WEIBANG WBLV506H V User manual

Model: WBLV506H
WBLV506H V
Owner's Manual
Copyright WEIBANG China
All rights reserved
DO NOT operatethisequipmentuntilyouhaveread and
understoodalltheenclosedOperator'sManual.
READ ALL the sections in this manual PRIOR to attempting to
service,maintainoroperatethisequipment.!
M----11010
(Original instructions)
Leaf Vacuum
WBLV506C
WBLV506C V

DO NOT operatethisequipmentuntilyouhaveread and
understoodalltheenclosedOperator'sManual.
READ ALL the sections in this manual PRIOR to attempting to
service,maintainoroperatethisequipment.!
Explanation ofsymbols onthe vacuum
Read Operator's manual Beware ofthrown orflying
objects tobystanders.
General hazardsafety alert Keep bystanders away from
Wear hearingprotection
while operatingthe powertool.
Wear breathprotection
Wear eyeprotection
SAFETY PRECAUTIONS 01
CONTENTS
PRE-OPERATIONNOTE 01
ASSEMBLY 05
INSTRUCTION LABELS 03
OPERATION 08
STORAGE 12
12
SERVICE &ADJUSTMENT
MAINTENANCE 13
TROUBLE SHOOTING 17
GUIDE TO PARTS BREAKDOWN 18
WARRANTY 20
WBLV50 Leaf Vacuum
Owner's Manual
Residual risks
Even when the powertool is usedas prescribed it isnot possible to eliminate allresidual risk
factors. Thefollowing hazardsmay arisein connectionwith thepower tool'sconstruction and
design:
1.Damageto lungsif aneffective dustmask isnot worn.
2.Damageto hearingif effectivehearing protectionis notworn.
3.D
amages to health resulting from vibration emission if the power tool is being used over longer
period oftime ornot adequatelymanaged andproperly maintained.
WARNING!
This powertool producesan electromagnetic fieldduring operation. Thisfield may
under s
ome circumstances interfere with active or passive medical implants. Toreduce the risk
of serious or fatalinjury, we recommend persons with medical implants to consult their physician
and themedical implantmanufacturer beforeoperating thismachine.
The declaredvibration totalvalue hasbeen measuredin accordancewith astandard testmethod and
may beused forcomparing onetool withanother.
The declaredvibration totalvalue mayalso beused ina preliminaryassessment ofexposure.
Warning
The vibra
tion emission during actual use of the power tool can differ from the declared total value
depending onthe waysin whichthe toolis used.
There is the
need to identifysafety measures toprotect the operatorthat are basedon an estimation
of exposure in the actual conditions of use (taking account of all parts of the operating cyclesuch as
the timeswhen thetool isswitched offand whenit isrunning idlein additionto thetrigger time).
the machine

i. Any impairment (i.e.: medical conditions, medicinal side-effects, alcohol, drugs etc.) of the operator.
ii. The operator has not read or understood the operator's manual for this machine.
iii. The operator does not clearly understand the operations of the machine.
iv. The machine is in need of repair.
v. The operator is inappropriately attired to operate the machine.
Do not operate the vacuum or run the engine in unventilated areas.
Engine exhaust contains carbon monoxide, a deadly gas that is odorless, colorless, and tasteless.
ALWAYS OPERATE VACUUM OUTDOORS!!
4. When operating the vacuum, follow these guidelines for operator's personal safety:
Always wear proper safety clothing andequipment for the job.
These can and should include eye and ear protection, gloves, dust mask and any other items that are appropriate
for the job and jobsite requirements.
Always operate the machine in arecommended position.
Never wear anyjewelry, neck ties, or other looseor hanging items that can be caught on any part of the machine.
Tie back or removeany loose hair,clothing and any other potential hazards andobstructions.
Before starting the machine, make certain thatthe turbin chamber is empty.
Keep your face and body awayfrom the discharging opening.
When draw material intothe machine, be extremely careful toexclude pieces of metal,rocks, bottles, cansor other
foreign objects.
Do not allow processed material tobuild up in the discharge area,which may prevent proper discharge.
Keep the engine clean of debris andother accumulations.
Avoid comingin contact with themuffler andother engine parts after the engine isstarted and the timeimmediately
after the machine is turned off. Machine and engine temperatures may exceed 150 F or 66 C
Machine must be allowed to cool beforetouching it or attempting to perform anymaintenance!
Do not tamper with the enginegovernor settings on the machine;
The governor controls the maximum safe operating speed and protects the engine and all moving parts from damage
caused by dangerously high speeds.
Do not transport or move machinewhile the engine or machine isrunning.
5. For the safety of others and that of the operator, observe the following precautions:
While the machine is inuse, keep observers and bystanders atleast 35 feet away from the vacuumand its immediate
working environment.
Stop operations or if anyone or anything (i.e.: humans, animals, etc.) approaches from the front or the sides while the
machine is in operation.
If the cutting mechanismstrikes any foreign objector if themachine should start makingan unusual noise or vibration,
immediately shut off the engine and allow the machine to stop. Disconnect the spark plug wire from the spark plug
and take the following steps:
i. Inspect for damage.
ii. Replace or repair damaged parts.
iii. Check for and tighten any loose parts.
Stop work and turn offthe vacuum if debris jams themachine or causes it to laborunnecessarily.
Inspect the machine for any possible causes.
Before attempting to clear any jams inthe unit, inspecting or servicing any part of the machine,stop the engine and
remove the sparkplug wire, and make sure that all moving parts have come to a complete stop.
Never leave machine unattended. Shut off the engine whenever you leavethe work area.
Position the machine such that it isnot necessary to work downwind of theexhaust.
DO NOT, under any circumstances, operate machineif any of the following conditionsare applicable:
2
SAFETY PRECAUTIONS CONT D...
,
6. Take care children. Tragic accidents can occur if the operator is not alert to the presence of children.
Child
ren are often attracted to the vacuum and to the operation activity. Never assume that childrenwill remain where
you last saw them.
SAFETY PRECAUTIONS
PRE-OPERATION NOTE
Thank you for your purchase of the WEIBANG professional WBLV50 series leaf vacuum.This vacuum has been
designed. And manufactured to our highest quality demands for durability and performance.
WEIBANG Garden Machine Company is committed to offering durable products and quality after-market service.
