wavin NeoStat User manual

neo
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 1

2
Wavin neo Wavin neo
Table of Contents
1
2
3-4
5
5
6
7
8
9
Product Image
Table of Contents
What is a Programmable
Room Thermostat?
Pairing the neoHub
Pairing the neoStat
What is a Mesh Network?
Mode 1 - Thermostat
LCD Display
Temperature Display
Setting the Clock
Setting the Comfort Levels
Setting the Temperature
Temperature Hold
Locking/Unlocking the neoStat
Frost Protection
Power ON/OFF
Holiday Programming
Model:
1
10
11-12
13
14
15
16
17
18
Optional Features
Re-calibrating the Thermostat
Error Codes
Thermostat Mode Wiring Diagrams
Factory Reset
Mode 2 - Time Clock
LCD Display
Setting the Switching Times
Timer Override
Optional Features
Optional Features Table
19-22
23
23
24-27
24
25
26
27
28
29
29
Available in : Sapphire Black and Glacier White
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 2

2
Wavin neo Wavin neo
Table of Contents
1
2
3-4
5
5
6
7
8
9
Product Image
Table of Contents
What is a Programmable
Room Thermostat?
Pairing the neoHub
Pairing the neoStat
What is a Mesh Network?
Mode 1 - Thermostat
LCD Display
Temperature Display
Setting the Clock
Setting the Comfort Levels
Setting the Temperature
Temperature Hold
Locking/Unlocking the neoStat
Frost Protection
Power ON/OFF
Holiday Programming
Model:
1
10
11-12
13
14
15
16
17
18
Optional Features
Re-calibrating the Thermostat
Error Codes
Thermostat Mode Wiring Diagrams
Factory Reset
Mode 2 - Time Clock
LCD Display
Setting the Switching Times
Timer Override
Optional Features
Optional Features Table
19-22
23
23
24-27
24
25
26
27
28
29
29
Available in : Sapphire Black and Glacier White
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 2

Wavin neo Wavin neo
43
The way to set and use your programmable room thermostat is to find the lowest
temperature settings that you are comfortable with at the different times you have
chosen, and then leave it alone to do its job.
The best way to do this is to set the room thermostat to a low temperature
– say 18°C , and then turn it up by 1°C each day until you are comfortable with the
temperature. You won’t have to adjust the thermostat further. Any adjustment above
this setting will waste energy and cost you more money.
You are able to temporarily adjust the heating program by overriding or using the
temperature hold feature. These features are explained further on pages 17 and 18
of this manual.
Programmable room thermostats need a free flow of air to sense the temperature, so
they must not be covered by curtains or blocked by furniture. Nearby electric fires,
televisions, wall or table lamps may also prevent the thermostat from working
properly.
What is a Programmable Room Thermostat?
A programmable room thermostat is both a programmer and a room thermostat.
A programmer allows you to set “On”and“Off” periods to suit your own lifestyle.
A room thermostat works by sensing the air temperature, switching on the heating
when the air temperature falls below the thermostat setting, and switching it off once
this set temperature has been reached.
So a programmable room thermostat lets you choose what times you want the heating
to be on, and what temperature it should reach while it is on. It will allow you to select
different temperatures in your home at different times of the day (and days of the week)
to meet your particular needs and preferences.
Setting a programmable room thermostat to a higher temperature will not make the
room heat up any faster. How quickly the room heats up depends on the design and
size of the heating system.
Similarly reducing the temperature setting does not affect how quickly the room cools
down. Setting a programmable room thermostat to a lower temperature will result in
the room being controlled at a lower temperature, and saves energy.
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 4

