed on the unit. WaveRider does not warrant that the
operation of the unit or firmware will be uninterrupted or error-free.
Limitation of Warranty
The foregoing warranty shall not apply to defects resulting from improper or inadequate mainte-
nance by the buyer, buyer-supplied interfacing, unauthorized modification or misuse, operation
outside the environmental specifications for the product, or improper site preparation or mainte-
nance. No other warranty is expressed or implied. WaveRider specifically disclaims the implied
warranties of merchantability and fitness for any particular purpose.
No Liability for Consequential Damages
To the maximum extent permitted by applicable law, in no event shall WaveRider or its suppli-
ers be liable for any damages whatsoever (including, without limitation, damages for loss of
business profits, business interruption, loss of business information, or any other pecuniary
loss) arising from the use of or inability to use the product, even if WaveRider has been advised
of the possibility of such damages, or for any claim by any other party.
Because some states/jurisdictions do not allow the exclusion or limitation of liability for conse-
quential or incidental damages, the above limitation may not apply to you.
In no event will WaveRider’s liability exceed the amount paid for the product.
Regulatory Notices
This equipment has been tested and found to comply with the limits for a Class B Intentional
Radiator, pursuant to Part 15 of the FCC Regulations. These limits are intended to provide pro-
tection against harmful interference when the equipment is operated in a residential environ-
ment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation.
Notice to User
Any changes or modifications to equipment that are not expressly approved by WaveRider may
void the user’s authority to operate the equipment.

APCD-WM001-1.0 v
Contents
Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vi
Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .viii
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 MMT9000 Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2 Document Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 MMT9000 - MobileWAN Mobile Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3.1 MMT9000 Modem - External Indicators and Connectors . . . . . . . . . . . . . . . . . 5
1.3.2 MMT9000 Suite of Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3.3 MMT9000 Nomadic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1 Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2 Pre-Installation Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2.1 Network and MMT9000 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2.2 Verifying the MMT9000 Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2.3 End-Users PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.3 Installation Steps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3.1 Locating the MMT9000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3.2 Connecting to Vehicle Power System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.3.3 Connecting the End-User’s PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.3.4 Locating the MMT9000 Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.3.5 Testing the Data Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.4 Post-Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3 Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.1 Accessing the Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.2 Setup Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.3 Radio Link Status Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.4 Troubleshooting Information Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Appendix A Factory Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Appendix B Ethernet Cables and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

APCD-WM001-1.0 vi
Figures
Figure 1 MMT9000 MobileWAN Mobile Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Figure 2 MMT9000 Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Figure 3 MMT9000 Modem - External Indicators and Connectors . . . . . . . . . . . . . . . 6
Figure 4 MMT9000 Suite of Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Figure 5 Possible Locations for MMT9000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Figure 6 Possible Locations for MMT9000 Mobile Antenna . . . . . . . . . . . . . . . . . . . 15
Figure 7 T568A Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Figure 8 T568B Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

APCD-WM001-1.0 vii
Tables
Table 1 Ethernet Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Table 2 Signal Level LED Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Table 3 MMT9000 Mobile Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Table 4 MT9000 Mobile Antenna Mounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Table 5 Pre-Installation Stage Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table 6 Installation Stage Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Table 7 MMT9000 Wiring to Vehicle Power System . . . . . . . . . . . . . . . . . . . . . . . . 14
Table 8 Signal Strength Figure of Merit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Table 9 Signal Quality Figure of Merit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Table 10 Ethernet Interface Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Table 11 Wiring T568A and T568B ends for Ethernet Cables . . . . . . . . . . . . . . . . . . 30

:
APCD-WM001-1.0 viii
Preface
Conventions
The following conventions are used throughout this document:
WARNING!
Whenever you see this icon and heading, the associated text
addresses or discusses a critical safety or regulatory issue.
CAUTION: Whenever you see this icon and heading, the
associated text discusses an issue, which, if not followed, could
result in damage to, or improper use of, the equipment or
software.
TIP: Whenever you see this icon and heading, the associated
text provides a tip for facilitating the installation, testing, or
operation of the equipment or software.
Regulatory Notices
This device has been designed to operate with only the antenna types listed in this manual.
This device has been tested using unshielded Ethernet CAT-5 cable.
There can be no modications made to the MMT9000 or its antennas without the express
permission of WaveRider. Failure to comply may void the user’s authority to operate this
equipment in accordance with FCC regulations.
Federal Communications Commission
The MMT9000 has been designed and manufactured to comply with FCC Part 15.
Operators must be familiar with the requirements of the FCC Part 15 Regulations prior
to operating any link using this equipment. For installations outside the United States,
contact local authorities for applicable regulations.
The FCC ID for the MMT9000 equipment is OOX-MMT9000.
The transmitter of this device complies with Part 15.247 of the FCC Rules.