The WBLV50 series leaf vacuum is warranted to be free frommanufacturer's defects in material and workmanship
for a period of one year from the date of purchase (except used for commercial purpose or hire and rental applications).
This warranty will be void ifthe machine has not been operatedand maintained in the manner prescribedin this
Operator's Manual. Any machine malfunctions, and/or warranty claims that arise from the misinterpretation or the
misunderstanding of the instructions and cautions discussed in this booklet will notbe eligible for warranty protection.
In order for the leaf vacuum to perform at its optimum capabilities, the operator must read this manual thoroughly
before using this unit. This Operator's Manual contains important product operation procedures, safety precautions,
maintenance and troubleshooting tips as well as other advisories. Please keep this manual nearby when operating the
vacuum as a reference should any questions arise.
The WBLV50 series is a petrol engine powered central vacuum to load leafs and similar product sucked. It has a flexible
hose (on suction side) of a length of 4 M provided with a nozzle with handle. The ejection is channelled through a straight
chute with a deflector for directing the debris precisely ejected. This leaf vacuum has a internal flow developed specifically
for the collection of leaves, paper and grass clippings less than 10cm.When this machine is used as a leaf vacuum, it
can turn fall leaves into high quality compost for agriculture and gardening instead of burning them. DO NOT USE
THE LEAF VACUUM FOR ANY OTHER MATERIAL THAN FALL LEAVES. The machine should not be used for any
other purpose than that stated above. The inappropriate use of any machine can cause serious damage and/or bodily
harm to the environment and operator. It is imperative that the operator of this equipment be responsible for the opera-
tional environment of the leaf vacuum. Please be prepared and well-informed for all specific requirements, precautions
and work hazards that may and/or do exist at the jobsite.
Powered by a 6 HP HONDA or LONCIN engine, the WBLV50 series is a powerful unit which drives a suction
turbine. Failure to maintain the vacuum in a proper manner will lead to decreased productivity of the tool and hazards
This machine is a ground supported unit and it should not be mounted to atruck or
changes or usage to the sweeper render manufacturer liability null and void.
All jobsites are different. Please ensure that when using the WEIBANG leaf vacuum, all local bylaws and codes
are followed. All operators and mechanics of this machine should be trained in general machine use and safety.
Every care and effort has been made to ascertain the accuracy and completeness of procedures described in
this document to ensure your enjoyment and satisfaction. If you have any questions or concerns, please contact the
WEIBANG'S local dealer or WEIBANG's exclusive national distributor.
1. READ AND UNDERSTAND OPERATOR'S MANUAL PRIOR TO USE OF THE VACUUM.
2. Before operating leaf vacuum, ensure that it is structurally and mechanically safe.
a. Check if all engine controls and the clutch action functioning within acceptable tolerances.
b. Keep all nuts and bolts in good working condition, tight and keep all guards an d deflectors in place and in good working
condition.
! READ AND UNDERSTAND OPERATOR'S MANUAL PRIOR TO USE OF THE VACUUM. If any of the above
checks fail, please take necessary steps to maintain or repair the unit before operating it in any environment.
3. Before using the vacuum on proposed jobsite. Check for ventilation in area.
1
to a trailer for operation.Do not use this machine if it has been modified or improperly maintained. Any unauthorized
a. Keep children out of the working area and under the watchful care of a responsible adult.
b. Be alert and turn machine off if children enter the area.
c. Never allow children to operate the vacuum.
to the operator and bystanders.

SERVICE: Qty Required=1
ART No.L0106070
ENGINE: Qty Required=1
PART No.L0106040
NOTE: For engine safety and instruction decals, see engine owner's manual or contact the engine supplier.
Below are the decals available for re-ordering to facilitate maintenance.
All decals are available for replacement except that with the serial number of the unit for each number serves as an
unique identifier for warranty and support purposes.
If you have any questions, please do not hesitate to contact WEIBANG'S local dealer or WEIBANG's exclusive national
distributor for further assistance.
SECURE NOZZLE: Qty Required=1
PARTNo.XYJLP010
LABEL SPARK ARRESTER: QtyRequired=1
PARTNo.XYJLP020
OPERATOR: Qty Required=1
PARTNo.L0106060
OPERATOR: Qty Required=1
PARTNo.XYJLP080
OPERATOR: Qty Required=1
PARTNo.XYJLP070
OPERATOR: Qty Required=1
PARTNo.XYJLP050
HAND: Qty Required=1
PARTNo.L0202010
4
INSTRUCTION LABELS CONT D...
,
Safety and instruction decals are located on the vacuum frame and engine.Replace any decal that is damaged or
unreadable, replace them before operating this equipment,call dealer for information on decals.
For location of safety decals on the vacuum frame, see parts drawings and lists provided for convenience in ordering
replacement labels.
3
7. Use extra care in handling fuels. They are flammable and vapours are explosive.
Use only an approved container.
Never remove fuel cap or add fuelwith the engine running.Allow engine to cool before refueling.
Do not smoke.
Never refuel the machine indoors.
Never store the machine or fuel containerinside where there is an open flame,such as a water heater.
If fuel is spilled, do not attempt to start the engine, but move the machine away from the area of spillage before starting.
Always replace and securely tighten fuel capafter refueling.
Your machine is equipped with a safety device which prevents the engine start when the vacuum house is not in place.
In operation, the removal of the hose stops the engine.Never use a machine with defective guards or safety devices off.
Regularly check the proper functioning of safety devices.
RESPONSIBILITY OF THE OPERATOR
The operator must be one close to the vacuum cleaner during operation.
Responsibility of the user is bound towards third parties:
- In the working area of the machine,
- In the case of using non-original parts when replacing parts used,
- In the case of using a modified machine or poorly maintained,
- If the work to be performed outside the normal course of use.
SAFETY DEVICE
SAVE THESE INSTRUCTIONS!!
INSTRUCTION LABELS
SAFETY PRECAUTIONS CONT D...