Wavin neo Wavin neo
43
The way to set and use your programmable room thermostat is to find the lowest
temperature settings that you are comfortable with at the different times you have
chosen, and then leave it alone to do its job.
The best way to do this is to set the room thermostat to a low temperature
– say 18°C , and then turn it up by 1°C each day until you are comfortable with the
temperature. You won’t have to adjust the thermostat further. Any adjustment above
this setting will waste energy and cost you more money.
You are able to temporarily adjust the heating program by overriding or using the
temperature hold feature. These features are explained further on pages 17 and 18
of this manual.
Programmable room thermostats need a free flow of air to sense the temperature, so
they must not be covered by curtains or blocked by furniture. Nearby electric fires,
televisions, wall or table lamps may also prevent the thermostat from working
properly.
What is a Programmable Room Thermostat?
A programmable room thermostat is both a programmer and a room thermostat.
A programmer allows you to set “On”and “Off” periods to suit your own lifestyle.
A room thermostat works by sensing the air temperature, switching on the heating
when the air temperature falls below the thermostat setting, and switching it off once
this set temperature has been reached.
So a programmable room thermostat lets you choose what times you want the heating
to be on, and what temperature it should reach while it is on. It will allow you to select
different temperatures in your home at different times of the day (and days of the week)
to meet your particular needs and preferences.
Setting a programmable room thermostat to a higher temperature will not make the
room heat up any faster. How quickly the room heats up depends on the design and
size of the heating system.
Similarly reducing the temperature setting does not affect how quickly the room cools
down. Setting a programmable room thermostat to a lower temperature will result in
the room being controlled at a lower temperature, and saves energy.
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 4

Wavin neo Wavin neo
65
Pairing the neoHub
To pair the neoHub with the neoApp, follow these steps.
Connect the power supply to the neoHub.•
Connect the neoHub to your router with the Ethernet cable provided. The router•
will automatically assign an IP address to the neoHub, the Link LED will light up
once the neoHub has connected to your network.
Connect your smartphone or tablet device to the same WiFi network as your router.•
Download the FREE Heatmiser neoApp from the Apple App Store,•
Google Play Store, Amazon App Store or Windows Phone App Store and register
an account.
Once you have registered your account, press the Login button then press the•
Add Location option.
Press the connect button on the neoHub to add the location to your account.•
When successfully connected, enter a title for the new location (e.g. Home) and•
configure the time zone for the system.
What is a Mesh Network
NeoStats work using a mesh network, meaning neoStats have the ability to send &
receive signals via other thermostats on the network. This signal is relayed from one
thermostat to another until it reaches its destination. This communication method
extends the communication range whilst offering increased network stability when
compared with standard RF thermostats.
The Mesh symbol is shown when the device is communicating with the neoHub, if
the mesh symbol disappears this indicates connection to the neoHub has been lost.
The next step is to join the neoStat to the neoHub, we recommend joining the neoStat
located nearest to the neoHub first.
To add a neoStat, follow these steps;
Select Add Zone, enter a zone title and press Add Zone again.•
You now have two minutes to join the neoStat to the neoHub.•
On the neoStat, use the Left / Right keys to select SETUP and press Tick ...•
Feature 01 is displayed on screen.•
Press the Tick key to pair the neoStat to the neoHub .........................................•
The MESH symbol appears flashing on the display.•
When the neoStat successfully connects to the neoHub the MESH symbol will be•
permanently displayed.
Press Next to add more zone or press Finish to complete the setup.•
Please note, you only have to pair the hub to your account once. To pair any additional
neoStats, select Add Zones from the Manage Zones option in the neoApp.
Pairing the neoStat
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 6

