Wazo PALMA B1036Q User manual

ASSEMBLY INSTRUCTIONS
VERSION 1.0
PALMA
PALMA ACACIA BED (QUEEN)
B1036Q

ASSEMBLY INSTRUCTIONS
PALMA ACACIA BED (QUEEN) Page 2 of 6
Read these instructions carefully and keep for future reference. Ensure that you have all the
Pieces before starting assembly by referring to the parts inventory. When starting assembly,
Place all pieces on a soft, clean, and flat surface like a carpet to prevent scratches or damage.
If you are having difficulty, our VIP Team is always here for you. Call us at 1-800-684-6014
During business hours or email us at [e-mail].
PARTS INVENTORY
ID
DESCRIPTION
QTY
HEADBOARD
1
TAILBOARD
1
WOODEN
LEG SUPPORT 4
WOODEN
MIDDLE SUPPORT 2
SIDE RAIL
2
SLATES
11
IRON LEGS
2
A
B
C
D
E
F
G

PALMA ACACIA BED (QUEEN) Page 3 of 6
IMPORTANT NOTES
1. Please check that all parts are
present before starting assembly.
2. For the protection of your furniture
and to ensure it is not damaged in
the assembly process, place all
parts on a clean, smooth surface.
3. In order to align all screws properly,
tighten all screws halfway first until
product frame is assembled and
then tighten fully when all screws
are aligned.
4. Do not use power tools for
assembly.
5. Please periodically check all fittings
and re-tighten as necessary.
6. Do not use furniture unless all bolts
and screws are firmly secured.
Structural integrity is warranted only if all
fasteners are properly installed & tightened,
and the bed is moved only per instructions.
!
DO NOT DRAG BED, ALWAYS LIFT WITH
AT LEAST TWO PEOPLE BEFORE MOVING
!
HARDWARE / TOOLS INVENTORY
ID
DESCRIPTION
QTY
SPANNER 12X13
1
BED BOLT 8X20
8
ALLEN KEY BOLT 6X70
4
ALLEN KEY 4MM
1
C
D
B
A

PALMA ACACIA BED (QUEEN) Page 4 of 6
1
2

PALMA ACACIA BED (QUEEN) Page 5 of 6
3
4

PALMA ACACIA BED (QUEEN) Page 6 of 6
5
6