,
SPECIFICATIONS
Engine Make/ Model
Engine Fuel Capacity
Engine Oil Capacity
TotalUnit Empty Weight:
Max operating slope
Overall HxWxL
3.6kW \3600min-1
HONDA GX160
1.57x0.87x1.0m
LONCIN G160F
3.6L
0.6L
80kgs80kgs 83kgs
8.5
97.4 dB(A),K=3dB(A) 104.8 dB(A),K=3dB(A)
2
4.66 m/s ,K=1.5m/s
Model WBLV506H WBLV506HV WBLV506C WBLV506CV
Working width 80cm
Collection bag (L) 240L
Hand-Arm Vibration
Drive speed m/s 0.75-0.86-1.1 0.75-0.86-1.1
Rated power, kW
82.5kgs
Sound noise declaration Lwa
Sound pressure level at operator's
ear Lpa
86kgs
94.7 dB(A),K=3dB(A)
0.9 0.9
93.7 dB(A),K=3dB(A)
2
2
3.93 m/s ,K=1.5m/s
2

ASSEMBLY
Carefully read these instructions and this manual in its entirety, before you attempt to operate your new vacuum.
IMPORTANT: THIS LEAF VACUUM IS DELIVERED WITHOUT OIL OR PETROL IN THE ENGINE.
Your new vacuum is shipped from the factory in one carton, and which has been pre-assembled at the factory,with the
exception of those parts such as nozzle, hose left unassembled for shipping purposes.
All parts such as nuts, washers, bolts, etc. necessary to complete the assembly have been attached on the machine.
To assure safe and proper operation of your vacuum, all parts and hardware you assemble must be tightened securely.
Use the correct tools needed to assure proper tightening.
I UNPACKING INSTRUCTIONS
WARNING: To prevent personal injury or property damage, do not attempt to start the engine until all assembly steps are
Complete and you have read and understand the safety controls and operating instructions in this manual.
Please carefully follow these assembly steps to properly prepare your machine for use.
We recommend that you read this Section in it's entirely before beginning assembly.
When unpacking the machine, inspect for shipping damage or missing parts,
if you find any damage, or if parts are missing, notify the WEIBANG Dealer who sold you the machine.
Active Wrench / Motor Oil
INTRODUCTION
INSPECTION AFTER DELIVERY
TOOLS/MATERIALS NEEDED:
EXPLOSIVE FUEL: Qty Required=1
PARTNo.XYJLP030
ENGINE OVERHEAT: Qty Required=1
PARTNo.XYJLP040
WARNING SECURE: Qty Required=1
PARTNo.XYJLP060
DO NOT operatethisequipmentuntilyouhaveread and
understoodalltheenclosedOperator'sManual.
READ ALL the sections in this manual PRIOR to attempting to
service,maintainoroperatethisequipment.!
LOGO: Qty Required=1
PARTNo.L0401040
5
INSTRUCTION LABELS CONT D...
,
PUT OIL IN ENGINE BEFORE STARTING
READ all safety instructions before assembling unit.
TAKE CAUTIONwhen removing the unit from the box.
PACKING CHECKLIST
Prior to setting up the leaf vacuum, check that the following items are enclosed:
Item Quantity Check if enclosed
If any of these items are missing, please contact local dealer and ask for the Service Department at once.
WBLV506 Leaf vacuum 1
WBLV506 Nozzle B with handle 1
WBLV506 Leaf vacuum Operator s manual 1
Engine Operator s manual 1
Yes No
Yes No
Yes No
Yes No
DO NOT ATTEMPTASSEMBLY OR OPERATION WITHOUT ANY OF THESE LISTED PARTS!
All WEIBANG parts are guaranteed by a thirty (30) day warranty against any manufacturer’s defects in workmanship
and material. Consult Warranty page in the Operator’s Manual for further details on our Warranty Policy.
6
ASSEMBLY CONT D...
,
3 Lift off the machine from pallet brackets and remove it from the wood pallet.
4 Check the box thoroughly and remove additional loose parts included with leaf vacuum.
5 Remove all packing materials.
PACKING CHECKLIST
II HOW TO SET UP YOUR LEAF VACUUM
CAUTION: Wear protective gloves during operation of setting up your vacuum.
NOTE: This unit is a ground supported machine, and it should not be mounted to a truck or to a trailer for operation.
1. SECURELY ATTACH exhaust chute to the turbinehouse with the hardware locatedon the exhaust chute.
Ｌｏｗｅｒ ｈａｎｄｌｅ
Ｈａｎｄｌｅｂａｒ
Ｌｉｆｔ ｕｐ
(fig.1)
Ｓｌｉｐｉｎｇ ｒｉｎｇ
Risk of high dead weight
• The machine must not be lifted manually.
• Pull the machine off the transporter by its handles.
• Remove machine parts separately from packaging.
WBLV506 Nozzle A 1 Yes No
WBLV506 Collecting bag 1 Yes No
●
●
●
TURN AND LOCK THE HANDLEBAR
Turn the handlebar toward machine tail until it's lower section is
Move down two slip ring respectively on both sides, until they
When storing the machine, in order to save space, you can
parallel and close together with vertical tube of lower handle.
they lock the handlebar securely.
turn the handlebar back to machine head by pulling up slipping
rings.
UNPACKING STEPS
1 Cut plastic banding. To open the box, remove top plywood panel firstly.
2 Remove all around wall panel. Remove the angle iron securing machine to wood pallet.

●
●
●
Ｓｔｒａｐ
Ｈｏｏｋ
Ｃｏｌｌｅｃｔｉｎｇ ｂａｇ
Ｉｎｔａｋｉｎｇ ｎｏｚｚｌｅ
Ｔｕｒｂｉｎｇ ｃｈａｍｂｅｒ
Ｓａｆｅｔｙ ｓｗｉｔｃｈ
Ｌｏｃｋｉｎｇ ｓｃｒｅｗ
●
●
The following is a overview of important control and operation mechanisms with which the operator must be familiar
PRIOR to using the leaf vacuum. Failure to do so may result in severe injury and/or fatality to the operator and others
and may lead to reduced machine life or damage to this machine.
FEATURES AND CONTROLS
OPERATION
(fig.5)
FEATURES AND CONTROLS
ASSEMBLY CONT D...
With nozzle installed (as shown in Fig. 3), the switch is open & the engine is not grounded, which allowing engine to run.
INTERLOCK SYSTEM
Twining straps on handlebar tube and make the straps buckle
Install intake opening of collecting bag on discharging opening,
Unfold collecting bag to mounting state.
INTALLING COLLECTING BAG
catching the hook on inside of tube.
and tighten the belt securely.
INSTALLING SUCTION NOZZLE
Along the direction from top to bottom,Insert the nozzle flange into slots on both sides of central opening.
