Webb Werr17 Installation and maintenance instructions

OPERATOR’S MANUAL AND PARTS LIST
PETROL LAWNMOWER - WERR17
Spares & Support: 01793 333212
www.webblawnmower.co.uk
Before use please read & understand this manual, paying particular
attention to the safety instructions.
12/10/2012 v1

User’s manual 1

2 User’s manual
Contents
What you get with your Webb roller mower................................................................................4
Mower features.............................................................................................................................5
Tips on mower safety ................................................................................................................6-7
Before you begin .......................................................................................................................8-9
Cutting height adjustment............................................................................................................10
Starting the engine .......................................................................................................................11
Basic maintenance made easy ................................................................................................12-14
Technical specifications ...............................................................................................................14
Fast trouble shooting.................................................................................................................... 15
Warranty conditions..................................................................................................................... 16
EC Declaration of Conformity...................................................................................................... 17
Notes............................................................................................................................................. 18
Warranty registration card.........................................................................................................19-20
Webb products are monitored and enhanced on an on-going basis to comply with changing
technical standards and requirements. As a result, Webb reserves the right to alter design and
specifications at any time without prior notice.

User’s manual 3
Thank you for choosing a Webb mower
We’re sure that you’ll enjoy many years if trouble-free performance, plus you have
the reassurance of an industry-leading 2-year domestic warranty as outlined on
page 15.
Inside this guide you will nd out all you need to know to correctly operate your new
Webb mower. To ensure that you use your new mower
responsibly and get the best results possible, please read all of the safety and
operating instructions carefully before using your lawnmower.
What you get with your Webb mower
YTQemaNYTQemaN
1tlobpmalC1rewomnwalenignelorteP
2eitelbaC1rehctacssargraeR
Sparkplug socket (21) 1 2
Socket (13) 1 Multi-function wrench 1
Spanner lever 1 Cover type nut (M8) 4
Quickstart hook1
Quickrelease handle

4 User’s manual
Mower features
gulpkrapS7revelevirD1
2 Operator presence control lever 8 Exhaust
Oil filler and dipstick9lortnocelttorhT3
relloR01rotcelfedraeR4
gabnoitcellocssarG11knatleuF5
eporretratS21retlifriA6

User’s manual 5
Tips on mower safety
WARNING! The information contained within this safety section is
extremely important. Personal injury to the user and to others may
result if this section is not read and followed at all times.
1. Before starting your mower inspect it carefully to ensure that there are no loose
parts and that it is in good working order.
2. Be sure of your footing. Always walk when operating the lawnmower, never run.
3. Clear the area to be mowed of any stones, sticks, wire and debris before
beginning, and always ensure that you mow a safe distance away (over 14 metres)
from adults, children and animals.
4. Keep hands, feet and clothing away from the mower’s moving parts, and always
wear appropriate footwear (do not wear sandals,open or soft shoes).
5. Never put your hands or feet underneath the chassis of the lawnmower while the
engine is running.
6. Be aware that the machine’s exhaust area and other parts of the lawnmower get
very hot during use, and will remain hot afterwards.
7. Turn off the engine and disconnect the spark plug cap before cleaning,
transporting, or making adjustments.Never leave the mower unattended.
8. Mow across the face of slopes, not up & down, and avoid mowing on very steep
slopes. We recommend you avoid mowing when it is raining, or after nightfall.
9. Do not operate the machine by pulling it towards you as you risk pulling it on to
your feet. Instead, always push and walk behind your lawnmower.
10. Do not fill the tank, or start the lawnmower indoors, or in a poorly ventilated area,
as exhaust gases contain poisonous substances and petrol fumes are flammable
and dangerous.
11. Use unleaded petrol that is not more than 3 months old. Use a funnel. Do not fill the
tank completely. Clean up any overflow or splashes before starting the engine or storing.