Wavin neo Wavin neo
65
Pairing the neoHub
To pair the neoHub with the neoApp, follow these steps.
Connect the power supply to the neoHub.•
Connect the neoHub to your router with the Ethernet cable provided. The router•
will automatically assign an IP address to the neoHub, the Link LED will light up
once the neoHub has connected to your network.
Connect your smartphone or tablet device to the same WiFi network as your router.•
Download the FREE Heatmiser neoApp from the Apple App Store,•
Google Play Store, Amazon App Store or Windows Phone App Store and register
an account.
Once you have registered your account, press the Login button then press the•
Add Location option.
Press the connect button on the neoHub to add the location to your account.•
When successfully connected, enter a title for the new location (e.g. Home) and•
configure the time zone for the system.
What is a Mesh Network
NeoStats work using a mesh network, meaning neoStats have the ability to send &
receive signals via other thermostats on the network. This signal is relayed from one
thermostat to another until it reaches its destination. This communication method
extends the communication range whilst offering increased network stability when
compared with standard RF thermostats.
The Mesh symbol is shown when the device is communicating with the neoHub, if
the mesh symbol disappears this indicates connection to the neoHub has been lost.
The next step is to join the neoStat to the neoHub, we recommend joining the neoStat
located nearest to the neoHub first.
To add a neoStat, follow these steps;
Select Add Zone, enter a zone title and press Add Zone again.•
You now have two minutes to join the neoStat to the neoHub.•
On the neoStat, use the Left / Right keys to select SETUP and press Tick ...•
Feature 01 is displayed on screen.•
Press the Tick key to pair the neoStat to the neoHub .........................................•
The MESH symbol appears flashing on the display.•
When the neoStat successfully connects to the neoHub the MESH symbol will be•
permanently displayed.
Press Next to add more zone or press Finish to complete the setup.•
Please note, you only have to pair the hub to your account once. To pair any additional
neoStats, select Add Zones from the Manage Zones option in the neoApp.
Pairing the neoStat
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 6

Wavin neo Wavin neo
87
Day Indicator - Displays the day of the week.1.
Mesh Symbol - Displayed when connected to the neoHub.2.
Floor Limit Symbol - Displayed when the floor probe has reached the3.
temperature limit set on feature 07.
Frost Symbol - Displayed when frost protection mode is active.4.
Flame Symbol - Displayed when the thermostat is calling for heat, flashes5.
when optimum start is active.
Heat/Cool - Indicates the current operation mode, only shown when6.
neoChill is connected to the system.
Floor/Room Temp - Indicates the current sensor mode.7.
Set - Displayed when changes are being made to the program schedule8.
or current set point.
Key Lock Indicator - Displayed when the KeyLock is Locked.9.
Program Indicator - Displayed during programming to show which10.
period is being altered.
Main Menu - Displays which option is currently selected.11.
Temperature Format - Degrees Celsius or Fahrenheit.12.
Temperature - Displays the current sensor temperature.13.
Cool On - Displayed when cooling is active.14.
Clock - Time displayed in 24 hour format.15.
Holiday Left - Displayed when the thermostat is in holiday mode.16.
Hold Left - Displayed when a temperature hold is active, the remaining17.
time will be shown.
LCD Display
Mode 1 - Thermostat
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 8

Wavin neo Wavin neo
87
Day Indicator - Displays the day of the week.1.
Mesh Symbol - Displayed when connected to the neoHub.2.
Floor Limit Symbol - Displayed when the floor probe has reached the3.
temperature limit set on feature 07.
Frost Symbol - Displayed when frost protection mode is active.4.
Flame Symbol - Displayed when the thermostat is calling for heat, flashes5.
when optimum start is active.
Heat/Cool - Indicates the current operation mode, only shown when6.
neoChill is connected to the system.
Floor/Room Temp - Indicates the current sensor mode.7.
Set - Displayed when changes are being made to the program schedule8.
or current set point.
Key Lock Indicator - Displayed when the KeyLock is Locked.9.
Program Indicator - Displayed during programming to show which10.
period is being altered.
Main Menu - Displays which option is currently selected.11.
Temperature Format - Degrees Celsius or Fahrenheit.12.
Temperature - Displays the current sensor temperature.13.
Cool On - Displayed when cooling is active.14.
Clock - Time displayed in 24 hour format.15.
Holiday Left - Displayed when the thermostat is in holiday mode.16.
Hold Left - Displayed when a temperature hold is active, the remaining17.
time will be shown.
LCD Display
Mode 1 - Thermostat
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 8