Press down the top side of nozzle flange to let bottom side of flange to press on the safety switch, and
then tighten the self-locking screw.
Note: If the locking screw loose, the nozzle may not contact the safety switch, which will cause
engine flameout.
(fig.3)
Ｒａｉｓｅ ｎｏｚｚｌｅ
Ｌｏｗｅｒ ｎｏｚｚｌｅ
Park the machine steadly on horizontal surface. Observe the
thickness of deposited ground leaves,
Pull out the adjustment lever from catch and turn to desired
between nozzle and ground surface should suit for sucking in
●
●
position, and then release lever back to catch. The clearance
falling leaves.
SETTING MACHINE
(fig.2)
,
78
CAUTION:For maintenance perpose, If the bag need removing from the discharging opening, make sure the ma-
chine have been stopped completly before you work on it.
Ｆｒｏｎｔ ｗｈｅｅｌ ｗｉｔｈ ｂｒａｋｅ
Ｒｅａｒ ｗｈｅｅｌ
Ｔｕｒｂｉｎｇ ｃｈａｒｍｂｅｒ
Ｓｕｃｔｉｏｎ ｎｏｚｚｌｅ
Ｌｏｗｅｒ ｈａｎｄｌｅ
Ｕｐｐｅｒ ｈａｎｄｌｅｂａｒ
Ｃｏｌｌｅｃｔｉｎｇ ｂａｇ
Ｈｅｉｇｈｔ ａｄｊｕｓｔｍｅｎｔ
Ｓｅｌｆｐｒｏｐｅｌｌｉｎｇ ｌｅｖｅｒ
Ｄｉｓｃｈａｒｇｉｎｇ ｃｈｕｔｅ
Ｓｐｅｅｄ ａｎｄ ｔｈｒｏｔｔｌｅ ｌｅｖｅｒ
Ｅｎｇｉｎｅ
(fig.4)

Ｃｈｏｋｅ
Ｆｕｌｅ ｖａｌｖｅ
Ｓｔａｒｔｉｎｇ ｋｎｏｂ
(fig.6)
Before using the WBLV50leaf vacuum, with the spark plug wire disconnected from the spark plug,please perform
the following procedures for the personal and property safety of the operator and jobsite and for optimal performance.
1) Review section ''Safety'' and section ''features and Controls'' which is in this owner's manual. Read the separate
Engine Owner's Manual provided with the unit. Read all safety,controls and operating instructions on decals located
on machine.
PRE-OPERATIONCHECKLIST
9
2) Check and make sure that all nuts and bolts, especially the blade attachment-bolt, are tighten and all guards and
deflectors are in place and in good working condition. Tighten or replace as needed.
If there are any worn or damaged parts,DO NOT ATTEMPT TO OPERATE THE MACHINE. Make note of required
parts, and contact WEIBANG'S local dealer or WEIBANG's exclusive national distributor for replacement parts and
further assistance to service the unit PRIOR to any further use.
3) Are there any cracks or damage on the engine. Consult with the engine Manufacturer's Manual'' for guidelines and
Instructions
on service. DO NOT ATTEMPT TO OPERATE THEMACHINE until engine is refurbished to engine
Factory standards.
4) With the unit on level ground, check the engine oil level according to the instructions in the engine owner's manual.
The oil level should be at the ''FULL'' mark on the dipstick or up to the top of the oil fill hole on engines without a dipstick.
6) Check and make sure that the turbin chamber is empty.
CAUTION: If any of the above checks fail, please take necessary steps to maintain or repair the unit before operating
it in any environment.
CAUTION: Always wear proper safety clothing and equipment for the job.
These can and should
include eye and ear protection, gloves, dust mask and any other items that are appropriate for the
job and jobsite requirements.
WARNING: Before operating th
e machine, be sure to read all safety, controls and operating instructions in this Owner's
Manual and on decals located on machine. Server personal injury or property damage could result if this instruction is not
followed.
Always start your vacuum with the machine speed control lever in SLOW speed.
STARTINGAND STOPPING THE ENGINE
To start the engine
1) Move the engine chock control lever to choke setting to start a cold engine.
2) Pull the brake control lever and lock it to release the engine brake.
The operator must be one close to the vacuum when it use.
Before starting up the machine, check the following:
- The condition of the cable winch.
- The side panel with hose must be securely attached.
- The suction nozzle shall be keep a suitable distance to the floor to prevent aspiration of a foreign body at boot time.
- The environment of the machine must be free, pay special attention to the ejection zone.
- The discharge deflector must be adjusted so that the product is ejected not harmful to the environment.
- Check the engine oil level.
- Check the fuel level.
- The throttle lever must be in position starting mid-accelerated.
DANGER
: Do not operate the engine in an enclosed area. Engine exhaust contains carbon monoxide, a deadly gas that
is odorless, colorless and tasteless.Always runengine outdoors andmake sure thereis adequate ventilation.
WARNING:To avoid injury, look behind you to be sure there are no obstacles before pulling recoil starter rope.
3) To start engine using recoil starter:
B: Stand on left side (as viewed from behind handlebars) of machine.
C: Grasp starter rope handle and pull slowly until rope pulls slightly harder. Let rope rewind slowly. Then pull rope
with a rapid, full arm stroke. Let rope return slowly.
D: when engi
ne starts, operate in fast throttle setting (move throttle from choke setting to fast setting slowlyto engage
10
PACKING CHECKLIST OPERATION CONT D...
,
CAUTION:
When you pull the engine starter knob to start the engine, When you pull the engine starter knob to start
starting operation. See trouble shooting.
IMPORTANT:With the machine off and spark plug disconnected check the condition of the replaceable liner before
every use and replace if necessary.
2. Move the throttle control all the way to stop position.
VACUUMING OPERATION
1. Move throttle from fast setting to slow position.( Whenever possible, gradually reduce engine speed before stopping
Engine.)
●
●
●
●
INTAKEOPERATION:
With machine running and fully assembled, move the nozzle in sweeping motions over
debris. Always
allow air to flow into the nozzle along with the debris. Do not completely block the nozzle when
vacuuming, it will reduce performance, and increase clogging (figure 3).
For removal of heavier debris, or debris that is stuck to the ground, rock nozzle forward to concentratesuction around
the debris ( figure 4).
