1 Hardware Connection
Figure 1-1 shows the power and video cables.
Power and video cables
Connect the BNC connector of the power or video cable to a video signal cable and
connect the other connector to a low-voltage power cable (12V DC). After installing
the camera, directly connect the video cable and power cable.
The BNC video output interface is used to emit composite video signals. Monitors with a
resolution of higher than 800 TVL are recommended.

Error! Use the Home tab to apply 标题 1
to the text that you want to appear here.
High-Resolution IR Camera
User Manual
6
Issue V1.0 (2018-03-20)
2 Eyeball Camera
2.1 Dimensions
Figure 2-1 shows the camera dimensions of 0E-HDD1MP28(G) and 0E-
HDD2MP28(G).
Dimensions of 0E-HDD1MP28(G) and 0E-HDD2MP28(G) (unit: mm)
Figure 2-2 shows the camera dimensions of 0E-HDDMO2812 and 0E-HDDM2812G.
Dimensions of 0E-HDDMO2812 and 0E-HDDM2812G (unit: mm)

High-Resolution IR Camera
User Manual
Error! Use the Home tab to apply
标题 1 to the text that you want to
appear here.
Issue V1.0 (2018-03-20)
7
2.2 Device Installation
Step 1 Open a package, take out the camera, unscrew the camera compression ring, and
disassemble the camera, the camera components is shown in Figure 2-3.
Camera components
Step 2 Use the base as drill template, drill holes on the ceiling or wall, and reserve the cable
entries of the video/power cables.
Figure 2-4 and Figure 2-5 shows the dimensions of the camera mounting base.
Dimensions of the 0E-HDD1MP28(G) and 0E-HDD2MP28(G) mounting
base

Error! Use the Home tab to apply 标题 1
to the text that you want to appear here.
High-Resolution IR Camera
User Manual
8
Issue V1.0 (2018-03-20)
Dimensions of the 0E-HDDMO2812 and 0E-HDDM2812G mounting base
Step 3 Nail swell plastic buttons in to drilled holes, and fix the camera mounting base to the
ceiling (or wall) by use of self-tapping screws.
Step 4 Install the compression ring, the dome shell, and the dome shell fixed base on the
camera mounting base.
Figure 2-6 shows camera installation.
Camera installation
Step 5 Turn the main body, adjust the lens direction, and note the position of the dome cover
window.

High-Resolution IR Camera
User Manual
Error! Use the Home tab to apply
标题 1 to the text that you want to
appear here.
Issue V1.0 (2018-03-20)
9
⚫Connect the BNC connector of the power or video cable to a video signal cable and
connect the other connector to a low-voltage power cable. After installing the camera,
directly connect the video cable and power cable.
⚫Adjust the position of the camera by triaxial rotation: rotating horizontally, rotating up
and down, and performing lens axial rotation, and adjust the camera direction and lens
alignment target.
⚫Set the zoom and focus value in UTC page of PTZ function of DVR user interface to
adjust the view angle and focal length when a Motorized lens camera is connected to the
DVR.(Only for 0E-HDDMO2812 and HDDM2812G)
Figure 2-7 shows monitoring direction adjustment.
Monitoring directionadjustment
Step 6 Use soft cloth to wipe the lens front glass which is likely to be soiled due to installation
for cleaning the camera, and complete product installation and debugging.
----End

Error! Use the Home tab to apply 标题 1
to the text that you want to appear
here.Error! Use the Home tab to apply 标
题7 to the text that you want to appear
here.
High-Resolution IR Camera
User Manual
10
Issue V1.0 (2018-03-20)
3 Bullet camera
3.1 Dimensions
Figure 3-1 shows the dimensions of 0E-HDBMO2812 and 0E-HDBM2812G.
dimensions of 0E-HDBMO2812 and 0E-HDBM2812G
Figure 3-2 shows the dimensions of 0E-HDB1MP36(G) and 0E-HDB2MP36(G).

High-Resolution IR Camera
User Manual
Error! Use the Home tab to apply 标题 1 to
the text that you want to appear here.Error!
Use the Home tab to apply 标题 7 to the text
that you want to appear here.
Issue V1.0 (2018-03-20)
11
dimensions of HDB1MP36(G) and 0E-HDB2MP36(G)
3.2 Device Installation
Step 1 Stick the Installation location sticker on the ceiling or wall, Drill three holes based on
the marks on the sticker. Drive the swell plastic buttons into the holes, as shown in
Figure 3-3.
Drilling holes
Step 2 Loosen the locking screw with L-Hex Wrench and rotate the camera, then attach the
camera to the surface, as shown in Figure 3-4.

Error! Use the Home tab to apply 标题 1
to the text that you want to appear
here.Error! Use the Home tab to apply 标
题7 to the text that you want to appear
here.
High-Resolution IR Camera
User Manual
12
Issue V1.0 (2018-03-20)
Installing camera
Step 3 Connect the Power and video cable, as shown in Figure 3-5.
Connecting cable
Step 4 Loosen the locking screw with L-Hex Wrench, rotate the camera to adjust the position
and image so that the camera faces the monitored area, then tighten the locking screw,
as shown in Figure 3-6.
To rotate the part 1 of the camera for 360°, loosen rotation lock.
To rotate the part 2 of the camera for180°, loosen screw 1.
To rotate the part 3 of the camera for 360°, loosen screw 2.

