VL53L1X Distance Sensor User Manual
Version: V1.0.0 Date: 2018.06.25 1
VL53L1X Distance Sensor
User Manual
OVERVIEW
VL53L1X Distance Sensor is a Time-of-Flight (ToF) ranging module based on the
VL53L1X from ST, with accurate ranging up to 4m and fast ranging frequency up to 50
Hz, it is controlled through I2C interface, and pretty low power consumption.
The VL53L1X is a ToF sensor which embeds the ST’s third generation FlightSense
patented technology. Compared with the second generation VL53L0X, the VL53L1X
extends the ToF ranging distance up to 4m, and features fast ranging frequency up to
50 Hz.
Unlike conventional ranging sensors, the VL53L1X integrates physical infrared
filters and optics, uses ST’s latest generation ToF technology which allows absolute
distance measurement whatever the target color and reflectance, achieves better anti-
interference capability.
FEATURES
⚫I2C communication interface, control the module on/off via IO pins
⚫Onboard voltage translator, compatible with 3.3V/5V operating voltage
⚫Comes with development resources and manual (examples for Raspberry
Pi/Arduino/STM32)

VL53L1X Distance Sensor User Manual
Version: V1.0.0 Date: 2018.06.25 2
SPECIFICATIONS
➢Operating voltage: 3.3V/5V
➢Dimension: 20mm × 24mm
➢Mounting holes size: 2.0mm
➢Ranging distance: 40 ~ 4000mm
➢Ranging accuracy: ±5%
➢Ranging time (min): 20ms (short distance mode), 33ms (medium/long distance
mode)
➢Field of view: 27°
➢Laser wavelength: 940nm
➢Operating temperature: -20 ~ 80°C
PINOUTS
VCC: 3.3V/5V power input
GND: ground
SDA: I2C data pin
SCL: I2C clock pin
SHUT: shutdown control, connects to IO pin
INT: interrupt output, connects to IO pin

VL53L1X Distance Sensor User Manual
Version: V1.0.0 Date: 2018.06.25 3
HARDWARE
VL53L1X
The VL53L1X is a state-of-the-art, Time-of-Flight (ToF), laser-ranging sensor,
enhancing the ST FlightSense™ product family. It is the fastest miniature ToF sensor
on the market with accurate ranging up to 4 m and fast ranging frequency up to
50 Hz.
Housed in a miniature and reflowable package, it integrates a SPAD receiving
array, a 940 nm invisible Class1 laser emitter, physical infrared filters, and optics to
achieve the best ranging performance in various ambient lighting conditions with a
range of cover window options.
Unlike conventional IR sensors, the VL53L1X uses ST’s latest generation ToF
technology which allows absolute distance measurement whatever the target color
and reflectance.
It is also possible to program the size of the ROI on the receiving array, allowing
the sensor FoV to be reduced.
Features:
⚫Fully integrated miniature module
–Size: 4.9x2.5x1.56 mm
–Emitter: 940 nm invisible laser (Class1)
–SPAD (single photon avalanche diode)

VL53L1X Distance Sensor User Manual
Version: V1.0.0 Date: 2018.06.25 4
⚫receiving array with integrated lens
–Low-power microcontroller running advanced digital firmware
⚫Pin-to-pin compatible with the VL53L0X FlightSense™ ranging sensor
⚫Fast and accurate long distance ranging
–Up to 400 cm distance measurement
–Up to 50 Hz ranging frequency
⚫Typical full field-of-view (FoV): 27 °
⚫Programmable region-of-interest (ROI) size on the receiving array, allowing the
sensor FoV to be reduced
⚫Programmable ROI position on the receiving array, providing multizone operation
control from the host
⚫Easy integration
–Single reflowable component
–Can be hidden behind many cover window materials
–Software driver and code examples for turnkey ranging
–Single power supply (2v8)
–I²C interface (up to 1 MHz)
–Shutdown and interrupt pins
Pictures:

VL53L1X Distance Sensor User Manual
Version: V1.0.0 Date: 2018.06.25 5
For more details, please read the datasheet.
USING DEMO CODE
WORKING WITH RASPBERRY PI
LIBRARIES INSTALLATION
To use the demo code for Raspberry Pi, you need to install wiringPi library first,
otherwise it cannot work properly. About how to install the library, you can visit the
page: Libraries_Installation_for_RPi#Install_WiringPi_Library
HARDWARE CONNECTION
The connection is based on Raspberry Pi 3 mode B+
VL53L1X Distance Sensor
Raspberry Pi
VCC
3.3V
GND
GND
SDA
SDA.1
SCL
SCL.1

VL53L1X Distance Sensor User Manual
Version: V1.0.0 Date: 2018.06.25 6
COMPILING AND RUNNING
1. Download the demo code on Wiki
2. Unzip and copy the Raspberry Pi code to your Pi (Recommend put on /home/pi)
3. Enter the path of the demo code and compile it:sudo make clean && sudo make
&& ./Range
4. Run the code: ./Range

VL53L1X Distance Sensor User Manual
Version: V1.0.0 Date: 2018.06.25 7
WORKING WITH ARDUINO
HARDWARE CONNECTION
This connection is based on Waveshare UNO PLUS
VL53L1X Distance Sensor
Arduino
VCC
3.3V
GND
GND
SDA
SDA
SCL
SCL
RUNNING CODE
Copy the VL53L1X-Arduino-Library folder which is under Arduino demo code
directory to Arduino IDE’s Libraries directory which is under the installation directory
of your IDE. Then Open Arduino IDE, and choose File->Examples-> VL53L1X-Arduino-
Library

VL53L1X Distance Sensor User Manual
Version: V1.0.0 Date: 2018.06.25 8
Compile and run three examples which are using Short Mode, Medium Mode and
Long Mode separately.
Short mode：For short distance ranging，range：0 ~ 1.3m
Medium mode：For medium distance ranging，range：0m ~ 3m
Long mode：For long distance ranging，range：0m ~ 4m
WORKING WITH STM32
HARDWARE CONNECTION
This connection is based on XNUCLEO-F411RE/NUCLEO-F401RE
VL53L1X Distance Sensor
XNUCLEO-F411RE/NUCLEO-F401RE
VCC
3.3V
GND
GND
SDA
SDA
SCL
SCL

VL53L1X Distance Sensor User Manual
Version: V1.0.0 Date: 2018.06.25 9
USING VL53L1X_GUI
1. Connect the sensor to NUCLEO-F401RE according to Hardware connection
2. Install ST’s VL53L1X_GUI software and run it. Open the software and write
firmware to NUCLEO board: About->Flash Fw (for this example, only supports
NUCLEO-F401RE)
3. Choose Low-Power Automous, and choose Distance Mode to Short. Click Start.
The distance curve will be displayed on software.

VL53L1X Distance Sensor User Manual
Version: V1.0.0 Date: 2018.06.25 10
SIMPLERANGIN EXAMPLES
Connect the VL53L1X sensor to NUCLEO-F401RE board (or the XNUCLEO-F411RE)
Open and run the example: .. \VL53L1X\SimpleRangingExamples\MDK-
ARM\STM32F401RE-Nucleo
Open Serial debug assistance tool, choose the right COM and set the baudrate to
115200. Then press reset button.

VL53L1X Distance Sensor User Manual
Version: V1.0.0 Date: 2018.06.25 11
MULIPLESENSORSRANGING
Connect the VL53L1X sensor to NUCLEO-F401RE board (or the XNUCLEO-F411RE)
Open and run the example: ..\VL53L1X\MulipleSensorsRanging\MDK-ARM\STM32F401RE-Nucleo
Open Serial debug assistance tool, choose the right COM and set the baudrate to
115200. Then press reset button.

VL53L1X Distance Sensor User Manual
Version: V1.0.0 Date: 2018.06.25 12
The information printed on serial；
For more information about STM32, please refer to the documents which is under
Documentation directory.