OPERATION CONT D...
,
the engine, please stop the operation and check the causes in case the engine fails to start in 30 second after repeated
Note: This machine is equipped with safety switch, the engine may not start if suction nozzle(hose) is installed improply.
Adjust the throttle lever slowly to accelerate the engine to
Adjust the driving speed lever to desired speed position.
Keep one hand holding handlebar, and other hand press
Two hands keep holding handlebar and clutch lever firmly,
rated speed.
down the selfpropell clutch lever slowly, to make driving wheel
turning.
and then can you suck falling leaves.
operation,and additional security.
SHIFT THROTTLE CONTROL LEVER ON SLOW POSITION FOR STARTING ENGINE.
Before using the machine, please refer to the operator's manual to find guidelines about starting,
Ｔｈｒｏｔｔｌｅ ｌｅｖｅｒ Ｄｒｉｖｉｎｇ ｓｐｅｅｄ ｌｅｖｅｒ
Ｓｅｌｆｐｒｏｐｅｌｌ
(fig.7)
ｃｌｕｔｃｈ ｌｅｖｅｒ
A: Turn engine switch to "ON".
the blades).
To stop the engine
Ｅｎｇｉｎｅ ｓｗｉｔｃｈ

12
THROTTLE CONTROL
If it becomes necessary to adjust or replace the throttle control, see the adjustment section of your engine manual.
CARBURETOR
The carburetor has been preset at the factory and adjustment should not be necessary.
However, minor adjustment may be required to compensate for differences in fuel, temperature, altitude or load.
The air filter must be assembled to the carburetor when running engine.
Best carburetor adjustment is obtained when fuel tank is full.
For further information, please see the Adjustment section of your engine manual for further instruction.
Contact your nearest authorized engine service department or your local dealer to maintenance engine and consulting
warranty issues.
In case any engine failure during the warranty period, the machine should be sent to authorized engine service department
for checking but not disassembled by customers, otherwise it will lead to the warranty invalid.
VACUUM
For easier access to cleaning the vacuum, the machine may be tipped on its engine guard for NO MORE THAN 2
MINUTES. Engine damage may result from gasoline flowing into the crankshaft due to prolonged tipping. Refer to the
engine operator's manual and maintenance instructions.
The vacuum can be tilted forward in 30 seconds, by lifting up the handle bar. Engine damage may result from gasoline
flowing into the engine's cylinder due to prolonged tipping.
Refer to the engine operator's manual and maintenance instructions.
When vacuum is to be stored for a period of time, clean it thoroughly, remove all dirt, grease, leaves, etc.
Store the vacuum in a clean and dry place.
1. Clean the entire vacuum (See "CLEANING" in the customer Responsibilities section of this manual)
2. Lubricate as shown in the Customer Responsibilities section of this manual.
3. Be sure that all nuts, bolts, screws and pins are securely fastened. Inspect moving parts for damage, breakage and
wear. Replace if necessary.
4. Touch up all rusted or chipped paint surfaces; sand lightly before painting.
5. Apply some grease or anti-rust paint on the blade surface will inhibit rusting.
6. Store the machine out of children’s access and in a covered or indoor storage area for increased protection and longevity.
Ensure that the area in which the machine will be stored is well-ventilat ed and free of any potential fire hazards such as open
flames, gas appliances, furnaces, water heaters, and other appliances.
CAUTION:
WEIBANG parts have been designed and manufactured to the highest quality demands for durability and performance
of a commercial operation. Always use original spare parts with the logo "WEIBANG" to ensure maximum performance,
reliability and service life from your WEIBANG machine.
Your engine speed has been preset at the factory.
Do not attempt to increase the engine speed, asthis may result in personal injury. If you believe that the engine is
running too fast or too slow, take your sod cutter to an authorized service centre for repair and adjustment.
ENGINE
ENGINE SPEED
Any modifications unauthorized by manufacturers to the machine will lead to the failure of warranty.
Do not operate the machine until read and understand all enclosed operator s manual.
CAUTION
STORAGE
2. Disconnect cable from the sparkplug and place where it cannot come in contact with plug.
Before any service and adjustments:
1. Make sure the blade and all moving parts have stopped completely.
11
SERVICE AND ADJUSTMENT
OPERATION CONT D...
,
UNCLOGGING A CLOGGED HOUSING OR EXHAUST CHUTE
Turn engine offimmediately and wait for impeller to come toa complete stop. Disconnect spark plug wires.
Remove the nozzlefrom the housing and determine where the clog is located. Ifpossible clear the clog through the
intake opening. It may require removal ofthe intake adaptor (item 16) to allowaccess to clear the housing.
If clog is in the exhaust chute,carefully remove the chute by removing thebolts and nuts on the chute.
Danger, the clog may contain sharp materials. Wearing durable gloves and clear the clog.
Reconnect spark plug wire after nozzle or hose is installed properlly.
●If the unit sucks debris too fast, the turbin chamber may be choked, and which may lead to engine flame out.
CAUTION:Do not cleaning theturbin room by handwithout tools. Only
remove the debris whenthe turbin come to a complete stop.
Ａｃｔｉｖｅ ｄｏｏｒ
Ｂａｇ
Ｃａｔｃｈ ｈｏｌｅ
(fig.8)
CLEANING COLLECTING BAG
When the collecting bag is full, you can discharge debris from
1. Unscrew lock buttons around the active door of collecting bag,
2. Wear gloves, use a suitable tool to clean up residual debris
3. Re-close the active door and then lock all buttons.
and then open the active door slowly to discharge debris.
in bag. it is prohibited to remove debris with bare hands directly.
bag's active door.
CAUTION:Make sure the active door is closed securely before
restart the engine,
CAUTION:Before opening the active door of collecting bag,
engine by turn engine switch to "off".
move throttle from fast setting to slow position and stop the

NOTE: Fuel stabilizers are an acceptable alternative for minimizing the formation of fuel gum deposits during storage.
add stabilizing agents to the petrol in fuel tank or storage container.Always observe the mixing ratio found on stabilizer
container. Run the engine for at least 10 minutes after adding a stabilized fuel, to allow the stabilizer to reach the
carburetor. Do not drain the gas tank and carburetor if using stabilizer.
Drain the fuel tank.
Start the engine and let it run until the fuel lines and carburetor are empty and dispose of it in a safe, responsible manner.