High-Resolution IR Camera
User Manual
Error! Use the Home tab to apply 标题 1 to
the text that you want to appear here.Error!
Use the Home tab to apply 标题 7 to the text
that you want to appear here.
Issue V1.0 (2018-03-20)
13
Adjusting monitored area
Set the zoom and focus value in UTC page of PTZ function of DVR user interface to adjust
the view angle and focal length when a Motorized lens camera is connected to the DVR
(Only for 0E-HDBMO2812 and 0E-HDBM2812G)
----End

Error! Use the Home tab to apply 标题 1
to the text that you want to appear
here.Error! Use the Home tab to apply 标
题7 to the text that you want to appear
here.
High-Resolution IR Camera
User Manual
14
Issue V1.0 (2018-03-20)
4 Technical Specifications
Table 4-1 lists the technical specifications of the camera.
Technical specifications
Specifications
0E-HDD1MP28
0E-HDD1MP28G
0E-HDB1MP36
0E-HDB1MP36G
CAMERA
Image Sensor
1/4”CMOS
Signal System
PAL/NTSC
Min. illumination
0.05Lux@(F1.2,AGC ON) ; ON); 0Lux@(IR LED ON)
S/N Ratio
≥50dB
Day & Night
ICR
Shutter Speed
PAL:1/50-1/50000, NTSC:1/60-1/60000
Wide Dynamic Range
dWDR
Digital Noise Reduction
2D
Lens
2.8mm
3.6mm
FOV
90°
85°
IR LED
18pcs
IR Wavelength
850nm
IR Range
20m
OSD Joystick
Support
Up the Coax
Support
Effective Resolution
1280x720
Frame
PAL:25fps ,NTSC:30fps
VIDEO OUTPUT
Max Distance
75-5 300m

High-Resolution IR Camera
User Manual
Error! Use the Home tab to apply 标题 1 to
the text that you want to appear here.Error!
Use the Home tab to apply 标题 7 to the text
that you want to appear here.
Issue V1.0 (2018-03-20)
15
Specifications
0E-HDD1MP28
0E-HDD1MP28G
0E-HDB1MP36
0E-HDB1MP36G
Video Output
AHD/TVI/CVI/CVBS
GENERAL
Power Supply
DC12V±10%
Power Consumption
3.5W(Max)
Operating Temperature
-25°C ~ 55°C (-13°F ~ 131°F )
Operating Humidity
0% - 85% RH
Ingress Protection
IP66
Material
Aluminium Alloy
Product Dimensions
Φ94×84mm
Φ176×60mm
Product Weight
360g
300g

Error! Use the Home tab to apply 标题 1
to the text that you want to appear
here.Error! Use the Home tab to apply 标
题7 to the text that you want to appear
here.
High-Resolution IR Camera
User Manual
16
Issue V1.0 (2018-03-20)
Specifications
0E-HDD2MP28
0E-HDD2MP28G
0E-HDDMO2812
0E-HDDM2812G
CAMERA
Image Sensor
1/2.9”Sony CMOS
Signal System
PAL/NTSC
Min. illumination
0.01Lux@(F1.2,AGC ON) ; 0Lux@(IR LED ON)
S/N Ratio
≥50dB
Day & Night
ICR
Shutter Speed
PAL:1/50-1/50000, NTSC:1/60-1/60000
Wide Dynamic Range
dWDR
Digital Noise Reduction
2D
Lens
2.8mm
Motorized 2.8-12mm
FOV
90°
90°-35°
IR LED
18pcs
24pcs
IR Wavelength
850nm
IR Range
20m
40m
OSD Joystick
Support
Up the Coax
Support
Effective Resolution
1920x1080
Frame
PAL:25fps ,NTSC:30fps
VIDEO OUTPUT
Max Distance
75-5 300m
Video Output
AHD/TVI/CVI/CVBS
GENERAL
Power Supply
DC12V±10%
Power Consumption
3.5W(Max)
4W(Max)
Operating Temperature
-25°C ~ 55°C (-13°F ~ 131°F )
Operating Humidity
0% - 85% RH
Ingress Protection
IP66
Material
Aluminium Alloy

High-Resolution IR Camera
User Manual
Error! Use the Home tab to apply 标题 1 to
the text that you want to appear here.Error!
Use the Home tab to apply 标题 7 to the text
that you want to appear here.
Issue V1.0 (2018-03-20)
17
Specifications
0E-HDD2MP28
0E-HDD2MP28G
0E-HDDMO2812
0E-HDDM2812G
Product Dimensions
Φ94×84mm
Φ119×100mm
Product Weight
360g
650g

Error! Use the Home tab to apply 标题 1
to the text that you want to appear
here.Error! Use the Home tab to apply 标
题7 to the text that you want to appear
here.
High-Resolution IR Camera
User Manual
18
Issue V1.0 (2018-03-20)
Specifications
0E-HDB2MP36
0E-HDB2MP36G
0E-HDBMO2812
0E-HDBM2812G
CAMERA
Image Sensor
1/2.9”Sony CMOS
Signal System
PAL/NTSC
Min. illumination
0.01Lux@(F1.2,AGC ON) ; 0Lux@(IR LED ON)
S/N Ratio
≥50dB
Day & Night
ICR
Shutter Speed
PAL:1/50-1/50000, NTSC:1/60-1/60000
Wide Dynamic Range
dWDR
Digital Noise Reduction
2D
Lens
3.6mm
Motorized 2.8-12mm
FOV
85°
90°-35°
IR LED
18pcs
24pcs
IR Wavelength
850nm
IR Range
20m
40m
OSD Joystick
Support
Up the Coax
Support
Effective Resolution
1920x1080
Frame
PAL:25fps ,NTSC:30fps
VIDEO OUTPUT
Max Distance
75-5 300m
Video Output
AHD/TVI/CVI/CVBS
GENERAL
Power Supply
DC12V±10%
Power Consumption
3.5W(Max)
4W(Max)
Operating Temperature
-25°C ~ 55°C (-13°F ~ 131°F )
Operating Humidity
0% - 85% RH
Ingress Protection
IP66
Material
Aluminium Alloy