:
APCD-WM001-1.0 ix
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Interference Environment
Operation is subject to the following conditions:
• This device may not cause harmful interference and,
• This device must accept any interference received, including interference that
might cause undesired operation.
Operational Requirements
In accordance with the FCC Part 15 regulations:
1. The maximum average power output of the intentional radiator shall not
exceed one (1) watt (30 dBm) for all spread spectrum systems operating in
the 902 to 928MHz band.
2. Stations operating in the 902 to 928MHz band may use transmitting antennas
of directional gain greater than 6dBi, provided the average output power from
the intentional radiator is reduced by the amount in dB that the directional gain
of the antenna exceeds 6dBi.
3. The operator of a spread spectrum system and the user of the radio device
are each responsible for ensuring that the system is operated in the manner
outlined in Interference Environment on page ix.
The MMT9000 with its certified antenna complies with these requirements.
Warnings and Advisories
General Advisory
Installers, operators and maintenance personnel must be familiar with the related safety
requirements before they attempt to install or operate the MMT9000.

:
APCD-WM001-1.0 x
It is the responsibility of the operator to ensure that the public is not exposed to excessive
Radio Frequency (RF) levels. The applicable regulations can be obtained from local
authorities.
WARNING!
To comply with FCC RF exposure limits, the MMT9000 mobile
antennas must be mounted to provide a separation distance
of 20cm (8 inches) or more from all persons. The MMT9000
panel antenna must be mounted to provide a separation
distance of 30cm (12 inches) or more from all persons. The
distance is measured from the nearest point of the antenna to
the human body.
WARNING!
The MMT9000 is only to be installed by qualified professional
installers, who are familiar FCC regulations and with
installing radio transmission equipment, especially in
vehicles. The installer must be familiar with all installation
procedures and restrictions contained herein.
Important Safeguards
WARNING!
CAUTION: To reduce risk of electrical shock, do not remove
covers, since there are no user-serviceable parts inside.
Refer servicing to qualified personnel.
1. Read all these instructions before installing and operating the MMT9000.
2. Retain these instructions for future reference.
3. Heed all warnings on the MMT9000 and in these instructions.
4. Follow all instructions.
5. Disconnect MMT9000 from its power source before cleaning. Clean only with a damp
cloth.
6. Use only attachments recommended by WaveRider.
7. The metal housing protects the MMT9000 from overheating to ensure reliable
operations. Do not cover the MMT9000. Although the MMT9000 has been rated for a
wide range of temperatures, it will perform better and longer if proper ventilation is
provided.

:
APCD-WM001-1.0 xi
8. Operate the MMT9000 only from a 13.8 VDC (+-/25%) power supply, such as a
standard vehicle power system. Using other voltages, such as 24 VDC or AC power,
can result in damage to the MMT9000.
9. Use the fuse assembly provided to protect the MMT9000 from power surges in the
vehicle power system as well as protecting the power system from short circuits in the
MMT9000 or its power cable.
10. Route the Power-supply cable, Ethernet cable and Antenna cable so that they are not
likely to be walked on or pinched by items placed upon or against them, paying
particular attention to cord and cables at their plugs, convenience receptacles and the
points where the cords exit the equipment.
11. Provide strain relief for cables near their connections. This is typically done by leaving
a loop in the cable near the connection.
12. Do not locate the MMT9000 in the vicinity of power lines or other electric light or power
circuits, or where it can fall onto such power lines or circuits.
13. For added protection during a lightning storm, or when it is left unattended and unused
for long periods of time, unplug the MMT9000. This will power down the MMT9000.
14. Never push foreign objects of any kind through openings (e.g. Ethernet jack) in this
wireless product as they may short-out parts that could result in a fire or electric shock
and damage the unit.
15. The MMT9000 is a rugged unit that can tolerate a wide range of environments if
installed correctly, but it is not rated as being submersible nor immune to all liquids
from all directions. If the MMT9000 may experience rain, then mount the unit so that
the rain does not fall on or drip directly onto the connector endplate.
16. Do not attempt to service this wireless product yourself. Refer all servicing to qualified
service personnel.
17. Unplug the unit and refer servicing to qualified service personnel under the following
conditions:
• When the power supply cord or plug is damaged.
• If the MMT9000 does not operate normally for an extended period of time when
following the operating instructions. Note that it is possible that Internet traffic can
be slow even under normal operations due to network congestion and radio
interference and fading and not as result of problems with the MMT9000.
• When the MMT9000 exhibits distinct changes in performance. This may indicate a
need for service.
18. When replacement parts are required, be sure the service technician has used
replacement parts specified by WaveRider or with the same characteristics as the
original part. Improper substitutions may result in fire, electric shock or other hazards.
19. Upon completion of any service or repairs to this wireless product, ask the service
technician to perform safety checks to determine that the wireless product is in proper
operating condition.