Never use engine or carburetor cleaning products in the fuel tank, as permanent damage may occur.
Refill the fuel tank with fresh fuel at the start of next season.
Drain oil (while engine is warm) and replace with clean engine oil (see "ENGINE" in the CUSTOMER RESPONSIBILITIES
section of this manual).
CYLINDER
Remove the sparkplug.
Pour (29 ml) oil through the sparkplug hole into the engine cylinder.
Pull the starter handle slowly a few times to distribute the oil.
Replace with new sparkplug.
OTHER
Do not store petrol from one season to another.
Replace your petrol can if your can starts to rust. Rust and/or dirt in your petrol will cause problems.
If possible, store your vacuum indoors and cover it to give protection from dust and dirt.
Cover your vacuum with a suitable protective cover that does not retain moisture. Do not use plastic. Plastic cannot
breathe which allows condensation to form and will cause your vacuum to rust.
IMPORTANT: NEVER COVER THE MACHINE WHILE ENGINE AND EXHAUST AREAS ARE STILL WARM.
CAUTION:
Never store the vacuum with petrol in the tank and inside a building, where fumes may reach anopen
flame or spark. Allow the engine to cool before storing in any enclosure.
CUSTOMER RESPONSIBILITIES
This section encompasses two general types of maintenance: 1. Preventative Maintenance and 2. General Service.
The first refers to regularly scheduled routine care ofthe sod cutter, such ascleaning and lubrication. The second
provides information on common procedures, such as changing blade, and adjusting the drive belt that are to be performed
as needed.
By following the Inspection Schedule below BEFORE and AFTER each use of the sod cutter, appropriate actions can
be taken to extend the service life of the machine and reduce any costly repairs and unnecessary downtime for the unit.
All service should be performed by trained technicians.
Inspection Schedule
The following list aims offer some basic guidelines to performing a detailed inspection BEFORE and AFTER each use.
Certain checks will require some disassembly, i.e. the removal of the drive guard, to perform. Depending on various
environmental conditions and frequency of use, other inspection points may have to be added for each machine
13
OF ACIDS DURING STORAGE. ACIDS CAN DAMAGE THE FUEL SYSTEM OF AN ENGINE WHILE IN STORAGE.
FUEL SYSTEM
IMPORTANT: DURING STORAGE, IT ISIMPORTANTTO PREVENT GUM DEPOSITS FROM FORMINGON
ESSENTIAL SYSTEM PARTS, SUCH AS THE CARBURETTOR, FUEL FILTER, FUEL HOSE OR FUEL TANK.
EXPERIENCE ALSO INDICATES THAT ALCOHOL BLENDED FUELS, ALSO CALLED GASOHOL, OR THE USE
OFETHANOL OR METHANOL, CANATTRACT MOISTUREWHICH LEADS TO SEPARATION AND THE FORMATION
MAINTENANCE
STORAGE CONT D...
,
Item Yes No
Is the engine oil filled to recommended levels? Consult Engine Manufacturer's Manual.
Is the engine air cleaner properly attached and clean? Consult Engine Manufacturer's Manual.
Are the safety warning labels and other decals clearly identifiable and legible? If not, ensure that
fresh decals will be re-applied prior to use for operator safety.
Are throttle cable and clutch cable properly attached? Refer to “Setting up the sod cutter” for details.
Are throttle cable and clutch cable worn or visibly damaged? Replace if necessary.
Is the frame and handle in good condition with no visible damage or rusting? If not, contact local
dealer to replace machine prior to further use.
Are all fasteners in good working condition? Tight all loosen fasteners.
Does the machine run with excessive vibration? If so, please contact your dealer for solutions.
GENERAL SERVICEPROCEDURES
General safety procedures
Before performing any service and maintenance procedures, consult these general safety procedures for a safe working
environment.
1. Make sure that both the engine and vacuum are cool prior to any service or maintenance work.
2. Verify that work area is clean and free of any debris, tripping or fire hazards, and other potential sources of danger.
3. Always wear proper safety clothing and equipment for the job. These can and should include eye and ear protection,
gloves, dust mask and any other items that are appropriate for the job and jobsite requirements.
4.Ensure that the technician has tied back or remove anyloose hair, clothing and any other potential hazards and obstructions
5. Disconnect spark plug.
Preventative Maintenance Procedures
Maintaining a regular cleaning and lubrication schedule as well as taking time to perform preventative maintenance
procedures will prolong the service life of the vacuum. The following are guidelines to setting up a regular maintenance
routine for the vacuum.
should read a
nd thoroughly understand all manuals pertaining to the machine to be serviced. Do NOT proceed
with any service and maintenance activity until ALL questions and concerns have been addressed. Please call your
local dealer for technical support and advice.
ALWAYS consult and verify that all local codes and bylaws are followed beforeperforming any service or
maintenance procedures.
Regular cleaning will help extend the service life of the machine.
i. After each use, the vacuum, in particular the blade should be cleaned. Scrape the bottom of gear box and blade to
remove accumulations of leaves or trash.
ii. Clean the engine often, to keep trash from accumulating. A clogged engine runs hotter and shortens engine life.
iii. We do not recommend using a garden hose to clean the leaf vacuum, unless the electrical system, muffler, air filter
and carburetor are properly covered to keep out water. Water in the engine can result in a shorter engine life.
Take care when using a power pressure washer to clean the unit, and avoid damaging any safety or operating instruction
decals. Avoid directly spraying engine. DO NOT USE ANY MACHINE RATED HIGHER THAN 1000 PSI.
iv. B
eware of damaging any warning decals and labels, as well as engine. Limit direct spray on these objects to help
prevent their wear and tear.
v. F
or easier access to cleaning the vacuum, the machine may be tipped on its engine guard for NO MORE THAN 2
MINUTES
. Engine damage may result from gasoline flowing into the crankshaft due to prolonged tipping. Technician
Cleaning the Vacuum
14
MAINTENANCE CONT D...
,
The following are general guidelines for servicing common wear components on the WBLV50 LEAF VACUUM.ALL
MAINTENANCE AND SERVICE WORK MUST BE PERFORMED BY A TRAINED AND EXPERIENCED TECHNICIAN.
Ensure that the work area is clean and free of debris prior to starting any maintenance or service work. Small particles
may become trapped in key components that may lead to serious damage to the machine and cause severe bodily harm
to the operator or technician.