6 User’s manual
12. To inspect the underside of your mower, only tilt the lawnmower backwards when
standing behind it (this is the side where the exhaust is near the ground) otherwise
oil may leak into inappropriate areas of the engine. Never tilt the lawnmower when
the engine is running.
13. Turn off the engine before emptying the grass-catcher, and before clearing any
grass caught in the rear flap where the catcher fits.
14. Do not alter engine governing settings or over-rev the engine, as excessive speed
is dangerous and can reduce engine life.
15. Never open the fuel filler cap, or fill the tank, if the engine is still hot after use. And
please ensure that you securely tighten the petrol cap after filling.
16. Do not transport the mower in a vehicle if there is any petrol in the tank.
17. Store fuel and oil in a cool well-ventilated place, away from direct sunlight and not
near gas cylinders or hot water heater systems.
18. Do not smoke when filling the fuel tank, using the machine, or when petrol is in the
immediate area. And never use or store the mower near a naked flame.
19. Webb recommends that you wear a safety helmet, ear protectors, safety goggles
and safety boots when using a lawnmower. These are available on 01793 333212.
20. All servicing and repair work under warranty must be carried out by an Authorised
Webb Dealer, otherwise the 2-year warranty may be void. You can find your nearest
dealer at www.webblawnmowers.co.uk.

User’s manual 7
Before you begin.
WARNING! The following procedures must be carried out before you
start the engine of your lawnmower.
1. Fill oil sump with oil.
The mower is NOT supplied with oil in
the engine, add 591ml SAE30 oil before
starting the engine for the first time.
Firstly, remove the warning label from under
the dipstick, then remove the dipstick
and slowly pour 591ml SAE30 oil into the
engine via the oil filler. Replace the dipstick
and tighten.
Before you use the mower each time, check
the oil level and if necessary top up with
SAE30 engine oil. To check the oil level,
just unscrew the yellow dipstick, wipe clean
and replace into the oil filler, remove it
again to check the oil level. The oil level
must be between the min and max marks on
the dipstick.

8 User’s manual
2. Fill fuel tank with unleaded petrol.
Petrol is highly flammable so extreme caution must be
taken when handling it. Always store petrol in approved
containers and you must ensure that you use fresh
petrol that is less than three months old. Do not mix oil
with petrol.
To put petrol in the fuel tank, firstly remove the warning
label from under the petrol cap. It’s best to fill the tank
using a clean funnel, but never fill it completely. Instead,
leave at least 13mm from the bottom of the filler neck to
allow for expansion. Ensure that you securely tighten the
petrol cap after filling.
3. Attach the grass box or mulch plug.
The grass catcher attaches easily by
lifting the mower’s rear deflector and
inserting the grass catcher.
Just lift the rear deflector with one hand and then
gently slide the catcher into position
(as shown in photo on right).
Your mower comes with a mulch plug, this
enables you to cut your grass without collection, the cuttings disappear into your lawn.
For efficient mulching you can only cut the top 1/3 of the height of your grass, cutting
more than 1/3 stops the mulching action. To attach the mulch plug simply remove the
grass catcher and insert the plug into the rear opening.
Alternatively you can remove the grass catcher and mulch plug to discharge the cuttings
from the rear of the machine.

User’s manual 9
Cutting height adjustment.
WARNING! Turn mower off before adjusting cutting height lever.
Your lawnmower’s height adjustment is positioned on
the rear left side. There is a single 6-position lever
that adjusts the front wheels and rear roller at the
same time.
The lower the level, the shorter the cut. For very thick
or moist grass, you should select a higher setting than
usual to avoid clogging and stalling the lawnmower
under the extra cutting load.

10 User’s manual
Starting the engine.
WARNING! Keep hands, feet, and clothing well away from moving parts,
the exhaust, and the engine cowling. Refer to ‘Tips on mower safety’ on
pages 6 and 7 for more information.
1. Make sure that your mower is on a safe, flat area (a paved area or path is ideal
– avoid thick wet grass and gravel surfaces) to make starting safe.
2. Move the throttle control lever located on the handle to the ‘ ’ position.
3. Slide the ‘Red’ petrol tap lever to the left ‘On’ position.
4. Firmly hold the top handle with one hand, and then with your other hand pull the
cord slowly until you feel resistance. Then pull vigorously.
5. When the engine has been running for at least 15 seconds (more time on cold days)
adjust the throttle control lever to the ‘ ’ position.
6. To re-start a hot engine, move the throttle control lever to the ‘ ’ position
and then refer to ‘Point 4’ above.
7. To turn off your mower, slide the throttle control lever down to the ‘Stop’ position.
After it has stopped, slide the ‘Red’ petrol tap lever to the right ‘Off’ position.