:
APCD-WM001-1.0 xii
20. Install the MMT9000 in compliance with local and national electrical codes where
applicable. The following are the national codes. The installer is responsible for
knowing the appropriate local codes.
• In the United States, use the National Electrical Code (NEC);
• In Canada, use the Canadian Electrical Code, Part 1, CSA C22.1;
• In other countries, use International Electrotechnical Commission (IEC) 364,
part 1 through 7.
Revision History
Customer Support
An extensive knowledge base is available at www.waverider.com.
WaveRider offers a complete training program. Please contact your sales representative for
training information.
WaveRider also offers priority telephone and email support. Please contact your sales
representative for details.
Date Revision Description
July 2005 1.0 Initial Release Version

APCD-WM001-1.0 1
1 Introduction
The WaveRider MobileWAN family of wireless systems enables mobile, field deployable
wireless access networking and operates in the 900 MHz ISM band. The MobileWAN consists
of a base station and a mix of multiple fixed subscriber terminals and mobile subscriber
terminals. The MobileWAN system comes fully configured as a basic system to provide high-
speed data services. With optional components, the WaveRider MobileWAN has the capability
to provide enhanced telephone service via an IP PBX, as well as security video and short
message text services. The system connects to all standard IP and telephony networks using
standard interface protocols.
The basic components of the MobileWAN system include:
1. MBT9000 - MobileWAN Base Terminal
2. MFT9000 - MobileWAN Fixed Terminal
3. MMT9000 - MobileWAN Mobile Terminal
Figure 1 MMT9000 MobileWAN Mobile Terminal

1: Introduction
APCD-WM001-1.0 2
The MMT9000 is the first component of the MobileWAN family to be released. The MMT9000
is a rugged vehicle data-radio that provides Ethernet access to the IP-based internet. The
MMT9000 has been designed to be easily installed into a vehicle and be powered from a
vehicle's 12 VDC1power system.
1.1 MMT9000 Features
The MMT9000 is well suited for mobile applications in the following industries:
• remote works sites,
• private communications networks,
• municipal governments,
• public works,
• large construction projects,
• homeland security,
• public safety (non life threatening),
• industrial solutions, and
• special events.
The MMT9000 is capable of delivering high-speed data, voice, and video. It can work with
VPNs and other security middle ware.
The MMT9000 is a mobile wireless modem that connects to the user's computer through an
Ethernet connection. It is intended to be installed in a vehicle and provides an interface to the
customer's computer or local area network on one side and wireless access to the LMS4000
network on the other.
The MMT9000, which acts as a network bridge, receives data from the Base Station
(MBT9000, CCU3000 or NCL1900)2over the 900 MHz radio link, and forwards this data to the
user's computer through the Ethernet port. In the other direction, the MMT9000 forwards data
received from the user's computer over the radio link to the Base Station.
The MMT9000 has a compact form factor designed for use in a vehicle, including emergency
vehicles. The MMT9000 has outstanding RF performance in a hostile mobile environment.
Temperature, vibration, shock, exposure to moisture and ease of installation have all been
considered in the modem packaging. Set-up and configuration is rapid and simple.
1. We refer to the MMT9000 as being powered by 12 VDC. This is by convention and
refers to the 12 VDC power system on most vehicles. The actual input power
specification is 13.8 VDC +/- 25%.
2. We will use the generic term “Base Station” throughout this document to stand for any of
the WaveRider 900 MHz base station products, the CCU3000, NCL1900 or MBT9000

