Coyote
WB00377
Coyote Pizza Oven
INSTRUCTION GUIDE
Pizzaofen
BEDIENUNGSANLEITUNG
Four à pizza
GUIDE D’UTILISATION
Coyote pizzasütő
HASZNÁLATI ÚTMUTATÓ
Cuptor pentru pizza
GHID DE INSTRUCȚIUNI

EN
IMPORTANT:
Save for electrical inspector’s use.
Installer: Leave installation instructions with the homeowner.
Homeowner: Keep installation instructions for future reference
EN Coyote Pizza Oven
INSTRUCTION GUIDE

Welcome
Thank you for purchasing your Coyote Pizza Oven Appliance! We appreciate
your business and we recommend that you read this entire User’s Manual
before operating your new appliance for the rst time.
This manual contains instructions on how to properly install and set up your
new range, as well as insights into the unique features that our product offers.
Please keep this manual for future reference, as it contains answers to ques-
tions that you might have as you begin to cook.
Thank you
This manual applies to the following models’ series:
Model # WB00377 (Coyote Pizza Oven)

EN Parts Explosive Pictures

Explosive Part Name Quantity
1 Chimney coping 1
2 Chimney supporting rod 1
3 Chimney pipe assembly 1
4 Pizza oven cavity 1
5 Thermometer 1
6 Mica plate 1 4
7 Pizza oven door handle assembly 1
8 Pizza oven door assembly 1
9 Beam welding assembly 1
10 Cabinet left side panel 1
11 Left/Right handle welding assembly 1
12 S-shape Pothook 1
13 Pothook 1 3
14 Pothook 2 1
15 Cabinet top panel welding assembly 1
16 Condiment storage welding assembly 1
17 Kick panel plate 1
18 Supporting leg 2
19 Fixed caster 2
20 Universal caster with brake 2
21 Cabinet bottom panel welding assembly 1
22 Left door assembly 1
23 Right door assembly 1
24 Beam welding assembly 1
25 Cabinet right side panel welding assembly 1
26 back panel welding assembly 1
27 Ash pan welding assembly 1
28 Cordierite rebrick B 4
29 Cordierite rebrick A 2
30 Net Cover 1
31 Door hinge 4
32 Ash pan holder 2
33 Pizza wheel 1
Parts List

EN 34 Pizza cutter 1
35 Pizza oven brush 1
36 Large pizza oven shovel 1
37 ¼” Philips thumb head screw with antislip design 65
38 Philips thumb head screw 2
39 at head screw 24
40 1/4” nut 3
41 cabinet back connecting plate 2
42 cabinet front connecting plate 1
43 ¼” at gasket 3
44 ¼” spring washer 1

Product Dimension

EN Cabinet Installation
Step 1
1. Install 2 pcs supporting legs (Part # 18) to bottom welding part
(Part # 21) and adjust the supporting legs to suitable position;
2. Use 16 pcs ¼” at Philip’s screw head (Part # 37) to connect 2 pcs
xed casters (Part # 19) and 2 pcs universal casters with brake
(Part # 20) to Part #21

Step 2
1. Use 2 pcs Philips thumb head screw (Part # 38) to install Kick panel plate
(Part # 17) to Part # 21;
2. Use 3 pcs ¼” at Philip’s screw head (Part # 37) to connect left side panel
(Part # 10) to Part # 21;
3. Use 3 pcs Part # 37 to connect right side panel (Part # 25) to Part # 21;
4. Use 8 pcs Part # 37 to connect back panel (Part # 26) to Part #21, # 10
and #25;
5. Make sure all the connections are smooth, Do not over-tighten all the
screws until parts are lined up

EN Step 3
1. Use 4 pcs Part # 37 to connect beam welding part (Part # 24) to
Part # 10 and Part # 25;
2. Use 4 pcs Part # 37 to connect top cover welding part (Part # 15)
to Part # 10 and Part # 25
Door Stop: Front
