Well FAN-DESK-WINDY-WL User manual

USER’S MANUAL
TABLE FAN
1
Thank you for choosing WELL. Please read carefully the following instructions and keep them within reach.
IMPORTANT SAFEGUARDS
Check that your mains voltage corresponds to that stated on the appliance.
Only use the appliance for domestic purposes and household or similar appliances such as:
–Staff kitchen areas, in shops, offices and other working environments
–To hotels, motels and other residential type environments
Only use the appliance in the way indicated in this manual.
Never use this unit near bathtub, shower, wash-hand basins or other containers with water
Never use this apparatus near water projections
Never use this aparatus with wet hands
If, unfortunately the apparatus is wet, immediately withdraw the cord of the socket outlet
Inform potential users of these instructions
Never leave the appliance unsupervised when in use.
The appliance must be used only for its intended purpose. No responsibility can be taken for any possible damage causen by incorrect use or improper
handling.
Children and any persons with disabilities are not always aware of the danger posed by the use of appliances.
This device can be used by children aged 8years and older and adults, with reduced physicall, sensory or mintal capabilities or lack of experience and
knowledge, if they have been given supervision or instruction concerninguse of the appliance in a seif way and understand the hazards involved.
Cleaning and mentenance must be not made by children withour supervision.
Keep the appliance and its cord aut of reach of children ages less than 8 years of age when it is nenergized or cooling down
This device is not a toy, do not leave small children or people with disabilities to paly with
In order to ensure your childrens safety, please keep all packaging (plastic bags, boxes, polysterene, etc) aut of their reach.
Warning! Never use withiut the guards in place. After assembly, do not remove the guards for mentenece or purpose of cleaning
Caution! Do not allow small childrens to play with the foil: THERE IS DANGER OF SUFFOCATION!
From time to time check the cord for damages. Never use the appliance if cord or appliance shows any signs of damage.
Never immerse the appliance in water or any liquid for any reaso whatsover, never place into the dishwasher.
Never use the appliance near hot surfaces.
Do not operate the appliance with a damaged cord or plug, or after the appliance has been damaged in any manner. If the supply cord or appliance is
damaged, it must be replaced by the manufacturer or its servoce agent, or similarly qualified person in order to avoid a hazard.
Disconnect the power source cable before any operation of cleaning of mentenaince and accesories assembly.
Never use the appliance outside and always place it in a dry environment.
Nu utilizaţi niciodată accesorii care nu sunt recomandate de către producător. Ele pot reprezenta un pericol pentru utilizator şi un risc de avariere a aparatului.
Nu utilizaţi niciodată altfel de conectori decât cel ce v-a fost livrat.
Never move the appliance by pulling the cord. Make sure the cord cannot get caught an any way.
Never wind the cord around the appliance and do not bend it.
Ensure that the power cord does not come into contact with hot parts of the unit.
Make sure the appliance has cooled down before clening and storing it.
The temperature os accesible surfaces may be hot when the appliance is operating. Never touch this parts os the apparatus to avoid burning itself.
Makle sure the appliance never comes into contact with flammable materials, such as cartons, cloths..etc, and the power cord and plug do not come in contact
with water.
Before cleaning always unplug the appliance from the power supply and let it cool down.
This appliance is not intended to be operated by means of an external timer or separate remote control system.
Always place the unit on a flat surface. Ensure, also, not to cover the device and not to put anything on it.
Always remove the plug from the wall socket when the appliance is not in use.
When using and extension lead always make sure that the entire cable si unwound from the reel. Use solely CE approved extension leads. Input power must
be at least 16A, 250V, 3000 W.
Incorrect operation and improper use can damage the appliance and cause injury the user.
This device is designed for home use, complies with standards relating to this type of product.
The appliance must be used and rested on a table or flat & stable surface.
The item must be not be left unattented when it is connected to main supply.
The item is not to be used, if it has been dropped or if there are visible signs or damage
This appliance is only intented for household use.
SPECIFIC SAFETY REQUIRED FOR THIS PRODUCT
1. Use the fan always set it on a flat surface
2. Do not carry the device by holding the power cord
3. Do not insert objects through the protective grill
4. Do not use the device in bathroom
5. Always use the fan with the included foot and upright
6. Do not use near curtains, etc.
No warranty will be applied if the appliance is used for other than is intended use.