ENGINE
Read the Maintenance section of your engine manual.
CHANGING ENGINE OIL
1. Disconnect sparkplug cable from sparkplug and place the cable where it can not come into contact with sparkplug.
2. Remove engine oil cap; lay aside on a clean surface.
3. Remove the drain plug on the bottom of the engine and drain oil into a suitable container. Grasp starter rope handle
and pull slowly to rotate the crank shaft and remove any oil trapped inside of engine.
4. Reassemble and fasten the drain plug. Wipe off any spilled oil from the engine.
5. Refill engine with the recommended lubricant. See "ADD OIL" in the Operation instructions section of this manual.
6. Reconnect sparkplug cable to sparkplug.
CAUTION: Disconnect sparkplug cable from the sparkplug and place wire where it cannot come into contact with
Sparkplug.
AIR FILTER
Your engine will not run properly and may be damaged by using a dirty air filter. Clean the element after every 25 hours
of operation, or more often if chipper/shredder is used in very dusty or dirty conditions. See the Maintenance section of
your engine manual.
MUFFLER
Inspect the muffler regularly and replace a corroded muffler, as it could create a fire hazard and/or cause damages.
SPARKPLUG
Change your sparkplug each year to make sure your engine starts more easily and runs better.
Set the sparkplug gap at 0.7-0.8 mm.
PERIODIC MAINTENANCE
Periodic maintenance should be performed at the following intervals:
Maintenance Operation Every use Every 5 hours (daily) Every 10 Hours Every 25 Hours
vacuum
engine
Inspect for loose, worn
or damaged parts.
Clean hose
Keep engine free of debris
Checkfor excessive vibration
Check engine oil level
Change engine oil
Clean air filter
Inspect muffler
Clean or replace sparkplug
Replace air filter paper
cartridge
16
LUBRICATION
Use only high quality detergent oil, which has an API service classification of SF-SJ. Select the oil's SAE viscosity grade
according to your expected operating temperature.
NOTE: Although multi-viscosity oils (5W30,10W30 etc.) improve starting in cold weather, these multi-viscosity oils will
result in increased oil consumption when used above 0 C (32 F). Check your engine oil level more frequently to
avoid possible engine damage from running low on oil. Change the oil after every 25 hours of operation, or at least
once a year if the chipper/shredder is not used for 25 hours inone year. Check the crankcase oil level before starting
the engine and after each five (5) hours of continuous use. Retighten the oil plug securely each time you check the oil level.
MAINTENANCE CONT D...
,
MAINTENANCE CONTENTS
BEFORE EACH USE
Check engine oil liquid level.
Check for loose screws, nuts, bolts or fasteners.
LUBRICATION
Assure a proper lubrication of your chipper/shredder (See "LUBRICATION CHART").
LEAF VACUUM
Always observe safety regulations when performing any maintenance or service works.
15
WARNING: Do not leave machine unattended or attempt any inspection or service unless the engine is stopped.
Remove spark plug wire from spark plug. Allow machine to come to a complete stop.
General recommendations
The warranty on this vacuum does not cover articles that have been subjected to operator abuse or negligence.
To maintain a complete coverage by the warranties provided, the operator must maintain the vacuum as instructed in
this manual. For a propermaintenance of your vacuum, someadjustments will need to bemade periodically.All
adjustments in the Service Adjustments section of this manual should be checked at least once each season.
Replace the sparkplug, clean or replace the air filter element andcheck blade(s) for wear once very year. Anew
spark plug,
and a cleaned or new air filter element, assures a proper air-fuel mixture and helps your engine run better
and last longer.
Observe the maintenance schedule in this manual.
WARNING: MAKE SURE DO CARRY OUTALL MAINTENANCE AND SERVICE WORKS WHILE THE ENGINE IS
STOPPED.
Use WEIBANG brand-name parts for compatibility and optimum performance. Use of any other parts prior to consulting
with your local dealer will void all warranties expressed herein.
Pre-maintenance
1. When this equipment is stopped for servicing, inspection, storage, or to make adjustments, make sure the spark plug
wire is disconnected from the spark plug. Also, make sure the engine has cooled down before you make any inspections,
adjustments, etc.
2. Use only original WEIBANG replacement parts. Parts from other manufacturers could be dangerous during operation
even though they may appear to fit properly.
3. Make certain all safety decals on this equipment are kept clean and in goodcondition. The decals are shown (at
reduced sizes) before. All decals are available for replacement except that with the serial number of the unit for each
number serves as an unique identifier for warranty and support purposes. If you need a replacement decal, please call
your dealer for re-ordering.
MAINTENANCE CONT D...
,
Changing and Adjusting the Drive Belt
Do not proceed with drive belt (or chain) adjustment until engine is cool. Do not adjust drive belt (or chain) until engine
If it is needed to replace drive chain or drive belt, please contact your local dealer for details.
Be sure to wear personal protective equipment.
has been disabled. Disable engine by removing key from switch and then removing spark plug wire and battery cable.
The oil of gearbox need changing regulaly.
Manufacturer extremly recommends that this work should be operated by an professional maintenance personnel of authorized
Do not let the drive chain or belt too loose.
DRIVE BELT (CHAIN) MAINTENANCE
CHANGE GEARBOX OIL
dealer or service center.

TROUBLE SHOOTING
TRUBINE REPALACEMENT
1. Wait for engine to cool and disconnect spark plug wires from the engine.
2. Remove the nozzle or hose from the unit.
3. Remove the intake housing assembly by removing (6) locknuts. Be careful to place intake assembly to the side
without putting excess strain on safety switch wire harness.
4. Remove central bolt , and spacer using socket and impact wrench ( fig. 6).
5. Once central bolt is removed, the turbine should slide out freely. If the turbine does not slide off freely use pene-
trating oil and work the hub off using a pry bar. Do not use the pry bar on the impeller plate.
6. When turbine is free of the engine shaft, align turbine with the opening and pull it straight out of the housing.
7. Using a new central bolt, washer, install new turbine in reverse order.
Note: Be sure that the key is in place on the engine shaft before installing impeller.
8. Tighten turbine bolt. Torque the turbine bolt to [33-38 Ft. Lbs. (45-52 N.m)]
9. Repeat steps 2 through 5 in reverse order.
10. Reinstall spark plug wires.
17
Problem Possible Cause Solution
Engine will not start.