User’s manual 11
Basic maintenance made easy.
WARNING! If your mower is not serviced correctly, you could reduce
your mower’s ability to operate and void warranty.
1. Spark plug.
Firstly, wait until the engine has cooled
before disconnecting the spark plug cover
and then removethe spark plug with the
box spanner supplied. If it is dirty, you can
clean the plug with a wire brush.
For best results we advise you to replace
the spark plug after 100 hours of use. The
replacement spark plug is NGK BR2LM.
When refitting the spark plug do not over-
tighten. If adjusting yourself, note the spark
plug gap must be set to 0.75mm.
2. Air filter.
Ensure the engine is cool, unscrew the top
air filter nut, lift up the cover and remove
the air filter element. Put the cover back on the
housing immediately to prevent any objects
falling into the air intake.
Either carefully brush off any excess dirt
particles, or replace the air filter with a new
one. To protect your warranty, only use
a genuine B&S air filter. We recommend
that you replace the air filter after every 12
months of regular usage. When the air filter
has been cleaned or replaced, screw-in the
cover, taking care not to over-tighten.

12 User’s manual
3. Cleaning ABS deck often.
As the ABS material can be marked by petrol, please clean the deck immediately whenever you
find petrol on the deck or before storing.

User’s manual 13
6. Blades and cutting system.
Extreme care should be taken with blades.
Ensure the mower is off and the spark plug
lead disconnected from the spark plug, to
prevent accidental ignition.
Remove the catcher set the cutting height lever to
the highest level, and then hold up the rear
deflector in order to inspect your blade. Check
every few months to make sure they are not
damaged, loose, or overly worn. If loose, tighten,
but do not over-tighten, the nuts and bolts.
If you are planning to change the blades
yourself, use thick work gloves and take
extreme care at all times. A full range of
parts is available from your Authorised
Webb Dealer.
Technical specifications.
Model WERR17
Engine Briggs and Stratton 500 series
Displacement 158cc
Rated power 2 kW
Tank capacity 965 ml
Engine oil capacity 591ml
Spark plug BR2LM, WPG3RF, RJ19LM, W9LMR-US or WR11E0
Rated speed 2800 rpm
Cutting width 430 mm
Adjustable cutting heights 6
Cutting height 21-77 mm
Grass collection capacity 55 litres
Noise level 96 dB (A)
Weight (including catcher) 32kg
Chassis ABS

14 User’s manual
Fast trouble shooting
Often, a depleted, loose, or dirty spark plug is responsible for a mower not being able
to start, but there can be a number of other reasons. Refer below to the list of potential
problems you may encounter, along with suggested remedies. For servicing and all
warranty work, contact your local Authorised Webb Dealer.
Problem Likely cause
Throttle lever not set properly
Out, or almost out, of fuel
Spark plug failed
Suggested remedy
Set to ‘Cold Start’ for cold or a little lower when warm
Fill tank with unleaded petrol
Replace with a suitable new spark plug
Engine does
not start.
Engine stops
often
Engine loses
power
Mower
vibrates
too much
Poor cutting
catching
Spark plug dirty
Spark plug not connected
Flooded engine
Old petrol in the tank
Water in the fuel tank
Blocked fuel supply
Fuel cap is not venting
Wrong type of fuel
Dirty air cleaner filter
Incorrect height adjustment
Blocked fuel cap vent holes
Loose cutting blade
Bent or broken blade
Excessive grass/dirt build-up
Blade worn/damaged
Catcher not fitted correctly
Incorrect cutting height set
Blocked grass catcher vents
Clean or replace with a new spark plug
Press firmly on the terminal cover
Turn fuel ‘off’ then pull cord until it starts, then turn ‘on’
Drain stale fuel and replace with new unleaded
Contact an authorised Webb dealer
Ensure the fuel line is not pinched or blocked
You may need to slightly loosen the fuel cap
Drain petrol tank and fill with new unleaded
Clean or replace with a new B&S air-filter
Raise the mower’s cutting height lever
Ensure the 3 holes in the fuel tank cap are clear
Check and tighten bolts and nuts
Replace disc or blades
Clean and ensure underside clear of build up
Replace blade
Reattach carefully and also check for damage
Adjust the cutting height
Clear and clean the vents
Reinsert carefully and also check for damage