1: Introduction
APCD-WM001-1.0 3
Features of the MMT9000 include:
•Nomadic Base Station Discovery (factory default) - The MMT9000 searches all
available channels or channels from a user-defined list. The MMT9000 selects which
Base Station or access point to establish a connection based on airlink quality and
authorization acceptance. With this and DCHP Client enabled (factory defaults), the
installer does not need to enter ANY configuration parameters into the MMT9000 in
order to install it.
•DHCP Client (factory default)- The MMT9000 can obtain its IP address, subnet mask
and IP gateway information from a DHCP server, reducing the amount of
configuration required for installation. This allows the network operator to reassign IP
addresses to MMT9000s without having to access the mobile terminal itself.
•Auto Remote Configuration - The MMT9000 will accept parameters from a RADIUS
server to set other configurable parameters in the modem. These parameters include:
password, all SNMP parameters, RF Frequency (including enabling auto-discovery),
and number of hosts.
•Monitoring Tools - The MMT9000 has a Windows GUI, LEDs and a SETUP Menu to
make monitoring the airlink very accessible to the user. The MMT9000 supports the
local link IP address, 169.254.10.250, on its Ethernet port at all times. Using the local-
link address, the user can use the password “setup” at any time to call up the setup
menu that allows any user to check the RF link quality to verify connectivity.
•Mobile and Fixed Antennas - The MMT9000 is certified to work with a variety of
antennas, including whip antennas that can be permanently mounted on a vehicle or
magnetically mounted and a high-gain panel antenna that can be mounted on a
mobile command center or permanently installed as required.
•Interoperable with LMS4000 System - The MMT9000 can connect to the MBT9000,
CCU3000 or NCL1900 as Base Stations. It can also share the network with a mixture
of MMT9000s, MFT9000s, and residential EUMs. Thus the MMT9000 can use a
network designed exclusively for its use and/or existing LMS4000 networks.
Detailed specifications for the MMT9000 can be found on the WaveRider website.
1.2 Document Scope
This installation guide provides general guidelines for the installation and configuration of the
MMT9000, its performance, and any required regulatory information, including approved
installation notices. The Setup menu is described, which can be used to align the MMT9000
antennas.
The concepts for the MobileWAN family of components are the same as the fixed wireless
LMS4000 family. Related information can be found in the suite of available LMS4000
manuals, which includes the following:
•LMS4000 900 MHz Radio Networking Concepts (APCD-LM053)
•LMS4000 Data Networking Concepts (APCD-LM050)
•LMS4000 Managing the Network (APCD-LM052)
•LMS4000 CLI Reference Manual (APCD-LM051)

1: Introduction
APCD-WM001-1.0 4
•LMS4000 SNMP Reference Manual (APCD-LM049)
• Acronyms and Glossary (APCD-LM056)
These manuals provide information not included in this Installation Guide, including
information on:
• Planning, installing and managing the network.
• Diagnostic tools for the network and modems.
• Details on the Command Line Interface and methods of accessing the modems.
• Manual configuration of the modem via the CLI.
• Glossary of network terms.
These manuals can be found on WaveRider’s Web site (http://www.waverider.com).
NOTE: The installer may be required to manually configure the
MMT9000. In this case, the installer should be familiar with
LMS4000 CLI Reference Manual (APCD-LM051).
Other documents on the WaveRider web site are useful to assist in installing and operating the
MMT9000.
WaveRider recommends that you be familiar with the following sections before proceeding
with the instructions in this guide:
•Software License Agreement on page iii
•Warranty on page iv
•Conventions on page viii
•Warnings and Advisories on page ix
•Important Safeguards on page x
NOTE: The information contained in this manual is subject to change
without notice. The reader should consult the WaveRider web
site for updates.
1.3 MMT9000 - MobileWAN Mobile Terminal
Figure 2 shows the components that make up the MMT9000 MobileWAN Mobile Terminal.
Key elements of the MMT9000 are described on the following pages:
•MMT9000 Modem - External Indicators and Connectors on page 5
•MMT9000 Suite of Antennas on page 7
•MMT9000 Nomadic Operation on page 9

1: Introduction
APCD-WM001-1.0 5
Figure 2 MMT9000 Components
1.3.1 MMT9000 Modem - External Indicators and Connectors
All interfaces on the MMT9000 are on one side of the radio for ease of installation. The
following interfaces are:
• Ethernet port - 10BaseT RJ45 receptacle to connect the modem to the end-user’s
computer. Details on the Ethernet port are found in Appendix B on page 29.
CAUTION: Any DC voltage applied to the Ethernet port may
damage the MMT9000, the Ethernet cable, and/or network gear.
The MMT9000 is not a Power-over-Ethernet device.
• SMA-F Antenna Port - for connecting one of the approved mobile or fixed antennas to
the MMT9000. See section 1.3.2, MMT9000 Suite of Antennas for details on the
antennas.
• DC Power Connector - a watertight, locking 4 pin receptacle receives the connector
from vehicle power system cable. The MMT9000 comes with an 18-ft. cable for
connecting to the vehicle power system as well as a fuse assembly. The pin out and
connection details are discussed in Connecting to Vehicle Power System on page 14.
CAUTION: Use standard vehicle power system (13.8 VDC +/-
25%) only. Any other voltage can result in damage to the modem.
• Chassis Ground Lug - this should be connected to the vehicle chassis or ground
system.
The MMT9000 also has 3 LEDs. Figure 3 shows the layout of the MMT9000 Connectors and
LEDs, while Table 1 and Table 2 explain what each LED means.
MMT9000 Modem Fuse Assembly12 VDC Power Cable

