Wells RW-16HD thru RW-36HD User manual

PARTS LIST
WELLS BLOOMFIELD, LLC
2 ERIK CIRCLE, P. O. Box 280 Verdi, NV 89439
www.wellsbloomfield.com
PRINTED IN UNITED STATES OF AMERICA
telephone: [phone]
fax: [phone]
042b
p/n PL042b Rev. B 080219 cps
BUILT-IN DRAWER WARMERS
HEAVY-DUTY MODELS
RW-16HD, RW-26HD, RW-36HD
RW-176HD
CONTENTS
Description page
Parts List ………………………………………………….. 2
RW-16HD, RW-26HD, RW-36HD .…………….………... 3
RW-176HD ………………………………………………… 4
PL042 part B

PART # DESCRIPTION
OPTIONAL ACCESSORIES
20624 HUMIDITROL RACK (ALL EXC. -176HD)
21488 REPLACEMENT PAN (ALL EXC. -176HD)
22412 HUMIDITROL RACK (-176HD ONLY)
22414 REPLACEMENT PAN (-176HD ONLY)
ELECTRICAL
50482 ELEMENT 240V 450W (ALL EXC. –176HD)
50519 ELEMENT 120V 450W (ALL EXC. –176HD)
54131 CONNECTOR, ELECTRICAL 12-14 GA
54136 FTG FLEX CONN 90ºx1/2
55687 LIGHT, SIGNAL RED
58936 THERMO, TEMP CONTROL W/O AUX
500449 ELEMENT 120V 550W (-176HD)
2
PART # DESCRIPTION
MECHANICAL
50372 KNOB ASSY, WARMERS
50471 CATCH ASSY COMPLETE
50483 ROLLER ASSY, DRAWER (pk 6)
51674 SPACER, 1/2” LG
51801 CONTROL PANEL w/o THERMOMETER
51808 OUTLET BOX RW
51809 FLANGE, ATTACH RW-16HD
52112 HANDLE, RW DRAWER
53565 CONTROL PANEL, LOWER
55677 SUPPORT, ELEMENT
55683 SHIELD, THERMOBULB
55726 ASSY, SLIDE VENT
55988 DRAWER STOP RW
56050 INSULATION 1”x36”W (pk 450 SQ.FT.)
60083 TRADEMARK, CASTING
63263 KNOB (ONLY), DRAWER VENT
65351 CAVITY ASSY (ALL EXC. –176HD)
65405 SPACER, DRAWER STOP
65923 DRAWER STOP ASSY (INCL LF & RT)
67096 DRAWER ASSY, RWHD
Note: Does NOT include drawer insert
506374 DRAWER ASSY, RW-176HD
Note: Does NOT include drawer insert
PART # DESCRIPTION
HARDWARE, etc.
18-302 NUT 8-32 HEX SS
51040 BUSHING 7/8 OD
51053 NUT 8-32 KEPS Ni (pk 100)
51717 SCREW 8-32x3/8 ROLOCK Ni (pk 40)
53935 SCREW 6ABx5/16 PAN SMS (pk 100)
53977 SCREW 8-32x3/8 BND HD (pk 100)
53988 SCREW 6Ax1/2 PAN SMS Ni (pk 10)
54284 POP RIVET 3/32Dx1/8
55135 SCREW 6-32x1/4 FIL HD Ni (pk 25)
55487 SCREW 8-32x5/16TR HD SS (pk 50)
55530 SCREW 8-32x3/8 SEMS Ni (pk 100)
55565 WASHER, DRAWER BACK 2-1/16
55566 SCREW 6-32x1/4 TR HD SS (pk 100)
55736 NUT 8-32 HEX KEPS GREEN (pk 10)
60019 COTTER PIN 1/16x3/8 SS
61974 NUT 8-32x7/8 ALUM (pk 10)
61262 POP RIVET 1/8x .265 SS (pk 50)
63271 CLIP, RETAINER PILOT LIGHT (pk 10)
LITERATURE
300597 WIRING DIAGRAM 1-DRAWER
300959 WIRING DIAGRAM 2-DRAWER
300961 WIRING DIAGRAM 3-DRAWER
303334 OPERATION MANUAL BUILT-IN RW
PL042b Service Parts List - Built-In Heavy Duty Drawer Warmer

33
DRAWER ASSEMBLY - COMMON TO ALL “HEAVY DUTY” VERSIONS (except RW-176HD)
CAVITY and CABINET INTERIOR - COMMON TO ALL “HEAVY DUTY” VERSIONS (except RW-176HD)
PL042b Service Parts List - Built-In Heavy Duty Drawer Warmer

34
DRAWER ASSEMBLY - RW-176HD only
CAVITY and CABINET INTERIOR - RW-176HD only
PL042b Service Parts List - Built-In Heavy Duty Drawer Warmer

NOTES
PL042b Service Parts List - Built-In Heavy Duty Drawer Warmer
5