Wavin neo Wavin neo
109
This neoStat can be configured for different sensor options such as built in air sensor,
floor sensor or both. The display will clearly indicate which sensor is being used by
showing either “Room Temp” or “Floor Temp”before the actual temperature value.
When the neoStat is set to use both the air & the floor sensor, the room temperature will
be displayed by default.
To view the current floor temperature, press and hold the Left and Right arrow keys
for 5 seconds, the floor temperature will then be displayed .......................................
Setting the Clock
To set the clock, follow these steps.
Use the Left / Right keys to scroll to CLOCK .........................................................•
Press Tick to confirm selection ...........................................................................................•
Use the Up / Down keys to set the hours (24 hour format) ............................•
Press Tick to confirm selection ...........................................................................................•
Use Up / Down keys to set the minutes ................................................................•
Press Tick to confirm selection ...........................................................................................•
Use Left / Right keys to set the the day .................................................................•
Press Tick to confirm selection and return to the main display ............................•
Temperature Display
Room Temperature Floor Temperature
Day
Minutes
Hours
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 10

Wavin neo Wavin neo
109
This neoStat can be configured for different sensor options such as built in air sensor,
floor sensor or both. The display will clearly indicate which sensor is being used by
showing either “Room Temp” or “Floor Temp”before the actual temperature value.
When the neoStat is set to use both the air & the floor sensor, the room temperature will
be displayed by default.
To view the current floor temperature, press and hold the Left and Right arrow keys
for 5 seconds, the floor temperature will then be displayed .......................................
Setting the Clock
To set the clock, follow these steps.
Use the Left / Right keys to scroll to CLOCK .........................................................•
Press Tick to confirm selection ...........................................................................................•
Use the Up / Down keys to set the hours (24 hour format) ............................•
Press Tick to confirm selection ...........................................................................................•
Use Up / Down keys to set the minutes ................................................................•
Press Tick to confirm selection ...........................................................................................•
Use Left / Right keys to set the the day .................................................................•
Press Tick to confirm selection and return to the main display ............................•
Temperature Display
Room Temperature Floor Temperature
Day
Minutes
Hours
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 10

Wavin neo Wavin neo
1211
Comfort Levels Explained
The neoStat offers three program mode options; Weekday/Weekend programming,
7 Day programming and 24 Hour programming. There is also the option to
use the thermostat as a Non-Programmable thermostat.
When thermostats are connected to the mesh network, the program mode for
the system is configured by using the neoApp.
The thermostat is supplied with comfort levels already programmed, but these can be
changed easily. The default times and temperature settings are;
07:00 - 21°C (Wake) 09:00 - 16°C (Leave) 16:00 - 21°C (Return) 22:00 - 16°C (Sleep)
If you only want to use 2 levels, you should program the unused levels to --:--
For Weekday/Weekend programming, the four comfort levels are the same for Mon-Fri, but can
be different for Sat-Sun. For 7 Day programming each day of the week can have four different
comfort levels. In 24 Hour mode all days are programmed with the same comfort levels.
To program the comfort levels, use the Left / Right keys to scroll to EDIT .............•
Press Tick to confirm selection .......................................................................................................•
Use the Left / Right keys to select day / period of week (the selection will flash).•
Press Tick to confirm selection .......................................................................................................•
WAKE will now flash and the current time and temperature setting will be shown.•
Press Tick to alter WAKE settings ...................................................................................................•
Use the Up / Down keys to set the hours ..............................................................•
Press Tick to confirm ..............................................................................................................•
Use the Up / Down keys to set the minutes .........................................................•
Press Tick to confirm ..............................................................................................................•
Use the Up / Down keys to set the temperature .................................................•
Press Tick to confirm the settings .....................................................................................•
Press the right arrow key .....................................................................................................•
LEAVE will now flash and the current settings will be displayed.•
Press Tick to alter LEAVE settings ......................................................................................•
Repeat these steps to set all comfort levels.•
For any unused periods set time to --:--
•
Use the Left / Right keys to scroll to DONE and press Tick .....................•
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 12