User’s manual 15
Warranty conditions
Please note that your warranty is affected by terms and conditions. Read on to fully
For full warranty conditions please contact the domestic office as listed on page 1 or
local dealer where you purchased the machine from.
understand what is covered by the warranty and what is not covered. Those items not
covered by the warranty are the responsibility of the owner and any repairs will be at
the owner’s expense.
The warranty does not affect your statutory rights or remedies as outlined in applicable
consumer legislation.
Webb provides an express warranty for this product for a period of 2 years
from your original purchase date with the exception of commercial-use which is for
a period of 90 days. The warranty is not transferable and is only applicable to the
original purchaser that can provide original proof of purchase.
Defective parts will be replaced or repaired by an Authorised Webb Dealer without
charge for labour or materials, subject to conditions. Repairs or adjustments required
by failure to follow the manufacturer’s instructions are chargeable to the owner.
This express warranty does not cover;
 Intentional or unintentional misuse, abuse or breakages
 Normal wear and tear
 Oiled air cleaner or starting difficulty caused by mower incorrectly tipped on its
side
 Consumable items (including oil, blades and sparkplugs)
 Defects or faults caused by an act or omission after leaving manufacture
 Incorrect, contaminated or poor quality fuel (older than 3 months) or oil
 Incorrect maintenance or storage of the product
 Water damage or environmental conditions
 Failure to observe safety requirements
 Any loss or damage arising from faulty parts or workmanship
The warranty may become void if any unauthorised person dismantles, repairs, or
modifies the product.