Throttle & / or stop switch in off position.
Out of gasoline. Bad or old gasoline.
Spark plug wire disconnected.
Hose not installed, allowing interlock wire
to ground.
Harness wire is bad or disconnected
from interlock switch.
Dirty air cleaner.
Check stop switches, throttle, and
gasoline.
Connect spark plug wire.
Install hose coupler securely to the
unit and check whether interlock switch
is engaged by hose flange.
Check harness wire connection and
replace if necessary.
Clean or replace air cleaner.
Engine is locked, will
not pull over. Debris locked against impeller.
Engine problem. Clearing clogged impeller housing.
Contact an engine servicing dealer for
engine problems.
MAINTENANCE CONT D...
,18
Regular maintenance and parts replacement are important steps to extending the life of your equipment and enjoying
its optimum performance. When performing or conducting any maintenance or repairs, always check that your working
surroundings are safe and well-ventilated and that the technician is familiar and comfortable with all aspectsof the
machine and required procedures.
This guide aims to serve as a representational guide to the WBLV50KL. Any other uses or application beyond the scope
of this document are strictly prohibited. While every attempt has been made to maintain its accuracy WEIBANG reserves
the right to update and modify the equipment without prior notification.
To order spare parts, please provide the following information:
1. Machine Make
2. Model Number
3. Machine Serial Number
4. Quantity Required of Each Part
5. Part Numbers
6. Part Descriptions.
All WEIBANG parts are guaranteed by a thirty (30) day warranty against any manufacturer's defects in workmanship
and material. Consult Warranty page in the Operator's Manual for further details on our Warranty Policy.
Prior to undertaking to perform any maintenance or repair procedures, please contact our Technical Support Hotline for
clarification and to acquire appropriate parts.
Engine lacks power
Fuel hose choked or has air in it
Muffler, exhaust carbon deposits
Air filter element(s) clogged
Breather tube leak
Piston, piston ring and cylinder wore
Interface leak between cylinder head and
cylinder block
Valve clearance improper
Plug wire loosed
Impurity or water in fuel system
Fuel filter cap exhaust choked
Carburetor improper adjust
Fuel hose choked or has air in it
Valve leak
Clean and let air out
Clean
Clean or replace
Fix or replace
Replace
Replace cylinder gasket
Readjust
Connect firmly
Drain tank, refuel fresh gasoline
Clean
Readjust
Clean and let air out
Honing valve
Flameout during running
Out of fuel
Carburetor choked
Spark plug damage
Ignition winding damaged
Cylinder or valve damaged
Machine overload or turbin chamber
is jammed
Refuel
Check and clean
Replace
Replace
Fix or replace
Open the active screen to eliminate the
jam. Then restart the engine.
Engine overheat Engine oil lack Air circulate is not expedite
Carburetor improper adjust
Add engine oil
Clean engine fan
Readjust
Abnormal vibration. Loose or out of balance impeller or
loose engine
Check impeller and replace if
necessary.
Check engine.
Will not vacuum or has
poor vacuum performance Nozzle buried in debris. Clogged exhaust
Excessive quantity of debris.
Withdraw nozzle from debris pile.
Unclog exhaust.
Allow air to feed debris.
GUIDE TO PARTS BREAKDOWN
TROUBLE SHOOTING CONT D...
,
If turbing is damaged, repair it or replace it with new one.
(fig.10)
Impeller
Central bolt

WEIBANG WARRANTY STATEMENT
YANGZHOU WEIBANG GARDEN MACHINE COMPANY LIMITEDguarantees all WEIBANGLeaf Vacuum to be
free from any manufacturer's defects in material and workmanship for aperiod of 1year from the date of
purchase.This warranty is exclusive of the engine(please consult theaccompanying engine manual withyour
unit fordetails), andany normal wear andtear and/orconsumable parts, suchas, butnot limitedto,spacers,
blade,brake cable, and throttlecable.All normal wearand tearand/or consumableparts areprotected from
manufacturer's defects inmaterial andworkmanship for aperiod of thirty (30)days fromthe dateof purchase.
Awarranty period of 180days appliesto machinesused inhire andrental applications.
To makea warrantyclaim withinthis timeperiod, pleasecontact WEIBANG'slocal dealeror WEIBANG's
exclusive nationaldistributor,who willadvise thevalidity andclaim procedure.
Warranties expressedin this documentare void ifrepairs are attemptedby anyone otherthan anAuthorized
Service Centreor WEIBANG'sexclusive nationaldistributor,or ifthe unithas beenmodified fromoriginal
factory designin anyway.This warrantyis expresslyconditional uponthe customer'scompliance withall
precautions andinstructions containedin thismanual andexcludes anyclaims madeas aresult ofabuse,
neglect, accident,normal wear and tearand misuse.This warrantyis nontransferable.
Weibang Warranty Summary
1. WEIBANGProfessional Leaf VacuumUnit
2. WEIBANGnormal wear and tearparts
or consumableparts
3. Engine
1 yearparts and labour
30 daysparts and labour
Consult withengine manufacturer
Protection
Yangzhou Weibang Garden Machine Company Limited
Hanjiang Industrial Park
Yangzhou,Jiangsu,P.R.CHINA
Tel :[phone] Fax:[phone]
Email questions and comments to:
[email protected]
Visit our website:
www.weibang.com
20
19
EC DECLARATION OF CONFORMITY
Business name of the manufacturer: Yangzhou Weibang Garden Machine Company Limited
full address of the manufacturer: Hanjiang Industrial Park, Yangzhou City,
Jiangsu Province 225127, P. R. China
name and address of the person (established in the Community) compiled the technical file:
Van Dyck Marcel Belgium, Provinclebaan 79, 2235 Houtvenne Belgium
We declaring that the machinery
product name: Universal sucker , powered by Gasoline
commercial name: Leaf vacuum, powered by Gasoline
function: Pick up leaf
Model:
series no.:
type: gasoline powered
fulfils all the relevant provisions of Directives:
2006/42/EC
and tested in accordance with below standards:
ISO 21628
place and date of the declaration: Yangzhou, P. R. China,2016-08-26
signature of the person:
General Manager
WBLV506H WBLV506HV WBLV506C WBLV506CV
