We BTOF User manual

Item #: BTOF
Assembly Instructions
For our most current instructions, to request missing, lost or broken parts, or for any other Customer
Service issues, please visit our website at www.walkeredison.com or call us at 877-207-5906.
Revised 03/2012

Instruction Manual
IMPORTANT INFORMATION
READ BEFORE ASSEMBLING THIS PRODUCT
Follow the information on the warning labels found on the bunk bed and on the packaging.
Do not remove the warning label from the bed.
Use only a mattress with the dimensions 74-75 in.L x 37.5-38.5 in.W x 9 in.H on the upper
bunk.
The surface of the mattress must be at least 5 in. (127mm) below the upper edge of the
guardrails. Mattress must not exceed the maximum thickness of 9 in.
Always use the recommended size of mattress or mattress support, or both, to help prevent
the likelihood of entrapment or falls.
The use of a water or sleep flotation mattress is prohibited.
Replacement parts, including additional guardrails, may be obtained from any of Walker
Edison Furniture Company’s dealers or by contacting us online at www.walkeredison.com.
DO NOT use substitute parts. Contact the manufacturer or dealer for replacement parts.
Always use guardrails on the upper bunk. If the bunk bed will by placed next to a wall, the
guardrail running the full length of the bed should by placed against the wall to prevent
entrapment between the bed and the wall.
Periodically check that the guardrails, ladders and other components of the bed are in their
proper position, free from damage, and that all connectors are tight.
Always use the ladder to access the upper bunk.
DO NOT allow children under 6 years of age to use the upper bunk.
DO NOT allow horseplay on or under the bed. Prohibit jumping on the bed.
Prohibit more than one person on the upper bunk.
The use of a night light may provide an added safety precaution for a child using the upper
bunk.
STRANGULATION HAZARD – Never attach or hang items to any part of the bunk bed that
are not designed for use with the bed; including but not limited to hooks, belts and jump
ropes.
Keep these instructions for future reference.

Parts List
P.4

Attach crossbar (H) to guardrail (I) using extra-large bolts (3) with large washers (2). Repeat this step for
second crossbar (H) and second guardrail (I).
Attach double crossbar (G) and crossbar (H) with guardrail (I) to posts (A,B) using extra-small bolts (1) with
small washers (7). Note that the end of guardrail (I) with the manufacturer label will attach to post (B).
P.6

Attach double crossbar (U) and crossbar (H) with guardrail (I) to posts (C,D) using extra-small bolts (1) with
small washers (7).
Screw double-headed bolts (4) into posts (B,D).
P.7

Screw ladder rungs (M) onto double-headed bolts (4). Attach ladder rail (F) to ladder rungs (M) using small
bolts (5) with small washers (7).
Secure ladder rail (F) to double crossbar (G) using small bolt (5) with small washer (7). Secure ladder rail (F)
to crossbar (H) using extra-small bolt (1) with small washer (7).
P.8

Screw ladder rungs (M) onto double-headed bolts (4). Attach ladder rail (F) to ladder rungs (M) using small
bolts (5) with small washers (7).
Secure ladder rail (F) to double crossbar (U) using small bolt (5) with small washer (7). Secure ladder rail (F) to
crossbar (H) using extra-small bolt (1) with small washer (7).
P.9

Attach crossbars (J,K) to posts (A,B) using extra-small bolts (1) with small washers (7).
P.10

Attach crossbars (J,K) to posts (C,D) using extra-small bolts (1) with small washers (7).
P.11

Insert mattress support bars (O) into the provided slots of crossbars (J). Secure mattress support bars (O) in
place by snapping plastic tab locks (8) into the slots of crossbars (J). It may be necessary to apply more
pressure to some plastic tab locks than others.
P.12

Snap plastic links (9) onto mattress support bars (O).
P.13

Attach guardrail (E) to posts (A,C) using extra-small bolts (1) with small washers (7). Attach guardrail (E) to
crossbar (J) using extra-large bolts (3) with large washers (2).
A
J
C
P.14

Attach guardrail (E) to posts (B,D) using extra-small bolts (1) with small washers (7). Attach guardrail (E) to
crossbar (J) using extra-large bolts (3) with large washers (2).
J
B
D
P.15

Attach futon adjustment mechanisms (L,R) to the bed frame using medium bolts (10) with large washers (2)
and nuts (11) with large washers (2). Using wrenches (14,15) together, tighten medium bolts (10) and nuts (11)
firmly. Attach foam pads (6) to bed frame as desired.
P.16

Slide futon frame portion (Q) into futon frame portion (P) and secure using extra-small bolts (1). Slide futon
frame portion (S) into futon frame portion (N) and secure using extra-small bolts (1).
P.17

Attach the futon frames from the previous step to the futon adjustment mechanisms using large bolts (12) with
large washers (2) and nuts (11) with large washers (2). Using wrenches (14,15) together, tighten large bolts
(12) and nuts (11) firmly.
P.18

Insert connecting arms (T) into the futon frames.
P.19

Raise the futon frames into a sitting position. Insert connecting arms (T) into the futon frames.
P.20