1: Introduction
APCD-WM001-1.0 6
Figure 3 MMT9000 Modem - External Indicators and Connectors
Table 1 Ethernet Status LEDs
Table 2 Signal Level LED Status
Signal Level
Ethernet Link
Ethernet Socket
Power Connector
Antenna Connector
Ethernet Traffic
Ground Lug
LED State Ethernet Status
Ethernet Link If the Link LED is ON, the Ethernet physical connection is configured and working
properly. If the Link LED is OFF, then the Ethernet physical connection is not
working properly, which could be because the wrong type of cable was used or
there is a problem with the host or device Ethernet interface.
If connecting directly to the end-user PC, use the crossover Ethernet cable pro-
vided. If connecting to a router or switch, use a straight-through cable.
Ethernet Traffic The Ethernet Traffic LED flashes whenever the link is transferring data.
Signal Level
State Status
Flashing The MMT9000 has adequate signal level to support the radio link. As the signal
level increases, the flash rate increases. If possible, turn or move the antenna
slowly until the Signal Level LED flashes as fast as possible (i.e. turn panel
antenna, reposition magnetic mounted antennas).
Off The MMT9000 does not have adequate signal level (<-86 dBm). Move and/or
turn the antenna until it begins flashing. If a permanently mounted mobile
antenna is being used, then the vehicle needs to move.

1: Introduction
APCD-WM001-1.0 7
1.3.2 MMT9000 Suite of Antennas
Only the following antennas are approved by FCC to be used with the MMT9000. All of these
antennas and their mounting assemblies can be purchased from WaveRider.
The end user must position the antenna correctly to receive an adequate signal level.This is
especially true of the panel antenna which is a directional antenna. The Radio LED on the
MMT9000, described in section 1.3.1, MMT9000 Modem - External Indicators and
Connectors, or the Setup menu, described in Setup Menu on page 21, can be used to help
with the alignment..
WARNING!
To comply with FCC RF exposure limits, the MMT9000 mobile
antennas must be mounted to provide a separation distance
of 20cm (8 inches) or more from all persons. The MMT9000
panel antenna must be mounted to provide a separation
distance of 30cm (12 inches) or more from all persons. The
distance is measured from the nearest point of the antenna to
the human body.
MMT9000 Mobile Antennas
The MMT9000 is designed for use with variety of mobile whip antennas. The following mobile
antennas has been certified to be used with MMT9000:
Table 3 MMT9000 Mobile Antennas
NOTE: The mobile antennas must be mounted on a metal surface at
least 1 Meter diameter for best performance.
Maker Model Gain Mount
Pacific Wireless RFLMA9 7 dBi RFLMM-110
MAXRAD MUF9035NGP(S) 5 dBi BGMML or BMAML
MAXRAD MUF9025NGP(S) 5 dBi BGMML or BMAML
MAXRAD MUF9003NGP(S) 3 dBi BGMML or BMAML
MAXRAD MUF9035NGP(S) 3 dBi BGMML or BMAML
MAXRAD MUF9000NGP(S) Unity BGMML or BMAML

1: Introduction
APCD-WM001-1.0 8
Figure 4 MMT9000 Suite of Antennas
The following are the mounting options for these mobile antennas:
Table 4 MT9000 Mobile Antenna Mounts
*1 - Installer will need to replace existing connector with SMA-M connector to mate with
MMT9000.
MMT9000 Fixed Antenna
The MMT9000 has an FCC-approved, fixed outdoor panel antenna, the Maxrad Z1836. It is
provided with 25-ft. LMR200 RF cable. Since the panel antenna has a 65 degree beam width
and better than 17 dB front-to-back ratio, it can be positioned to suppress interference from
other wireless devices.
WARNING!
To comply with FCC RF exposure limits, the MMT9000 panel
antenna use at least 6 feet of LMR200 cable.
Pacific Wireless
RFLMA9
MAXRAD
MUF9035NGPS
MAXRAD
Z1836
Maker Model Type Cable Length / Type
Provided
Pacific Wireless RFLMM-110 RFLinx Magnetic Mount 10-ft. RG-58/U (*1)
MAXRAD BGMML Magnetic Mount 12-ft. LMR195
MAXRAD BMAML Permanent Mount 12-ft. LMR195
Table of contents