Parts Diagram

No. Webb No. Descri
p
tion Qt
y
. No. Webb No. Descri
p
tion Qt
y
.
1 WE106-01 Grass channel 1 58 WE106-58 Deflector spring, right 1
2 WE106-02 Self-tapping screw & washer 5×30F 9 59 WE106-59 Deflector axle 1
3 WE106-03 Belt cover 1 60 WE106-60 Deflector spring, left 1
4 WE106-04 Self-tapping screw & washer 5×20F 4 61 WE106-61 Mulching plu
g
1
5 WE106-05 Self-tapping screw with washer 5×50
F
5 62 WE106-62 Connecting bar extension spring 1
6 WE106-06 Cross recessed bolt M6×16 2 63 WE106-63 Spring washer 12 4
7 WE106-07 Hex bolt with spring & flat washer M8×60 3 64 WE106-64 Bearing 6001-2RS 8
8 WE106-08 Bus
h
3 65 WE106-65 Roller bearing housing 1
9 WE106-09 Washer 1 66 WE106-66 One-way bearing housing, lef
t
1
10 WE106-10 Webb decal 1 67 WE106-67 One-way needle bearing HF-1216 2
12 WE106-12 Dec
k
1 68 WE106-68 Roller 2
13 WE106-13 Tensioner fixing plate 1 69 WE106-69 Roller cover 2
14 WE106-14 Hex bolt M6×16 1 70 WE106-70
N
ylon bus
h
2
15 WE106-15 Cover lower handle, lef
t
1 71 WE106-71 Flat washer 14 1
16 WE106-16 Cross recessed bolt M5×12 1 72 WE106-72 Roller axle 1
17 WE106-17 Cover lower handle, righ
t
1 73 WE106-73 Crankshaft washe
r
1
18 WE106-18 Self-tapping screw & washer 5×35F 3 74 WE106-74 One-way bearing housing, righ
t
1
19 WE106-19 Extension spring bol
t
1 75 WE106-75 Hub cap 1
20 WE106-20 Hex lock nut M8 2 76 WE106-76 Rear axle assy. 1
21 WE106-21 Big washer 8 3 77 WE106-77 Woodruff key 3×5×13 2
22 WE106-22 Bolt 3/8"-24UNF-2B 1 78 WE106-78 Chain 06B-1×37 1
23 WE106-23 Spring washer 10 1 79 WE106-79 Sprocket 20T 1
24 WE106-24 Flat washer 10.5*30.3 3 80 WE106-80 Cross recessed bolt M6×40 1
25 WE106-25 Cutting blade 1 81 WE106-81 Sprocket protective cover 1
26 WE106-26 Blade flange 1 82 WE106-82 Sprocket 11T 1
27 WE106-27 Woodruff key 4.8×6.5×16 1 83 WE106-83
N
on-metal lock nut M6 1
28 WE106-28 Front belt pulley 1 84 WE106-84 Tensioner bracket 1
29 WE106-29 Belt A710 1 85 WE106-85 Spring, tensione
r
2
30 WE106-30 BS500 engine 1 86 WE106-86 Cross recessed hexagon bolt with
indentation M6×35 1
31 WE106-31 Split washer 5 2 87 WE106-87 Clip, gear box 1
32 WE106-32 Spin φ6×20 2 88 WE106-88 Gland bush, rear axle 2
33 WE106-33 Bolt M8×67 2 89 WE106-89 Sealed washer 12.3×3.4×3.4 2
34 WE106-34 Lower left handle 1 90 WE106-90 Gear box 1
35 WE106-35 Lower right handle 1 91 WE106-91 Spring type straight pin 5×40 1
36 WE106-36 Starting hoo
k
1 92 WE106-92 Rear belt pulley 1
37 WE106-37 Quick release handle assy. 2 93 WE106-93 Front wheel cover 2
38 WE106-38 Lower handle rubber cap 2 94 WE106-94 Hexagon flange nut M8 5
39 WE106-39 Fixing plate, lef
t
1 95 WE106-95 Front wheel cove
r
2
40 WE106-40 Double-ended bolt 4 96 WE106-96 Front axle assy. 1
41 WE106-41 Acorn nut M8 4 97 WE106-97 Front axle bush 2
42 WE106-42 Fixing plate, righ
t
1 98 WE106-98 Gland bush, front axle 2
43 WE106-43 Throttle cable 1 99 WE106-99 Hexagon flange nut M8, lef
t
1
44 WE106-44 Upper padded handle 1 100 WE106-100 Split pin 2×20 3
45 WE106-45 OPC cable 1 101 WE106-101 Flat washer 8 1
46 WE106-46 Hex bolt M6×30 1 102 WE106-102 Hex lock nut M6 5
47 WE106-47 Throttle control unit 1 103 WE106-103 Connecting bar 1
48 WE106-48 Hex nut M6 3 104 WE106-104 Small washer, 10 2
49 WE106-49 Screw M6×52 1 105 WE106-105 Height adjustment suppor
t
1
50 WE106-50 Drive leve
r
1 106 WE106-106 Height adjustment sprin
g
1
51 WE106-51 Brake lever 1 107 WE106-107 Height adjustment leve
r
1
52 WE106-52 Grass bag 1 108 WE106-108 Hex bolt with spring & flat washer M6×25 2
53 WE106-53 Grass bag frame 1 109 WE106-109 Height adjustment handle knob 1
54 WE106-54 Rear flap metal plate 1 110 WE106-110 Height adjustment board 1
55 WE106-55 Self-tapping ST3.5*9 4 111 WE106-111 Height adjustment fixed plate 1
56 WE106-56 Rear Deflector 1 112 WE106-112 Screw M6×10 1
57 WE106-57 Split washer 6 2
WERR17(17inch roller mower with B&S500) Parts List

EC Declaration of Conformity
We, Importer
Handy Distribution
SN3 4NS
Declare that the product
Model: WERR17
Complies with the following directives:
2006/42/EC- Machinery Directive
2004/108/EC- Electromagnetic Compatibility Directive
2000/14/EC amended by 2005/88/EC- Noise Emission in the Environment by Equipment for
Use Outdoors Directive.
The conformity assessment procedure followed was in accordance with
Annex VI of the Directive 2000/14/EC and the Directive 2005/88/EC
Name of the Notified Body:
TÜV SÜD Product Service GmbH-
Address: Ridlerstrasse 65-80339 München (Germany)
TÜV SÜD Product Service GmbH-
Address: Westendstrasse 65-80686 München (Germany)
-Measured Sound Pressure Level: 92 dB (A)
-Guaranteed Sound Power Level: 96 dB (A)
Authorised signatory and technical file holder
Date: 24/10/2012
Signature:
Name / title: Mr. Simon Belcher / Managing Director
Hobley Drive, Stratton St Margaret, Swindon, Wiltshire, SN3 4NS.

User’s manual
Notes