Wavin neo Wavin neo
1211
Comfort Levels Explained
The neoStat offers three program mode options; Weekday/Weekend programming,
7 Day programming and 24 Hour programming. There is also the option to
use the thermostat as a Non-Programmable thermostat.
When thermostats are connected to the mesh network, the program mode for
the system is configured by using the neoApp.
The thermostat is supplied with comfort levels already programmed, but these can be
changed easily. The default times and temperature settings are;
07:00 - 21°C (Wake) 09:00 - 16°C (Leave) 16:00 - 21°C (Return) 22:00 - 16°C (Sleep)
If you only want to use 2 levels, you should program the unused levels to --:--
For Weekday/Weekend programming, the four comfort levels are the same for Mon-Fri, but can
be different for Sat-Sun. For 7 Day programming each day of the week can have four different
comfort levels. In 24 Hour mode all days are programmed with the same comfort levels.
To program the comfort levels, use the Left / Right keys to scroll to EDIT .............•
Press Tick to confirm selection .......................................................................................................•
Use the Left / Right keys to select day / period of week (the selection will flash).•
Press Tick to confirm selection .......................................................................................................•
WAKE will now flash and the current time and temperature setting will be shown.•
Press Tick to alter WAKE settings ...................................................................................................•
Use the Up / Down keys to set the hours ..............................................................•
Press Tick to confirm ..............................................................................................................•
Use the Up / Down keys to set the minutes .........................................................•
Press Tick to confirm ..............................................................................................................•
Use the Up / Down keys to set the temperature .................................................•
Press Tick to confirm the settings .....................................................................................•
Press the right arrow key .....................................................................................................•
LEAVE will now flash and the current settings will be displayed.•
Press Tick to alter LEAVE settings ......................................................................................•
Repeat these steps to set all comfort levels.•
For any unused periods set time to --:--
•
Use the Left / Right keys to scroll to DONE and press Tick .....................•
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 12

Wavin neo Wavin neo
1413
Temperature Control
The Up / Down keys allow you to adjust the set temperature .............................
When you press either key, you will see the word SET and the desired
temperature value. Use the Up / Down keys to adjust the SET value ...............
Press Tick to confirm settings and return to the main display .....................................
Temperature Hold
The temperature hold function allows you to manually override the current operating
program and set a different temperature for a desired period.
Use the Left / Right keys to scroll to HOLD ..........................................................•
Press Tick to confirm selection ..........................................................................................•
Use the Up / Down keys to set the desired Hold period .................................•
Press Tick to confirm selection ..........................................................................................•
Use the Up / Down keys to set the desired Hold temperature ......................•
Press Tick to confirm selection ..........................................................................................•
You will see the HOLD LEFT indication is displayed on screen.
The time will countdown the set duration and then revert to the normal program.
To cancel a temperature Hold, repeat these steps but reduce the Hold time to 00:00hrs.
HOLD LEFT Indicator
Hold Time Remaining
Note: This new temperature is maintained only until the next programmed comfort level.
At this time, the thermostat will revert back to the programmed levels.
Set Temperature
Set Icon
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 14

Wavin neo Wavin neo
1413
Temperature Control
The Up / Down keys allow you to adjust the set temperature .............................
When you press either key, you will see the word SET and the desired
temperature value. Use the Up / Down keys to adjust the SET value ...............
Press Tick to confirm settings and return to the main display .....................................
Temperature Hold
The temperature hold function allows you to manually override the current operating
program and set a different temperature for a desired period.
Use the Left / Right keys to scroll to HOLD ..........................................................•
Press Tick to confirm selection ..........................................................................................•
Use the Up / Down keys to set the desired Hold period .................................•
Press Tick to confirm selection ..........................................................................................•
Use the Up / Down keys to set the desired Hold temperature ......................•
Press Tick to confirm selection ..........................................................................................•
You will see the HOLD LEFT indication is displayed on screen.
The time will countdown the set duration and then revert to the normal program.
To cancel a temperature Hold, repeat these steps but reduce the Hold time to 00:00hrs.
HOLD LEFT Indicator
Hold Time Remaining
Note: This new temperature is maintained only until the next programmed comfort level.
At this time, the thermostat will revert back to the programmed levels.
Set Temperature
Set Icon
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 14