USER’S MANUAL
TABLE FAN
2
SPECIFICATIONS
FAN-DESK-ICY-WL
FAN-DESK-FROSTY-WL
Diameter: 34 cm
Diameter: 43 cm
Power: 40 W
Power: 45 W
Voltage: 230V~ 50 Hz
Voltage: 230V~ 50 Hz
3-speed:950RPM-
1100RPM- 1250RPM
3 speed : 950RPM- 1100RPM-
1250RPM
Color: white
Color: white
Oscillation: 90°
Oscillation: 90°
Noisy level: <65 dB
Noisy level: <65 dB
Mesh grill
Mesh grill
IP 20
IP 20
TO KNOW IT’S UNIT
1. Guard screw
2. Front guard
3. Blade mounting nut
4. Blade
5. Guard mounting nut
6. Rear guard
7. Screw nut of guard
8. Motor housing
9. Oscillaation knob
10. Stand
11. Base
12. Screw of the base
13. Non sleep feet
BLADE & PROTECTION GRILL ASSEMBLY METHODE
1. Secure the rear grid on the motor house with the four foreseens screws
2. Install the propeller blades on the motor shaft and screw the blade clamping nut.
3. Centre the front grid alinging to logo, it must be horizontal and parallel to the
ground.
4. Secure Front & Rear grids tightening the fixing clips. Make sure the clips are firmly
in place.
5. Tighten the locking screw at the bottom of the back gate
FAN-BASE ASSEMBLY METHOD
1. Position the bottom of the U-shaped fan on the top of the base & insert pin in the first part of the U and in the tube and finally the other part of the U.
2. Screw the clamping screw.
FAN-DESK-WINDY-WL
Diameter: 27 cm
Power: 30 W
Voltage: 230V~ 50 Hz
2 speed: 1800RPM- 2200RPM
Color: white
Oscillation: 90°
Noisy level: <65 dB
Mesh grill
IP 20

USER’S MANUAL
TABLE FAN
3
USE
Unroll the power cord completely
Check that the tension in force in the country where you are corresponds to that indicated on the apparatus.
Connect the apparatus in a correct socket outlet and connected to the ground to avoid any danger.
Disconnect the power source cable before any operation of cleaning, mentenance and accesories assembly.
Never modify the appliance in anyway.
Adjust speed by pressing the buttons on the bottom of the unit.
0 –STOP; 1 –Soft speed ; 2 –Fast speed
Oscillation: Press the oscillation button on the motor housing to activate the oscillation function. Pulling up on the oscillation button to stop it.
CLEANNG AND MENTENANCE
Allways unplug the appliance and let it cool before cleaning.
Clean the outside of the appliance with a sponge or damp cloth.
Never immerse the appliance in water or other liquids.
Never use abrasives, wire brush or other sharp object.
The front and rear gates can be cleaned with a brush or a soft , damp cloth.
The motor housing and feet can be cleaned with a damp cloth.
Use only original accesories.
STORAGE
–Ensure the unit is completely cool and dry.
–Do not wrap the cord around the appliance as this will cause damage.
–Keep the appliance in a cool, dry place and aut of reach from children.
Always unplug the appliance before any claning or maintenance operation and accesories assembly.
Disconnect the electrical mains supply cable before any maintenance , cleaning operation and installation of accesories.
The device should not be exposed to moisture or rain
ECOLOGICAL INFORMATION
Waste electrical and electronic equipment are a special waste category, collection , storage, transport , treatment and recycling are important
because they can avoid environmental pollution and are harmful to health
Submitting waste electrical and electronic equipment to special collection centers makes the waste to be recycled properly and protecting the
environment.
Do not forget !Each electric appliance that arrive at the landfill, the field , pollute the environment!
