Well SPLT-HDMI1.4/4-WL User manual
V1.4 HDMI Splitter 1X4 with full 3D and 4K@30Hz(340MHz)
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
USER MANUAL
Table of Contents
1.0 Introduction..........................................................................01
2.0 Feature.................................................................................01
3.0 Specification........................................................................02
4.0 Package Content.................................................................02
5.0 Panel Description................................................................03
6.0 Connection and Operation.................................................03
V1.4 HDMI Splitter 1X4 with full 3D and 4K@30Hz(340MHz)
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
V1.4 HDMI Splitter 1x4 with full 3D and 4K@30Hz (340MHz)
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this
manual for future reference
1.0 Introduction
This 4-port 4K HDMI splitter lets you share four HDMI displays or projectors with an HDMI
-enabled audio / video source device, such as a computer, Blu-ray player or cable TV, set-top box.
With support for Ultra HD (4K) the HDMI splitter ensures astonishing picture quality, four times
the resolution of high-definition 1080p. The 4K splitter is also backward compatible with previous
HDMI revisions, supporting 1080p / 720p HDMI video resolution devices. Even if you don't
require 4K video today, this 4 ports splitter ensures you'll be ready to take advantage of
tomorrow's display technology.
2.0 Feature
* Easy to Use: Install in seconds, no need of setting
* One HDMI Input, four HDMI outputs
* Supports Full 3D and 4K@30Hz resolution
* Supports 340MHz/3.4Gbps per channel (10.2Gbps all channels)
* Supports 12bit per channel (36bit all channels) deep color
* Supports HDCP 1.4
* Supports uncompressed audio such as LPCM7.1
* Support compressed audio such as DTS, Dolby Digital (including DTS-HD Master AudioTM and
Dolby TrueHD).
Note: Dolby is a trademark of Dolby Laboratories.
1
V1.4 HDMI Splitter 1X4 with full 3D and 4K@30Hz(340MHz)
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
3.0 Specification
Input DDC Signal
5 Volts p-p (TTL)
Maximum Single Link Range
4K@30Hz
Output Video
HDMI Signal
Vertical Frequency Range
50/60Hz
Video Amplifier Bandwidth
3.4Gbps/340MHz
Interlaced Resolutions(50&60Hz)
480i,576i,1080i
Progressive Resolutions(50&60Hz)
480p,576p,720p,1080p,4K@30Hz
Size(L-W-H)
81x58x18mm
Limited Warranty
1 Year Parts and Labor
Operating Temperature
0℃to 70℃
Operating Humidity
10% to 85% RH (no condensation)
Storage Temperature
-10℃to +80℃
Storage Humidity
5% to 90% RH (no condensation)
Power Supply
5V DC @1A
Power Consumption(Max)
8W
Splitter Unit Cert
FCC,CE, RoHS
Power Supply Cert
CE,FCC, RoHS
Power Adapter
US,UK,EU,AUS Standard etc
User Manual
English Version
Note: Specification is subject to change without prior notice.
4.0 Package Content
1) Main Unit
2) 5V DC Power Supply
3) User Manual
2
V1.4 HDMI Splitter 1X4 with full 3D and 4K@30Hz(340MHz)
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
5.0 Panel Description
6.0 Connection and Operation
1) Connect the HDMI input source and output devices into the HDMI Splitter.
2) Insert the DC side of 5V power supply into the splitter and then connect theAC side of the
power supply into the wall outlet.
3) Turn on the power.
Attention: Insert / Extract cable gently.
6.1 Connection Diagram