Wavin neo Wavin neo
1615
Locking the neoStat
The thermostat has a keypad lock facility. To activate the lock follow these steps.
Use the Left / Right keys to scroll to HOLD & press Tick for 10 seconds.•
The display will show 00:00 and you will need to enter a four digit pin number.•
Use the Up / Down keys to enter the first two digits .......................................•
Press Tick to confirm .............................................................................................................•
Use the Up / Down keys to enter the second two digits ................................•
Press Tick to confirm ............................................................................................................•
The display will return to the main screen and display the keypad lock indicator ....
Note: The keypad lock indicator is only displayed when the lock is active.
Unlocking the neoStat
To unlock the neoStat press Tick once. The display will show 00:00 and you will need to
enter the four digit pin number you set previously.
Use the Up / Down and Tick keys to enter the first two digits ............•
Use the Up / Down and Tick keys to enter the second two digits .....•
The display will unlock and return to the main screen.
Use the Left / Right keys to scroll to the Power Icon .............................................
The frost icon will toggle ON/OFF each time Tick is pressed ..................................................
In this mode, the neoStat will display the frost icon and will only turn the heating
ON should the room temperature drop below the set frost temperature (see page 23).
If the heating is turned ON whilst in frost mode, the flame symbol will be displayed.
To cancel the frost protect mode, navigate to the Power button again and press Tick.
Frost Protection Mode Enabled
Frost Mode
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 16

Wavin neo Wavin neo
1615
Locking the neoStat
The thermostat has a keypad lock facility. To activate the lock follow these steps.
Use the Left / Right keys to scroll to HOLD & press Tick for 10 seconds.•
The display will show 00:00 and you will need to enter a four digit pin number.•
Use the Up / Down keys to enter the first two digits .......................................•
Press Tick to confirm .............................................................................................................•
Use the Up / Down keys to enter the second two digits ................................•
Press Tick to confirm ............................................................................................................•
The display will return to the main screen and display the keypad lock indicator ....
Note: The keypad lock indicator is only displayed when the lock is active.
Unlocking the neoStat
To unlock the neoStat press Tick once. The display will show 00:00 and you will need to
enter the four digit pin number you set previously.
Use the Up / Down and Tick keys to enter the first two digits ............•
Use the Up / Down and Tick keys to enter the second two digits .....•
The display will unlock and return to the main screen.
Use the Left / Right keys to scroll to the Power Icon .............................................
The frost icon will toggle ON/OFF each time Tick is pressed ..................................................
In this mode, the neoStat will display the frost icon and will only turn the heating
ON should the room temperature drop below the set frost temperature (see page 23).
If the heating is turned ON whilst in frost mode, the flame symbol will be displayed.
To cancel the frost protect mode, navigate to the Power button again and press Tick.
Frost Protection Mode Enabled
Frost Mode
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 16

Wavin neo Wavin neo
1817
Power On/Off
The heating is indicated ON when the flame icon is displayed.
When the flame icon is absent, there is no requirement for heating to achieve the set
temperature but the neoStat remains active.
To turn the neoStat off completely, scroll to the Power Icon and hold
the Tick key for approximately 4 seconds until the display goes blank ...................
The display and heating output will be turned OFF.
To turn the thermostat back ON, press the Tick key once .............................................................
Holiday
In thermostat mode, the holiday function reduces the set temperature in your home
to the frost protection temperature setting (see page 23).
In time clock mode, the holiday function maintains the timed output as OFF.
The thermostat will maintain this temperature for the duration of the holiday and will
then automatically return to the program mode on your return.
Use the Left / Right keys to scroll to HOLIDAY and press Tick ...............•
Using the Up / Down keys enter the number of days holiday .....................•
Press Tick to confirm settings ............................................................................................•
To cancel, repeat these steps but reduce the Holiday duration to 00 days.
Note: A holiday period does not start until 00:00 the next day. For example, if you set a
holiday period on Friday for 2 days, Saturday will be counted as the first day and the
thermostat will revert back to the programmed schedule at 00:00 on Monday.
Thermostat completely OFF Thermostat powered ON
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 18

Wavin neo Wavin neo
1817
Power On/Off
The heating is indicated ON when the flame icon is displayed.
When the flame icon is absent, there is no requirement for heating to achieve the set
temperature but the neoStat remains active.
To turn the neoStat off completely, scroll to the Power Icon and hold
the Tick key for approximately 4 seconds until the display goes blank ...................
The display and heating output will be turned OFF.
To turn the thermostat back ON, press the Tick key once .............................................................
Holiday
In thermostat mode, the holiday function reduces the set temperature in your home
to the frost protection temperature setting (see page 23).
In time clock mode, the holiday function maintains the timed output as OFF.
The thermostat will maintain this temperature for the duration of the holiday and will
then automatically return to the program mode on your return.
Use the Left / Right keys to scroll to HOLIDAY and press Tick ...............•
Using the Up / Down keys enter the number of days holiday .....................•
Press Tick to confirm settings ............................................................................................•
To cancel, repeat these steps but reduce the Holiday duration to 00 days.
Note: A holiday period does not start until 00:00 the next day. For example, if you set a
holiday period on Friday for 2 days, Saturday will be counted as the first day and the
thermostat will revert back to the programmed schedule at 00:00 on Monday.
Thermostat completely OFF Thermostat powered ON
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 18

Wavin neo Wavin neo
2019
Optional Features Explained
THE FOLLOWING SETTINGS ARE OPTIONAL AND IN MOST CASES
NEED NOT BE ADJUSTED
Feature 01 – Pairing To neoHub: This function is used to connect the thermostat to the
neoHub.
Feature 02 - Switching Differential: This function allows you to increase the switching
differential of the thermostat. The default is 1°C which means that with a set temperature of
20°C, the thermostat will switch the heating on at 19°C and off at 20°C. With a 2°C differential,
the heating will switch on at 18°C and off at 20°C.
Feature 03 - Frost Protect Temperature: This is the temperature maintained when the
thermostat is in Frost Mode. The range is 07 - 17°C. The default is 12°C and is suitable for most
applications.
Feature 04 – Output Delay: To prevent rapid switching, an output delay can be entered.
This can be set from 00 - 15 minutes. The default is 00 which means there is no delay.
Feature 05 – Temperature Up/Down Limit: This function allows you to limit the use of the up
and down temperature arrow keys. This limit is also applicable when the thermostat is locked
and so allows you to give others limited control over the heating system.
Feature 06 – Sensor Selection: On this neoStat, you can select which sensor should be used.
You can select between air temperature only, floor temperature, or both. When you enable
both sensors, the floor sensor is used as a floor limiting sensor and is designed to prevent the
floor from overheating.
Feature 07 – Floor Temp Limit: This function is available when mode 07 is set to 03 or 04.
You can set a floor limiting temperature between 20-45°C (28°C is the default setting).
Note: Air Sensor only MUST NOT be used to control electric under-floor heating.
Floor Sensor or Both should be used.
Feature 08 – Optimum Start: Optimum start will delay the start up of the heating
system to the latest possible moment to avoid unnecessary heating and ensure the
building is warm at the programmed time. The thermostat uses the rate of change
information to calculate how long the heating needs to raise the building
temperature 1°C (with a rate of change of 20, the thermostat has calculated the
heating needs 20 minutes to raise the building temperature 1°C) and starts the
heating accordingly.
Feature 09 - Rate of Change: Number of minutes for 1°C temperature rise.
Feature 10 – Cool Enable: This function is used to enable/disable cooling mode.
Feature 11 – Cool Set Temperature: This is the set temperature that the thermostat will
start cooling.
Feature 12 – Program Mode: Non-Programmable, Weekday/Weekend (5/2),
7 Day Programming or 24 Hour. The thermostat offers three programming modes and the
option of configuring it to work as a non-programmable thermostat.
Weekday/ Weekend - allows you to program 4 comfort levels for the weekday and
4 different comfort levels for the weekend.
7 Day Program Mode - Each day has 4 comfort levels that can be programmed
independently.
24 Hour Mode - All days are programmed the same and repeat continuously.
Feature 13 - Temperature Format: This function allows you to select between °C and °F.
50110_HM-neoStat-2014_Layout 1 31/10/2014 11:33 Page 20
